Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine. The
use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
Please read the operator's manual carefully and make sure you understand the instructions
before using the machine.
584 84 86-27 Rev. 3
MOWCART 66
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOWCART 66 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for McCulloch MOWCART 66

Summary of Contents for McCulloch MOWCART 66

  • Page 1 MOWCART 66 English Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine. The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty. Please read the operator's manual carefully and make sure you understand the instructions before using the machine.
  • Page 2 SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Never leave a running machine unattended. Always turn WARNING: In order to prevent ac ci den tal off blades, set parking brake, stop engine, and remove starting when setting up, trans port ing,...

  • Page 3: Safety Rules

    SAFETY RULES Safe Operation Practices for Ride-On Mowers III. CHILDREN • If fuel is spilled on clothing, change clothing immediately. • Never overfill fuel tank. Replace gas cap and tighten securely. WARNING. CHILDREN CAN BE INJURED BY THIS EQUIPMENT. The American Academy GENERAL SERVICE of Pediatrics recommends that children be a •...

  • Page 4: Table Of Contents

    PRODUCT SPECIFICATIONS CUSTOMER RESPONSIBILITIES • Read and observe the safety rules. Gasoline Capacity 1.25 Qt./1,18 L • Follow a regular schedule in main tain ing, caring for and using your riding mower. and type: Regular Unleaded • Follow the instructions under “Main te nance” and “Stor age” Power Rating: 3.44 kW @ 2800 RPM sec tions of this manual.
  • Page 5 UNASSEMBLED PARTS...

  • Page 6: Assembly

    ASSEMBLY Your new riding mower has been assembled at the factory with the exception of those parts left unassembled for ship- ping purposes. To ensure safe and proper operation of your riding mower all parts and hardware you as sem ble must be tightened securely.
  • Page 7 ASSEMBLY CHECK TIRE PRESSURE The tires on your riding mower were overinflated at the factory for shipping purposes. Correct tire pressure is important for best cutting performance. • Reduce tire pressure to PSI shown on tires. CHECK DECK LEVELNESS Flat Washer For best cutting results, mower housing should be properly leveled.

  • Page 8: Operation

    OPERATION These symbols may appear on your riding mower or in literature supplied with the product. Learn and understand their meaning. REVERSE NEUTRAL HIGH CHOKE FAST SLOW IGNITION SWITCH ENGINE ENGINE ENGINE DIFFERENTIAL CLUTCH/ PARKING MOWER MOWER START LOCK BRAKE PEDAL BRAKE HEIGHT LIFT...
  • Page 9 OPERATION KNOW YOUR RIDING MOWER READ THIS OPERATOR'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR RIDING MOWER Compare the illustrations with your riding mower to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Parking Brake Pedal Brake...
  • Page 10 OPERATION The op er a tion of any riding mower can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Al ways wear safety glass es or eye shields while op er at ing your riding mower or per form ing any ad just ments or repairs.

  • Page 11: Before Starting The Engine

    OPERATION TO OPERATE ON HILLS 1. Select desired height of cut. 2. Start mower blade by engaging deck clutch lever. WARNING: Do not drive up or down hills with slopes TO STOP MOWER BLADE- great er than 15° and do not drive across any slope. Use Disengage deck clutch lever.

  • Page 12: Mowing Tips

    OPERATION ADD GASOLINE MOWING TIPS • Fill fuel tank to bottom of filler neck. Do not overfill. Use • Mower should be properly leveled for best mowing per- fresh, clean, regular gasoline with a minimum of 87 formance. See “TO LEVEL MOWER HOUSING” in the octane.

  • Page 13: Maintenance Schedule

    MAINTENANCE MAINTENANCE GENERAL RECOMMENDATIONS BEFORE EACH USE The warranty on this riding mower does not cover items that 1. Check engine oil level. have been subjected to operator abuse or negligence. To 2. Check brake operation. receive full value from the warranty, operator must main tain 3.

  • Page 14: Blade Care

    MAINTENANCE RIDING MOWER • The deck clutch lever should never operate unless the operator is in the seat. Always observe safety rules when per form ing any CHECK REVERSE OPERATION (ROS) SYSTEM main te nance. • When the engine is running with the ignition switch in the BRAKE OPERATION engine "ON"...
  • Page 15 MAINTENANCE BATTERY TO CHANGE ENGINE OIL Determine temperature range expected before oil change. Your riding mower has a battery charging sys tem which is All oil must meet API service classification SG-SL. suf fi cient for normal use. • Keep battery and connectors clean. •...
  • Page 16 MAINTENANCE CLEAN AIR SCREEN AIR FILTER The air screen is over the air intake blower located on top Your engine will not run properly using a dirty air filter. of engine. The air screen must be kept free of dirt and Replace the air filter every 100 hours of operation or every chaff to prevent engine dam age from overheating.

  • Page 17: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: 1. Depress clutch/brake pedal fully and set parking brake. 2. Place motion control lever in neutral (N) position. 3. Place deck clutch in “DISENGAGED” position. 4.
  • Page 18 SERVICE AND ADJUSTMENTS TO LEVEL MOWER HOUSING "G" "H" Adjust the mower while riding mower is parked on level ground or driveway. Make sure tires are properly inflated (See side of tire for proper PSI). If tires are over or under- inflated, you will not properly adjust your mower.
  • Page 19 SERVICE AND ADJUSTMENTS TO ADJUST BRAKE NOTE: To seal tire punctures and pre vent flat tires due Your riding mower is equipped with an adjustable brake to slow leaks, purchase and use tire sealant. Tire sealant system which is mounted on the right side of the transaxle. also pre vents tire dry rot and corrosion.

  • Page 20: Interlocks And Relays

    SERVICE AND ADJUSTMENTS 1. Lift seat for bolt access. 2. Disconnect BLACK battery cable then RED battery cable. 3. Remove battery bracket bolt. 4. Install new battery with terminals facing to the right, and away from seat as shown. 5. Reinstall battery bracket and bolt. 6.

  • Page 21: Storage

    STORAGE Immediately prepare your riding mower for stor age at the ENGINE OIL end of the season or if the riding mower will not be used Drain oil (with engine warm) and replace with clean engine for 30 days or more. oil.

  • Page 22: Troubleshooting Points

    TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION Out of fuel. Fill fuel tank. Will not start Bad spark plug. Replace spark plug. Dirty air filter. Clean/replace air filter. Water in fuel. Empty fuel tank and carburetor, refill tank with fresh gasoline and replace fuel filter.
  • Page 23 TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION Engine continues to Faulty operator-safety presence Check wiring, switches and control system. connections. If not corrected, run when operator contact a qualified service center. leaves seat with attachment clutch CAUTION: DO NOT engaged operate machine until problem is corrected.
  • Page 24 02.11.14 BD Printed in U.S.A.
