Wind Board 330
MS-7314 (v2.X) Mainboard
G52-73141X6
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wind Board 330 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MSI Wind Board 330

Summary of Contents for MSI Wind Board 330

  • Page 1 Wind Board 330 MS-7314 (v2.X) Mainboard G52-73141X6...

  • Page 2: Trademarks

    Alternatively, please try the following help resources for further guidance. Visit the MSI website for FAQ, technical guide, BIOS updates, driver updates, an d oth er in forma tion : htt p:// glob al.m si.com.tw /ind ex.p hp?

  • Page 3: Safety Instructions

    Safety Instructions Always read the safety instructions carefully. Keep this User’s Manual for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equip- ment from overheating.

  • Page 4: Fcc-B Radio Frequency Interference Statement

    FCC-B Radio Frequency Interference Statement Th is eq u ip men t h as been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Weee (Waste Electrical And Electronic Equipment) Statement

    WEEE (Waste Electrical and Electronic Equipment) Statement...

  • Page 8: Table Of Contents

    CONTENTS Copyright Notice ....................ii Trademarks ......................ii Revision History ....................ii Technical Support ....................ii Safety Instructions ....................iii FCC-B Radio Frequency Interference Statement ........... iv WEEE (Waste Electrical and Electronic Equipment) Statement ........ v Chapter 1. Getting Started ................1-1 Mainboard Specifications ................

  • Page 9: Chapter 1. Getting Started

    Getting Started Chapter 1 Getting Started Thank you for choosing the Wind Board 330 (MS-7314 v2.X) Mini-ITX mainboard. The Wind Board 330 is based ® on Intel brand new Atom CPU and 945GC + ICH7 chipsets for optimal system efficiency. The Wind Board 330 delivers a high performance and professional desk- top platform solution.

  • Page 10: Mainboard Specifications

    ICH7 chipset Memory Support - DDR2 533 SDRAM (2GB Max) - 1 DDR2 DIMM (240pin / 1.8V), single channel (For more information on compatible components, please visit http://global.msi.com.tw/index.php?func=testreport) ® - Supports Realtek RTL8101E 10/100 Mb/s - Supports ACPI Power Management Audio ®...
  • Page 11 Getting Started Connectors Back panel - 1 PS/2 mouse port - 1 PS/2 keyboard port - 1 serial port (COM1) - 1 VGA port - 1 parallel port supporting SPP/EPP/ECP mode - 4 USB 2.0 Ports - 1 RJ-45 LAN jack - 3 flexible audio jacks On-Board Pinheaders / Connectors - 2 USB 2.0 pinheaders...

  • Page 12: Mainboard Layout

    VG A port Intel JC I1 945GC Clock USB ports Top: LAN jack Bottom : U SB ports R TL8101E Intel Line-In ICH7 Line-O ut JUSB1 M ic JUSB2 JBAT1 JAU D1 PCI 1 ALC888 Wind Board 330 (MS-7314 v2.X) Mini-ITX Mainboard...

  • Page 13: Packing Checklist

    Getting Started Packing Checklist Back IO Shield MSI Driver/Utility CD MSI motherboard Power Cable SATA Cable IDE Cable User’s Guide * The pictures are for reference only and may vary from the packing contents of the product you purchased.

  • Page 14: Chapter 2. Hardware Setup

    Hardware Setup Chapter 2 Hardware Setup This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the components and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work properly.

  • Page 15: Quick Components Guide

    MS-7314 Mainboard Quick Components Guide SYS_FAN1, p.2-13 SYS_FAN2, p.2-13 DDR2 DIMMs, p.2-3 JPW1, p.2-6 JCI1, p.2-14 IDE1, p.2-11 Back Panel, p.2-9 ATX1, p.2-6 SATA, p.2-12 JFP1, p.2-14 JBR1, p.2-12 JBAT1, PCI, JUSB1~2, p.2-16 JAUD1, p.2-15 p.2-17 p.2-13...

  • Page 16: Memory

    Hardware Setup Memory The DIMM slot is used for installing memory module. For more information on compatible components, please visit http://global.msi.com. tw/index.php?func=testreport DDR2 240-pin, 1.8V 56x2=112 pin 64x2=128 pin Important - DDR2 memory module is not interchangeable with DDR and the DDR2 stan- dard is not backwards compatible.
  • Page 17 ADATA ADQPE1A08 (Adata AD20908A8A-3EC) AENEON AET760UD00-30DB97X (AENEON AET93R30DB) Important 1. For more information on compatible components, please visit http://global. msi.com.tw/index.php?func=testreport. 2. Due to the CPU limitation, the installed 667 MHz memory will be dropped to 533 MHz for system stability.
  • Page 18 Hardware Setup Vendor Model Size Apacer 78.01G9O.9K5 (Apacer AM4B5808CQJS7E) Bufaullo D2U667C-1GMDJ (Micron D9GNH) CORSAIR VALUESELECT VS1GB667D2 (CORSAIR 64M8CFEG) 鐵殼 ) Crucial BL12864AA663.16FD4 ( 鐵殼 ) Geil GX22GB5300LDC ( GOODRAM GR667D264L5/1G (Goodram GE5108GC-JN) HYNIX HYMP112U64CP8-Y5 (HYNIX HY5PS1G831CFP-Y5) HYNIX HYMP512U64CP8-Y5 (HYNIX HY5PA12821CFP-Y5) KINGBOX UP1GD2667PS (KINGBOX ULD264082200P-4) KINGMAX KLCD48F-A8KB5 [FHES] (KINGMAX KKEA88B4LAUG-29DX)

  • Page 19: Power Supply

    MS-7314 Mainboard Power Supply ATX 20-Pin Power Connector: ATX1 This connector allows you to connect to an ATX power supply. To connect to the ATX power supply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned.
  • Page 20 Hardware Setup Compatible Power Supply list Please refer to the following list to find the available power supplies. Vendor Model Spec. Afocus WIN-300XPX-X 20+4pin; 300W ANTEC TP3-550 20+4pin; 550W Coolermaster RS-430-PCAP 20+4pin,430W Coolermaster R7133C-400-C 20+4pin,300W KMG-4000LPPC 20+4pin; 400W AX500-A 20+4pin; 500W ATX-S650 勁霸...
  • Page 21 HK650-11PEP 24pin; 650W Seventeam ST-750EAJ-05G 24pin; 750W Seventeam ST-850E-AD 20+4pin; 850W Antec TPQ-850 20+4pin,850W Important 1. For more information on compatible components, please visit http://global. msi.com.tw/index.php?func=testreport. 2. Power supply of 400 watts (and lower) is strongly recommended for system stability.

  • Page 22: Back Panel

    Hardware Setup Back Panel Parallel Port Mouse Line-In Line-Out Keyboard USB Port Serial Port USB Port VGA Port Mouse/Keyboard ® ® The standard PS/2 mouse/keyboard DIN connector is for a PS/2 mouse/keyboard. Parallel Port A parallel port is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.
  • Page 23 MS-7314 Mainboard Audio Ports These audio connectors are used for audio devices. It is easy to differentiate be- tween audio effects according to the color of audio jacks. Line-In (Blue) - Line In is used for external CD player, tapeplayer or other audio devices.

  • Page 24: Connectors

    Hardware Setup Connectors IDE Connector: IDE1 This connector supports IDE hard disk drives, optical disk drives and other IDE devices. Important If you install two IDE devices on the same cable, you must configure the drives separately to master / slave mode by setting jumpers. Refer to IDE devi ce’s documentation suppl i ed by the vendors for jumper setting instructions.
  • Page 25 MS-7314 Mainboard Serial ATA Connector: SATA1~2 This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device. SATA1 SATA2 Important Please do not fold the Serial ATA cable into 90-degree angle. Otherwise, data loss may occur during transmission. Speaker Connector: JBR1 This connector connects to the speaker of the case.
  • Page 26 Hardware Setup Fan Power Connectors: SYS_FAN1/ SYS_FAN2 The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND. SENSOR +1 2V SYS_FAN1...
  • Page 27 MS-7314 Mainboard Front Panel Connector: JFP1 This connector is for electrical connection to the front panel switches and LEDs. The ® JFP1 is compliant with Intel Front Panel I/O Connectivity Design Guide. Power Reset Switch Switch Power JFP1 JFP1 Pin Definition SIGNAL DESCRIPTION HD_LED +...
  • Page 28 Hardware Setup Front USB Connector: JUSB1~2 ® These connectors, compliant with Intel I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Pin Definition SIGNAL SIGNAL USB0- USB1-...

  • Page 29: Jumper

    MS-7314 Mainboard Jumper Clear CMOS Jumper: JBAT1 There is a CMOS RAM onboard that has a power supply from an external battery to keep the data of system configuration. With the CMOS RAM, the system can auto- matically boot OS every time it is turned on. If you want to clear the system configuration, set the jumper to clear data.

  • Page 30: Slot

    Hardware Setup Slot PCI (Peripheral Component Interconnect) Slot The PCI slot supports LAN card, SCSI card, USB card, and other add-on cards that comply with PCI specifications. 32-bit PCI Slot Important When adding or removing expansion cards, make sure that you unplug the power supply first.

  • Page 31: Chapter 3 Bios Setup

    BIOS Setup Chapter 3 BIOS Setup This chapter provides information on the BIOS Setup program and allows you to configure the system for optimum use. You may need to run the Setup program when: ² An error message appears on the screen during the system booting up, and requests you to run SETUP.

  • Page 32: Entering Setup

    MS-7314 Mainboard Entering Setup Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press <DEL> key to enter Setup. Press DEL to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On or pressing the RESET button.

  • Page 33: Control Keys

    BIOS Setup Control Keys <↑> Move to the previous item <↓> Move to the next item <←> Move to the item in the left hand <→> Move to the item in the right hand <Enter> Select the item <Esc> Jumps to the Exit menu or returns to the main menu from a submenu <+/PU>...

  • Page 34: The Main Menu

    MS-7314 Mainboard The Main Menu Standard CMOS Features Use this menu for basic system configurations, such as time, date etc. Advanced BIOS Features ® Use this menu to setup the items of AMI special enhanced features. Integrated Peripherals Use this menu to specify your settings for integrated peripherals. Power Management Setup Use this menu to specify your settings for power management.
  • Page 35 BIOS Setup Load Fail-Safe Defaults Use this menu to load the default values set by the BIOS vendor for stable system performance. Load Optimized Defaults Use this menu to load the default values set by the mainboard manufacturer specifi- cally for optimal performance of the mainboard. Save &...

  • Page 36: Standard Cmos Features

    MS-7314 Mainboard Standard CMOS Features The items in Standard CMOS Features Menu includes some basic setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. Date (MM:DD:YY) This allows you to set the system to the date that you want (usually the current date).
  • Page 37 BIOS Setup Device / Vendor / Size It will showing the device information that you connected to the SATA connector. LBA/Large Mode This allows you to enable or disable the LBA Mode. Setting to Auto enables LBA mode if the device supports it and the devices is not already formatted with LBA mode disabled.

  • Page 38: Advanced Bios Features

    MS-7314 Mainboard Advanced BIOS Features Full Screen Logo Display This item enables this system to show the company logo on the bootup screen. Settings are: [Enabled] Shows a still image (logo) on the full screen at boot. [Disabled] Shows the POST messages at boot. Quick Booting Setting the item to [Enabled] allows the system to boot within 10 seconds since it will skip some check items.
  • Page 39 BIOS Setup Primary Graphic’s Adapter This setting specifies which graphic card is your primary graphics adapter. PCI Latency Timer This item controls how long each PCI device can hold the bus before another takes over. When set to higher values, every PCI device can conduct transactions for a longer time and thus improve the effective PCI bandwidth.
  • Page 40 MS-7314 Mainboard DVMT Mode Select This item allows you to set the mode for the graphics core. [Fixed] mode, a fixed-size fragment of the system memory is allocated to the graphics core. It can only be used by the graphics core. [DVMT] mode, the driver of the graphics core uses the system memory like any other OS component or application does.

  • Page 41: Integrated Peripherals

    BIOS Setup Integrated Peripherals USB Controller This setting allows you to enable/disable the onboard USB controller. USB Device Legacy Support Select [Enabled] if you need to use a USB-interfaced device in the operating system. Onboard LAN Controller This item is used to enable/disable the onboard 1st LAN controller (Realtek 8111B, the one next to the USB connector).
  • Page 42 MS-7314 Mainboard On-Chip IDE Controller These items allow users to enable or disable the IDE controller. PCI IDE BusMaster This item allows you to enable/ disable BIOS to used PCI busmastering for reading/ writing to IDE drives. On-Chip SATA Controller These items allow users to enable or disable the SATA controller.

  • Page 43: Power Management Setup

    BIOS Setup Power Management Setup Important S3-related functions described in this section are available only when your BIOS supports S3 sleep mode. ACPI Function This item is to activate the ACPI (Advanced Configuration and Power Management Interface) Function. If your operating system is ACPI-aware, such as Windows 2000/ XP, select [Enabled].
  • Page 44 MS-7314 Mainboard Power Button Function This feature sets the function of the power button. Settings are: [Power Off] The power button functions as normal power off button. [Suspend] When you press the power button, the computer enters the suspend/sleep mode, but if the button is pressed for more than four seconds, the computer is turned off.
  • Page 45 BIOS Setup Resume By Onboard LAN When set to [Enabled], the feature allows your system to be awakened from the power saving modes through onboard LAN. Resume By RTC Alarm The field is used to enable or disable the feature of booting up the system on a scheduled time/date.

  • Page 46: H/W Monitor

    MS-7314 Mainboard H/W Monitor Chassis Intrusion The field enables or disables the feature of recording the chassis intrusion status and issuing a warning message if the chassis is once opened. To clear the warning message, set the field to [Reset]. The setting of the field will automatically return to [Enabled] later.

  • Page 47: Bios Setting Password

    BIOS Setup BIOS Setting Password When you select this function, a message as below will appear on the screen: Type the password, up to six characters in length, and press <Enter>. The password typed now will replace any previously set password from CMOS memory. You will be prompted to confirm the password.

  • Page 48: Cell Menu

    MS-7314 Mainboard Cell Menu Important Change these settings only if you are familiar with the chipset. Current CPU / DRAM Frequency These items show the current clocks of CPU and Memory speed. Read-only. Advance DRAM Configuration Press <Enter> to enter the sub-menu and the following screen appears. Configure DRAM Timing by SPD Setting to [Auto] enables DRAM CAS# Latency automatically to be determined by BIOS based on the configurations on the SPD (Serial Presence Detect) EEPROM...
  • Page 49 BIOS Setup CAS# Latency (CL) When the Configure DRAM Timing by SPD sets to [Manual], the field is adjustable. This controls the CAS latency, which determines the timing delay (in clock cycles) before SDRAM starts a read command after receiving it. tRCD When the Configure DRAM Timing by SPD sets to [Manual], the field is adjustable.
  • Page 50 MS-7314 Mainboard Important 1. If you do not have any EMI problem, leave the setting at [Disabled] for optimal system stability and performance. But if you are plagued by EMI, select the value of Spread Spectrum for EMI reduction. 2. The greater the Spread Spectrum value is, the greater the EMI is reduced, and the system will become less stable.

  • Page 51: Load Fail-Safe/ Optimized Defaults

    BIOS Setup Load Fail-Safe/ Optimized Defaults The two options on the main menu allow users to restore all of the BIOS settings to the default Fail-Safe or Optimized values. The Optimized Defaults are the default values set by the mainboard manufacturer specifically for optimal performance of the mainboard.
