- Page 1 Compressor MODEL NUMBER: AS18-2 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508530 YEAR WEBSITE: www.airbrushheaven.co.uk EMAIL: enquiries@airbrushheaven.co.uk WARRANTY...
-
Page 2: Table Of Contents
Contents 1. Welcome Section 2. General Information & Safety Instructions 3. Contents & Features 4. Parts & Assembly 5. General Maintenance 6. Using the Airbrush 7. Specifications 7. Trouble Shooting After Sales Support 01270 508530 UK/N.IRELAND HELPLINE N WEBSITE: www.airbrushheaven.co.uk EMAIL: enquiries@airbrushheaven.co.uk... - Page 3 Airbrush Heaven. We want you to be completely satisfied with your purchase so this AIRBRUSH HEAVEN product is backed by a comprehensive manufacturer’s 1 year warranty and outstanding after sales service through our helpline.
-
Page 4: General Information & Safety Instructions
General Information & Safety Instructions • Industrial applications must follow OSHA requirements. • Maintain a safe working environment. Keep the work area well lit and make sure there is adequate work space. • Use the product only in a well ventilated area with an ambient temperature of between 5 C &... -
Page 5: Contents & Features
Contents & Features Contents 1 x Single cylinder piston compressor 1 x Pressure regulator with gauge and water release valve 1 x 3m Air hose 1 x 3 way adaptor 1 x Compressor mounted twin airbrush holder 1 x 1/8th to 5mm Hose adaptor 1 x 1/4”... -
Page 6: Parts & Assembly
Parts & Assembly After Sales Support UK/N.IRELAND HELPLINE N 01270 508530 WEBSITE: www.airbrushheaven.co.uk EMAIL: enquiries@airbrushheaven.co.uk... - Page 7 Setup Attaching the 3 Way Adaptor • Place the female end of the 3 way adaptor to the 1/8” connector on the regulator valve and turn till tight by hand. Please Note: To attach additional hoses please remove the end caps. Using more than one airbrush simultaneously will lower the output pressure from the select pressure.
- Page 8 Reading the Gauge Setting up & using the Regulator The gauge shows both PSI (Pounds per Square Inch) and BAR (Atmospheric Presure at Sea Level) measurments. These are indicated with 2 rings of measurement. • BAR - Red • PSI - Black The gauge will allow you to setup the pressure accurately.
-
Page 9: Specifications
Specifications • Single cylinder piston compressor • 1/6HP • 1450/1700 rpm • 20-23 L/Min Airflow • 0-57psi maximum pressure • 3.6kg total weight • 275mm X 140mm X 220mm overall dimensions Trouble Shooting PROBLEM CAUSE SOLUTION No Air Not connected to mains Check mains is connected Not switched on... -
Page 10: Proof Of Purchase
Warranty Certificate Warranty This product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. - Page 11 Warranty Card Compressor Model Number: AS18-2 Please keep your purchase receipt/invoice together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: We recommend that you attach a photocopy of your receipt/invoice, showing the date of purchase, to this warranty card and keep it for your reference.
- Page 12 For further help, advice and video demonstrations please visit: www.airbrushheaven.co.uk...
