Standard status
3
indicators
24
Multifunction display
1 Fuel capacity (
2 Gear indicator (
z
3 Engine temperature
( 24)
4 Clock ( 51)
5 Odometer
6 Trip meter (
Telltale lights
1 Flashing turn indicators,
left
2 High-beam headlight
24)
3 Idle
24)
4 Flashing turn indicators,
right
Fuel capacity
The column below the fuel-
51)
pump symbol indicates the
remaining quantity of fuel.
When the fuel in the tank is
topped up the gauge briefly
shows the original level, before
the reading is updated.
Gear indicator
N
The gear engaged or
ral appears on the display.
If no gear is engaged, the
'neutral' telltale light also
lights up.
Engine temperature
The column below the tem-
perature symbol indicates
the engine temperature.
Service-due indicator
If the next service is due in less
than one month, the date for the
next service 1 is shown briefly
after the Pre-Ride Check com-
for neut-
