ETHANoL FirEpLAcE
Model: SOEMM808-47CCN
Patent Pending
INSTRUCTION MANUAL
ATTENTioN: Find a location for the ethanol fireplace that is
protected from direct sunlight.
IMpORTANT:
rEAd THis mANuAL cArEFuLLy To LEArN How
To AssEmBLE, opErATE ANd mAiNTAiN your
producT propErLy. iT is EssENTiAL THAT you
or ANy oTHEr opErATor oF THE AppLiANcE
rEAd ANd uNdErsTANd THE coNTENTs oF THis
mANuAL BEForE opErATiNg THE AppLiANcE. THE
iNFormATioN iN THis mANuAL cAN HELp you ANd
oTHErs Avoid iNjury ANd producT dAmAgE.
sTorE THis mANuAL iN A sAFE pLAcE For FuTurE
rEFErENcE.
This manual identifies potential hazards and has special safety
messages that help you and others avoid personal injury and
even death. Danger, Warning and Caution are signal words used
to identify the level of hazard.
wArNiNg sigNALs A HAzArd THAT mAy cAusE
sErious iNjury or dEATH iF you do NoT
FoLLow THE rEcommENdEd prEcAuTioNs.
cAuTioN sigNALs A HAzArd THAT mAy cAusE
miNor or modErATE iNjury iF you do NoT
FoLLow THE rEcommENdEd prEcAuTioNs.
However, regardless of the hazard, be extremely careful.
CAUTION:
IMpORTANT SAFETY INSTRUCTIONS
If you have any problems with this unit or there are missing or
damaged parts, please call toll free: 1-800-459-4409. DO NOT
RETURN THE UNIT TO THE PLACE OF PURCHASE before calling
the toll free number above.
wArNiNg - do NoT ToucH THE FirEpLAcE
wHiLE iT is BurNiNg. ALLow AT LEAsT 15
miNuTEs To cooL dowN AFTEr THE FLAmE
is ExTiNguisHEd For ANy rEFiLL / rEsTArT /
cLEANiNg / mAiNTENANcE.
wArNiNg - do NoT smoKE wHiLE HANdLiNg
FuEL.
wArNiNg - risK oF FirE ANd BurN iNjury.
NEvEr pour FuEL iNTo THE BurNiNg FLAmE!
wArNiNg - ALLow THE BurNEr To cooL
dowN For AT LEAsT 15 miNuTEs BEForE
rEFiLLiNg. do NoT pour FuEL iNTo A HoT
BurNEr!
wArNiNg - KEEp cHiLdrEN ANd ANimALs
AwAy From THE FirEpLAcE.
wArNiNg - do NoT sTorE / pLAcE FLAmmABLE
goods cLosE To FirEpLAcE.
wArNiNg - FuEL musT BE KEpT A sAFE
disTANcE oF AT LEAsT 1m (40 iN) From THE
FirEpLAcE. do NoT pLAcE FuEL iN FroNT oF
THE FirEpLAcE.
wArNiNg - rEsTricT THE usE oF THis producT
To pErsoNs wHo rEAd, uNdErsTANd ANd
FoLLow THE wArNiNgs ANd iNsTrucTioNs iN
THis mANuAL ANd oN THE uNiT.
wArNiNg - THis AppLiANcE HAs NoT BEEN
TEsTEd wiTH AN uNvENTEd gAs Log sET. To
rEducE risK oF FirE or iNjury, do NoT
iNsTALL AN uNvENTEd gAs Log sET iNTo THE
AppLiANcE.
wArNiNg - THis FirEpLAcE iNsErT cANNoT
BE usEd ALoNE ANd cANNoT BE iNsTALLEd
iN oTHEr FirEpLAcE mANTEL. FoLLow THE
iNsTALLATioN iNsTrucTioNs ANd usE oNLy iN
THis FirEpLAcE.
check with your insurance company, landlord or local
authorities for details and regulations before using the
fireplace.
The fireplace must only be installed on a solid wall of
non-flammable material.
The ethanol fire will use oxygen from the air inside
the room where it is operated. The room should be
well ventilated with enough oxygen and fresh air being
supplied (i.e. open windows).
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOEMM808-47CCN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sylvania SOEMM808-47CCN

Summary of Contents for Sylvania SOEMM808-47CCN

  • Page 1 CAUTION: IMpORTANT SAFETY INSTRUCTIONS ETHANoL FirEpLAcE Model: SOEMM808-47CCN If you have any problems with this unit or there are missing or damaged parts, please call toll free: 1-800-459-4409. DO NOT Patent Pending RETURN THE UNIT TO THE PLACE OF PURCHASE before calling the toll free number above.
  • Page 2 The room where the fireplace is operated should not be TOOLS REQUIRED: PHILLIPS HEAD SCREWDRIVER smaller than 44 cubic meters (1550 cubic feet). The area of the room needs to be at least 20 square meters (215 square feet) with a ceiling height of 2.3 meter (8 feet). it is not recommended to use more than one fireplace at a time in one room.

  • Page 3: Product Labels

    pROdUCT LAbELS wArNiNg - rEAd, uNdErsTANd ANd FoLLow ALL sAFETy LABELs ANd mArKiNgs oN THE uNiT.
  • Page 4 MANTEL ANd INSERT ASSEMbLY: NoTE: Place a piece of cardboard or protective sheet on the floor in order to avoid scratching the decorative surface of your mantel during assembly. Please DO NOT fully tighten the KD screws until all panels are assembled. NOTE: If the KD screw(s) do not fit during assembly, loosen the 2 screws to adjust the plastic connector until the panel/ KD screws are able to be installed.
  • Page 5 Step 6: Attach panel C to the unit as shown in Fig. F with 6 KD screws. Fig. H Step 9: Attach 4 mounting brackets [U] with 4 KD screws at the bottom of insert (2 mounting bracket at each side). See Fig.

  • Page 6: Operation

    3) Attach the safety cable to the mantle using the screw for wArNiNg – do NoT ExcEEd mAximum FuEL mantel. See Fig. J. cApAciTy - 1.8 LiTrEs. Fig. 2 Fig. j 4) Use the screw for wall to attach the other end of safety cable to the wall.

  • Page 7: Cleaning And Maintenance

    2) If you wish to extinguish the flame before the fuel is 5) The flame will ignite slowly and grow to full size in 5 to 10 completely burned out, push the front handle of burner minutes. The flame intensity control knob can be turned until opening of burner is completely closed.
  • Page 8 REpAIR SET 2. Drill the holes with diameter 3/4 inches (10 mm) and depth 3/4 inches (10 mm) on the mantel. Each plastic connector needs 3 holes. See Fig. C. TOUCH-Up REpAIR pAINT Fig. c Paint directly on the mantel unit if necessary. Fig. A. 3.
  • Page 9 2. Drill the holes with diameter 1/16 inches (2 mm) and depth This warranty is void if in the opinion of Quality Craft, the 5/16 inches (8 mm) on the mantel. Each small l-bracket unit has been tampered with, altered, misused, damaged, needs 4 holes.
