- Page 1 Belt Driven Compressor Operation Manual Model No. SACBD-100 www.synairgy-eu.com...
-
Page 2: Table Of Contents
Contents Important Notice Preparation for Usage Safety Guidelines Caution Brief Description Compressor Overview Technical Specification Parts List Operation and Adjustment Maintenance Troubleshooting Belt Driven Compressor Operation Manual Model No. SACBD-100... -
Page 3: Important Notice
The normal working temperature should be -5°C - +35°C The normal working temperature of the air compressor is 180°C and the lubricating oil in the crankcase is 70°C Open the outlet valve and let the air compressor run for 10 minutes without load before operation www.synairgy-eu.com... -
Page 4: Safety Guidelines
If you are using these solvents, please use only stainless steel spray equipment. Never directly inhale the compressed air produced by a compressor. Belt Driven Compressor Operation Manual Model No. SACBD-100... - Page 5 Fasten the compressor down securely, and release the pressure from the tank before transportation Protect the air hose and electrical wire from damage and punctures. Inspect them weekly for weak or worn spots, and replace them if necessary www.synairgy-eu.com...
-
Page 6: Caution
11. The maximum decibel of the compressor is 89db Brief Description This range of Synairgy belt driven air compressors are built with performance and reliability in mind. These units are designed for use in industrial and commercial environments, with the air capacity and power to drive many of the most commonly used air compressor tools. -
Page 7: Compressor Overview
Motor Air pump Air tank Air regulator Wheel Handle Safety relief valve Technical Specification Rated Voltage Power Cylinder Capacity Pressure Tank Speed Code V/Hz KW hp mm*n l/min C.F.M bar/psi Usgal SACBD-100 220/50 2.2 3.0 Ø55*2 1050 8/115 6.34 www.synairgy-eu.com... -
Page 8: Parts List
Parts List Belt Driven Compressor Operation Manual Model No. SACBD-100... - Page 9 Release pipe Crank case Discharge pipe Bearing Starting capacitor Crank shaft Working capacitor Oil seal Pressure gauge 40mm Pump pulley Handle Breather pipe Crank case side cover Oil level indicator Baseboard for crank case Check valve Air tank Air switch www.synairgy-eu.com...
-
Page 10: Operation And Adjustment
Open the drain cock under the tank to exhaust condensation after every 60 working hours Clean the crankcase every 120 working hours and renew the oil, clean the air filter, check the safety valve and pressure gauge Belt Driven Compressor Operation Manual Model No. SACBD-100... -
Page 11: Troubleshooting
1. The oil level is too high 1. Keep the level within the set range consumption (in the middle of oil indicator) 2. Breather pipe is blocked 2. Check and clean 3. Piston ring and cylinder worn or damaged 3. Replace with new one www.synairgy-eu.com... -
Page 12: Belt Driven Compressor Operation Manual Model No. Sacbd
Belt Driven Compressor Operation Manual Model No. SACBD-100...
