Page 1 Challenger 2 0 1 2 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and the features and equipment that are either standard or optional name Chrysler Canada Inc.
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
Page 5 INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 The vehicle identification number (VIN) is also located VEHICLE MODIFICATIONS/ALTERATIONS on the right front strut tower inside the engine compart- WARNING! ment. Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a accident resulting in serious injury or death.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Vehicle Security Alarm ....18 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Using The Panic Alarm ....25 Trunk Lock And Release ....41 ▫...
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ Seat Belt Extender ..... 56 Safety Tips ......82 ▫...
Page 14: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Wireless Ignition Node (WIN) Your vehicle uses a keyless ignition system. This system The Wireless Ignition Node (WIN) operates similar to an consists of a Key Fob with Remote Keyless Entry (RKE) ignition switch.
Page 15: Key Fob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. Insert the square end of the key fob into the ignition switch located on the instrument panel and rotate to the desired posi- tion.
Page 16: Removing Key Fob From Ignition
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch Removing Key Fob From Ignition at the top of the Key Fob sideways with your thumb and Place the shift lever in PARK. Turn the Key Fob to the then pull the key out with your other hand.
Page 17 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 CAUTION! WARNING! (Continued) • Never leave children alone in a vehicle, or with • If your vehicle battery becomes low or dead, your access to an unlocked vehicle. Key Fob will become locked in the ignition. •...
Page 18: Key-In-Ignition Reminder
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE will cause the reminder chime to sound. Refer to “Start- CAUTION! ing Procedures” in “Starting And Operating” for further information. An unlocked car is an invitation to thieves. Always remove the Key Fob from vehicle, cycle the ignition SENTRY KEY OFF with Keyless Enter-N-Go, and lock all doors The Sentry Key Immobilizer System prevents unauthor-...
Page 19: Replacement Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 After placing the ignition switch in the ON/RUN posi- All of the Key Fobs provided with your new vehicle have tion, the Vehicle Security Light will turn on for three been programmed to the vehicle electronics. seconds for a bulb check.
Page 20: Customer Key Programming
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • This device may not cause harmful interference. At the time of purchase, the original owner is provided with a four-digit Personal Identification Number (PIN). • This device must accept any interference that may be Keep the PIN in a secure location.
Page 21: To Arm The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 • Press LOCK on the interior power door lock switch off after three minutes, turn all of the visual signals off after an additional 15 minutes, and then the Vehicle with the driver and/or passenger door open. Security Alarm will rearm itself.
Page 22 20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Grasp the Passive Entry Unlock Door Handle (if the Vehicle Security Alarm. If someone enters the equipped, refer to Keyless Enter-N-Go in Things To vehicle through the trunk and opens any door the Know Before Starting Your Vehicle for further infor- alarm will sound.
Page 23: Illuminated Entry
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 Tamper Alert NOTE: • The front courtesy overhead console and door cour- If something has triggered the Vehicle Security Alarm in your absence, the horn will sound three times and the tesy lights do not turn on if the dimmer control is in exterior lights will blink three times when you disarm the the Dome ON position (extreme top position).
Page 24: To Unlock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Inserting the Key Fob with RKE transmitter into To Unlock The Doors the ignition switch disables the system from responding Press and release the UNLOCK button on the RKE to any button presses from that RKE transmitter. Driving transmitter once to unlock the driver’s door or twice at speeds 5 mph (8 km/h) and above disables the system within five seconds, to unlock both doors.
Page 25 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 • When not using the EVIC, perform the following activated will cause the alarm to sound. Press the UN- steps: LOCK button to deactivate the Security Alarm. 1. Press and hold the LOCK button on a programmed Flash Lights With Remote Key Lock RKE transmitter for at least 4 seconds, but no longer than This feature will cause the turn signal lights to flash when...
Page 26: To Lock The Doors
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Test the feature while outside of the vehicle by press- To Lock The Doors ing the LOCK/UNLOCK buttons on the RKE transmitter Press and release the LOCK button on the RKE transmit- with the ignition switch in the OFF position and the Key ter to lock both doors.
Page 27: To Open The Trunk
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 • When not using the EVIC, perform the following Alarm. Opening a door with the Security Alarm activated steps: will cause the alarm to sound. Press the UNLOCK button to deactivate the Security Alarm. 1.
Page 28: Programming Additional Transmitters
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Panic Alarm will stay on for three minutes unless Transmitter Battery Replacement you turn it off by either pressing the PANIC button a The recommended replacement battery is CR2032. second time or drive the vehicle at a speed of 5 mph NOTE: Perchlorate Material –...
Page 29: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 3. To reassemble the RKE transmitter case, snap the two If your RKE transmitter fails to operate from a normal halves of the case together. Make sure there is an even distance, check for these two conditions: “gap”...
Page 30: How To Use Remote Start
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Use Remote Start WARNING! All of the following conditions must be met before the • Do not start or run an engine in a closed garage or engine will remote start: confined area.
Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 NOTE: To Exit Remote Start Mode Without Driving The • If an engine fault is present the vehicle will start and Vehicle then shut down 10 seconds later. • Press and release the REMOTE START button one time •...
Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Cancel Remote Start • For vehicles not equipped with the Keyless Enter- Remote Starting will also cancel if any of the following N-Go feature, the ignition switch must be in the occur: ON/RUN position in order to drive the vehicle.
Page 33: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 DOOR LOCKS If the door lock knob is down when you shut the door, the door will lock. Therefore, make sure the Key Fob is Manual Door Locks not inside the vehicle before closing the door. To lock each door, push the door lock knob on each door trim panel downward.
Page 34: Power Door Locks
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Chil- dren should be warned not to touch the parking brake, brake pedal or the shift lever.
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 If you press the power door lock switch while the Key 2. The transmission was in gear and the vehicle speed Fob is in the ignition, and either door is open, the power returned to 0 mph (0 km/h) locks will not operate.
Page 36: Keyless Enter-N-Go
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Place the Key Fob in the ignition switch. KEYLESS ENTER-N-GO The Passive Entry system is an enhancement to the 3. Within 15 seconds, cycle the ignition switch between vehicle’s Remote Keyless Entry (RKE) system and a OFF and ON/RUN and then back to OFF four times feature of Keyless Enter-N-Go.
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 • If wearing gloves on your hands, or if it has been raining on the Passive Entry door handle, the unlock sensitivity can be affected, resulting in a slower re- sponse time. •...
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If “Unlock All Doors 1st Press” is programmed Preventing Inadvertent Locking Of Passive Entry RKE all doors will unlock when you grab hold of the front Transmitter In Vehicle driver’s door handle. To select between “Unlock Driver To minimize the possibility of unintentionally locking a Door 1st Press”...
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 To Enter The Trunk NOTE: If you inadvertently leave your vehicle’s Passive With a valid Passive Entry RKE transmitter within 3 ft Entry RKE transmitter in the trunk and try to close the (1.0 m) of the deck lid, press the button on the located on deck lid, the deck lid will automatically unlatch, unless the center of the light bar which is located on the deck lid...
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Lock The Vehicle’s Doors NOTE: • After pressing the door handle LOCK button, you With one of the vehicle’s Passive Entry RKE transmitters within 5 ft (1.5 m) of the driver or passenger front door must wait two seconds before you can lock or unlock handles, press the door handle LOCK button to lock both the doors, using either Passive Entry door handle.
Page 41: Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 WINDOWS There is a single window control on the passenger’s door trim panel that operates the window on the passenger’s Power Windows door. The window controls will operate only when the The window controls on the driver’s door control both of ignition switch is in the ON/RUN or ACC position.
Page 42: Wind Buffeting
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The power window switches will remain active for up to WARNING! 60 minutes after the ignition switch is turned OFF. Opening either door will cancel this feature. The time for Never leave children in a vehicle with the key in the this feature is programmable.
Page 43: Trunk Lock And Release
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 TRUNK LOCK AND RELEASE With the ignition switch in the ON/RUN position, the The trunk lid can be released from inside the vehicle by Trunk Open symbol will display in the instrument cluster pressing the Trunk Release button.
Page 44: Trunk Safety Warning
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE TRUNK SAFETY WARNING Trunk Emergency Release As a security measure, a trunk internal emergency release lever is built into the trunk latching mechanism. In the WARNING! event of an individual being locked inside the trunk, the Do not allow children to have access to the trunk, trunk can be simply opened by pulling on the glow-in-the- either by climbing into the trunk from outside, or...
Page 45: Occupant Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 • Knee bolsters/blockers for front seat occupants OCCUPANT RESTRAINTS Some of the most important safety features in your • Front seat belts incorporate pretensioners that may vehicle are the restraint systems: enhance occupant protection by managing occupant •...
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you will be carrying children too small for adult-sized WARNING! seat belts, the seat belts or the Lower Anchors and Tether for CHildren (LATCH) feature also can be used to hold Infants in rear facing child restraints should never infant and child restraint systems.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 If a child from 1 to 12 years old (not in a rear facing child 5. If the air bag system in this vehicle needs to be seat) must ride in the front passenger seat, move the seat modified to accommodate a disabled person, contact as far back as possible and use the proper child restraint.
Page 48: Lap/Shoulder Belts
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Buckle up even though you are an excellent driver, even WARNING! (Continued) on short trips. Someone on the road may be a poor driver • Being too close to the steering wheel or instrument and cause an accident that includes you.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 normal conditions. However, in an accident, the belt will WARNING! (Continued) lock and reduce your risk of striking the inside of the • Wearing a seat belt incorrectly is dangerous. Seat vehicle or being thrown out. belts are designed to go around the large bones of your body.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the front seat. 2. The seat belt latch plate is contacting the seat when the belt is routed through the seat web guide. When the belt is routed outside of the seat web guide, the latch plate will contact the quarter trim panel.
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 3. When the belt is long enough to fit, insert the latch WARNING! plate into the buckle until you hear a “click.” • A belt that is buckled into the wrong buckle will not protect you properly.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your WARNING! (Continued) abdomen. To remove slack in the lap belt portion, pull up • A belt that is worn under your arm is dangerous. a bit on the shoulder belt.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 5. Position the shoulder belt on your chest so that it is 6. To release the belt, push the red button on the buckle. comfortable and not resting on your neck. The retractor The belt will automatically retract to its stowed position.
Page 54: Lap/Shoulder Belt Untwisting Procedure
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Untwisting Procedure additional information, refer to “Installing Child Re- Use the following procedure to untwist a twisted lap/ straints Using The Vehicle Seat Belt” under the “Child shoulder belt. Restraints” section. The chart below defines the type of feature for each seating position.
Page 55: Automatic Locking Retractor Mode (Alr) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 out only the amount of webbing necessary to comfort- How To Engage The Automatic Locking Mode ably wrap around the occupant’s mid-section. Slide the 1. Buckle the combination lap and shoulder belt. latch plate into the buckle until you hear a click.
Page 56: Energy Management Feature
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! • The belt and retractor assembly must be replaced • The belt and retractor assembly must be replaced if the seat belt assembly Automatic Locking Re- if the seat belt assembly Automatic Locking Re- tractor (ALR) feature or any other seat belt func- tractor (ALR) feature or any other seat belt func- tion is not working properly when checked ac-...
Page 57: Enhanced Seat Belt Use Reminder System (Beltalert )
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 NOTE: These devices are not a substitute for proper seat Reminder Light and sounding an intermittent chime. belt placement by the occupant. The seat belt still must be Once the sequence starts, it will continue for the entire worn snugly and positioned properly.
Page 58: Seat Belts And Pregnant Women
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE BeltAlert can be enabled or disabled by your authorized Seat Belt Extender dealer. Chrysler Group LLC does not recommend deac- If a seat belt is too short even when fully extended your tivating BeltAlert .
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 Bag is mounted in the center of the steering wheel. The NOTE: These air bags are certified to the new Federal passenger’s Advanced Front Air Bag is mounted in the regulations for Advanced Air Bags. instrument panel, above the glove compartment.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Air Bag Warning Light protection for an occupant during a side impact. The Supplemental Seat-Mounted Side Air Bags are located in • Steering Wheel and Column the outboard side of the front seats. •...
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Advanced Front Air Bag Features WARNING! The Advanced Front Air Bag system has multistage • No objects should be placed over or near the air driver and front passenger air bags. This system provides output appropriate to the severity and type of collision as bag on the instrument panel, because any such determined by the Occupant Restraint Controller (ORC),...
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Do not mount any accessories to the knee bolster such as alarm lights, stereos, citizen band radios, etc. Supplemental Seat-Mounted Side Air Bags (SAB) Supplemental Seat-Mounted Side Air Bags (SAB) may provide enhanced protection to help protect an occupant during a side impact.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 When the air bag deploys, it opens the seam between the front and side of the seat’s trim cover. Each air bag deploys independently; a left side impact deploys the left air bag only and a right-side impact deploys the right air bag only.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: WARNING! • Air Bag covers may not be obvious in the interior trim, • If your vehicle is equipped with left and right but they will open during air bag deployment. Supplemental Side Air Bag Inflatable Curtain •...
Page 65: Air Bag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Along with seat belts and pretensioners, Advanced Front WARNING! (Continued) Air Bags work with the knee bolsters to provide im- • If your vehicle is equipped with SABIC air bags, proved protection for the driver and front passenger. Side do not have any accessory items installed which air bags also work with seat belts to improve occupant will alter the roof, including adding a sunroof to...
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Advanced Front Air Bags are designed to provide addi- Because air bag sensors measure vehicle deceleration tional protection by supplementing the seat belts in over time, vehicle speed and damage by themselves are certain frontal collisions depending on the severity and not good indicators of whether or not an air bag should type of collision.
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Also, the ORC turns on the Air Bag Warning WARNING! Light in the instrument panel for approxi- mately four to eight seconds for a self-check Ignoring the Air Bag Warning Light in your instru- when the ignition is first turned on.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE are possible, based on the collision type and severity. The Based on the severity and type of collision, the side air steering wheel hub trim cover and the upper right side of bag inflator on the crash side of the vehicle may be the instrument panel separate and fold out of the way as triggered, releasing a quantity of non-toxic gas.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 A quantity of non-toxic gas is generated to inflate the side Enhanced Accident Response System curtain air bag. The inflating side curtain air bag pushes In the event of an impact causing air bag deployment, if the outside edge of the headliner out of the way and the communication network remains intact, and the covers the window.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Front and/or side air bags will not deploy in all bag inflation. These airborne particles may irritate the collisions. This does not mean something is wrong with skin, eyes, nose, or throat. If you have skin or eye the air bag system.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Maintaining Your Air Bag System WARNING! (Continued) • Do not attempt to modify any part of your air bag WARNING! system. The air bag may inflate accidentally or • Modifications to any part of the air bag system may not function properly if modifications are could cause it to fail when you need it.
Page 72: Event Data Recorder (Edr)
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light NOTE: If the speedometer, tachometer, or any engine You will want to have the air bags ready to related gauges are not working, the Occupant Restraint inflate for your protection in a collision. The Controller (ORC) may also be disabled.
Page 73: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 • How various systems in your vehicle were operating; To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. • Whether or not the driver and passenger safety belts In addition to the vehicle manufacturer, other parties, were buckled/fastened;...
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Child Restraints WARNING! Safety experts recommend that children ride rearward- facing in the vehicle until they are two years old or until In a collision, an unrestrained child, even a tiny baby, they reach either the height or weight limit of their rear can become a projectile inside the vehicle.
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 held in the vehicle by the lap/shoulder belt or the have outgrown the rear-facing weight or height limit of LATCH child restraint anchor system. Refer to “Lower their rear-facing convertible child seat. Children should Anchors and Tether for CHildren (LATCH)”.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children Too Large For Booster Seats NOTE: additional information, refer Children who are large enough to wear the shoulder belt www.seatcheck.org or call 1–866–SEATCHECK. Canadian comfortably and whose legs are long enough to bend residents should refer to Transport Canada’s website for over the front of the seat when their back is against the additional information: http://www.tc.gc.ca/roadsafety/...
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Here are some tips on getting the most out of your child WARNING! restraint: When your child restraint is not in use, secure it in • Before buying any restraint system, make sure that it the vehicle with the seat belt or remove it from the has a label certifying that it meets all applicable Safety vehicle.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH-compatible child restraint systems are now avail- anchorage. If installing child seats in adjacent rear- able. However, because the lower anchorages are to be seating positions, or if your child restraints are not introduced over a period of years, child restraint systems LATCH-compatible, install the restraints using the vehi- having attachments for those anchorages will continue to...
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 Installing The LATCH-Compatible Child Restraint In addition, there are tether strap anchorages System behind each rear seating position located in the We urge you to follow the manufacturer’s directions panel between the rear seatback and the rear carefully when installing your child restraint.
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • When using the LATCH attaching system to install a You will first loosen the child seat adjusters on the lower straps and on the tether strap so that you can more easily child restraint, please ensure that all seat belts not attach the hooks or connectors to the vehicle anchorages.
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 then allow the belt to retract into the retractor. For WARNING! additional information on ALR, refer to “Automatic Locking Mode”. Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or Driver Center Passenger...
Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the lap portion around the child restraint. Any seat belt system will loosen with time, so check the belt occasion- ally, and pull it tight if necessary. To attach a child restraint tether strap: 1.
Page 83: Engine Break-In Recommendations
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 3. Attach the tether strap hook (A) of the child restraint to Transporting Pets the anchor (B) and remove slack in the tether strap Air Bags deploying in the front seat could harm your pet. according to the child restraint manufacturer’s instruc- An unrestrained pet will be thrown about and possibly tions.
Page 84: Safety Tips
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE While cruising, brief full-throttle acceleration within the NOTE: A new engine may consume some oil during its limits of local traffic laws contributes to a good break-in. first few thousand miles (kilometers) of operation. This However, wide-open throttle acceleration in low gear can should be considered a normal part of the break-in and be detrimental and should be avoided.
Page 85: Exhaust Gas
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 Exhaust Gas WARNING! (Continued) • It is extremely dangerous to ride in a cargo area, WARNING! inside or outside of a vehicle. In a collision, people Exhaust gases can injure or kill. They contain carbon riding in these areas are more likely to be seri- monoxide (CO), which is colorless and odorless.
Page 86: Safety Checks You Should Make Inside The Vehicle
84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE inspect the exhaust system each time the vehicle is raised WARNING! (Continued) for lubrication or oil change. Replace as required. • If it is necessary to sit in a parked vehicle with the Safety Checks You Should Make Inside The engine running, adjust your heating or cooling Vehicle...
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 Air Bag Warning Light Floor Mat Safety Information The light should come on and remain on for four to eight Always use floor mats designed to fit the footwell of your seconds as a bulb check when the ignition switch is first vehicle.
Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • Never place or install floor mats or other floor • Always make sure that objects cannot fall into the coverings in the vehicle that cannot be properly driver footwell while the vehicle is moving.
Page 89: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 Periodic Safety Checks You Should Make Outside Door Latches The Vehicle Check for positive closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 91 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ “Slide-On-Rod” And Extender Features Of Mirrors ......93 Sun Visor .
Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Command — If Equipped ... 128 Lights ......146 ▫...
Page 93 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 ▫ Flash-To-Pass ..... . . 151 ▫ To Deactivate ..... . . 157 ▫...
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Security ......167 ▫ Wind Buffeting ..... . 171 ▫...
Page 95: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 MIRRORS Inside Day/Night Mirror — If Equipped A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 96: Automatic Dimming Mirror - If Equipped
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light to the left of the button will illuminate to indicate when the dimming feature is activated.
Page 97: Outside Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Outside Mirrors Outside Mirrors Folding Feature To receive maximum benefit, adjust the outside mirror(s) The mirrors are equipped with a rotational hinge. The to center on the adjacent lane of traffic and a slight mirrors have one detent (clockwise) towards the rear of overlap of the view obtained from the inside mirror.
Page 98: Power Mirrors
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors The power mirror controls are located on the driver’s door trim panel. To adjust a mirror, turn the control wand toward the left or right mirror positions indicated. Tilt the control wand in the direction you want the mirror to move.
Page 99: Heated Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 Heated Mirrors — If Equipped These mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the rear window defroster. Refer to “Rear Window Features” in “Understanding The Features Of Your Vehicle” for fur- ther information.
Page 100: Slide-On-Rod" And Extender Features Of Sun Visor
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE “Slide-On-Rod” And Extender Features Of Sun Visor To use the “Slide-On-Rod” feature of the sun visor, rotate the sun visor downward and swing the sun visor so it is parallel to the side window, grabbing the sun visor with your left hand pull rearwards until the sun visor is in the desired position.
Page 101: Uconnect™ Phone - If Equipped
For Uconnect™ customer support, visit the following long as your phone is turned on and has been paired to websites: the vehicle’s Uconnect™ Phone. The Uconnect™ Phone • www.chrysler.com/uconnect allows up to seven mobile phones to be linked to the • www.dodge.com/uconnect...
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE system. Only one linked (or paired) mobile phone can be Voice Command Button used with the system at a time. The system is available in Actual button location may vary with the ra- English, Spanish, or French languages.
Page 103: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 Operation example, you can use the compound form voice Voice commands can be used to operate the Uconnect™ command “Phonebook New Entry”, or you can break Phone and to navigate through the Uconnect™ Phone the compound form command into two voice com- menu structure.
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, after the beep, say “Pair a Device” Cancel Command At any prompt, after the beep, you can say “Cancel” and and follow the audible prompts. you will be returned to the main menu. However, in a •...
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 • The Uconnect™ Phone will confirm the phone number phone to use if multiple mobile phones are in the vehicle at the same time. For example, if priority three and then dial. The number will appear in the display and priority five phones are present in the vehicle, the of certain radios.
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ system will confirm the name and • When prompted, enter the number designation (e.g., then dial the corresponding phone number, which “Home”, “Work”, “Mobile”, or “Other”). This will may appear in the display of certain radios. allow you to store multiple numbers for each phone- book entry, if desired.
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 • Depending on the maximum number of entries down- Phonebook Download – Automatic Phonebook Transfer From Mobile Phone loaded, there may be a short delay before the latest If equipped and specifically supported by your phone, downloaded names can be used.
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Edit Uconnect™ Phonebook Entries After you are finished editing an entry in the phonebook, you will be given the opportunity to edit another entry in NOTE: the phonebook, call the number you just edited, or return •...
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 • After you enter the Phonebook Delete menu, you will Delete/Erase “All” Uconnect™ Phonebook Entries then be asked for the name of the entry that you wish • Press the button to begin. to delete.
Page 110: Phone Call Features
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say mobile service plan. For example, if your mobile service “Phonebook List Names”. plan provides three-way calling, this feature can be accessed through the Uconnect™ Phone. Check with •...
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 mobile phone. Press the button to place the current Place/Retrieve A Call From Hold call on hold and answer the incoming call. To put a call on hold, press the button until you hear a single beep.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say Three-Way Calling To initiate three-way calling, press the button while “Redial”. a call is in progress, and make a second phone call, as •...
Page 113: Uconnect™ Phone Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 • After the ignition key is switched to OFF, a call can After selecting one of the languages, all prompts and continue on the Uconnect™ Phone for a certain dura- voice commands will be in that language. tion, after which the call is automatically transferred NOTE: After every Uconnect™...
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say WARNING! “Emergency” and the Uconnect™ Phone will instruct the paired mobile phone to call the emergency num- To use your Uconnect™ Phone System in an emer- ber.
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Mexico City in Mexico). Please refer to the 24-Hour Working With Automated Systems “Towing Assistance” coverage details on the DVD in This method is used in instances where one generally has the Warranty Information Booklet and the 24-Hour to press numbers on the mobile phone keypad while Towing Assistance references.
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE is also to be used for navigating through an automated Barge In — Overriding Prompts customer service center menu structure, and to leave a The “Voice Command” button can be used when you number on a pager.
Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 Phone And Network Status Indicators NOTE: Certain brands of mobile phones do not send the If available on the radio and/or on a premium display dial ring to the Uconnect™ Phone to play it on the vehicle such as the instrument panel cluster, and supported by audio system, so you will not hear it.
Page 118: Advanced Phone Connectivity
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Following the beep, say “Mute off”. Uconnect™ Phone System, follow the instructions de- scribed in your mobile phone User’s Manual. Advanced Phone Connectivity List Paired Mobile Phone Names Transfer Call To And From Mobile Phone •...
Page 119: Things You Should Know About Your Uconnect™ Phone
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 • After the “Ready” prompt and the following beep, say Select Another Mobile Phone This feature allows you to select and start using another “Setup Phone Pairing”. phone paired with the Uconnect™ Phone. •...
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Voice Training feature may be used. To enter this This procedure may be repeated with a new user. The training mode, follow one of the two following proce- system will adapt to the last trained voice only. dures: Reset From outside the Uconnect™...
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 • Speak normally, without pausing, just as you would • When navigating through an automated system such speak to a person sitting a few feet/meters away from as voice mail, or when sending a page, at the end of you.
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • In a convertible vehicle, system performance may be • Echo at the phone far end can sometimes be reduced compromised with the convertible top down. by lowering the in-vehicle audio volume. • In a convertible vehicle, system performance may be Far End Audio Performance compromised with the convertible top down.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 • After the “Ready” prompt and the following beep, say Uconnect™ Phone will prompt you to say the name or “SMS Read” or “Read Messages.” number of the person you wish to send the message to. •...
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Press the 11. See You in 15 minutes button. • After the “Ready” prompt and the following beep, say 12. I am on my way “Setup, SMS Incoming Message Announcement,” you 13. I’ll be late will then be given a choice to change it.
Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123...
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125...
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...
Page 130: General Information
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information NOTE: Take care to speak into the Voice Interface This device complies with Part 15 of the FCC rules and System as calmly and normally as possible. The ability of RSS 210 of Industry Canada. Operation is subject to the the Voice Interface System to recognize user voice com- following conditions: mands may be negatively affected by rapid speaking or a...
Page 131: Commands
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 NOTE: If you do not say a command within a few When using this system, you should speak clearly and at seconds, the system will present you with a list of a normal speaking volume. options.
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Memo” (to switch to the memo recorder) Changing the Volume • “Setup” (to switch to system setup) 1. Start a dialogue by pressing the Voice Command button. Radio AM 2. Say a command (e.g., “Help”). To switch to the AM band, say “AM”...
Page 133 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 • “Next Station” (to select the next station) • “Select Name” (to say the name of a channel) • “Previous Station” (to select the previous station) • “Menu Radio” (to switch to the radio menu) •...
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Memo − “Previous” (to play the previous memo) To switch to the voice recorder mode, say “Memo”. In − “Delete” (to delete a memo) this mode, you may say the following commands: • “Delete All” (to delete all memos) •...
Page 135: Voice Training
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 • “Language Spanish” 2. Repeat the words and phrases when prompted by Uconnect™ Voice. For best results, the “Voice Training” • “Tutorial” session should be completed when the vehicle is parked, • “Voice Training” engine running, all windows closed, and the blower fan switched off.
Page 136: Power Seats
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Adjusting The Seat Up Or Down Push the switch rearward to decrease the lumbar sup- The height of the seats can be adjusted up or down. Pull port. Pushing upward or downward on the switch will upward or push downward on the seat switch, the seat raise and lower the position of the support.
Page 138: Heated Seats
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! CAUTION! • Adjusting a seat while driving may be dangerous. Do not place any article under a power seat or Moving a seat while driving could result in loss of impede its ability to move as it may cause damage to control which could cause a collision and serious the seat controls.
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 You can choose from HIGH, LOW or OFF heat settings. WARNING! Amber indicator lights in each switch indicate the level of • Persons who are unable to feel pain to the skin heat in use. Two indicator lights will illuminate for HIGH, one for LOW and none for OFF.
Page 140: Manual Forward Or Rearward Adjustment
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Forward Or Rearward Adjustment Manual Front Seatback Recline The adjusting bar is at the front of the seat, near the floor. To adjust the seatback, lift the lever located on the Pull the bar upward to move the seat forward or rear- outboard side of the seat, lean back to the desired ward.
Page 141: Passenger Seat Easy Entry
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death. Passenger Seat Easy Entry On the passenger seat, pull forward on the lever located on the side of the seatback in order to dump the seatback...
Page 142: Head Restraints
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Head Restraints Active Head Restraints — Front Seats The front driver and passenger seats are equipped with Head restraints are designed to reduce the risk of injury Active Head Restraints (AHR). In the event of a rear by restricting head movement in the event of a rear impact the AHRs will automatically extend forward impact.
Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 To raise the head restraint, pull upward on the head NOTE: The head restraints should only be removed by restraint. To lower the head restraint, press the push qualified technicians, for service purposes only. If either button, located at the base of the head restraint, and push of the head restraints require removal, see your autho- downward on the head restraint.
Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Head Restraints The center rear head restraint has two positions, up or down. When the seat is being occupied the head restraint should raised. When there are no occupants in the center seat position the head restraint can be lowered for maximum visibility for the driver.
Page 145: Folding Rear Seat
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 Folding Rear Seat The rear seatbacks can be folded forward to provide an additional storage area. Pull on the loops located on the upper part of the rear seatback to fold down either or both seatbacks.
Page 146: To Open And Close The Hood
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD WARNING! Two latches must be released to open the hood. • Be certain that the seatback is securely locked into 1. Pull the hood release lever located under the left side position.
Page 147 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 2. Move to the outside of the vehicle and push the safety CAUTION! catch to the left. The safety catch is located under the center front edge of the hood. To prevent possible damage, do not slam the hood to close it.
Page 148: Lights
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlights And Parking Lights The headlight switch is located on the left side of the instrument panel. This switch controls the operation of the headlights, parking lights, instrument panel lights, instrument panel light dimming, interior lights and fog lights.
Page 149: Automatic Headlights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Automatic Headlights — If Equipped addition, the headlights will turn off when the wipers are This system automatically turns the headlights on or off turned off if they were turned on by this feature. according to ambient light levels.
Page 150: Daytime Running Lights - If Equipped
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you turn the headlights off before the ignition, they will If vehicle is equipped with High Intensity Discharge turn off in the normal manner. Headlights, the front turn signal lamps provide the Daytime Running Lamp (DRL) function.
Page 151: Lights-On Reminder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 Lights-On Reminder If the headlights or parking lights are on after the ignition is in the OFF position, a chime will sound to alert the driver when the driver’s door is opened. Fog Lights — If Equipped The front fog light switch is built into the head- light switch.
Page 152: Multifunction Lever
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Multifunction Lever Turn Signals The multifunction lever controls the operation of the turn Move the multifunction lever up or down and the arrows signals, headlight beam selection, and passing lights. The on each side of the instrument cluster flash to show multifunction lever is located on the left side of the proper operation of the front and rear turn signal lights.
Page 153: High/Low Beam Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 High/Low Beam Switch transmitter is pressed, or when the dimmer control is Push the multifunction lever away from you to switch turned fully upward, past the second detent. the headlights to high beam. Pull the multifunction lever toward you to switch the headlights back to low beam.
Page 154: Windshield Wipers And Washers
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the OFF position. This will occur if the interior lights Interior Light Defeat (OFF) were switched on manually or are on because a door is Rotate the dimmer control to the extreme bottom off open.
Page 155: Intermittent Wiper System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 CAUTION! Turn the windshield wipers off when driving through an automatic car wash. Damage to the wind- shield wipers may result if the wiper switch is left in any position other than off. Intermittent Wiper System Use the intermittent wiper when weather conditions make a single wiping cycle with a variable pause be-...
Page 156: Mist Feature
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mist Feature three wipe cycles after releasing the multifunction lever Rotate the end of the lever downward to the Mist and then resume the intermittent interval previously position to activate a single wipe cycle to clear off road selected.
Page 157: Headlights On With Wipers (Available With Automatic Headlights Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 Headlights On With Wipers (Available With Automatic Headlights Only) When this feature is active, the headlights will turn on approximately 10 seconds after the wipers are turned on if the headlight switch is placed in the A (AUTO) position. In addition, the headlights will turn off when the wipers are turned off if they were turned on by this feature.
Page 158: Electronic Speed Control - If Equipped
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE wheel outward or push it inward as desired. To lock the steering column in position, push the lever upward until fully engaged. WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle.
Page 159: To Activate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 System can be reactivated by pushing the Electronic To Set A Desired Speed Speed Control ON/OFF button and resetting the desired Turn the Electronic Speed Control ON. When the vehicle vehicle set speed. has reached the desired speed, press the SET (-) button and release.
Page 160: To Resume Speed
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Resume Speed decrease until the button is released. Release the button To resume a previously set speed, push the RES (+) when the desired speed is reached, and the new set speed button and release.
Page 161: Overhead Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 On steep hills, a greater speed loss or gain may occur so it may be preferable to drive without Electronic Speed Control. WARNING! Electronic Speed Control can be dangerous where the system cannot maintain a constant speed. Your ve- hicle could go too fast for the conditions, and you could lose control and have an accident.
Page 162: Sunglasses Storage
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE These lights also turn on when a door is opened, when The HomeLink buttons that are located in the overhead the UNLOCK button on the Remote Keyless Entry (RKE) console designate the three different HomeLink chan- transmitter is pressed, or when the dimmer control is nels.
Page 163: Before You Begin Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 NOTE: HomeLink is disabled when the Vehicle Secu- position and press and hold the two outside HomeLink rity Alarm is active. buttons (I and III) for up 20 seconds. The Electronic Vehicle Information Center (EVIC) will display “CLEAR- Before You Begin Programming HomeLink ING CHANNELS”.
Page 164: Programming A Rolling Code
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming A Rolling Code For programming garage door openers that were manu- factured after 1995. These garage door openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener.
Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 1. Turn the ignition switch to the ON/RUN position. 5. At the garage door opener motor (in the garage), locate the “LEARN” or “TRAINING” button. This can 2. Place the hand-held transmitter 1 to 3 inches (3 to usually be found where the hanging antenna wire is 8 cm) away from the HomeLink button you wish to attached to the garage door opener/device motor.
Page 166: Programming A Non-Rolling Code
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To program the remaining two HomeLink buttons, 1. Turn the ignition switch to the ON/RUN position. repeat each step for each remaining button. DO NOT 2. Place the hand-held transmitter 1 to 3 inches (3 to erase the channels.
Page 167: Canadian/Gate Operator Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 5. Press and hold the programmed HomeLink button. Canadian/Gate Operator Programming The EVIC will display “CHANNEL # TRANSMIT”. If the For programming transmitters in Canada/United States garage door opener/device activates, programming is that require the transmitter signals to “time-out” after complete.
Page 168: Using Homelink
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Simultaneously press and hold both the Homelink Reprogramming A Single HomeLink Button button while you press and release (“cycle”), your hand- To reprogram a channel that has been previously trained, held transmitter every two seconds. follow these steps: 4.
Page 169: Security
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Security Troubleshooting Tips It is advised to erase all channels before you sell or turn If you are having trouble programming HomeLink , here in your vehicle. are some of the most common solutions: •...
Page 170: General Information
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information WARNING! This device complies with FCC rules Part 15 and Industry • Your motorized door or gate will open and close Canada RSS-210. Operation is subject to the following while you are programming the universal trans- two conditions: ceiver.
Page 171: Power Sunroof - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 POWER SUNROOF — IF EQUIPPED WARNING! The power sunroof switch is located between the sun • Never leave children in a vehicle with the key in visors on the overhead console. the ignition switch (or with the ignition in the Accessory or Run position, for vehicles equipped with Keyless Enter-N-Go).
Page 172: Opening Sunroof - Express Mode
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE will close fully and stop automatically. This is called WARNING! (Continued) “Express Close”. During “Express Close” operation, any • Do not allow small children to operate the sun- movement of the switch will stop the sunroof. roof.
Page 173: Pinch Protect Override
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Pinch Protect Override NOTE: The sunshade cannot be closed if the sunroof is If a known obstruction (ice, debris, etc.) prevents closing open. the sunroof, press the switch forward and hold for two Wind Buffeting seconds after the reversal occurs.
Page 174: Ignition Off Operation
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ignition Off Operation CAUTION! The power sunroof switches remain active for up to • Do not exceed the maximum power of 160 Watts approximately ten minutes after the ignition switch has been turned OFF. Opening either front door will cancel (13 Amps) at 12 Volts.
Page 175 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 The center console power outlet is powered directly from the battery (power available at all times). Front Power Outlet Center Console Power Outlet...
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Items plugged into this power outlet may discharge the WARNING! battery and/or prevent the engine from starting. To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet.
Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 CAUTION! CAUTION! (Continued) • After the use of high power draw accessories or • Many accessories that can be plugged in draw long periods of the vehicle not being started (with power from the vehicle’s battery even when not in accessories still plugged in), the vehicle must be use (i.e., cellular phones, etc.).
Page 178: Cupholders
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Illuminated Front Cupholders — If Equipped The front cupholders are illuminated with LEDs. They Front Cupholders are turned on with the headlights or parking lights. Refer The front cupholders are located in the center console. to “Lights”...
Page 179: Console Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 CONSOLE FEATURES Sliding Center Console Armrest The center console armrest slides forward with three detents to provide flexibility for comfort, cupholder use and shifting ease. Rear Cupholders Sliding Console Armrest...
Page 180: Console Storage
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Console Storage The center console has a storage compartment located underneath the armrest, and also contains a 12 Volt power outlet, a molded-in coin holder (designed to hold various size coins). The center console may also be equipped with a Universal Consumer Interface (UCI).
Page 181: Rear Window Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 NOTE: To prevent excessive battery drain, use the rear WARNING! window defroster only when the engine is operating. Do not operate this vehicle with a console compart- CAUTION! ment lid in the open position. Cellular phones, music players, and other handheld electronic devices Failure to follow these cautions can cause damage to should be stowed while driving.
Page 183 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Keyless Enter-N-Go Display Instrument Panel Features ....184 — If Equipped ..... . 204 Instrument Cluster .
Page 184 182 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Operating Instructions — Radio Mode ..222 Media Center 730N/430/430N (RHR/RER/ RBZ/RHB) CD/DVD/HDD/NAV — If ▫ Operation Instructions — CD Mode For CD Equipped ......212 And MP3 Audio Play .
Page 185 UNDERSTANDING YOUR INSTRUMENT PANEL 183 ▫ Play Mode ......240 CD/DVD Disc Maintenance ....247 ▫...
Page 186: Instrument Panel Features
184 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlets 6 — ESC OFF Switch 11 — Ignition Switch 2 — Instrument Cluster 7 — Sport Button 12 — Trunk Release Button 3 — Glove Compartment 8 — Hazard Warning Switch 13 —...
Page 187: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 185 INSTRUMENT CLUSTER...
Page 188: Instrument Cluster Descriptions
186 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 4. Electronic Speed Control Indicator Light This light will turn on when the electronic 1. Fuel Gauge speed control is on. The pointer shows the level of fuel in the fuel tank when the ignition switch is placed in the ON/RUN position.
Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL 187 it means that the charging system is experiencing a If the light is flashing when the engine is running, problem. See your local authorized dealer to obtain immediate service is required. In this case, you may service immediately.
Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL 9. Turn Signal Indicators CAUTION! The arrow will flash with the exterior turn signal when the turn signal lever is operated. Driving with a hot engine cooling system could damage your vehicle. If the temperature gauge reads NOTE: “H,”...
Page 191 UNDERSTANDING YOUR INSTRUMENT PANEL 189 11. Engine Temperature Warning Light cycles, and the vehicle has been driven several miles This light will turn on and a single chime will (kilometers) at speeds greater than 30 mph (48 km/h), see sound to warn of an overheated engine condition. your authorized dealer as soon as possible to have the When this light turns on, the engine temperature problem diagnosed and corrected.
Page 192 190 UNDERSTANDING YOUR INSTRUMENT PANEL 13. Electronic Stability Control (ESC) OFF Indicator 15. High Beam Indicator Light — If Equipped This indicator will turn on when the high beam This light indicates the Electronic Stability Con- headlights are on. Push the multifunction lever trol (ESC) is off.
Page 193 UNDERSTANDING YOUR INSTRUMENT PANEL 191 17. Shift Lever Indicator — Automatic Transmission the repair technician should leave the odometer reading Only the same as it was before the repair or service. If s/he The Shift Lever Indicator is self-contained within the cannot do so, then the odometer must be set at zero, and instrument cluster.
Page 194 192 UNDERSTANDING YOUR INSTRUMENT PANEL If the light remains on when the parking brake has been If brake failure is indicated, immediate repair is neces- disengaged, and the fluid level is at the full mark on the sary. master cylinder reservoir, it indicates a possible brake WARNING! hydraulic system malfunction.
Page 195 UNDERSTANDING YOUR INSTRUMENT PANEL 193 unless the parking brake is applied or a brake fault is by the vehicle manufacturer on the vehicle placard or tire detected. If the light does not illuminate, have the light inflation pressure label. (If your vehicle has tires of a inspected by an authorized dealer.
Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL maintain correct tire pressure, even if under-inflation has tires or wheels on your vehicle, to ensure that the not reached the level to trigger illumination of the TPMS replacement or alternate tires and wheels allow the TPMS low tire pressure telltale.
Page 197 UNDERSTANDING YOUR INSTRUMENT PANEL 195 23. Anti-Lock Brake (ABS) Light 25. Malfunction Indicator Light (MIL) This light monitors the Anti-Lock Brake System The Malfunction Indicator Light (MIL) is part of (ABS). The light will turn on when the ignition an onboard diagnostic system called OBD. The switch is placed in the ON/RUN position and may stay OBD system monitors engine and automatic on for as long as four seconds.
Page 198: Electronic Vehicle Information Center (Evic)
196 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER CAUTION! (EVIC) The Electronic Vehicle Information Center (EVIC) fea- Prolonged driving with the MIL on could cause tures a driver-interactive display which is located in the damage to the engine control system. It also could instrument cluster.
Page 199 UNDERSTANDING YOUR INSTRUMENT PANEL 197 • Surround Sound Modes (if equipped with Driver- This system conveniently allows the driver to select a variety of useful information by pressing the switches Selectable Surround [DSS]) mounted on the steering wheel. The EVIC consists of the The system allows the driver to select information by following: pressing the following buttons mounted on the steering...
Page 200: Electronic Vehicle Information Center (Evic) Displays
198 UNDERSTANDING YOUR INSTRUMENT PANEL MENU Button SELECT Button Press and release the MENU button to access Press and release the SELECT button for access the main menu, or to return to the main menu to main menus, sub-menus or to select a per- from the sub-menus.
Page 201 UNDERSTANDING YOUR INSTRUMENT PANEL 199 • Right Rear Turn Signal Lamp Out (with a single • Did Not Train chime) • Low Tire Pressure (with a single chime) • Personal Settings Not Available – Vehicle Not in PARK • Service TPM System (with a single chime) •...
Page 202: Engine Oil Change Indicator System
200 UNDERSTANDING YOUR INSTRUMENT PANEL • Press Brake & Push Button to Start position or cycle the ignition to the ON/RUN position if equipped with Keyless Enter-N-Go. To turn off the • Push Button or Insert Key/Turn To Run (refer to message temporarily, press and release the MENU but- “Remote Starting System”...
Page 203: Trip Functions
UNDERSTANDING YOUR INSTRUMENT PANEL 201 • Trip B Vehicles Not Equipped With Keyless Enter-N-Go • Elapsed Time 1. Turn the ignition switch to the ON/RUN position (Do not start the engine.) • Display Units of Measure in 2. Fully depress the accelerator pedal, slowly, three times Press the UP or DOWN buttons to cycle through all the within 10 seconds.
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL The FUEL SAVER MODE message will display above the This feature allows you to monitor when you are driving average fuel economy in the EVIC display. This message in a fuel efficient manner, and it can be used to modify will appear whenever the Multi-Displacement System driving habits in order to increase fuel economy.
Page 205 UNDERSTANDING YOUR INSTRUMENT PANEL 203 • Distance To Empty (DTE) • Trip A Shows the estimated distance that can be traveled with the Shows the total distance traveled for Trip A since the last fuel remaining in the tank. This estimated distance is reset.
Page 206: Sport Mode
204 UNDERSTANDING YOUR INSTRUMENT PANEL To Reset The Display Reset will only occur while a resettable function is being displayed. Press and release the SELECT button once to clear the resettable function being displayed. To reset all resettable functions, press and release the SELECT button a second time within three seconds of resetting the currently-displayed function.
Page 207: Driver-Selectable Surround Sound (Dss) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 205 Refer to “Keyless Enter-N-Go” in “Starting And Operat- Compass Display ing” for more information. The compass readings indicate the direction the vehicle is facing. Press and release the NOTE: Under certain conditions, the display may be MENU button until “Compass”...
Page 208 206 UNDERSTANDING YOUR INSTRUMENT PANEL degree turns (in an area free from large metal or metallic 5. Slowly complete one or more 360-degree turns (in an objects) until the “CAL” message displayed in the EVIC area free from large metal or metallic objects) until the turns off.
Page 209: System Warnings (Customer Information Features)
UNDERSTANDING YOUR INSTRUMENT PANEL 207 3. Press the UP or DOWN button until “COMPASS VARIANCE” message and the last variance zone number displays in the EVIC. 4. Press and release the SELECT button until the proper variance zone is selected according to the map. 5.
Page 210: Personal Settings (Customer-Programmable Features)
208 UNDERSTANDING YOUR INSTRUMENT PANEL • Oil Pressure SELECT button while in this display to select English, Shows the actual oil pressure. Espanol, or Francais. Then, as you continue, the informa- tion will display in the selected language. • Tire Pressure Shows the actual tire pressure for each tire (EXCLUDING NOTE: The EVIC will not change the Uconnect™...
Page 211 UNDERSTANDING YOUR INSTRUMENT PANEL 209 the doors will unlock on the first press of the RKE Remote Start Comfort Sys. transmitter UNLOCK button. To make your selection, When this feature is selected and the remote start is press and release the SELECT button until “Driver Door activated, the heated steering wheel and driver heated 1st Press”...
Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL Flash Lights with Remote Key Lock NOTE: Turning the headlights on during the daytime When ON is selected, the front and rear turn signals will causes the instrument panel lights to dim. To increase the flash when the doors are locked or unlocked with the brightness, refer to “Lights”...
Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 Turn Headlights On with Remote Key Unlock Turn-by-Turn Navigation — If Equipped When this feature is selected, the headlights will activate When ON is selected, the Turn-by-Turn directions will and remain on for up to 90 seconds when the doors are appear in the display as the vehicle approaches a desig- unlocked with the RKE transmitter.
Page 214: Media Center 730N/430/430N
212 UNDERSTANDING YOUR INSTRUMENT PANEL been deactivated. Refer to “Keyless Enter-N-Go” in measure. To make your selection, press and release the “Things To Know Before Starting Your Vehicle”. SELECT button until “ENGLISH” or “METRIC” appears. Enable/Disable the Rear Park Assist System MEDIA CENTER 730N/430/430N (RHR/RER/RBZ/ The Rear Park Assist system will scan for objects behind RHB) CD/DVD/HDD/NAV —...
Page 215: Media Center 130 (Sales Code Res)
UNDERSTANDING YOUR INSTRUMENT PANEL 213 MEDIA CENTER 130 (SALES CODE RES) Operating Instructions — Radio Mode NOTE: The radio sales code is located on the lower right NOTE: The ignition switch must be in the ON or ACC side of the radio faceplate. position to operate the radio.
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons 4. Adjust the minutes using the right side TUNE/ Press and release the SEEK buttons to search for the next SCROLL control knob. Press the TUNE/SCROLL control listenable station in AM/FM mode. Press the right switch knob to save time change.
Page 217 UNDERSTANDING YOUR INSTRUMENT PANEL 215 Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the AM/FM Button mid-range tones.
Page 218: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
216 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second station to each pushbutton by Operation Instructions — CD MODE For CD And repeating the above procedure with this exception: Press MP3 Audio Play the SET/RND button twice and SET 2 will show in the NOTE: display window.
Page 219 UNDERSTANDING YOUR INSTRUMENT PANEL 217 If you insert a disc with the ignition ON and the radio EJECT Button - Ejecting a CD ON, the unit will switch from radio to CD mode and Press the EJECT button to eject the CD. begin to play when you insert the disc.
Page 220: Notes On Playing Mp3 Files
218 UNDERSTANDING YOUR INSTRUMENT PANEL the current selection. Pressing and holding the SEEK SET/RND Button (Random Play Button) button will allow faster scrolling through the tracks in Press this button while the CD is playing to activate CD and MP3 modes. Random Play.
Page 221 UNDERSTANDING YOUR INSTRUMENT PANEL 219 Supported Media (Disc Types) a number instead. With a maximum number of files, The MP3 file recording media supported by the radio are exceeding 20 folders will result in this display. With CDDA, CD-R, CD-RW, MP3, and CDDA+MP3. 200 files, exceeding 50 folders will result in this display.) Supported Medium Formats (File Systems)
Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats MPEG Specifi- Sampling Fre- Bit Rate (kbps) The radio will recognize only files with the *.MP3 exten- cation quency (kHz) sion as MP3 files. Non-MP3 files named with the *.MP3 160, 128, 144, extension may cause playback problems.
Page 223: Operation Instructions - Auxiliary Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 221 Loading times for playback of MP3 files may be affected Operation Instructions - Auxiliary Mode by the following: The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device, such as an •...
Page 224: Media Center 130 With Satellite Radio (Sales Code Res+Rsc)
222 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 130 WITH SATELLITE RADIO Operating Instructions — Radio Mode (SALES CODE RES+RSC) NOTE: The ignition switch must be in the ON or ACC NOTE: The radio sales code is located on the lower right position to operate the radio.
Page 225 UNDERSTANDING YOUR INSTRUMENT PANEL 223 to seek up and the left switch to seek down. The radio Phone Button Uconnect™ Phone — If Equipped will remain tuned to the new station until you make Press this button to operate the Uconnect™ Phone feature another selection.
Page 226 224 UNDERSTANDING YOUR INSTRUMENT PANEL 3. After adjusting the hours, press the right side TUNE/ INFO Button SCROLL control knob to set the minutes. The minutes Press the INFO button for an RDS station (one with call will begin to blink. letters displayed).
Page 227 UNDERSTANDING YOUR INSTRUMENT PANEL 225 Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the MUSIC TYPE Button mid-range tones.
Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL 16-Digit Character Dis- 16-Digit Character Dis- Program Type Program Type play play Classic Rock Cls Rock Soft Soft College College Soft Rock Soft Rck Country Country Soft Rhythm and Blues Soft R&B Foreign Language Language Sports Sports Information...
Page 229 UNDERSTANDING YOUR INSTRUMENT PANEL 227 SETUP Button window. Select the button (1–6) you wish to lock onto this Pressing the SETUP button allows you to select between station and press and release that button. If a button is the following items: not selected within five seconds after pressing the SET/ RND button, the station will continue to play but will not •...
Page 230: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
228 UNDERSTANDING YOUR INSTRUMENT PANEL Buttons 1 - 6 Inserting Compact Disc(s) These buttons tune the radio to the stations that you Gently insert one CD into the CD player with the CD commit to pushbutton memory (12 AM and 12 FM label facing up.
Page 231 UNDERSTANDING YOUR INSTRUMENT PANEL 229 SEEK Button CAUTION! (Continued) Press the right SEEK button for the next selection on the • Do not use adhesive labels. These labels can peel CD. Press the left SEEK button to return to the beginning away and jam the player mechanism.
Page 232: Notes On Playing Mp3 Files
230 UNDERSTANDING YOUR INSTRUMENT PANEL SET/RND Button (Random Play Button) Supported Medium Formats (File Systems) Press this button while the CD is playing to activate The medium formats supported by the radio are ISO 9660 Random Play. This feature plays the selections on the Level 1 and Level 2 and includes the Joliet extension.
Page 233 UNDERSTANDING YOUR INSTRUMENT PANEL 231 • Maximum number of characters in file/folder names: When using the MP3 encoder to compress audio data to an MP3 file, the bit rate and sampling frequencies in the • Level 1: 12 (including a separator . and a three- following table are supported.
Page 234: List Button (Cd Mode For Mp3 Play)
232 UNDERSTANDING YOUR INSTRUMENT PANEL Playlist files are not supported. MP3 Pro files are not To increase the speed of disc loading, it is recommended supported. to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option Playback of MP3 Files before writing to the disc.
Page 235: Uconnect™ Multimedia (Satellite Radio) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 233 Press the INFO button once more to return to elapsed is not loud enough, turn the device’s volume up. If the time priority mode. AUX audio sounds distorted, turn the device’s volume down. Press and hold the INFO button for three seconds or more and the radio will display song titles for each file.
Page 236 234 UNDERSTANDING YOUR INSTRUMENT PANEL System Activation To access the ESN/SID, refer to the following steps: Sirius Satellite Radio service is pre-activated, and you ESN/SID Access may begin listening immediately to the one year of audio With the ignition switch in the ON/RUN or ACC posi- service that is included with the factory-installed satellite tion and the radio on, press the SETUP button and scroll radio system in your vehicle.
Page 237 UNDERSTANDING YOUR INSTRUMENT PANEL 235 bikes should be placed as far rearward as possible, within Operating Instructions - Uconnect™ Multimedia the loading design of the rack. Do not place items directly (Satellite) Mode on or above the antenna. NOTE: The ignition switch must be in the ON/RUN or Reception Quality ACC position to operate the radio.
Page 238 236 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button Toggle the MUSIC TYPE button again to select the music Pressing the INFO button will cycle the display information type. between Artist, Song Title, and Composer (if available). By pressing the SEEK button when the Music Type Also, pressing and holding the INFO button for an addi- function is active, the radio will be tuned to the next tional three seconds will make the radio display the Song...
Page 239: Ipod /Usb/Mp3 Control - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 237 SET Button – To Set the Pushbutton Memory Every time a preset button is used, a corresponding When you are receiving a channel that you wish to button number will display. commit to pushbutton memory, press the SET button. Buttons 1 - 6 The symbol SET 1 will now show in the display window.
Page 240: Connecting The Ipod Or External Usb Device
238 UNDERSTANDING YOUR INSTRUMENT PANEL This feature allows an iPod or external USB device to be Connecting The iPod Or External USB Device plugged into the USB port, located in the center console Use the connection cable to connect an iPod or external or glove compartment.
Page 241: Using This Feature
UNDERSTANDING YOUR INSTRUMENT PANEL 239 NOTE: The center console will have a position where Leaving the audio device connected to the iPod /USB/ the iPod or consumer electronic audio device cable can MP3 control system may charge it to the required level. be routed through without damaging the cable when Using This Feature closing the lid.
Page 242: Play Mode
240 UNDERSTANDING YOUR INSTRUMENT PANEL • Turning it counterclockwise (backward) by one on the radio faceplate or press the VR button and say USB or Switch to USB . Once in the iPod /USB/MP3 click, will jump to the previous track in the list or control mode, audio tracks (if available from audio press the VR button and say Previous Track device) start playing over the vehicle’s audio system.
Page 243: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 241 • While a track is playing, press the INFO button to see • RND button (available on sales code RES radio only): the associated metadata (artist, track title, album, etc.) Pressing this button toggles between Shuffle ON and for that track.
Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL • Preset 5 – Audiobooks press the TUNE control knob to select and start playing the track. Turning the TUNE control knob • Preset 6 – Podcasts fast will scroll through the list faster. During fast •...
Page 245: Bluetooth Streaming Audio (Btsa)
UNDERSTANDING YOUR INSTRUMENT PANEL 243 • MUSIC TYPE button: The MUSIC TYPE button is WARNING! another shortcut button to the genre listing on your audio device. Do not plug in or remove the iPod or external USB device while driving. Failure to follow this warning CAUTION! could result in an accident.
Page 246 244 UNDERSTANDING YOUR INSTRUMENT PANEL phone system. Seven devices can be paired to the Previous Track Uconnect™ phone system, but just one can be selected Use the SEEK DOWN button, or press the VR button on and played. the radio and say “Previous Track” to jump to the previous track music on your cellular phone.
Page 247 UNDERSTANDING YOUR INSTRUMENT PANEL 245 The 12 Channel Class D GreenEdge high efficiency Vehicle Information Center (EVIC). Refer to “Driver- amplifier is governed by a high voltage tracking power Selectable Surround Sound (DSS)” under “Electronic supply and drives a 7.4-channel playback architecture. Vehicle Information Center (EVIC)”...
Page 248: Equipped
246 UNDERSTANDING YOUR INSTRUMENT PANEL STEERING WHEEL AUDIO CONTROLS — IF The right-hand control is a rocker-type switch with a EQUIPPED pushbutton in the center and controls the volume and The remote sound system controls are located on the rear mode of the sound system.
Page 249: Cd Player
UNDERSTANDING YOUR INSTRUMENT PANEL 247 The button located in the center of the left-hand control CD/DVD DISC MAINTENANCE will tune to the next preset station that you have pro- To keep a CD/DVD in good condition, take the following grammed in the radio preset pushbutton. precautions: CD Player 1.
Page 250: Radio Operation And Mobile Phones
248 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If you experience difficulty in playing a particu- CLIMATE CONTROLS lar disc, it may be damaged (i.e., scratched, reflective Automatic Temperature Control (ATC) coating removed, a hair, moisture or dew on the disc) The Automatic Temperature Control system automati- oversized, or have protection encoding.
Page 251: Automatic Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 249 Automatic Operation the “O” (OFF) position on the blower control stops the Operation of the system is quite simple. system completely and closes the outside air intake. 1. Turn the Mode Control knob (on the right) and the The recommended setting for maximum comfort for the Blower Control knob (on the left) to AUTO.
Page 252: Blower Control
250 UNDERSTANDING YOUR INSTRUMENT PANEL the radiator and through the condenser. Fabric front Manual Operation fascia protectors may reduce airflow to the condenser, This system offers a full complement of manual override reducing air conditioning performance. features, which consist of Blower Preferred Automatic, Mode Preferred Automatic, or Blower and Mode Pre- Blower Control ferred Automatic.
Page 253 UNDERSTANDING YOUR INSTRUMENT PANEL 251...
Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL • Floor The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control Air is directed through the floor outlets with a knob (on the right) to one of the following positions. small amount flowing through the defrost and side window demist outlets.
Page 255 UNDERSTANDING YOUR INSTRUMENT PANEL 253 • Air Conditioner Control NOTE: • When the ignition switch is turned to the LOCK Press this button to turn on the air conditioning during manual operation position, the recirculation feature will be cancelled. only. When the air conditioning is •...
Page 256: Operating Tips
254 UNDERSTANDING YOUR INSTRUMENT PANEL • Most of the time, when in Automatic Operation, you Summer Operation can temporarily put the system into Recirculation The engine cooling system in air-conditioned vehicles Mode by pressing the Recirculation button. However, must be protected with a high-quality antifreeze coolant under certain conditions, while in Automatic Mode, to provide proper corrosion protection and to protect the system is blowing air out the defrost vents.
Page 257 UNDERSTANDING YOUR INSTRUMENT PANEL 255 adequate system lubrication to minimize the possibility Outside Air Intake of compressor damage when the system is started again. Make sure the air intake, located directly in front of the windshield, is free of obstructions such as leaves. Leaves Window Fogging collected in the air intake may reduce airflow, and if they Interior fogging on the windshield can be quickly re-...
Page 258 256 UNDERSTANDING YOUR INSTRUMENT PANEL Control Setting Suggestions for Various Weather Conditions...
Page 259 STARTING AND OPERATING CONTENTS Starting Procedures ....262 Engine Block Heater — If Equipped ..270 ▫...
Page 260 258 STARTING AND OPERATING ▫ Anti-Lock Brake System (ABS) — If AutoStick ......283 Equipped ......295 ▫...
Page 261 STARTING AND OPERATING 259 ▫ Tire Spinning ..... . . 322 Tire Safety Information ....306 ▫...
Page 262 260 STARTING AND OPERATING ▫ 5.7L Engine (With Manual Transmission) ..338 Vehicle Loading ..... . 345 ▫...
Page 263 STARTING AND OPERATING 261 ▫ Trailer And Tongue Weight ... . . 351 ▫ Automatic Transmission — If Equipped ..359 ▫ Towing Requirements ....352 ▫...
Page 264: Starting Procedures
262 STARTING AND OPERATING STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust the • Do not leave the key fob in or near the vehicle, and inside and outside mirrors, fasten your seat belt, and if do not leave a vehicle equipped with Keyless present, instruct all other occupants to buckle their seat Enter-N-Go in the ACC or ON/RUN mode.
Page 265: Automatic Transmission - If Equipped
STARTING AND OPERATING 263 ignition switch to the START position and release when Automatic Transmission – If Equipped the engine starts. If the engine fails to start within The shift lever must be in the NEUTRAL or PARK 15 seconds, turn the ignition switch to the OFF position, position before you can start the engine.
Page 266: Keyless Enter-N-Go - If Equipped
264 STARTING AND OPERATING Using Fob With Integrated Key (Tip Start) Keyless Enter-N-Go – If Equipped This feature allows the driver to oper- NOTE: Normal starting of either a cold or a warm ate the ignition switch with the push engine is obtained without pumping or pressing the of a button, as long as the ENGINE accelerator pedal.
Page 267: Normal Starting
STARTING AND OPERATING 265 Removing The Button To start the engine, the transmission must be in PARK or NEUTRAL. Press and hold the brake pedal while press- 1. The ENGINE START/STOP button can be removed ing the ENGINE START/STOP button once. The system from the ignition switch for key fob use.
Page 268 266 STARTING AND OPERATING to 15 seconds, then repeat the “Normal Starting” proce- display a “VEHICLE NOT IN PARK” message and the dure. If you wish to stop the cranking of the engine prior engine will remain running. Never leave a vehicle out of to the engine starting, release the button.
Page 269 STARTING AND OPERATING 267 NOTE: Keyless Enter-N-Go Functions – With Driver’s Foot • If the ignition switch is left in the ACC position, the OFF The Brake Pedal/Clutch Pedal (In PARK Or system will automatically time out after 30 minutes of NEUTRAL Position) inactivity and the ignition will switch to the OFF The Keyless Enter-N-Go feature operates similar to an...
Page 270: Extreme Cold Weather (Below -20°F Or 29°C)
268 STARTING AND OPERATING • Press the ENGINE START/STOP button a third time WARNING! (Continued) to return the ignition switch to the OFF position (EVIC • Do not attempt to push or tow your vehicle to get displays “IGNITION MODE OFF”). it started.
Page 271 STARTING AND OPERATING 269 Clearing A Flooded Engine (Using ENGINE the way to the floor and hold it, then press and hold the START/STOP Button) – Automatic Transmission ENGINE START/STOP button for no more than 15 sec- Only onds. Release the accelerator pedal and the clutch pedal, If the engine fails to start after you have followed the wait 10 to 15 seconds, then repeat the “Normal Starting”...
Page 272: After Starting
270 STARTING AND OPERATING The engine block heater must be plugged in at least one CAUTION! hour to have an adequate warming effect on the engine. To prevent damage to the starter, wait 10 to 15 sec- WARNING! onds before trying again. Remember to disconnect the engine block heater After Starting cord before driving.
Page 273 STARTING AND OPERATING 271 NOTE: During cold weather, you may experience in- CAUTION! creased effort in shifting until the transmission fluid • Never drive with your foot resting on the clutch warms up. This is normal. pedal, or try to hold the vehicle on a hill with the clutch pedal partially engaged, as this will cause abnormal wear on the clutch.
Page 274 272 STARTING AND OPERATING Shifting CAUTION! Fully press the clutch pedal and lift your foot off the accelerator pedal before shifting gears. As you release the Always make sure the vehicle comes to a complete clutch pedal, lightly press the accelerator pedal. Damage stop before shifting into REVERSE.
Page 275 STARTING AND OPERATING 273 stop, you may notice lighter shift efforts into REVERSE MANUAL TRANSMISSION with the ignition switch in the ON position (RUN RECOMMENDED SHIFT SPEEDS position for Keyless Enter-N-Go), as compared to the Axle ignition LOCK position (OFF position for Keyless Ratio Enter-N-Go).
Page 276 274 STARTING AND OPERATING gear to second gear. This is to help you get the best WARNING! possible fuel economy from your vehicle. This occurs when the engine coolant (antifreeze) is higher than 106°F Skipping more than one gear while downshifting, (41°C), vehicle speed is greater than 19 mph (30 km/h) could cause you to lose control of your vehicle.
Page 277: Automatic Transmission - If Equipped
STARTING AND OPERATING 275 AUTOMATIC TRANSMISSION — IF EQUIPPED NOTE: You must press and hold the brake pedal while shifting out of PARK. CAUTION! WARNING! Damage to the transmission may occur if the follow- • Unintended movement of a vehicle could injure ing precautions are not observed: •...
Page 278: Key Ignition Park Interlock
276 STARTING AND OPERATING Brake/Transmission Shift Interlock System WARNING! (Continued) This vehicle is equipped with a Brake Transmission Shift • It is dangerous to move the shift lever out of PARK Interlock (BTSI) that holds the shift lever in the PARK or NEUTRAL if the engine speed is higher than position unless the brakes are applied.
Page 279: Gear Ranges
STARTING AND OPERATING 277 vehicle may be somewhat abrupt. This is a normal condition, and precision shifts will develop within a few hundred miles (kilometers). Shifting from DRIVE to PARK or REVERSE should be done only after the accelerator pedal is released and the vehicle is stopped.
Page 280 278 STARTING AND OPERATING PARK WARNING! This range supplements the parking brake by locking the • Never use the PARK position as a substitute for transmission. The engine can be started in this range. Never attempt to use PARK while vehicle is in motion. the parking brake.
Page 281 STARTING AND OPERATING 279 WARNING! (Continued) WARNING! (Continued) • It is dangerous to move the shift lever out of PARK • Unintended movement of a vehicle could injure or NEUTRAL if the engine speed is higher than those in or near the vehicle. As with all vehicles, idle speed.
Page 282 280 STARTING AND OPERATING WARNING! (Continued) CAUTION! • Never leave children alone in a vehicle, or with • Before moving the shift lever out of PARK, you access to an unlocked vehicle. Allowing children must turn the ignition switch from the LOCK/OFF to be in a vehicle unattended is dangerous for a position to the ON/RUN position, and also press number of reasons.
Page 283 STARTING AND OPERATING 281 The following indicators should be used to ensure that WARNING! you have engaged the shift lever into the PARK position: Do not coast in NEUTRAL and never turn off the • When shifting into PARK, move the shift lever all the ignition to coast down a hill.
Page 284 282 STARTING AND OPERATING DRIVE Transmission Limp Home Mode This range should be used for most city and highway Transmission function is monitored electronically for driving. It provides the smoothest upshifts and down- abnormal conditions. If a condition is detected that could shifts, and the best fuel economy.
Page 285: Autostick
STARTING AND OPERATING 283 2. Shift the transmission into PARK. Overdrive Operation The automatic transmission includes an electronically 3. Turn the engine OFF. controlled Overdrive (fifth gear). The transmission will 4. Wait approximately 10 seconds. automatically shift into the Overdrive gear if the follow- ing conditions are present: 5.
Page 286: Operation
284 STARTING AND OPERATING Operation driver to upshift to the next gear. The “UPSHIFT” When the shift lever is in the DRIVE position, the message will appear when approaching the maximum transmission will operate automatically, shifting between engine speed. the five available gears. To engage AutoStick , simply •...
Page 287 STARTING AND OPERATING 285 • The transmission will automatically downshift to first To disengage AutoStick mode, hold the shift lever to the gear when coming to a stop. After a stop, the driver right or press and hold the (+) shift paddle (if equipped) should manually upshift (+) the transmission as the until “D”...
Page 288: Sport Mode - If Equipped
286 STARTING AND OPERATING SPORT MODE — IF EQUIPPED This vehicle is equipped with an electronic controlled dampening system. This system reduces body roll and pitch in many driving situations including cornering, acceleration and braking. There are two modes of opera- tion: •...
Page 289: Driving On Slippery Surfaces
STARTING AND OPERATING 287 AUTO mode will be a more soft touring ride, where as WARNING! SPORT will be a firmer, sportier suspension for better handling. SPORT mode also affects transmission shifting Rapid acceleration on slippery surfaces is dangerous. in either Auto or Manual mode. Refer to “AutoStick ” in Unequal traction can cause sudden pulling of the rear “Starting And Operating”...
Page 290: Driving Through Water
288 STARTING AND OPERATING 2. Slow down if the road has standing water or puddles. Flowing/Rising Water 3. Replace tires when tread wear indicators first become WARNING! visible. Do not drive on, or cross, a road or a path where 4.
Page 291 STARTING AND OPERATING 289 CAUTION! CAUTION! (Continued) • Driving through standing water may cause dam- • Always check the depth of the standing water age to your vehicle’s drivetrain components. Al- before driving through it. Never drive through ways inspect your vehicle’s fluids (i.e., engine oil, standing water that is deeper than the bottom of transmission, axle, etc.) for signs of contamination the tire rims mounted on the vehicle.
Page 292: Power Steering
290 STARTING AND OPERATING POWER STEERING WARNING! Your vehicle is equipped with an electro-hydraulic power • Driving through standing water limits your vehi- steering system that will give you good vehicle response and increased ease of maneuverability in tight spaces. cle’s traction capabilities.
Page 293: Parking Brake
STARTING AND OPERATING 291 If the “SERVICE POWER STEERING SYSTEM” NOTE: • Even if power steering assistance is no longer opera- message and a flashing icon are displayed on the EVIC screen, it indicates that the vehicle tional, it is still possible to steer the vehicle. Under needs to be taken to the dealer for service.
Page 294: Manual Transmission - If Equipped
292 STARTING AND OPERATING NOTE: Manual Transmission – If Equipped • When the parking brake is applied and the transmis- The foot operated parking brake is positioned below the sion is placed in gear, the “Brake Warning Light” will lower left corner of the instrument panel. To release the flash.
Page 295: Automatic Transmission - If Equipped
STARTING AND OPERATING 293 Automatic Transmission – If Equipped The foot operated parking brake is located below the lower left corner of the instrument panel. To apply the park brake, firmly push the park brake pedal fully. To release the parking brake, press the park brake pedal a second time and let your foot up as you feel the brake disengage.
Page 296 294 STARTING AND OPERATING WARNING! WARNING! (Continued) • Do not leave the key fob in or near the vehicle, and • Never use the PARK position as a substitute for do not leave a vehicle equipped with Keyless the parking brake. Always apply the parking Enter-N-Go in the ACC or ON/RUN mode.
Page 297: Brake System
STARTING AND OPERATING 295 OFF) the brakes will still function. The effort required to CAUTION! brake the vehicle will be much greater than that required with the power system operating. If the “Brake Warning Light” remains on with the parking brake released, a brake system malfunction Anti-Lock Brake System (ABS) —...
Page 298 296 STARTING AND OPERATING is working properly. This self check occurs each time the WARNING! vehicle is started and accelerated past 7 mph (11 km/h). • The Anti-Lock Brake System (ABS) contains so- ABS is activated during braking under certain road or phisticated electronic equipment that may be sus- stopping conditions.
Page 299 STARTING AND OPERATING 297 All vehicle wheels and tires must be the same size and WARNING! (Continued) type and tires must be properly inflated to produce • The Anti-Lock Brake System (ABS) cannot prevent accurate signals for the computer. the natural laws of physics from acting on the Anti-Lock Brake Warning Light vehicle, nor can it increase braking or steering The “Anti-Lock Brake System (ABS) Warning...
Page 300: Electronic Brake Control System
298 STARTING AND OPERATING If the “ABS Warning Light” is on, the brake system TCS (Traction Control System), the BAS (Brake Assist should be serviced as soon as possible to restore the System), and the ESC (Electronic Stability Control). These benefits of anti-lock brakes.
Page 301: Traction Control System (Tcs) - If Equipped
STARTING AND OPERATING 299 A feature of the TCS system functions similar to a WARNING! limited-slip differential (LSD) and controls the wheel spin across a driven axle. If one wheel on a driven axle is The ABS cannot prevent the natural laws of physics spinning faster than the other, the system will apply the from acting on the vehicle, nor can it increase the brake of the spinning wheel.
Page 302: Hill Start Assist (Hsa) - Manual Transmission Only
300 STARTING AND OPERATING Applying the brakes very quickly results in the best BAS Hill Start Assist (HSA) – Manual Transmission assistance. To receive the benefits of this system, you Only must apply continuous brake pedal pressure during the The HSA system is designed to assist the driver when stopping sequence.
Page 303 STARTING AND OPERATING 301 • Gear selection matches vehicle uphill direction (i.e., For vehicles not equipped with the EVIC, perform the vehicle facing uphill is in forward gear; vehicle back- following steps: ing uphill is in REVERSE gear). NOTE: You must complete Steps 1 through 8 within 90 seconds.
Page 304: Electronic Stability Control (Esc) - If Equipped
302 STARTING AND OPERATING 8. Rotate the steering wheel back to center and then an power may also be reduced to assist in counteracting the additional half-turn to the right. condition of oversteer or understeer and help the vehicle maintain the desired path. 9.
Page 305 STARTING AND OPERATING 303 ESC Operating Modes WARNING! The ESC system has two available operating modes: The Electronic Stability Control (ESC) cannot pre- ESC On vent the natural laws of physics from acting on the This is the normal operating mode for the ESC. When- vehicle, nor can it increase the traction afforded by ever the vehicle is started, the ESC system will be in this prevailing road conditions.
Page 306: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
304 STARTING AND OPERATING The “ESC Off” switch is located in the switch bank near WARNING! the bottom center of the instrument panel. To enter the “Partial Off” mode, momentarily press the “ESC Off” When in “Partial Off” mode, the TCS portion of ESC, switch and the “ESC Activation/Malfunction Indicator except for the limited wheel spin feature described in Light”...
Page 307 STARTING AND OPERATING 305 light remains on after several ignition cycles, and the NOTE: • The “ESC Activation/Malfunction Indicator Light” vehicle has been driven several miles (kilometers) at speeds greater than 30 mph (48 km/h), see your autho- and the “ESC OFF Indicator Light” come on momen- rized dealer as soon as possible to have the problem tarily each time the ignition switch is turned ON.
Page 308: Synchronizing Esc
306 STARTING AND OPERATING Synchronizing ESC TIRE SAFETY INFORMATION If the power supply is interrupted (battery Tire Markings disconnected discharged), “ESC Activation/Malfunction Indicator Light” may illuminate with the engine running. If this should occur, turn the steering wheel completely to the left and then to the right.
Page 309 STARTING AND OPERATING 307 • Temporary spare tires are spares designed for tempo- NOTE: • P (Passenger) - Metric tire sizing is based on U.S. rary emergency use only. Temporary high pressure design standards. P-Metric tires have the letter “P” compact spare tires have the letter “T”...
Page 310 308 STARTING AND OPERATING Tire Sizing Chart TIRE SIZING TERMS Size Designation: P = Passenger Car tire size based on U.S. design standards ..blank..= Passenger Car tire based on European design standards LT = Light Truck tire based on U.S. design standards T or S = Temporary compact spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 311 STARTING AND OPERATING 309 TIRE SIZING TERMS Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 312 310 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 313: Tire Terminology And Definitions
STARTING AND OPERATING 311 Tire Terminology and Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 314: Tire Loading And Tire Pressure
312 STARTING AND OPERATING Tire Loading And Tire Pressure Tire and Loading Information Placard Tire and Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door.
Page 315 STARTING AND OPERATING 313 Loading combined weight of occupants, cargo/luggage and The vehicle maximum load on the tire must not exceed trailer tongue weight (if applicable) should never exceed the load carrying capacity of the tire on your vehicle. You the weight referenced here.
Page 316 314 STARTING AND OPERATING available cargo and luggage load capacity is 650 lbs NOTE: • The following table shows examples on how to calcu- (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs [295 kg]). late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations 5.
Page 317 STARTING AND OPERATING 315...
Page 318: Tires - General Information
316 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 319: Tire Inflation Pressures
STARTING AND OPERATING 317 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the ve- driver’s side “B” Pillar or rear edge of the driver’s side hicle to the other can cause the vehicle to drift to door.
Page 320 318 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the winter.
Page 321: Radial Ply Tires
STARTING AND OPERATING 319 loading may be required for high-speed vehicle opera- Radial Ply Tires tion. Refer to original equipment or an authorized tire WARNING! dealer for recommended safe operating speeds, loading and cold tire inflation pressures. Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle WARNING! poorly.
Page 322: Spare Tire Matching Original Equipped Tire And Wheel - If Equipped
320 STARTING AND OPERATING Spare Tire Matching Original Equipped Tire and CAUTION! Wheel – If Equipped Your vehicle may be equivalent with a spare tire and Because of the reduced ground clearance, do not take wheel in look and function as the original equipment tire your vehicle through an automatic car wash with a and wheel found on the front or rear axle of your vehicle.
Page 323: Full Size Spare - If Equipped
STARTING AND OPERATING 321 Since this tire has limited tread life the original equip- Full Size Spare – If Equipped ment tire should be repaired (or replaced) and reinstalled The full size spare is for temporary emergency use only. on your vehicle at the first opportunity. This tire may look like the original equipped tire on the front or rear axle of your vehicle, but it is not.
Page 324: Tire Spinning
322 STARTING AND OPERATING your original equipment tire, replace (or repair) the Tire Spinning original equipment tire and reinstall on the vehicle at the When stuck in mud, sand, snow, or ice conditions, do not first opportunity. spin your vehicle’s wheels above 30 mph (48 km/h). Refer to “Freeing A Stuck Vehicle”...
Page 325: Tread Wear Indicators
STARTING AND OPERATING 323 Tread Wear Indicators These indicators are molded into the bottom of the tread Tread wear indicators are in the original equipment tires grooves. They will appear as bands when the tread depth to help you in determining when your tires should be becomes 1/16 in (2 mm).
Page 326: Replacement Tires
324 STARTING AND OPERATING Keep dismounted tires in a cool, dry place with as little WARNING! exposure to light as possible. Protect tires from contact • Do not use a tire, wheel size or rating other than with oil, grease, and gasoline. that specified for your vehicle.
Page 327: Tire Chains
STARTING AND OPERATING 325 using model 0143 (tirechaindealer.com) and on P235/ WARNING! (Continued) 55R19 using model Z-575 (scc-chain.com). • Failure to equip your vehicle with tires having NOTE: Do not use tire chains on a compact spare tire. adequate speed capability can result in sudden tire failure and loss of vehicle control.
Page 328: Snow Tires
326 STARTING AND OPERATING pavement. Observe the tire chain manufacturer’s instruc- CAUTION! (Continued) tions on method of installation, operating speed, and • Do not exceed 30 mph (48 km/h). conditions for usage. • Drive cautiously and avoid severe turns and large Always use the lower suggested operating speed if both bumps, especially with a loaded vehicle.
Page 329: Tire Rotation Recommendations
STARTING AND OPERATING 327 Snow tires generally have lower speed ratings than what TIRE ROTATION RECOMMENDATIONS was originally equipped with your vehicle and should Tires on the front and rear axles of vehicles operate at not be operated at sustained speeds over 75 mph different loads and perform different steering, handling, (120 km/h).
Page 330: Tire Pressure Monitor System (Tpms)
328 STARTING AND OPERATING The suggested rotation method is the “forward-cross” TIRE PRESSURE MONITOR SYSTEM (TPMS) shown in the following diagram. The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recom- mended cold placard pressure.
Page 331 STARTING AND OPERATING 329 The TPMS will warn the driver of a low tire pressure if For example, your vehicle may have a recommended the tire pressure falls below the low-pressure warning cold (parked for more than three hours) placard pressure limit for any reason, including low temperature effects of 30 psi (207 kPa).
Page 332 330 STARTING AND OPERATING NOTE: CAUTION! • The TPMS is not intended to replace normal tire care • The TPMS has been optimized for the original and maintenance or to provide warning of a tire failure or condition. equipment tires and wheels. TPMS pressures and warning have been established for the tire size •...
Page 333: Base System
STARTING AND OPERATING 331 • Seasonal temperature changes will affect tire pressure, Tire Pressure Monitoring Low Pressure Warnings and the TPMS will monitor the actual tire pressure in The “TPM Telltale Light” will illuminate in the the tire. instrument cluster, a “LOW TIRE” message will be displayed and a chime will sound when tire pres- Base System sure is low in one or more of the four active road tires.
Page 334 332 STARTING AND OPERATING system fault still exists. The “TPM Telltale Light” will Vehicles With Compact Spare turn off when the fault condition no longer exists. A 1. The compact spare tire does not have a TPM sensor. system fault can occur due to any of the following: Therefore, the TPMS will not monitor the pressure in the 1.
Page 335: Premium System - If Equipped
STARTING AND OPERATING 333 4. For each subsequent ignition switch cycle, a chime will Premium System – If Equipped sound and the “TPM Telltale Light” will flash on and off The Tire Pressure Monitor System (TPMS) uses wireless for 75 seconds and then remain on solid. technology with wheel rim mounted electronic sensors to monitor tire pressure levels.
Page 336 334 STARTING AND OPERATING • Four TPM sensors, • Various TPMS messages, which display in the Elec- tronic Vehicle Information Center (EVIC), and • TPM Telltale Light Tire Pressure Monitoring Low Pressure Warnings The “TPM Telltale Light” will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires.
Page 337 STARTING AND OPERATING 335 Should this occur, you should stop as soon as possible and inflate all of the tires with a low pressure condition (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure inflation value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flashing, and the “TPM Telltale Light”...
Page 338 336 STARTING AND OPERATING If the ignition switch is cycled, this sequence will repeat, The EVIC will also display a SERVICE TPM SYSTEM message for a minimum of five seconds when a system providing the system fault still exists. If the system fault no fault related to an incorrect sensor location fault is longer exists, the “TPM Telltale Light”...
Page 339: General Information
STARTING AND OPERATING 337 Light” will remain ON and a chime will sound. In addition, EVIC will display a new pressure value instead of dashes the graphic in the EVIC will still display a flashing pressure (- -), as long as no tire pressure is below the low-pressure value.
Page 340: Fuel Requirements
338 STARTING AND OPERATING FUEL REQUIREMENTS as hard starting, stalling, and hesitations. If you experi- ence these symptoms, try another brand of gasoline 3.6L And 5.7L Engine (With Automatic before considering service for the vehicle. Transmission) The 3.6L and 5.7L engine (with automatic Over 40 auto manufacturers worldwide have issued and transmission) is designed to meet all emis- endorsed consistent gasoline specifications (the World...
Page 341: Reformulated Gasoline
STARTING AND OPERATING 339 Reformulated Gasoline CAUTION! Many areas of the country require the use of cleaner burning gasoline referred to as “reformulated gasoline.” Do not use gasolines containing Methanol or E-85 Reformulated gasolines contain oxygenates and are spe- Ethanol. Use of these blends may result in starting cifically blended to reduce vehicle emissions and im- and driveability problems and may damage critical prove air quality.
Page 342: Mmt In Gasoline
340 STARTING AND OPERATING If a Non-FFV vehicle is inadvertently fueled with E-85 More extensive repairs will be required for prolonged fuel, the engine will have some or all of these symptoms: exposure to E-85 fuel. • operate in a lean mode MMT In Gasoline MMT is a manganese-containing metallic additive that is •...
Page 343: Materials Added To Fuel
STARTING AND OPERATING 341 Materials Added To Fuel CAUTION! (Continued) All gasoline sold in the United States is required to • An out-of-tune engine or certain fuel or ignition contain effective detergent additives. Use of additional malfunctions can cause the catalytic converter to detergents or other additives is not needed under normal overheat.
Page 344: Carbon Monoxide Warnings
342 STARTING AND OPERATING NOTE: Intentional tampering with the emissions con- WARNING! (Continued) trol system can result in civil penalties being assessed • Guard against carbon monoxide with proper against you. maintenance. Have the exhaust system inspected Carbon Monoxide Warnings every time the vehicle is raised.
Page 345 STARTING AND OPERATING 343 Fuel Filler Cap – Base Model Fuel Filler Cap – R/T Model NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler door.
Page 346 344 STARTING AND OPERATING CAUTION! WARNING! • Damage to the fuel system or emissions control • Never have any smoking materials lit in or near system could result from using an improper fuel the vehicle when the gas cap is removed or the tank filler tube cap (gas cap).
Page 347: Loose Fuel Filler Cap Message
STARTING AND OPERATING 345 • When the fuel nozzle “clicks” or shuts off, the fuel VEHICLE LOADING tank is full. The load carrying capacity of your vehicle is shown on the “Vehicle Certification Label.” This information Loose Fuel Filler Cap Message should be used for passenger and luggage loading as If the vehicle diagnostic system determines that the fuel indicated.
Page 348: Gross Vehicle Weight Rating (Gvwr)
346 STARTING AND OPERATING • Gross Axle Weight Rating (GAWR) rear WARNING! • Vehicle Identification Number (VIN) Because the front wheels steer the vehicle, it is • Type of Vehicle important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can •...
Page 349: Loading
STARTING AND OPERATING 347 Figure out the weight on the front and rear of the vehicle NOTE: Refer to the “Vehicle Certification Label” affixed separately. It is important that you distribute the load to the rear of the driver’s door for your vehicle’s GVWR evenly over the front and rear axles.
Page 350: Common Towing Definitions
348 STARTING AND OPERATING Common Towing Definitions Gross Combination Weight Rating (GCWR) The GCWR is the total permissible weight of your vehicle The following trailer towing related definitions will assist and trailer when weighed in combination. you in understanding the following information: NOTE: The GCWR rating includes a 150 lbs (68 kg) Gross Vehicle Weight Rating (GVWR) allowance for the presence of a driver.
Page 351 STARTING AND OPERATING 349 Tongue Weight (TW) of hitches are the most popular on the market today and The TW is the downward force exerted on the hitch ball they are commonly used to tow small- and medium- by the trailer. In most cases, it should not be less than 10% sized trailers.
Page 352: Trailer Hitch Classification
350 STARTING AND OPERATING Trailer Hitch Classification Definitions WARNING! Class Max. Trailer Hitch Industry • An improperly adjusted weight distributing hitch Standards system may reduce handling, stability, braking Class I - Light Duty 2,000 lbs (907 kg) performance, and could result in a collision. Class II - Medium 3,500 lbs (1587 kg) •...
Page 353: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING 351 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Transmission Frontal Area Max. GTW Max. Tongue Wt. (Gross Trailer Wt.) 3.6L Automatic 12 sq ft (1.11 sq m) 1,000 lbs (454 kg) 100 lbs (45 kg) 5.7L Automatic...
Page 354: Towing Requirements
352 STARTING AND OPERATING Consider the following items when computing the Towing Requirements weight on the rear axle of the vehicle: To promote proper break-in of your new vehicle drive- train components the following guidelines are recom- • The tongue weight of the trailer. mended: •...
Page 355 STARTING AND OPERATING 353 WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to a collision. Follow these vehicle and trailer. Always connect the chains to guidelines to make your trailer towing as safe as the frame or hook retainers of the vehicle hitch.
Page 356 354 STARTING AND OPERATING − Check for signs of tire wear or visible tire damage WARNING! (Continued) before towing a trailer. Refer to “Tires – General 2. GTW Information” in “Starting and Operating” for the 3. GAWR proper inspection procedure. 4.
Page 357 STARTING AND OPERATING 355 actuated brakes. When towing a trailer equipped with WARNING! a hydraulic surge actuated brake system, an electronic • Do not connect trailer brakes to your vehicle’s brake controller is not required. hydraulic brake lines. It can overload your brake −...
Page 358 356 STARTING AND OPERATING Towing Requirements – Trailer Lights And Wiring Whenever you pull a trailer, regardless of the trailer size, stoplights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four- and seven- pin wiring harness.
Page 359: Towing Tips
STARTING AND OPERATING 357 Towing Tips Before setting out on a trip, practice turning, stopping, and backing up the trailer in an area located away from heavy traffic. Automatic Transmission The DRIVE range can be selected when towing. How- ever, if frequent shifting occurs while in this range, use the AutoStick mode to select a lower gear range.
Page 360: Maintenance Schedules
358 STARTING AND OPERATING specified for “police, taxi, fleet, or frequent trailer tow- − Extended driving at high RPM should be avoided to ing.” Refer to “Maintenance Schedule” for the proper prevent excess heat generation. A reduction in vehicle maintenance intervals. speed may be required to avoid extended driving at high RPM.
Page 361: Automatic Transmission - If Equipped
STARTING AND OPERATING 359 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing Condition Wheels OFF the Manual Transmission Automatic Transmission Ground Flat Tow None NOT ALLOWED • Transmission in NEUTRAL • 65 mph (105 km/h) maximum speed Front Not Recommended NOT ALLOWED Dolly Tow Rear Not Recommended...
Page 362: Manual Transmission - If Equipped
360 STARTING AND OPERATING Use of a towing dolly is not recommended, as vehicle CAUTION! damage may occur. Towing this vehicle in violation of the above require- CAUTION! ments can cause severe transmission damage. Dam- age from improper towing is not covered under the Towing this vehicle in violation of the above require- New Vehicle Limited Warranty.
Page 363 WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....363 Jacking And Tire Changing ....375 ▫...
Page 364 362 WHAT TO DO IN EMERGENCIES ▫ Automatic Transmission ....392 Freeing A Stuck Vehicle ....388 ▫...
Page 365: Hazard Warning Flashers
WHAT TO DO IN EMERGENCIES 363 HAZARD WARNING FLASHERS NOTE: With extended use the Hazard Warning flashers The Hazard Warning flasher switch is located in the may wear down your battery. switch bank near the bottom center of the instrument IF YOUR ENGINE OVERHEATS panel.
Page 366: Tirefit Kit - If Equipped
364 WHAT TO DO IN EMERGENCIES to high. This allows the heater core to act as a WARNING! supplement to the radiator and aids in removing heat from the engine cooling system. You or others can be badly burned by hot engine coolant (antifreeze) or steam from your radiator.
Page 367: Tirefit Storage
WHAT TO DO IN EMERGENCIES 365 TIREFIT Storage TIREFIT Kit Components And Operation The TIREFIT kit is located in the trunk. 1. Sealant Bottle TIREFIT Location 2. Deflation Button 3. Pressure Gauge 4. Power Button...
Page 368 366 WHAT TO DO IN EMERGENCIES 5. Mode Select Knob Selecting Sealant Mode Turn the Mode Select Knob (5) to this 6. Sealant Hose (Clear) position to inject the TIREFIT Sealant 7. Air Pump Hose (Black) and to inflate the tire. Use the Sealant Hose (clear hose) (6) when selecting 8.
Page 369: Tirefit Usage Precautions
WHAT TO DO IN EMERGENCIES 367 • For optimum performance, make sure the valve stem TIREFIT Usage Precautions on the wheel is free of debris before connecting the • Replace the TIREFIT Sealant Bottle (1) and Sealant TIREFIT kit. Hose (6) prior to the expiration date (printed on the •...
Page 370 368 WHAT TO DO IN EMERGENCIES WARNING! WARNING! (Continued) − If you are unsure of the condition of the tire or the • Do not attempt to seal a tire on the side of the wheel. vehicle closest to traffic. Pull far enough off the •...
Page 371: Sealing A Tire With Tirefit
WHAT TO DO IN EMERGENCIES 369 Sealing A Tire With TIREFIT WARNING! (Continued) (A) Whenever You Stop To Use TIREFIT: • Take care not to allow the contents of TIREFIT to come in contact with hair, eyes, or clothing. TIRE- 1.
Page 372 370 WHAT TO DO IN EMERGENCIES (B) Setting Up To Use TIREFIT: (C) Injecting TIREFIT Sealant Into The Deflated Tire: 1. Turn the Mode Select Knob (5) to the Sealant Mode • Always start the engine before turning ON the TIRE- position.
Page 373 WHAT TO DO IN EMERGENCIES 371 Sealant Hose (6) to the valve stem. Check that the Mode 1. Continue to operate the pump until sealant is no Select Knob (5) is in the Sealant Mode position and not longer flowing through hose (typically takes 30 - 70 sec- Air Mode.
Page 374 372 WHAT TO DO IN EMERGENCIES NOTE: If the tire becomes over-inflated, press the CAUTION! Deflation Button to reduce the tire pressure to the recom- • The metal end fitting from Power Plug (8) may get mended inflation pressure before continuing. hot after use, so it should be handled carefully.
Page 375 WHAT TO DO IN EMERGENCIES 373 3. Uncoil the Air Pump Hose (7) (black in color) and WARNING! screw the fitting at the end of hose (7) onto the valve stem. TIREFIT is not a permanent flat tire repair. Have the tire inspected and repaired or replaced after using 4.
Page 376 374 WHAT TO DO IN EMERGENCIES 2. Disconnect the TIREFIT kit from the valve stem, 2. Locate the round Sealant Bottle release button in the reinstall the cap on the valve stem and unplug from 12 recessed area under the sealant bottle. Volt outlet.
Page 377: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES 375 JACKING AND TIRE CHANGING WARNING! (Continued) • The jack is designed to be used as a tool for WARNING! changing tires only. The jack should not be used to • Do not attempt to change a tire on the side of the lift the vehicle for service purposes.
Page 378 376 WHAT TO DO IN EMERGENCIES 2. Lift the access cover using the pull strap. 3. Remove the fastener securing the spare tire. Opening The Access Panel Spare Tire Fastener 4. Remove the spare tire. 5. Remove the fastener securing the jack.
Page 379: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 377 WARNING! • A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the vehicle. Always stow the jack parts and the spare tire in the places provided. •...
Page 380: Jacking And Changing A Tire
378 WHAT TO DO IN EMERGENCIES NOTE: Passengers should not remain in the vehicle WARNING! when the vehicle is being jacked. Do not attempt to change a tire on the side of the Jacking And Changing A Tire vehicle close to moving traffic, pull far enough off the road to avoid being hit when operating the jack WARNING! or changing the wheel.
Page 381 WHAT TO DO IN EMERGENCIES 379 WARNING! (Continued) CAUTION! • Never start or run the engine with the vehicle on a Do not attempt to raise the vehicle by jacking on jack. locations other than those indicated in the Jacking •...
Page 382 380 WHAT TO DO IN EMERGENCIES 1. Remove the spare tire, jack, and lug wrench. 2. If equipped with aluminum wheels where the center cap covers the lug nuts, use the lug wrench to pry the center cap off carefully before raising the vehicle. 3.
Page 383 WHAT TO DO IN EMERGENCIES 381 WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6. Remove the lug nuts and tire. 7.
Page 384 382 WHAT TO DO IN EMERGENCIES NOTE: CAUTION! • For vehicles so equipped, do not attempt to install a center cap or wheel cover on the compact spare. Be sure to mount the spare tire with the valve stem facing outward. The vehicle could be damaged if the •...
Page 385: Road Tire Installation
WHAT TO DO IN EMERGENCIES 383 9. Lower the vehicle to the ground by turning the jack WARNING! handle counterclockwise. • A loose tire or jack thrown forward in a collision 10. Finish tightening the lug nuts. Push down on the or hard stop could endanger the occupants of the wrench while at the end of the handle for increased vehicle.
Page 386: Jump-Starting Procedures
384 WHAT TO DO IN EMERGENCIES 5. After 25 miles (40 km) check the lug nut torque with a WARNING! torque wrench to ensure that all lug nuts are properly seated against the wheel. To avoid the risk of forcing the vehicle off the jack, do not tighten the wheel nuts fully until the vehicle JUMP-STARTING PROCEDURES has been lowered.
Page 387: Preparations For Jump-Start
WHAT TO DO IN EMERGENCIES 385 CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur. WARNING! Do not attempt jump-starting if the battery is frozen.
Page 388: Jump-Starting Procedure
386 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park WARNING! the vehicle within the jumper cables reach, set the • Take care to avoid the radiator cooling fan when- parking brake and make sure the ignition is OFF. ever the hood is raised.
Page 389 WHAT TO DO IN EMERGENCIES 387 CAUTION! WARNING! Failure to follow these procedures could result in Do not connect the cable to the negative post (-) of the damage to the charging system of the booster vehicle discharged battery. The resulting electrical spark or the discharged vehicle.
Page 390: Freeing A Stuck Vehicle
388 WHAT TO DO IN EMERGENCIES 8. Disconnect the opposite end of the positive (+) jumper FREEING A STUCK VEHICLE cable from the positive (+) post of the booster battery. If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion.
Page 391 WHAT TO DO IN EMERGENCIES 389 NOTE: Turn off the Electronic Stability Program (ESP) WARNING! before rocking the vehicle. Refer to “Electronic Stability Program,” or “Traction Control” in “Starting And Oper- Fast spinning tires can be dangerous. Forces gener- ating” for further information. ated by excessive wheel speeds may cause damage, or even failure, of the axle and tires.
Page 392: Shift Lever Override
390 WHAT TO DO IN EMERGENCIES SHIFT LEVER OVERRIDE If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to temporarily move the shift lever: 1. Firmly apply the parking brake. 2.
Page 393: Towing A Disabled Vehicle
WHAT TO DO IN EMERGENCIES 391 TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial wrecker service. Wheels OFF The Towing Condition AUTOMATIC TRANSMISSION MANUAL TRANSMISSION Ground If transmission is operable: If transmission is operable: •...
Page 394: Automatic Transmission
392 WHAT TO DO IN EMERGENCIES Proper towing or lifting equipment is required to prevent CAUTION! damage to your vehicle. Use only tow bars and other • Do not attempt to use sling type equipment when equipment designed for the purpose, following equip- ment manufacturer’s instructions.
Page 395: Manual Transmission
WHAT TO DO IN EMERGENCIES 393 • The shift lever must be in NEUTRAL. Manual Transmission The manufacturer recommends towing your vehicle with • The towing distance must not exceed 15 miles (24 km). all four wheels OFF the ground using a flatbed. •...
Page 396: Without The Key Fob
394 WHAT TO DO IN EMERGENCIES There is no limitation on towing distance. If the trans- CAUTION! mission is not operable, then the only acceptable method of towing is with a flatbed truck. Failure to follow these towing methods can cause severe transmission damage.
Page 397 MAINTAINING YOUR VEHICLE CONTENTS ▫ Engine Oil ......404 Engine Compartment — 3.6L ... . . 398 ▫...
Page 398 396 MAINTAINING YOUR VEHICLE ▫ Cooling System ..... 416 Bulb Replacement ..... 442 ▫...
Page 399 MAINTAINING YOUR VEHICLE 397 ▫ Engine ......448 Fluid Capacities ..... . 447 ▫...
Page 400: Engine Compartment - 3.6L
398 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.6L 1 — Integrated Power Module (Fuses) 5 — Air Cleaner Filter 2 — Engine Oil Dipstick 6 — Engine Oil Fill 3 — Brake Fluid Reservoir Access Cover 7 — Remote Jump Start (Positive Battery Post) 4 —...
Page 401: Engine Compartment - 5.7L
MAINTAINING YOUR VEHICLE 399 ENGINE COMPARTMENT — 5.7L 1 — Integrated Power Module (Fuses) 5 — Engine Oil Fill 2 — Brake Fluid Reservoir Access Cover 6 — Engine Oil Dipstick 3 — Engine Coolant Reservoir 7 — Remote Jump Start (Positive Battery Post) 4 —...
Page 402: Onboard Diagnostic System - Obd Ii
400 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.
Page 403: Emissions Inspection And Maintenance Programs
MAINTAINING YOUR VEHICLE 401 Trip Odometer button to turn off the message. If the Normally, the OBD II system will be ready. The OBD II problem continues, the message will appear the next time system may not be ready if your vehicle was recently the vehicle is started.
Page 404: Replacement Parts
402 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced a.
Page 405: Maintenance Procedures
MAINTAINING YOUR VEHICLE 403 your vehicle. Refer to these Service Manuals before MAINTENANCE PROCEDURES attempting any procedure yourself. The pages that follow contain the required maintenance services determined by the engineers who designed your NOTE: Intentional tampering with emissions control vehicle.
Page 406: Engine Oil
404 MAINTAINING YOUR VEHICLE regular intervals, such as every fuel stop. The best time to CAUTION! (Continued) check the engine oil level is about five minutes after a • Your vehicle has been built with improved fluids fully warmed engine is shut off. that protect the performance and durability of Checking the oil while the vehicle is on level ground will your vehicle and also allow extended maintenance...
Page 407 MAINTAINING YOUR VEHICLE 405 regular intervals, such as every fuel stop. The best time to NOTE: Under no circumstances should oil change check the engine oil level is about five minutes after a intervals exceed 8,000 miles (13 000 km) or six months, fully warmed engine is shut off.
Page 408 406 MAINTAINING YOUR VEHICLE Engine Oil Viscosity (SAE Grade) – 5.7L Engine CAUTION! SAE 5W-20 engine oil is recommended for all operating temperatures. This engine oil improves low temperature Do not use chemical flushes in your engine oil as the starting and vehicle fuel economy.
Page 409: Engine Oil Filter
MAINTAINING YOUR VEHICLE 407 Synthetic Engine Oils Engine Oil Filter You may use synthetic engine oils provided the recom- The engine oil filter should be replaced with a new filter mended oil quality requirements are met, and the recom- at every engine oil change. mended maintenance intervals for oil and filter changes Engine Oil Filter Selection are followed.
Page 410: Maintenance-Free Battery
408 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter Selection WARNING! The quality of replacement engine air cleaner filters varies considerably. Only high quality filters should be The air induction system (air cleaner, hoses, etc.) can used to assure most efficient service. MOPAR engine air provide a measure of protection in the case of engine cleaner filters are a high quality filter and are backfire.
Page 411 MAINTAINING YOUR VEHICLE 409 NOTE: The battery is stored under an access cover in WARNING! the trunk. Remote battery terminals are located in the • Battery fluid is a corrosive acid solution and can engine compartment for jump-starting. Refer to “Jump- Starting Procedures”...
Page 412: Air Conditioner Maintenance
410 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! (Continued) For best possible performance, your air conditioner • The battery in this vehicle has a vent hose that should be checked and serviced by an authorized dealer should not be disconnected and should only be at the start of each warm season.
Page 413: Body Lubrication
MAINTAINING YOUR VEHICLE 411 Protection Agency and is an ozone-saving product. How- WARNING! ever, the manufacturer recommends that air conditioning • Use only refrigerants and compressor lubricants service be performed by authorized dealers or other service facilities using recovery and recycling equipment. approved by the manufacturer for your air condi- tioning system.
Page 414: Windshield Wiper Blades
412 MAINTAINING YOUR VEHICLE hood latching components to ensure proper function. Operation of the wipers on dry glass for long periods When performing other underhood services, the hood may cause deterioration of the wiper blades. Always use latch, release mechanism and safety catch should be washer fluid when using the wipers to remove salt or dirt cleaned and lubricated.
Page 415: Adding Washer Fluid
MAINTAINING YOUR VEHICLE 413 Adding Washer Fluid The fluid reservoir will hold nearly 1 gal (4 L) of washer The windshield washer fluid reservoir is located in the fluid when the message “Low Washer Fluid” appears in front of the engine compartment. Be sure to check the the Electronic Vehicle Information Center (EVIC) (if fluid level at regular intervals.
Page 416: Exhaust System
414 MAINTAINING YOUR VEHICLE Exhaust System WARNING! The best protection against carbon monoxide entry into • Exhaust gases can injure or kill. They contain the vehicle body is a properly maintained engine exhaust system. carbon monoxide (CO), which is colorless and odorless.
Page 417 MAINTAINING YOUR VEHICLE 415 Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- • The catalytic converter requires the use of un- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst leaded fuel only.
Page 418: Cooling System
416 MAINTAINING YOUR VEHICLE To minimize the possibility of catalytic converter dam- Cooling System age: WARNING! • Do not shut off the engine or interrupt the ignition, • When working near the radiator cooling fan, dis- when the transmission is in gear and the vehicle is in motion.
Page 419 MAINTAINING YOUR VEHICLE 417 Coolant Checks drain from the coolant recovery bottle. DO NOT RE- Check engine coolant (antifreeze) protection every MOVE THE COOLANT PRESSURE CAP WHEN THE 12 months (before the onset of freezing weather, where COOLING SYSTEM IS HOT. applicable).
Page 420 418 MAINTAINING YOUR VEHICLE CAUTION! CAUTION! (Continued) • This vehicle has not been designed for use with • Mixing of engine coolant (antifreeze) other than propylene glycol-based engine coolant (anti- specified HOAT engine coolant (antifreeze), may freeze). Use of propylene glycol-based engine result in engine damage and may decrease corro- coolant (antifreeze) is not recommended.
Page 421 MAINTAINING YOUR VEHICLE 419 Please review these recommendations for using Hybrid Please note that it is the owner’s responsibility to main- Organic Additive Technology (HOAT) engine coolant tain the proper level of protection against freezing ac- (antifreeze). When adding engine coolant (antifreeze): cording to the temperatures occurring in the area where the vehicle is operated.
Page 422 420 MAINTAINING YOUR VEHICLE rules for your community. To prevent ingestion by ani- WARNING! mals or children, do not store ethylene glycol-based • The warning words “DO NOT OPEN HOT” on engine coolant (antifreeze) in open containers or allow it to remain in puddles on the ground.
Page 423 MAINTAINING YOUR VEHICLE 421 • Do not overfill the coolant recovery bottle. of this. As long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once • Check engine coolant (antifreeze) freeze point in the a month.
Page 424: Brake System
422 MAINTAINING YOUR VEHICLE • Keep the front of the radiator clean. If your vehicle is WARNING! equipped with air conditioning, keep the front of the condenser clean. Riding the brakes can lead to brake failure and possibly a collision. Driving with your foot resting or •...
Page 425 MAINTAINING YOUR VEHICLE 423 Clean the top of the master cylinder area before removing WARNING! the cap. Add fluid to bring the level up to the “MAX” • Use only manufacturer’s recommended brake mark on the side of the master cylinder reservoir. fluid.
Page 426: Clutch Hydraulic System - Manual Transmission (If Equipped)
424 MAINTAINING YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum based fluid to contami- moisture, use only new brake fluid or fluid that nate the brake fluid. Brake seal components could has been in a tightly closed container.
Page 427: Automatic Transmission - If Equipped
MAINTAINING YOUR VEHICLE 425 bottom of the fill hole. Add fluid, if necessary, to maintain Automatic Transmission – If Equipped the proper level. Refer to “Fluids, Lubricants, and Genu- Selection Of Lubricant ine Parts” in “Maintaining Your Vehicle” for further It is important that the proper lubricant is used in the information.
Page 428 426 MAINTAINING YOUR VEHICLE policy is the use of special dyes to aid in detecting fluid CAUTION! leaks. In addition, avoid using transmission sealers as • Using a transmission fluid other than the manu- they may adversely affect seals. facturer’s recommended fluid may cause deterio- CAUTION! ration in transmission shift quality and/or torque converter shudder.
Page 429: Rear Axle
MAINTAINING YOUR VEHICLE 427 Fluid And Filter Changes Change Axle Fluid Refer to the “Maintenance Schedule” for the proper Refer to the “Maintenance Schedule” for the proper maintenance intervals. maintenance intervals. If the transmission is disassembled for any reason, the Appearance Care And Protection From Corrosion fluid and filter should be changed.
Page 430 428 MAINTAINING YOUR VEHICLE The following maintenance recommendations will enable Washing you to obtain maximum benefit from the corrosion • Wash your vehicle regularly. Always wash your ve- resistance built into your vehicle. hicle in the shade using MOPAR Car Wash or equiva- What Causes Corrosion? lent, or a mild car wash soap, and rinse the panels Corrosion is the result of deterioration or removal of...
Page 431 MAINTAINING YOUR VEHICLE 429 • If you detect any stone chips or scratches in the paint, CAUTION! touch them up immediately. The cost of such repairs is • Do not use abrasive or strong cleaning materials considered the responsibility of the owner. such as steel wool or scouring powder that will •...
Page 432 430 MAINTAINING YOUR VEHICLE Wheel And Wheel Trim Care Stain Repel Fabric Cleaning Procedure – If Equipped • All wheels and wheel trim, especially aluminum and Stain Repel seats may be cleaned in the following man- chrome plated wheels, should be cleaned regularly ner: with a mild soap and water to prevent corrosion.
Page 433 MAINTAINING YOUR VEHICLE 431 Interior Care solvents, detergents, or ammonia-based cleaners to clean Use MOPAR Fabric Cleaner or equivalent to clean fabric your leather upholstery. Application of a leather condi- upholstery and MOPAR Carpet Cleaner or equivalent tioner is not required to maintain the original condition. for carpeting.
Page 434 432 MAINTAINING YOUR VEHICLE Do not use abrasive cleaning components, solvents, steel Cleaning Plastic Instrument Cluster Lenses wool or other aggressive material to clean the lenses. The lenses in front of the instruments in this vehicle are molded in clear plastic. When cleaning the lenses, care Glass Surfaces must be taken to avoid scratching the plastic.
Page 435: Fuses
MAINTAINING YOUR VEHICLE 433 If the belts need cleaning, use MOPAR Total Clean or equivalent, a mild soap solution, or lukewarm water. Do not remove the belts from the vehicle to wash them. Dry with a soft cloth. Replace the belts if they appear frayed or worn or if the buckles do not work properly.
Page 436 434 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Description CAUTION! Fuse Fuse • When installing the integrated power module — 15 Amp Washer Motor cover, it is important to ensure the cover is prop- Blue erly positioned and fully latched. Failure to do so —...
Page 437 MAINTAINING YOUR VEHICLE 435 Cavity Cartridge Mini- Description Cavity Cartridge Mini- Description Fuse Fuse Fuse Fuse — — — 50 Amp — Radiator Fan Motor 30 Amp — Windshield Wiper Pink — — — 30 Amp — Anti-Lock Brake — —...
Page 438: Rear Power Distribution Center
436 MAINTAINING YOUR VEHICLE Rear Power Distribution Center CAUTION! There is also a power distribution center located in the • When installing the power distribution center trunk under the spare tire access panel. This center contains fuses and relays. cover, it is important to ensure the cover is prop- erly positioned and fully latched.
Page 439 MAINTAINING YOUR VEHICLE 437 Cavity Cartridge Mini- Description Cavity Cartridge Mini- Description Fuse Fuse Fuse Fuse 60 Amp — Ignition Off Draw 30 Amp — Heated Seats – If Yellow (IOD) Cavity 1 of Pink Equipped the Rear Power — 20 Amp Fuel Pump Distribution Center...
Page 440 438 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Description Cavity Cartridge Mini- Description Fuse Fuse Fuse Fuse 12 * — — — — — — 13 * — — — — — — — 10 Amp AC Heater — — — Control/Cluster/ —...
Page 441 MAINTAINING YOUR VEHICLE 439 Cavity Cartridge Mini- Description Cavity Cartridge Mini- Description Fuse Fuse Fuse Fuse — 5 Amp Cluster/Electronic — 5 Amp Antenna Module – Orange Stability Program Orange If Equipped/Power (ESP)/Powertrain Mirrors Control Module — 25 Amp Hands-Free Phone (PCM)/STOP Natural –...
Page 442: Vehicle Storage
440 MAINTAINING YOUR VEHICLE breaker in cavity 12. The door modules, the driver power Cavity Cartridge Mini- Description window switch, and the passenger power window Fuse Fuse switch are fused by the 25 Amp circuit breaker in cavity — 5 Amp Auto Inside Rear- 13.
Page 443: Replacement Bulbs
MAINTAINING YOUR VEHICLE 441 REPLACEMENT BULBS LIGHT BULBS – Exterior Bulb Number Headlamp – High Intensity Discharge (HID) ..D1S (Serviced at Authorized Dealer) LIGHT BULBS – Interior Bulb Number Halogen Headlamp..... . . H13 Rear Courtesy/Reading Lamps .
Page 444: Bulb Replacement
442 MAINTAINING YOUR VEHICLE BULB REPLACEMENT WARNING! Low Beam Headlamp, High Beam Headlamp, A transient high voltage occurs at the bulb sockets of Park/Turn Lamp — Models With Halogen HID headlamps when the headlamp switch is turned Headlamps — If Equipped ON.
Page 445: Tail/Turn And Stop Lamp
MAINTAINING YOUR VEHICLE 443 NOTE: • If a screwdriver is used, make sure a soft material is placed between the vehicle body and tool so not to scratch the paint. 2. Rotate the bulb’s socket counterclockwise, and remove the bulb and socket assembly from the housing. 3.
Page 446 444 MAINTAINING YOUR VEHICLE 3. Remove the fasteners from the back of the tail lamp 6. Pull the tail lamp assembly clear from the vehicle to assembly. access the bulbs. 4. Pull back the trunk liner. 7. Push the electrical connector locking tab to the side. 5.
Page 447 MAINTAINING YOUR VEHICLE 445 10. Disconnect the bulb from the socket assembly and install the replacement bulb. 11. Reinstall the bulb and socket assembly into the tail lamp assembly, and then turn it clockwise. 12. Reinstall the tail lamp assembly, fasteners, electrical connector, and trunk liner.
Page 448: Center Tail/Backup Lamp
446 MAINTAINING YOUR VEHICLE 14. Close the trunk. Center Tail/Backup Lamp See your authorized dealer for bulb replacement. Center High-Mounted Stop Lamp (CHMSL) The CHMSL uses LED lamps that are not serviceable separately. The CHMSL must be replaced as an assembly, see your authorized dealer.
Page 449: Fluid Capacities
MAINTAINING YOUR VEHICLE 447 FLUID CAPACITIES U.S. Metric Fuel (Approximate) All Engines 19 Gallons 72 Liters Engine Oil with Filter 3.6 Liter Engine (SAE 5W-30, API Certified) 6 Quarts 5.6 Liters 5.7 Liter Engine (SAE 5W-20, API Certified) 7 Quarts 6.6 Liters Cooling System * 3.6 Liter Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile...
Page 450: Engine
448 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent. Engine Oil – 3.6L Engine Use API Certified SAE 5W-30 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 451: Chassis
MAINTAINING YOUR VEHICLE 449 Chassis Component Fluid, Lubricant, or Genuine Part Manual Transmission – If Equipped MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. Automatic Transmission – If MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Equipped ATF+4 product. Brake Master Cylinder MOPAR DOT 3, SAE J1703 or equivalent should be used.
Page 453 MAINTENANCE SCHEDULES CONTENTS ▫ Required Maintenance Intervals ..454 Maintenance Schedule ....452...
Page 454 452 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE On Non-EVIC equipped vehicles, “Change Oil” will flash The Scheduled Maintenance services listed in this in the instrument cluster odometer and a single chime manual must be done at the times or mileages specified will sound, indicating that an oil change is necessary. to protect your vehicle warranty and ensure the best Based on engine operation conditions, the oil change vehicle performance and reliability.
Page 455 MAINTENANCE SCHEDULES 453 oil if it has been six months since your last oil change, referring to the steps described under “Electronic Vehicle even if the oil change indicator message is NOT Information Center (EVIC)/Oil Change Required” in illuminated. “Understanding Your Instrument Panel” or under “In- strument Cluster Description/Odometer/Trip Odom- •...
Page 456 454 MAINTENANCE SCHEDULES Once A Month At Each Oil Change • Check tire pressure and look for unusual wear or • Change the engine oil filter. damage. • Inspect the brake hoses and lines. • Inspect the battery, and clean and tighten the terminals CAUTION! as required.
Page 457 MAINTENANCE SCHEDULES 455 8,000 Miles (13,000 km) or 16,000 Miles (26,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 458: Service Schedule
456 MAINTENANCE SCHEDULES 24,000 Miles (39,000 km) or 32,000 Miles (52,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 459 MAINTENANCE SCHEDULES 457 40,000 Miles (65,000 km) or 48,000 Miles (78,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 460 458 MAINTENANCE SCHEDULES 56,000 Miles (91,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 56,000 miles (91 000 km). Odometer Reading Date Repair Order #...
Page 461 MAINTENANCE SCHEDULES 459 64,000 Miles (104,000 km) or 48 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 64,000 miles (104 000 km). ❏...
Page 462 460 MAINTENANCE SCHEDULES 72,000 Miles (117,000 km) or 80,000 Miles (130,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 463 MAINTENANCE SCHEDULES 461 88,000 Miles (143,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88,000 miles (143 000 km). Odometer Reading Date Repair Order #...
Page 464 462 MAINTENANCE SCHEDULES 96,000 Miles (156,000 km) or 72 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96,000 miles (156 000 km). ❏...
Page 465 MAINTENANCE SCHEDULES 463 104,000 Miles (169,000 km) or 112,000 Miles (182,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 466 464 MAINTENANCE SCHEDULES 120,000 Miles (195,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120,000 miles (195 000 km). ❏...
Page 467 MAINTENANCE SCHEDULES 465 128,000 Miles (208,000 km) or 96 Months Maintenance Service 136,000 Miles (221,000 km) or Schedule 102 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 468 466 MAINTENANCE SCHEDULES 144,000 Miles (234,000 km) or 108 Months Maintenance Service 152,000 Miles (247,000 km) or Schedule 114 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 469 MAINTENANCE SCHEDULES 467 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 471: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or Suggestions For Obtaining Service For Your Vehicle......471 Speech Impaired (TDD/TTY) .
Page 472 470 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades Department Of Transportation Uniform Tire ....477 Quality Grades ......476 ▫...
Page 473: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 471 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 474: Chrysler Group Llc Customer Center
472 IF YOU NEED CONSUMER ASSISTANCE • Vehicle delivery date and mileage This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- Chrysler Group LLC Customer Center solved with this process. P.O.
Page 475: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 473 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 476: Warranty Information
474 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment WARRANTY INFORMATION when you purchased the vehicle. An authorized dealer See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
Page 477: In Canada
IF YOU NEED CONSUMER ASSISTANCE 475 If NHTSA receives similar complaints, it may open an Canada, Motor Vehicle Defect Investigations and Recalls at investigation, and if it finds that a safety defect exists in 1-800-333-0510 or go to http://www.tc.gc.ca/roadsafety/ a group of vehicles, it may order a recall and remedy PUBLICATION ORDER FORMS campaign.
Page 478: Department Of Transportation Uniform Tire
476 IF YOU NEED CONSUMER ASSISTANCE LLC vehicles. A complete working knowledge of the acquaint you with specific Chrysler Group LLC ve- vehicle, system, and/or components is written in hicles. Included are starting, operating, emergency straightforward language with illustrations, diagrams, and maintenance procedures as well as specifications, and charts.
Page 479: Traction Grades
IF YOU NEED CONSUMER ASSISTANCE 477 in each category is shown on the sidewall of the tires on wet pavement, as measured under controlled conditions your vehicle. on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction perfor- All passenger car tires must conform to Federal safety mance.
Page 480 478 IF YOU NEED CONSUMER ASSISTANCE grade C corresponds to a level of performance, which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel, than the minimum required by law.
Page 481 INDEX...
Page 482 480 INDEX About Your Brakes ....291,295 Airbag, Side ......60,63,66 ABS (Anti-Lock Brake System) .
Page 483 INDEX 481 Automatic Door Locks ..... 33 Keyless Transmitter Replacement (RKE) ..26 Automatic Headlights ....147 Location .
Page 484 482 INDEX Bulbs, Light ......87,441 Checks, Safety ......82 Child Restraint .
Page 485 INDEX 483 Console ......177 Customer Assistance ..... 471 Console, Floor .
Page 486 484 INDEX Door Locks ......31 Emergency, In Case of Door Locks, Automatic ....33 Freeing Vehicle When Stuck .
Page 487 INDEX 485 Flooded, Starting ..... 268 Exhaust Gas Caution ....83,342 Fuel Requirements .
Page 488 486 INDEX Fluid Leaks ......87 Gasoline ......338 Fluid Level Checks Gauge .
Page 489 INDEX 487 Gasoline, Clean Air ..... . 339 Hazard Gasoline, Reformulated ....339 Driving Through Flowing, Rising, or Shallow Gauges Standing Water .
Page 490 488 INDEX Heater, Engine Block ..... 270 Integrated Power Module (Fuses) ... . 433 High Beam/Low Beam Select (Dimmer) Switch .
Page 491 INDEX 489 Kicker Sound System ..... 244 Brake Warning ....191,295 Knee Bolster .
Page 492 490 INDEX High Beam/Low Beam Select ... . 151 Tire Pressure Monitoring (TPMS) ..193,328 Illuminated Entry ..... 21 Traction Control .
Page 493 INDEX 491 Maintenance Free Battery ....408 Outside ......95 Maintenance Procedures .
Page 494 492 INDEX Oil Filter, Change ......407 Outside Rearview Mirrors ....95 Oil Filter, Selection .
Page 495 INDEX 493 Distribution Center (Fuses) ....436 Radio Remote Controls ....246 Door Locks .
Page 496 494 INDEX Replacement Keys ......17 Seat Belt Reminder ..... . . 55 Replacement Parts .
Page 497 INDEX 495 Seatback Release ..... 143 Shoulder Belts ......46 Tilting .
Page 498 496 INDEX Cold Weather ..... . . 268 Sunroof Maintenance ..... 171 Engine Fails to Start .
Page 499 INDEX 497 TIREFIT ......364 Rotation ......327 Tires .
Page 500 498 INDEX Cooling System Tips ....358 Transmitter, Remote Keyless Entry (RKE) ..21 Hitches ......350 Transporting Pets .
Page 501 INDEX 499 Vehicle Certification Label ....345 Water Vehicle Identification Number (VIN) ... . 6 Driving Through .
Page 502 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 503 Chrysler Group LLC 3rd Edition Printed in U.S.A. 12D491-126-AC...

Dodge Challenger 2012 Owner's Manual

Table of Contents

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

Quick Links

Chapters

Related Manuals for Dodge Challenger 2012

Summary of Contents for Dodge Challenger 2012
