VHF/UHF Amplified Antenna
(illus)
Your RadioShack VHF/UHF Amplified Antenna provides
excellent reception of VHF and UHF broadcast TV chan-
nels in most viewing locations. The antenna's supplied
power injector helps you boost the signal through a long
coaxial cable for better reception. You can connect the an-
tenna either directly to your TV or to your direct-to-home
satellite system. The antenna's compact modern styling
blends well with the decor of almost any home, and you
can install it in a variety of places such as your attic, loft,
or garage. The antenna's UV-protected housing is made
of impact-resistant filled copolymer, making the exterior
resistant to weathering and color change. The antenna's
built-in fixed FM trap helps prevent strong FM stations
from interfering with TV Channels 2–13.

IMPORTANT SAFETY PRECAUTIONS

Many do-it-yourself and professional antenna installers are
injured or killed each year by electric shock. Many power
wires are within 20 to 25 feet of the ground and could easi-
ly be touched by an assembled antenna or cable. Touch-
ing the overhead wires with any part of the antenna is the
same as touching the wires with your bare hand. Contact-
ing an electrical wire almost always results in a very seri-
ous shock.
WARNING! When you install an outdoor antenna,
use extreme caution. If the antenna starts to fall,
let it go! It could contact overhead power lines. If
the antenna touches the power line, contact with
the antenna, mast, cable, or guy wires can cause
electrocution and death. Call the power company
to remove the antenna. Do not attempt to remove
it yourself!
© 1997 Tandy Corporation.
All Rights Reserved.
RadioShack is a registered trademark used by Tandy Corporation.
To avoid electric shock, please read and follow these im-
portant safety precautions:
• Be sure to select an antenna site well away from all
overhead wires.
• Do not try to guess which overhead wires carry high
voltage. Check with the power company.
• If you notice anything making contact with the over-
head wires, call the power company to have it
removed safely.
• Do not run the antenna's cable over power wires.
• Get help from a qualified professional when removing
the old antenna if there is any doubt of clearing over-
head wires.
• Never install an antenna by yourself. Be sure to have
at least two people available for help, if needed.
• Never install the antenna when it is windy.

BEFORE YOU BEGIN

Be sure to remove these items before you store or dis-
pose of the packing material.
• Antenna (1)
• Outside diplexer (1)
• Inside diplexer (1)
1
• 1
/
-inch screws (3)
4
• AC adapter/power injector (1)
(illus)
You also need the following items, available at your local
RadioShack store:
• 75-ohm coaxial cable RG-6/U (such as Cat. No. 278-
1316)
• Sealant tape (such as Cat. No. 278-1645)
Depending upon your audio/video system setup, you
might need additional cables or adapters.
15-1847
Cat. No.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15-1847 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Radio Shack 15-1847

  • Page 1: Before You Begin

    15-1847 Cat. No. VHF/UHF Amplified Antenna To avoid electric shock, please read and follow these im- portant safety precautions: • Be sure to select an antenna site well away from all overhead wires. • Do not try to guess which overhead wires carry high voltage.
  • Page 2: Coaxial Cable Installation Precautions

    Coaxial Cable Installation Precautions 3. Thread one of the supplied screws through the an- tenna’s center mounting hole. Then use a Phillips • Do not bend coaxial cable (RG-6/U) into less than a screwdriver to temporarily secure the antenna to the 3-inch radius.
  • Page 3: Connecting The Antenna

    CONNECTING THE ANTENNA 4. Plug the AC adapter into a standard AC outlet. You can connect your antenna directly to your TV or ex- isting direct-to-home satellite system. (illus) Caution: Do not connect devices such as amplifiers, splitters, combiners, or matching transformers between the power injector and the antenna.
  • Page 4 1. Connect one end of a 75-ohm coaxial cable to the 9. To amplify the antenna’s signal, set on the OFF/ON antenna’s jack, then seal the connection with sealant power injector to tape. 2. Connect the other end of the coaxial cable to the supplied outside diplexer.
  • Page 5: Troubleshooting

    TROUBLESHOOTING If you have problems, here are some suggestions that might help. If you still have trouble, contact your local RadioShack store for assistance. PROBLEM POSSIBLE CAUSE REMEDY All or most channels are not received The power injector is not turned on. OFF/ON clearly.
  • Page 6 Limited Ninety-Day Warranty This product is warranted by RadioShack against manufacturing defects in material and workman- ship under normal use for ninety (90) days from the date of purchase from RadioShack company- owned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES...
