Summary of Contents for August Smart Lock
- Page 1 Installation Guide...
- Page 2 Go to august.com/install to watch a video version of this installation guide. Installation Guide...
- Page 3 Welcome! This guide will get you up and running with your August Smart Lock. Installation generally takes less than 15 minutes. If you have any trouble, please check our support section (august.com/support), contact our installer network (august.com/installers) or call 844-AUGUST1 (284-8781) for help.
- Page 4 Preparation Make sure your existing deadbolt is compatible with the August Smart Lock. Only standard deadbolts are supported. Use our compatibility assistant to double-check: august.com/compatibility TOOLS NEEDED You will need a standard Phillips screwdriver. Alternately, we have a network of installers who can help with installation.
- Page 5 Compatibility Standard Deadbolt is mounted and operates independently of the door handle. Integrated Mortise Lock & Handle An integrated Cylinder Handle and lock door handle Mounted on thumb-latch are and deadbolt the inside, both mounted in a single on top of the together on a metal unit door and...
-
Page 6: Package Contents
Package Contents 1 Adhesive Strip (Inside Envelope) 1 August Smart Lock (4 AA Batteries Pre-installed) 4 Adhesive Rubber Bumpers (Inside Envelope) Installation Guide... - Page 7 3 Adapters 3 Mounting Plates...
-
Page 8: Installation Overview
Installation Overview Before Installation Key Hole Deadbolt Tail Piece Thumb-latch Screws Installation Guide Installation Guide... - Page 9 After Installation Key Hole Deadbolt Tail Piece Mounting Plate Screws Tail Piece Adapter August Smart Lock & Faceplate Calibration Tape...
- Page 10 Step 1: Prepare existing deadbolt. Affix the supplied adhesive strip over the key hole, securing it to the exterior side of your door. This should hold the key hole in place when you remove the thumb-latch on the inside of the door. On some doors, such as those with glossy paint, the included tape may not be strong enough.
- Page 11 11 11...
- Page 12 Step 2: Remove your existing thumb-latch. Position your thumb-latch so that you can unscrew the existing screws on your deadbolt. Remove the screws entirely from the deadbolt and keep them to assist in the next step. After removing the screws, be sure to unlock your deadbolt before removing the thumb-latch.
- Page 14 Step 3: Select the correct mounting plate and adapter. If you know the brand of your deadbolt, please select the correct mounting plate and adapter from the Compatibility Chart on the next page, and then go to Step 4 (page 18). If not, go to Step 3a (page 16) to find the correct mounting plate and adapter.
- Page 15 844-AUGUST1 (284-8781) and we will walk you through installation. Compatible only with non-mortise, standard Omnia deadbolts. Commercial grade Schlage B560 deadbolts require supplemental screws. If your Schlage screws are too short please contact us at support@august.com...
- Page 16 Step 3a: Select the correct mounting plate. Insert the existing screws in the thumb-latch to help you choose the correct mounting plate. If there was a back plate under your thumb-latch, insert the screws into this back plate instead of the thumb-latch. Slide the mounting plates onto the screws one at a time until you find a mounting plate that allows the screws to fit straight through the holes.
- Page 17 NOT COMPATIBLE COMPATIBLE Having trouble selecting the right mounting plate? Try august.com/installation or call August customer support at 844-AUGUST1 (284-8781)
- Page 18 Step 4: Position the mounting plate. Remove the backing from the 4 rubber bumpers and place them on the back side of the mounting plate (the side that does not show a number). Remove the screws from the thumb-latch and use them to install the mounting plate over the existing deadbolt tail piece.
- Page 20 Step 5: Position adapter and align mounting plate. Remove the tape from the key hole, and use your key to turn your deadbolt to the fully unlocked position. If your lock was not in the Compatibility Chart, select the adapter that fits your tail piece. To do this, slide each adapter onto the tail piece.
- Page 21 Front View Deadbolt Tail Piece Adapter Alignment Having trouble selecting the right adapter? Call August customer support at 844-AUGUST1 (284-8781)
- Page 22 Pull out both side wing latches. Slide the August Smart Lock over tail piece and attach to mounting plate. Make sure the back of the lock is flush with the door. To secure the August Smart Lock, clamp down both side wing latches to the mounting plate completely.
-
Page 24: Step 7: Remove Battery Tab
Holding batteries in place, remove the plastic battery isolation tab. Make sure that the battery is properly seated in its compartment. Align faceplate hooks with the August Smart Lock. The faceplate will lock into place with the logo at the bottom. - Page 26 Install August App Download the App from august.com/app The app will help you create an account and set up your August Smart Lock. We suggest that you protect your phone with a passcode in case it is lost or stolen.
- Page 27 27 27...
- Page 28 Questions? If you have any questions or difficulties, visit august.com/support or call 844-AUGUST1 (284-8781) Lost your phone? Go to august.com to disable the August app running on your phone. ©2014 August Home Inc. 1006-0000-A Rev8.1 Installation Guide...
