Philips HX 2585 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
- Gum Protection System : The brush automatically fl exes back
- Active tip : Removes plaque between the teeth
- Number of brush heads
included in fancy box : 3
- Colours : White/ grey
- Timer / charging light : The pilot light blinks green during
- Waterproof : Yes
- Anti rolling strip : To prevent the appliance from
TECHNICAL DATA
Voltage
Power consumption
Speed (top)
Gum Protection System click at : 270 gr.
Charging time (empty to full)
Operating time (full to empty)
Battery type
Product meets the requirements regarding
interference suppression on radio and TV.
Published by Philips Domestic Appliances and Personal Care
4322 277 00936
02/06
when too much pressure is applied.
Because of this signal, the user will
develop a safe and effi cient brushing
technique.
charging.
When the brush time of two
minutes has passed, the pilot light
blinks red.
rolling away
: 110-127 V; 200-240 V, 50-60 Hz
: 2.8 Watts
: up to 15.000 brush strokes
per minute
: 16 hours
: ± 25 minutes
: NiCd
SERVICE INFORMATION
Hand unit tooth brush (1)
Never open the hand unit of the toothbrush because the
unit is no longer watertight after it has been opened.
Replace the entire unit in case of a defect.
When discarding the hand unit, remove the built-in
rechargeable battery.
The battery should be completely empty.
For instructions p.t.o.
Charging unit (2)
In case of a defective charging unit or damaged cord the
complete charging unit must be replaced.
Charging tips
· The appliance will only charge if the appliance is
switched off.
· Please note that the electricity supply to sockets in mirror
cabinets over washbasins or shaver sockets in bathrooms
may be cut off when the light is switched off.
· The toothbrush can be put back in the stand after use and
left to charge continuously. However, to extend the lifetime
of the battery proceed as follows:
When the appliance is used for the fi rst time, continue to
use it until the battery is empty.
Use the appliance in the normal way without recharging it
between the brushing sessions.
Recharge the appliance when the motor almost stops
running.
Repeat this procedure 3 times in a row every 6 months.
Printed in the Netherlands © Copyright reserved
Tooth brush
HX 2585
Subject to modification
