1.9 Functioning principle

The shape and the Keram re® lining of the combustion
chamber allow to reach and retain high temperatures inside of
it, thus maximizing the combustion phases with consequential
reduction in the amount of the fuel needed.
Thanks to its position (top of combustion chamber) and shape,
the " ame distributor-catalyzer" produces the catalysis of the
combustion products, dramatically reducing carbon dioxide,
nitrogen oxide, and other gases.
After passing through the ame distributor-catalyzer the
ue gases are forced to pass through integrated slowdown
channels, which allow to get warm air for heating by reducing
the temperature of the ue gases while they are passing
through. Warm air is then distributed into the room through
exible pipes positioned inside the nishing are of the
appliance cladding.
The heat exchangers surrounding the combustion chamber
and inside the appliance are are air-tight thanks to line
weldings, which prevent any gas exchange with the air to be
heated.
radiated and mostly di used by natural convection (air natural
convection movement): an air ow enters from the outside,
heats up when passing through heat exchangers positioned
inside the appliance are, it is channelled and emitted from
the unit's top into the room to be heated.
the heat released is partly
LIGHT series
