- Page 1 Garden + Hobby QUALITY FOR LIFE information i manuals i service benzinrasenmäher Powerline betriebsanleitung 474 130_a I 01/2011...
- Page 2 Benzin-Rasenmäher Powerline © Copyright 2009 AL-KO KOBER GROUP Kötz, Germany This documentation is allowed to-also in excerpts-only with express authorization of the AL-KO KOBER GROUP duplicates or third accessible is done. Technical alterations of influence of the function reservations. Original-Betriebsanleitung...
- Page 3 Benzin-Rasenmäher Powerline Original-Betriebsanleitung...
- Page 4 START 474130_a...
- Page 5 Benzin-Rasenmäher Powerline Briggs & Stratton Tecumseh, Honda, AL-KO Original-Betriebsanleitung...
- Page 6 474130_a...
-
Page 7: Table Of Contents
Petrol lawnmower About this handbook Product description „ Read through these operating instructions before This document describes various models of petrol starting up the machine. This is a prerequisite for lawnmowers. Some models are equipped with a grass safe and trouble-free working. Before use, familiar- catcher and/or are suitable for mulching. - Page 8 Starter cable Cutting height adjustment* Start, stop* Blade coupling* Wheel drive* Vario transmission* Safety brake handle Operating instructions Ergonomic height adjustment* Outlet shaft insert* Fill level indicator* Cover flap* Deflector plate* Mulch kit* Grass catcher* Ignition switch for electric start Quick guide Symbols on the device Caution!
-
Page 9: Safety Instructions
Petrol lawnmower Additional symbols on lawnmowers with do not work on slopes where the gradient is „ Electrostart greater than 20° Take particular care when turning „ Caution! Risk of electric shock. „ Only use the lawnmower if there is sufficient Keep the connection line away from the mower daylight or artificial lighting blades. -
Page 10: Assembly
„ Remove cuttings only when the motor has stopped „ Store petrol and oil only in containers intended for this purpose „ Switch off the motor / mower blade when passing over areas other than those that have to be mowed „... -
Page 11: Initial Startup
Petrol lawnmower Initial startup axle adjustment ( 1. To release the lever, press to the side and hold. Caution! 2. Push the lever to the left or right to select the The equipment should not be used if the cutting desired cutting height. - Page 12 Mulching with the mulch kit (optional) Mowing with the side outlet duct (optional) When mulching, the grass cuttings are not collected, but Caution - risk of injury! are left on the lawn. The grass mulch prevents the soil Attach/detach the side outlet only when the motor from drying out, and supplies it with nutrients.
-
Page 13: Starting Electrically (Optional)
Petrol lawnmower Starting the motor 16) - the brake handle does not lock. hold it ( 3. Pull out the starter cord sharply, then allow it to Caution - risk of poisoning! 17). slowly rewind ( Never leave a motor running in an enclosed space. - Page 14 Electrostart without primer/choke ( Lawnmower with blade coupling 1. Set the throttle lever to the "START" position 13/1). 1. Release the safety brake handle ( 25). 2. Pull in the safety brake handle on the handlebar and 12/2). 2. Set the throttle lever to position min ( hold it ( 16) –...
-
Page 15: Maintenance And Care
Petrol lawnmower Maintenance and care Charging the starter battery (optional) Caution - Risk of injury! The starter battery is maintenance-free and is normally charged by the lawnmower. ▪ Before carrying our any care or maintenance In certain cases, however, the battery will need to be work, always switch off the motor and pull out charged by the user: the spark plug connector. -
Page 16: Repairs
Storage Changing the air filter „ Follow the instructions of the manufacturer of the Caution - risk of explosion! motor. Do not store the equipment where there are naked flames or heat sources. Changing the spark plug „ Allow the motor to cool down „... -
Page 17: Faults And Remedies
Petrol lawnmower Faults and remedies Caution! The motor shaft and mower blade should not be aligned. Fault Solution The motor does not start ▪ Add petrol ▪ Set throttle lever to "Start" ▪ Switch on the choke ▪ Press the motor switch at the handlebar ▪... -
Page 18: Warranty
Warranty If any material or manufacturing defects are found during the statutory customer protection period, we will either repair or replace the equipment, whichever we consider the more appropriate. This statutory period may vary according to the legislation in force in the country where the equipment was purchased. Our warranty is valid only if: The warranty is no longer valid if: „... - Page 19 (+380) 44 / 4 92 33 97 aL-KO Geraete Gmbh l Head Quarter l Ichenhauser Str. 14 l 89359 Koetz l Deutschland Telefon: (+49) 82 21/ 2 03- 0 l Telefax: (+49) 82 21/ 20 3 -138 l www.al-ko.com Januar 2011...
