WUA-0605
300Mbps Wireless USB Network Adapter
User Manual
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WUA-0605 and is the answer not in the manual?

Questions and answers

Related Manuals for LevelOne WUA-0605

Summary of Contents for LevelOne WUA-0605

  • Page 1 WUA-0605 300Mbps Wireless USB Network Adapter User Manual V1.0...
  • Page 2 Certification FCC CE FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Table Of Contents

    Content Content ................2 1. Introduction ..............1 1.1. Product Overview ........................1 1.2. Main Features .......................... 1 1.3. Standards ..........................1 1.4. Working Environment ....................... 1 1.5. System Requirements ......................1 2. Hardware and Driver Installation ........2 2.1. Insert the Adapter ........................2 2.2.

  • Page 4: Introduction

    1. Introduction 1.1. Product Overview This USB Wireless adapter is a powerful USB 2.0 Adapter that installs quickly and easily with PCs. The Adapter can be used in ad hoc mode to connect directly with other wireless adapters for peer-to-peer file sharing, or in infrastructure mode to connect with a wireless access point or router. The adapter connects with 802.11n networks at up to 150Mbps, and is backwards compatible with 54Mbps 802.11g or 11Mbps 802.11b devices.

  • Page 5: Content

    2. Hardware and Driver Installation 2.1. Insert the Adapter Plug the USB Wireless Adapter into an available USB port on your computer, and the Found New Hardware Wizard (windows 7) screen will appear; Close the wizard, then clicks the following steps to install;...
  • Page 6 ► Click Next ► Automatically start the installation default "install drivers and utilities";...
  • Page 7 ► Click ‘Finish’ to finish installation. The installation is complete.

  • Page 8: System Configuration

    3. System configuration The USB Wireless Adapter provides two modes: Station mode and Access Point mode, the default is Station mode. You can select remote wireless AP to connect to Internet in station mode. But in the AP mode, the wireless USB adapter act as a wireless access point which wireless client can connect to share an Internet connection with others.

  • Page 9: Profile

    ► MAC Address: The MAC Address of the Adapter. ► IP Address: The IP Address of the Adapter. ► Subnet Mask: The Subnet Mask of the Adapter. ► Default Gateway: The Default Gateway address of the Adapter. Others ► Show Tray Icon: Show USB Wireless LAN Utility icon in the windows taskbar notification area.
  • Page 10 When the Network Info dialog box appears (the former picture), enter a name for the new profile. Enter the Network SSID. Choose the Network Authentication Mode and Data encryption from the drop-down menu and import the network key. Then click OK button. ►...
  • Page 11 Choose the Network Authentication Mode and Data encryption from the drop-down menu. And import the network key. Then click OK button. You have successfully created a profile. 3.2.2. Remove Select a profile and click Remove button to delete this profile (refer to the following picture).
  • Page 12 3.2.3. Edit Select a profile and click Edit button to edit this profile (refer to the following picture). Modify the profile information according to your demand.
  • Page 13 3.2.4. Duplicate Select a profile which you want to copy and then click Duplicate(refer to the following picture). Import the new profile name in the popup window blank (refer to the following picture). 3.2.5. Set default When you want to make one profile as a default wireless connection, you should select the profile and click Set default button.

  • Page 14: Available Network

    3.3. Available Network The Available Network tab displays a list of infrastructure and ad-hoc networks for available wireless connection (refer to the following picture). Double-click the network to which you wish to connect.

  • Page 15: Status

    Refer to the picture to choose the Authorization modes and Encryption modes in the drop-down box. If the wireless network uses a Passphrase, enter the Passphrase in the Passphrase field. Click the OK button to complete the network connection. 3.4. Status The Status tab displays the detailed information of current device and wireless connection.

  • Page 16: Statistics

    3.5. Statistics The Statistics tab display the stat. value of current wireless connection Tx and Rx, you can click Reset button to reset value and restart to count. 3.6. Wi-Fi Protect Setup Wi-Fi Protect Setup (WPS) function can let you create a safety network easily. You can through ‘PIN Input Config (PIN)’...
  • Page 17 WPS can connect the wireless adapter and the router in a safe way. If you have a router which has WPS button, you may set up a safe network via the following methods. Method 1: ► Push the WPS button in the Router until the WPS LED flashes ►...
  • Page 18 ► Click the ‘PIN Input Config (PIN)’ in the Wi-Fi protect setup of the adapter. ► Select the AP that you want to connect in the pop-up window, and then click ‘Select’. ► The connection between the adapter and the router will be established automatically. Note: If there is more than one AP on the PBC mode when you use the method 1, there will be session overlap.

  • Page 19: The Access Point Mode

    4. The Access Point Mode We can use the USB wireless adapter to build an access point apart from the station mode. The wireless client can connect to it if the USB wireless adapter is set to access point mode, then you can share an Internet connection with others Click Mode in the menu bar and select Access Point, then it will change to Access Point mode automatically.
  • Page 20 ► Profile name: The default is Access Point Mode and can’t be modified. ► Network name (SSID): The name of this AP and can be modified. ► Channel: You can select channel 1 to 14, which provides a choice of avoiding interference. ►...

  • Page 21: Advanced

    4.2. Advanced ► Beacon Interval: This represents the amount of time between beacon transmissions. Before a station enters power save mode, the station needs the beacon interval to know when to wake up to receive the beacon (and learn whether there are buffered frames at the access point). ►...

  • Page 22: Statistics

    4.3. Statistics It display receive and transmit information. 4.4. ICS You can set internet connecting sharing (ICS), select the network you want to share in the list, then click ‘apply’, the following picture appears. When you connect successfully, you can share network with others.

  • Page 23: Troubleshooting

    5. Troubleshooting This chapter provides solutions to problems that may occur during the installation and operation of the USB Wireless Adapter. Read the descriptions below to solve your problems. 1. The USB Wireless Adapter does not work properly? Reinsert the USB Wireless Adapter into your PC’s USB slot. Right click My Computer and select Properties.
