Summary of Contents for Navman MIVue 5 Series
-
Page 2: Table Of Contents
Table of Contents Getting to know the recorder ......................2 Power key ............................3 LED indicators ..........................3 Using the touch screen ......................4 Inserting a memory card ......................... 5 Using your recorder in a vehicle ....................6 Connecting to external devices .....................8 Connecting to your computer ....................8 Connecting to a High Definition (HD) device ...............8 Operating basics ..........................9 Turning the recorder ON and OFF ..................9... -
Page 3: Getting To Know The Recorder
Getting to know the recorder Name Device mount socket For the device mount. Mini-USB connector Connects to the charger. HD OUT connector Connects to an external device. Touch screen LED indicator 1 Indicates the system status of the recorder. Power key Memory card slot Data is recorded to a MicroSD card (not included). -
Page 4: Power Key
Power key Once the vehicle engine is started, the recorder automatically turns on. By default, the recording will start right after the recorder turns on. You can do the followings using the Power key: ƒ To manually turn the recorder on and off, press and hold the Power key for 2 seconds. -
Page 5: Using The Touch Screen
Using the touch screen To operate your recorder, touch the screen with your fingertip. The device provides the control buttons and system icons on the screen. Depending on your settings and usage, the displayed buttons and icons may be different to provide various function and information of your device. -
Page 6: Inserting A Memory Card
ƒ You are advised to use a Class 6 memory card with at least 8GB capacity. The recorder supports memory cards with up to 32GB capacity. ƒ Navman does not guarantee the product’s compatibility with memory cards from all manufacturers. -
Page 7: Using Your Recorder In A Vehicle
Using your recorder in a vehicle 1. Make sure that your car is parked on a level ground. 2. Follow the instruction below to mount your recorder in a vehicle securely. 3. Connect the car charger to the cigarette lighter. Route the cables through the top ceiling and the A-pillar so that it does not interfere with driving. - Page 8 4. When adjusting the angle of mounting, make sure that the camera’s view is parallel with the level ground, and the ground/sky ratio is close to 6/4. 5. When not using the recorder, follow the instruction below to remove the recorder from the holder.
-
Page 9: Connecting To External Devices
Connecting to external devices Connecting to your computer You can connect the recorder to your computer to access data on the memory card. The Mini-USB connector is located on the right side of the device. Follow the instruction below to connect the rcorder to the computer via the USB cable (not supplied). Connecting to a High Definition (HD) device For a better viewing experience, you can connect the recorder to an external viewing device that supports the High Definition (HD) feature via a HD cable (not supplied). -
Page 10: Operating Basics
Operating basics Turning the recorder ON and OFF Complete the installation according to the instructions in the “Using your recorder in a vehicle” section. ƒ Once the vehicle engine is started, the recorder automatically turns on. By default, the recording will automatically start in a few seconds after start-up. ƒ... -
Page 11: Recording In Driving Mode
Recording in driving mode NOTE: ƒ DO NOT remove the memory card while recording. ƒ If the recording (including continuous recording, event recording and parking recording) is ongoing but there is not enough space on your memory card, the system will display a warning message on the screen. -
Page 12: Recording In Parking Mode
Recording in Parking mode Your recorder supports parking recording function. Depending on how long the car is parked, you may need an external power source (e.g. a power bank) to record the video while the device's power cable is disconnected. ƒ... -
Page 13: Playback Mode
Playback mode To select a video or photo for playback: 1. Tap to access the Settings Menu. 2. Tap File Playback and then select the desired type. The types include: Video (continuous recordings), Emergency (event recordings), Parking (parking recordings) and Photo. 3. -
Page 14: System Settings
System settings Settings Menu To customise the system settings, tap Item Description File Playback Plays the recorded videos and photos. For more information on playback, see the "Playback mode" section. Record Voice Sets if you want to include sounds in the recordings. The default setting is On. - Page 15 (1 min, 3 min, or 5 min). - EV: Sets the proper exposure level (-1 ~ +1) to adjust the brightness of the image. The default setting is 0. - HDR: Select On or Off to enable or disable High Dynamic Range function of the device. - GPS Stamp: Sets if and how you want to record the GPS information.
-
Page 16: Mivue Manager
IMPORTANT! Your computer needs MOV and AVI codecs to play the recording files. Please visit www.navman.com.au or www.navman.co.nz to install the required codecs. Installing MiVue Manager Download the Setup file from www.navman.com.au or www.navman.co.nz. Double-click Setup.exe and follow the on-screen prompts to install MiVue Manager. - Page 17 NOTE: ƒ The Map screen may not appear when the computer is not connected to the Internet or when your MiVue model records without the GPS function. ƒ G sensor chart displays data in 3-axis waveform about the car’s shift forward/ backward (X), to the right/left (Y) and upward/downward (Z).
- Page 18 5. The playback controls are described as follows: Icon Description Starts or pauses the playback. ／ Skips to the previous / next file on the list. Changes the playback speed to 1/4x, 1/2x, 1x (default), 1.5x, or 2x. ／ Mutes or unmutes the volume. Adjusts the volume level.
- Page 19 ƒ Click to open the Settings Menu, including the following options: Change Language: Sets the display language of MiVue Manager. Change Skin: Sets the color scheme of MiVue Manager. Check for Update: Checks if there is any new version of MiVue Manager. Internet access is required for this feature.
-
Page 20: For More Information
For more information Caring for your device Taking good care of your device will ensure trouble-free operation and reduce the risk of damage. ƒ Keep your device away from excessive moisture and extreme temperatures. ƒ Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of time. -
Page 21: Precautions And Notices
Precautions and notices ƒ For your own safety, do not operate the controls of the product while driving. ƒ A window mount is needed when using the recorder in a car. Make sure that you place the recorder in an appropriate place, so as not to obstruct the driver’s view or deployment of airbags. -
Page 22: About Gps
About the battery CAUTION! This unit contains a non-replaceable internal Lithium Ion battery. The battery can burst or explode, releasing hazardous chemicals. To reduce the risk of fire or burns, do not disassemble, crush, puncture, or dispose of in fire or water. ƒ... -
Page 23: Regulatory Information
Regulatory information For regulatory identification purposes, Navman MiVue 560 series is assigned a model number of N467. Marking labels located on the exterior of your device indicate the regulations that your model complies with. Please check the marking labels on your device and refer to the corresponding statements in this section. - Page 24 Disclaimer Specifications and documents are subject to change without notice. Navman does not warrant this document is error-free. Navman assumes no liability for damage incurred directly or indirectly from errors, omissions, or discrepancies between the device and the documents.
