Summary of Contents for Mio Moov DR03
- Page 1 Mio Moov DR03 MiVue 128...
-
Page 2: Table Of Contents
Index 01 Table of Contents .................. 02 02 Product Features and Specifications ..........03 03 Caution Note .................... 05 04 Product Overview .................. 07 05 Getting Started ..................09 A. Setup Installation mode for car use ..09 Installation mode for bicycle use ... -
Page 3: Table Of Contents
Product Description DR-03’s lightweight stature surpasses all similar products available on the market, allowing for easy installation in your car, bicycle or motorcycle to keep a record of your journey; it can also be installed in your house to be used for home security. In addition to having outdoor recording and GPS functions, DR-03 is also combined with a map, keeping a faithful record of your life. -
Page 4: Product Features And Specifications
Product Features and Specifications ► VGA (640×480) with 300,000 pixels ► MPEG-4 A/V encoding; AVI format output; VGA with 30FPS ► Storage: MicroSD card (Class6 or above suggested) with a maximum support of 32G ► Built-in high resolution CMOS lens; enhanced night vision effects ►... - Page 5 Product Features and Specifications Car recorder host CMOS Sensor Module Array Element 640x480 (VGA) Dimension 98 x 34 28mm Sensor Size 1/4” Weight 47.5g Image Transfer Rate(Max) VGA, CIF, QCIF, QQCIF －30 fps． Storage MicroSD GPS Module QVGA, QQVGA －60 fps Scan Mode Progressive GPS Chipset...
-
Page 6: Caution Note
Caution Note 1. GPS Accuracy The Global Positioning System (GPS) technology is developed and managed by the U.S. Department of Defense. Based on policy or national security considerations, the U.S. has the right to adjust the positioning accuracy of this system without prior announcement. - Page 7 Caution Note 5. Memory Condition (If File Overwrite is not checked, the device will beep) When the memory card capacity has less than 175MB remaining, the recording indicator will flash quickly and the buzzer will beep three times every two minutes until the memory card only has 1MB left, then the system will force itself to shut down.
-
Page 8: Product Overview
Product Overview - Top View - - Bottom View - Screw hole for holder Low power indicator Recording indicator GPS indicator Battery cover GPS Satellite Signal Reception DC Jack (Frame) Microphone... - Page 9 Product Overview - Front View - - Back View - Power/function Button Camera lens - Left View - Buzzer MicroSD card Socket...
-
Page 10: Getting Started
Getting Started-Setup 1. Installation mode for car use 1. Please use Class6 or higher class 2. Combine the holder with device. MicroSD cards. ※Please format your MicroSD card with Mio Manager PC Suite before inserting it. - Page 11 Getting Started-Setup 3. Combine the holder with the mounting 4. Start the car engine. frame and attach it to the windshield. 5. Plug the DC jack of the car adaptor into the main device and the other end to the car’s cigarette lighter.
- Page 12 Getting Started-Setup 6. Adjust the setting angle to get the best view. ※Please do not insert or remove Micro SD card, when MiVue 128 is operating.
-
Page 13: Installation Mode For Bicycle Use
1. Please use Class6 or higher class 2. Use your fingertip to push the battery MicroSD cards. cover towards the direction which the word PUSH indicates to easily open the battery cover. ※Please format your MicroSD card with Mio Manager PC Suite before inserting it. - Page 14 Getting Started-Setup 3. Insert two AAA batteries according to 4. Attach the holder onto the bottom of the device. the directions indicated.
- Page 15 Getting Started-Setup 5.Pull the silicon holder down from front to 6.Use the hand screw to tighten and firmly back to wrap it around the device. hold the bottom holder and the device in (you can decide whether to use the place.
- Page 16 Getting Started-Setup 7.Combine the bicycle holder with the 8.Loosen the screw, then select a suitable device with the bottom holder attached. latch height and attach it to the bicycle, then tighten the screw again.
- Page 17 Getting Started-Setup 9. Adjust the setting angle to get the best view. ※Please format your MicroSD card with Mio Manager PC Suite before inserting it.
-
Page 18: Operating
Getting Started-Operating 1. Activating Recording Function A. Automatic Recording Mode (GPS positioning completes direct recording) 1) First insert the formatted memory card, then press the power/function button; the indicator will light up sequentially and the device will complete start up in approximately 1 second. - Page 19 Getting Started-Operating B. Manual Recording Mode (Force recording before the GPS has completed positioning) 1) First insert the formatted memory card, then press the power/function button; the indicator will light up sequentially and the device will complete start up in approximately 1 second.
-
Page 20: Power Off
Getting Started-Operating 2. Powering Off When the system is in automatic or manual recording mode, or before it started recording, press and hold the power/function button for 3 seconds and then release to power off the device. -
Page 21: Installation
Getting Started-Application Software 1. Installation of application software 1. Insert the CD-ROM into your computer. 2. The system will automatically pop up the setup window or you can also double-click on “Setup.exe” from the CD-ROM drive. - Page 22 Getting Started-Application Software 3. Click “Next” to continue installation. 4. When the application software is finished installing, the corresponding shortcut icon will appear on the desktop.
- Page 23 Getting Started-Application Software 5. Remove the used MicroSD card from the device and connect it to the computer. 6. Double-click the icon on the desktop to run the application program.
- Page 24 Getting Started-Application Software 7. Select the language you wish to use. 8. Click the first icon to open the recording files stored on the MicroSD card. 9. The information of the opened video file will be displayed in this field. 10.
- Page 25 Getting Started-Application Software 11. When the video is playing, the corresponding geographical location will also be marked on the map at the right side of the software. Click the icon at the top-right corner of the screen to enlarge the map. 12.
-
Page 26: System Setup
Getting Started-System Setup 1. Remove the MicroSD card from the device and connect it with the computer, then execute the software. 2. Click on the tools icon to open the System Setup window. - Page 27 Getting Started-Application Software The SD card must rst be formatted using this function when used for the Format rst time and before changing the previous settings! Di erent time zones can be set according to di erent countries. Time zone If the MicroSD card’s capacity is full, the device will automatically overwrite File overwrite older les.
-
Page 28: Appendix-Troubleshooting
Appendix-Troubleshooting This chapter will list some of the problems you might face when using this device and their solutions. Even if the following guide can not solve your problem, please do not dismantle this device on your own! Please send the product back to the store where you purchased it for maintenance. -
Page 29: Package Contents
Appendix-Package Contents Mio DVR x 1 Mounting frame x 1 Mounting frame x 1 (For car use) (for bicycle use) Holder for car x 1 Holder for bicycle x 1 Spill-resistant cover x 1 (Class:54) Quick Start Guide Mio Moov DR-03... -
Page 30: Safety Precautions
Appendix-Safety Precautions 1. Please turn off the power when inserting or removing the MicroSD card, or else it could cause damage to the device or the MicroSD card. 2. This device is a very sophisticated product; please avoid dropping it or expose it to strong shaking or vibrations.
