Roundup STS-200 Owner's Manual

Steamer/scale
Hide thumbs Also See for STS-200:
Table of Contents

Advertisement

Quick Links

Download this manual
MaNuFactuRiNg
NuMbeRs:
910 0 9 2 0
C
US
CM
P/N 1010853 Rev. F 11/09
Steamer/Scale
Owner
Model STS-200
s manual
'

Advertisement

Table of Contents
loading

Related Manuals for Roundup STS-200

Summary of Contents for Roundup STS-200

  • Page 1 MaNuFactuRiNg NuMbeRs: 910 0 9 2 0 Steamer/Scale Model STS-200 P/N 1010853 Rev. F 11/09 Owner s manual ’...

  • Page 2: Table Of Contents

    & Plug configurations .......5 Rotary switch settings ..........17 Model Designation .............5 maintenance ..............18 Dimensions ..............6 Cleaning the STS-200 During Daily Use ....18 Installation ..............7 Cleaning the STS-200 Steamer/Scale Daily ...19 unpacking ..............7 Weekly Maintenance ..........19 equipment setup ............7 cleaning the Water inlet tube .........20...

  • Page 3: Service/Technical Assistance

    Name: or operation of your unit, contact your local Roundup Phone No.: authorized service agency. they can be found in the service agency directory packaged with the equipment.
  • Page 4 • Do NOT clean this appliance with a water jet. • This equipment should be serviced by qualified personnel only. contact the nearest Roundup • Do NOT use a sanitizing solution or abrasive authorized service agency for adjustment or materials.

  • Page 5: Specifications

    STS-200 STeamer/Scale specIfIcatIOns electrical ratings cautIOn this equipment is to be installed to comply with model & Voltage Watts amps Hertz the basic plumbing code of the building Officials mfg. no and code administrators, Inc. (bOca) and the sts-200 food service sanitation manual of the food and 1500 12.5...

  • Page 6: Dimensions

    STS-200 STeamer/Scale specIfIcatIOns (continued) Dimensions 8 1/2" (215.9 mm) 13 1/2" (32.9 mm) 7 1/4" (184.15 mm) 11 1/4" (285.75 mm) P/N 1010853 Rev. F 11/09...

  • Page 7: Installation

    Zero (on) button General Digital air bulb the sts-200 steamer/scale is used to heat and por- Display Oz LED switch tion sliced meats. the air bulb switch initiates a shot with of steam while the digital display shows the weight of...
  • Page 8 STS-200 STeamer/Scale InstallatIOn (continued) 16 ounce (1 pound) calibration Weight stainless steel cleaning brush for steam Generator power cord power On/ Off switch air bulb Water supply switch tubing from Dual Water regulator Kit connection figure 3. back of steamer/scale with calibration Weight and cleaning brush...

  • Page 9: Installation Instructions For Dual Water Pressure Regulator Kit P/N 7000418

    STS-200 STeamer/Scale InstallatIOn (continued) InstallatIOn InstructIOns fOr Dual Water pressure reGulatOr KIt p/n 7000418 Water Pressure Water supply Outlet WarnInG Regulator (to steamer/scale) turn the power off, unplug the power cord, and Preset to 30 psi allow the unit to cool down before performing any and Fixed service or maintenance.

  • Page 10: Checking And Cleaning The Water Strainer

    STS-200 STeamer/Scale InstallatIOn (continued) checking and cleaning the Water strainer adjusting the Water pressure regulator the Water strainer protects your equipment from any The Dual Water Pressure Regulator uses a fixed foreign debris in the water line that could get into the regulator and an adjustable regulator (Figure 4c).
  • Page 11 STS-200 STeamer/Scale InstallatIOn (continued) Water Pressure Regulator Preset to Water Pressure 30 psi and Fixed Regulator set to 7–9 psi (not adjustable) (adjustable) Release Hose clamp Quick Hose clamp Disconnect #1 Quick (to steamer/ Disconnect #2 Nipple scale supplied Water Flow...

  • Page 12: Installation Instructions Optional Filter To Regulator Kit P/N 7000420

    Dual Water Pressure Regulator for the sts-200. it allows you to easily connect your existing water supply to the sts-200 steamer/scale. it is equipped with quick disconnect attachments for easy installation and also has a water shut-off valve for maintenance (Figure 5).

  • Page 13: Manual

    STS-200 STeamer/Scale InstallatIOn (continued) Dual Water Pressure Regulator Kit (P/N 7000418) to sts-200 Optional Filter to Regulator Kit (P/N 7000420) From cold Water supply Main shut Off Valve figure 6. Dual Water regulator Kit (p/n 7000418) with Optional filter to regulator Kit (p/n 7000420)

  • Page 14: Installation Instructions For Air Bulb Switch Kit P/N 7000419

    STS-200 STeamer/Scale InstallatIOn (continued) InstallatIOn InstructIOns fOr aIr bulb sWItcH KIt p/n 7000419 Hole cut into counter WarnInG with Rubber grommet turn the power off, unplug the power cord, and 12 inches behind unit. allow the unit to cool down before performing any service or maintenance.
  • Page 15 STS-200 STeamer/Scale InstallatIOn (continued) 4. if you chose options 2 or 3, skip to step 5. For option 1, you must cut a hole through the top of the counter. this hole Must be at least 12 inches directly behind the air switch connection located on the back of the unit.

  • Page 16: Operation

    STS-200 STeamer/Scale OperatIOn 6. When the blue LED turns on, another steam/time cautIOn cycle can be initiated. Handle the steamer/scale with great care. Do not place objects other than sliced meat on the unit 7. Remove steamed product and complete the and neVer place anything over 4 pounds (64 assembly of the sandwich.

  • Page 17: Rotary Switch Settings

    STS-200 STeamer/Scale OperatIOn (continued) rotary switch settings setting temp/f° cycle/sec shot/sec at the back of the sts-200 unit are three Rotary 375* 10.0 switches: temp, cycle, and shot. 4.0* 0.4* TEMP CYCLE SHOT the temp Rotary switch sets the operating temperature of the unit.

  • Page 18: Maintenance

    Ster-O-Kem® #15 Solution (HcS) sanitizer figure 8. steamer/scale components cleaning the sts-200 During Daily use this should be cleaned throughout the day. to do so, remove the Top Cover and Diffuser and clean them with cautIOn a damp cloth (not dripping).

  • Page 19: Cleaning The Sts-200 Steamer/Scale Daily

    1. Check the Water Quick Disconnect Fitting and all the sts-200 steamer/scale utilizes an open steam hose clamp connections for leakage. if leakage generator. Water sprayed into the steam generator...

  • Page 20: Cleaning The Water Inlet Tube

    STS-200 STeamer/Scale maIntenance (continued) ImpOrtant: In soft water areas, it may be necessary to add a small amount of lime to the steam Generator sur- face to “season” it. this will ensure proper steaming characteristics by producing a thin coating of mineral deposits on the sur- face.

  • Page 21: Weekly- Testing The Sts-200 For Weighing Accuracy

    15.9, 16.0, or 16.1 ounces (452.67 to 458.36 grams), you must cali- Weekly- testing the sts-200 for Weighing brate the scale according to the Operating section accuracy of this manual.

  • Page 22: Error Codes

    STS-200 STeamer/Scale trOublesHOOtInG (continued) error codes the table below lists the possible error codes displayed by the unit when an error occurs. nOte: If any of these errors appear on the steamer/scale display, contact the factory. error code Description and corrective action “e1”...
  • Page 23 STS-200 STeamer/Scale trOublesHOOtInG (continued) problem possible cause(s) corrective action the unit heats up and steams but Faulty scale control board. contact your maintenance person the front display is blank. or an authorized service agency for Faulty temperature control board. service.
  • Page 24 STS-200 STeamer/Scale trOublesHOOtInG (continued) problem possible cause(s) corrective action scale is not weighing scale requires calibration. calibrate scale according to calibrating properly and/or behaves the steamer scale section in the erratically. Operation section of this manual. interference/binding with the floating if unit was recently disassembled and/or “spider”...
  • Page 25 STS-200 STeamer/Scale trOublesHOOtInG (continued) problem possible cause(s) corrective action the unit is not the Water Pressure Regulator is adjust regulator to 7–9 psi. Refer to the section steaming the product improperly set. titled adjusting the Water Pressure Regulator” properly and/or the in this manual.

  • Page 26: Replacement Parts

    STS-200 STeamer/Scale replacement parts Page 31 Page 30 Page 29 See Page 27 See Page 28 P/N 1010853 Rev. F 11/09...
  • Page 27 STS-200 STeamer/Scale replacement parts (continued) Item part Description Qty. Item part Description Qty. 7000458 Hi-Limit Thermostat Kit* 7000424 Generator Kit (incl. 2, 4, 5, 7, 8, & 10) 4030373** thermostat 0100245** generator Machined 3040114** Screw #4-40 x 1/4 4050228** Probe, thermistor...
  • Page 28 STS-200 STeamer/Scale replacement parts (continued) Item part Description Qty. 308P189 screw 8-32 x 1/4” (10-pack) 310P170** Nut, #10-32 NY-Lock (10-pack) 800P007** screw, M6 x 16 mm Hex Head 0504087** spider 0504122** spacer, Load cell 4030367** Load cell Includes item #5, 3, and 2 310P146** Nut, Hex “KEPS”...
  • Page 29 STS-200 STeamer/Scale replacement parts (continued) Item part Description Qty. Item part Description Qty. 2120168 Spacer #6 0504057 Housing, steamer 0504123 bracket, terminal Mounting 4060386 Indicator, LED Blue 4060387 Terminal, Double Row x 2 Con 1001140 Label, control Panel 306P130 Nut, Hex KEPS #6-32 7000439 Membrane Switch (Incl.
  • Page 30 STS-200 STeamer/Scale replacement parts (continued) NOTE: Item 8 can be purchased separately in kit #7000429 Item part Description Qty. Item part Description Qty. 306P105* Screw, Mach #6-32 x 1/2” Sltrshd. 7000425 solenoid assy. (incl. items 2-9) 040P119* bushing, shorty 5/8”...
  • Page 31 STS-200 STeamer/Scale replacement parts (continued) Item part Description Qty. 0011784 top cover Weldment 304P114 Screw, Machine #4-40 x 1/4” (10-pack) 0504121 seal Retainer 0300145 screw, Locator (peg, steel) 2120157 spacer 2120154 standoff 7000423 Seal Kit, pack of 4 (Incl. #2)
  • Page 32 STS-200 STeamer/Scale replacement parts (continued) Dual Water Pressure Regulator Kit (P/N 7000418) Orange O-Ring Strainer Screen Strainer Cup Inlet Tubing NOT Supplied Must use 1/4" I.D Nylon Braided Hose Item part Description Qty. Item part Description Qty. 7000333 strainer 1/4 FtP (includes O-Ring,...
  • Page 33 STS-200 STeamer/Scale replacement parts (continued) Item part Description Qty. 7000435 Weight, 1 lb (16 ounces) (incl 1a) 2130173 Wire brush P/N 1010853 Rev. F 11/09...

  • Page 34: Wiring Diagram

    STS-200 STeamer/Scale WIrInG DIaGram NOTE: ALL WIRES TO BE 14 GA. TFE-200°C POWER UNLESS OTHERWISE SPECIFIED. ZERO/HIDDEN CORD SWITCH # 16 GA. TFE-200°C 22 GA. TFE-200°C FERRITE CORE TERMINAL BLOCK SCALE CONTROL VARISTORS (X3) LOAD CELL POWER SWITCH AIR SWITCH...

  • Page 35: Notes

    STS-200 STeamer/Scale nOtes P/N 1010853 Rev. F 11/09...

  • Page 36: Limited Warranty

    2. Roundup reserves the right to make changes in design or add any improvements on any product. the right is always reserved to modify equipment because of factors beyond our control and government regulations. changes to update equipment do not constitute a warranty charge.
