Tonze aw 6660 User Manual

Wireless 802.11ag ap
Hide thumbs Also See for aw 6660:
Table of Contents

Advertisement

Quick Links

Wireless 802.11ag AP
User's Manual
Version 1.0
0
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the aw 6660 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tonze aw 6660

Summary of Contents for Tonze aw 6660

  • Page 1 Wireless 802.11ag AP User’s Manual Version 1.0 User’s Guide...

  • Page 2: Copyright Statement

    Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording, or otherwise without the prior writing of the publisher. MAY. 2005 User’s Guide...

  • Page 3: Table Of Contents

    Contents 1. Introduction........................ 3 2. Safety Notification...................... 4 3. Hardware Installation ....................5 4. How to Configuring the Dual Band AP ............... 8 4.1 Setup – Network Setup.................... 9 4.2 Wireless – Wireless Settings ................. 10 4.3 Wireless – Wireless Mode ................... 12 4.4 Wireless MAC Filter ....................

  • Page 4: Introduction

    1. Introduction Thank you for purchasing your Wireless 802.11ag AP. This user guide will assist you with the installation procedure. User’s Guide...

  • Page 5: Safety Notification

    2. Safety Notification Your Wireless AP should be placed in a safe and secure location. To ensure proper operation, please keep the unit away from water and other damaging elements. Please read the user manual thoroughly before you install the device. The device should only be repaired by authorized and qualified personnel.

  • Page 6: Hardware Installation

    3. Hardware Installation Front Panel The front panel provides LED’s for device status. Refer to the following table for the meaning of each feature. The Power LED lights up and will keep while the AP is powered on. When the AP goes through its self- Power diagnostic mode during every boot-up, this LED will flash.
  • Page 7 Rear Panel The rear panel features 1 Ethernet port, Reset button and Power port. Refer to the following table for the meaning of each feature. Ethernet Power RESET The RESET button can restore device to factory default settings by press this button for approx. 10 RESET Button seconds during device power on status.
  • Page 8 Hardware Installation for Connection to Your local network 1. Power off your network devices. 2. Locate an optimum location for the AP. The best place for the AP is usually at the center of your wireless network, with line of sight to all of your wireless devices. 3.

  • Page 9: How To Configuring The Dual Band Ap

    4. How to Configuring the Dual Band AP TURN ON POWER SUPPLY Quick power cycle would caused system corruption. When power on, be careful not to shut down in about 5 seconds, because data is writing to the flash. START UP & LOGIN In order to configure the Wireless 11ag AP, you must use web browser and manually input http://192.168.1.250 into the Address box and press Enter.

  • Page 10: Setup - Network Setup

    4.1 Setup – Network Setup MAKE CORRECT NETWORK SETTINGS OF YOUR COMPUTER To change the configuration, use Internet Explorer (IE) or Netscape Communicator to connect the WEB management 192.168.1.250. This following screen contains all of the AP's basic setup functions. Most users will be able to configure the AP and get it working properly using the default settings.

  • Page 11: Wireless - Wireless Settings

    4.2 Wireless – Wireless Settings Wireless Settings Enable L2 isolation: Enable this checkbox can isolate each wireless client which associated this AP. Wireless-A Settings If you are using a Wireless-A network, then the following settings that you may need to configure. Mode: This mode is controlling the Wireless-A (802.11a) networking, Enabled or Disabled.
  • Page 12 Change these settings as described here and click the Apply button to apply your changes or click Cancel button to cancel your changes. For additional information, click Help. User’s Guide...

  • Page 13: Wireless - Wireless Mode

    4.3 Wireless – Wireless Mode There are 3 operating modes in each A,B/G band, using the following setting can perform each function. Wireless-A Settings Access Point: This mode provides access for wireless stations to wired LANs and from wired LANs to wireless stations.

  • Page 14: Wireless Mac Filter

    4.4 Wireless MAC Filter This function allows administrator to have access control by enter MAC address of wireless devices which transmitting within your wireless network. Wireless-A Setting Access Control List Mode: This drop-down menu can set Enable/Disable the ACL function. Default Access: Select the default policy for this ACL rule.

  • Page 15: Wireless - Wireless Security

    4.5 Wireless – Wireless Security The Wireless Security settings configure the security of your wireless network. There are three wireless security mode options supported by the AP: WEP (Wired Equivalent Privacy), WPA Pre-Shared Key, WPA RADIUS. Wireless Security The security options are the same and independent for your Wireless-A and Wireless-G networks. You can use different wireless security methods for your networks;...

  • Page 16: Wireless - Advanced Wireless Settings

    4.6 Wireless – Advanced Wireless Settings This section provides AP’s advanced wireless settings. These settings should be adjusted carefully. Any improper settings will affect the AP’s wireless performance. Advanced Wireless Wireless-A Settings Authentication Type: Open System: This is default setting, those wireless clients that NOT use a WEP key for authentication. Shared Key: This option means the wireless clients use a WEP key for authentication.
  • Page 17 Wireless-B/G Settings Authentication Type: Open System: This is default setting, those wireless clients that NOT use a WEP key for authentication. Shared Key: This option means the wireless clients use a WEP key for authentication. Shared Key is only available if the WEP option is implemented.
  • Page 18 Change these settings as described here and click the Apply button to apply your changes or click Cancel to cancel your changes. For additional information, click Help. User’s Guide...

  • Page 19: Administration - Management

    4.7 Administration – Management This section allows the network’s administrator to manage specific AP functions for access and security. Management UserName: The login username, default value is blank(null). Password: The login password, default value is admin. Re-enter to Confirm: You can change the AP’s password from here. Enter a new AP password and then type it again in the Re-enter to Confirm field to confirm.

  • Page 20: Administration - Reboot Ap

    4.8 Administration – Reboot AP AP Reboot: Click this button to initialize this device. User’s Guide...

  • Page 21: Administration - Firmware Upgrade

    4.9 Administration – Firmware Upgrade This Firmware Upgrade screen allows you to upgrade the AP’s firmware. Do not upgrade the firmware unless you are experiencing problems with the AP or the new firmware has a feature you want to use. Firmware Upgrade Please select a file to upgrade: In the field provided, enter the name of the extracted firmware upgrade file, or click the Browse button to find this file.

  • Page 22: Administration - Factory Defaults

    4.10 Administration – Factory Defaults This Factory Defaults allows you to restore the AP’s configuration to its factory default settings. Factory Defaults Restore Factory Defaults: Click this button to reset all configuration settings to their default values. Any settings you have saved will be lost when the default settings are restored.

  • Page 23: Status - Local Network

    4.11 Status – Local Network The Local Network screen on the Status Tab displays the status of your network. Identity Device Name: The device name for user identification. Firmware Version: The current AP firmware version display here. Local Area Network Local MAC Address: This is the AP’s local physical MAC Address.

  • Page 24: Status - Wireless Network

    4.12 Status – Wireless Network The Wireless Network screen on the Status Tab displays the information of your Wireless networks. Wireless Settings Wireless-A Settings MAC Address: This is the AP’s Wireless-A band MAC Address. Mode: This mode is displaying the current status of Wireless-A band network. Enabled means the A band network is Turbo Mode: This mode is displaying the turbo mode status.

  • Page 25: Status - Wireless Statistics

    4.13 Status – Wireless Statistics Wireless Statistics: This displays the AP and stations that are currently part of the BSS. User’s Guide...

  • Page 26: Troubleshooting - Q & A

    5. Troubleshooting – Q & A 1. I’m trying to log on the AP’s Web configuration page, but I do not see the login screen. Answer: 1. Please make sure the IP address that you input on address field of IE browser is correct. 2.
