Summary of Contents for Opel MOVANO 2013

  • Page 1 OPEL MOVANO Owner's Manual...

  • Page 3: Table Of Contents

    Contents Introduction ........2 In brief ..........6 Keys, doors and windows .... 19 Seats, restraints ......36 Storage ........61 Instruments and controls ..... 69 Lighting ........88 Climate control ......95 Driving and operating ....107 Vehicle care ....... 133 Service and maintenance ..

  • Page 4: Introduction

    Introduction Introduction...

  • Page 5: Introduction

    "Service and prices. Experienced mechanics ■ The Owner's Manual uses the maintenance" and "Technical data" trained by Opel work according to factory engine designations. The as well as on the identification plate. specific Opel instructions. corresponding sales designations...
  • Page 6 Text marked Caution provides information on possible damage to the vehicle. Disregarding this information may lead to vehicle damage. Symbols Page references are indicated with 3. 3 means "see page". We wish you many hours of pleasurable driving. Adam Opel AG...
  • Page 7 Introduction...

  • Page 8: In Brief

    In brief In brief Vehicle unlocking Unlocking with remote control Unlocking with key Initial drive information Press button c to unlock the front doors. Press again to unlock entire vehicle. Turn the key in the driver's door lock. Open the doors by pulling the Open the doors by pulling the handles.

  • Page 9: Seat Adjustment

    In brief Seat adjustment Seat backrests Seat height Seat positioning Pull lever, adjust inclination and Lever motion release lever. Allow the seat to = seat higher engage audibly. Pull handle, slide seat, release down = seat lower handle. Seat position 3 37, Seat adjustment Seat position 3 37, Seat adjustment 3 38.

  • Page 10: Head Restraint Adjustment

    In brief Head restraint adjustment Seat belt Mirror adjustment Interior mirror Press release catch, adjust height, Pull out the seat belt and engage in engage. belt buckle. The seat belt must not be twisted and must fit close against the To reduce dazzle, adjust the lever on Head restraints 3 36.

  • Page 11: Steering Wheel Adjustment

    In brief Steering wheel adjustment Exterior mirrors Electric adjustment Manual adjustment Select the relevant exterior mirror and Unlock lever, adjust steering wheel, adjust it. then engage lever and ensure it is Swivel mirror in required direction. Convex exterior mirrors 3 31, fully locked.
  • Page 12 In brief Instrument panel overview...
  • Page 13 In brief Fixed air vents ....105 Horn ........70 18 Cruise control and speed limiter ......... 122 Headlight range Driver airbag ......50 adjustment ......89 Manual transmission Remote control on automated, Ultrasonic parking assist ..125 steering wheel ....... 69 Winter and Laden modes ..
  • Page 14 In brief...

  • Page 15: Exterior Lighting

    In brief Exterior lighting Front and rear fog lights Headlight flash, high beam and low beam Turn light switch: Turn light switch: Pull lever. > = Front fog lights = Off r = Rear fog lights High beam 3 89, Headlight flash = Sidelights 3 89.
  • Page 16 In brief Horn Turn and lane-change signals Hazard warning flashers lever up = right turn signal Operated with the ¨ button. Press j. lever down = left turn signal Hazard warning flashers 3 90. Turn and lane-change signals 3 90.

  • Page 17: Washer And Wiper Systems

    In brief Washer and wiper systems Climate control Windscreen washer Windscreen wiper Heated rear window, heated exterior mirrors Pull lever. short = wiper swipes once and 0 = off pull washer fluid is sprayed Heating is operated by pressing the onto the windscreen P = timed interval wiping or Ü...
  • Page 18 In brief Transmission Demisting and defrosting the Electronic climate control system 3 97. windows Manual transmission ■ Air distribution to V. Reverse: with the vehicle stationary, ■ Set temperature control to warmest depress clutch pedal and then pull up level. the collar on the selector lever and ■...

  • Page 19: Starting Off

    In brief Starting off Manual transmission automated Starting the engine Check before starting off ■ Tyre pressure and condition 3 153, 3 190. ■ Engine oil level and fluid levels 3 135. ■ All windows, mirrors, exterior lighting and number plates are free from dirt, snow and ice and are operational.
  • Page 20 In brief Parking Stop-start system run in neutral for approx. 30 seconds before switching off, in order to protect the turbocharger. Caution ■ Switch off the engine. Turn the ignition key to position St and Do not park the vehicle on an remove it.

  • Page 21: Keys, Doors And Windows

    Keys, doors and windows Keys, doors and Keys, locks Radio remote control windows Keys Replacement keys The key number is specified in the Keys, locks ........19 Car Pass or on a detachable tag. Doors ........... 25 The key number must be quoted Vehicle security ......

  • Page 22: Central Locking System

    Keys, doors and windows Handle with care, protect it from Replace the battery (battery type moisture and high temperatures and CR2016), paying attention to the avoid unnecessary operation. installation position. Reattach both halves of cover Fault ensuring it engages correctly. If the central locking system cannot Replace screw and tighten.
  • Page 23 Keys, doors and windows Unlocking the vehicle Unlocking with 3-button remote Locking the vehicle control Close all doors and load Unlocking with 2-button remote compartment. If the doors are not control closed properly, the central locking system will not work. Locking with 2-button remote control Depending on vehicle configuration: ■...
  • Page 24 Keys, doors and windows Locking with 3-button remote control Load compartment Locking and unlocking load compartment with 3-button remote Locking and unlocking load control compartment with 2-button remote control Press button e: All doors and the load compartment are locked. Depending on vehicle configuration: Note ■...

  • Page 25: Power Door Locks

    Keys, doors and windows Fault in central locking system Unlocking Manually unlock the front door by turning the key in the lock. The other doors can be opened by pulling the interior handles. Locking Push inside locking knob of all doors except driver's door.

  • Page 26: Child Locks

    Keys, doors and windows Child locks Warning lights in the appropriate doors remain illuminated. To unlock, press 0 side of switch. 9 Warning Fault Use the child locks whenever In the event of a fault in the system, children are occupying the rear the warning light alongside the switch seats.

  • Page 27: Doors

    Keys, doors and windows Doors Power sliding door Closing Press switch again; the LED flashes Opening and a chime sounds during operation. Sliding door In the event of opening or closing difficulties, e.g. due to frost, press and hold the switch to increase power to the sliding door.
  • Page 28 Keys, doors and windows Emergency exit Maintenance Power side step In an emergency, the door can be It is the owner's responsibility to have The power side step operates opened manually after releasing the the drive belt replaced after every automatically when the power sliding interior handle.

  • Page 29: Rear Doors

    Keys, doors and windows The left-hand rear door is released The indicator illuminates during To open the doors to 180º or further, using the lever. operation of the power side step. If it release locking stays from the remains illuminated with the door catches on the door frames and swing 9 Warning closed, the step has not retracted.

  • Page 30: Vehicle Security

    Keys, doors and windows Vehicle security When opening the doors to 270º, the Activation doors are retained in the fully open position by magnets on the body side. Anti-theft locking system 9 Warning 9 Warning Ensure extended opening doors Do not use the system if there are are secured when fully opened.
  • Page 31 Keys, doors and windows ■ Load compartment Deactivation Unlocking the vehicle or switching on ■ Vehicle inclination, e.g. if it is raised the ignition deactivates the anti-theft ■ Ignition alarm system. Hazard warning lights ■ Interruption of alarm siren power flash once to confirm deactivation.
  • Page 32 Keys, doors and windows Activation without monitoring of deactivate the anti-theft alarm system Note vehicle inclination if the vehicle battery must be The immobiliser does not lock the disconnected. doors. You should always lock the Additionally, disable monitoring of vehicle after leaving it and switch on vehicle inclination because of high To silence the alarm siren (if the anti-theft alarm system 3 20,...

  • Page 33: Exterior Mirrors

    Keys, doors and windows Exterior mirrors Electric adjustment Folding mirrors Convex shape The convex exterior mirror contains an aspherical area and reduces blind spots. The shape of the mirror makes objects appear smaller, which will affect the ability to estimate distances.

  • Page 34: Interior Mirrors

    Keys, doors and windows Interior mirrors Heated mirrors Heating works with the engine running and is switched off automatically after a short time. Manual anti-dazzle Climate control system 3 95. Electronic climate control system 3 97. Operated by pressing the Ü button on either system.

  • Page 35: Windows

    Keys, doors and windows Windows Overload If the windows are repeatedly Manual windows operated within short intervals, the window operation is disabled for The door windows can be opened or some time. closed with the window winders. Rear windows Power windows Sliding side windows 9 Warning Take care when operating the...

  • Page 36: Heated Rear Window

    Keys, doors and windows Opening side windows To provide an emergency exit from the vehicle, use hammer 1 to strike glass 2. Heated rear window Press catch and slide window to open. Ensure catch engages when Pull handle to open window. closing.

  • Page 37: Roof

    Keys, doors and windows Roof Sun visors also feature a holder for parking tickets etc. Glass panel Emergency exit Heating works with the engine running and is switched off automatically after a short time. Climate control system 3 95. Electronic climate control system 3 97.

  • Page 38: Seats, Restraints

    Seats, restraints Seats, restraints Head restraints Height adjustment Position Head restraints ......36 9 Warning Front seats ........37 Rear seats ........42 Only drive with the head restraint Seat belts ........44 set to the proper position. Airbag system ......46 Child restraints ......

  • Page 39: Front Seats

    Seats, restraints Front seats Removal ■ Sit with shoulders as far back against the backrest as possible. Set the backrest rake so that it is Seat position possible to reach the steering wheel with arms slightly bent. 9 Warning Maintain contact between shoulders and the backrest when Only drive with the seat correctly turning the steering wheel.
  • Page 40 Seats, restraints Seat adjustment Pull handle, slide seat, release Seat backrests handle. 9 Danger Suspension seat positioning Do not sit nearer than 25 cm from the steering wheel, to permit safe airbag deployment. 9 Warning Never adjust seats while driving as they could move uncontrollably.
  • Page 41 Seats, restraints Suspension seat backrests Seat height Suspension seat height Pull lever, adjust inclination and Pull up front release lever up to adjust Lever pumping motion release lever. Allow the seat to height of front part of seat. = seat higher engage audibly.
  • Page 42 Seats, restraints Lumbar support Suspension seat lumbar support Suspension seat sensitivity Adjust lumbar support to suit personal Adjust lumbar support to suit personal Rotate knob to adjust the sensitivity of requirements. requirements. the suspension seat. Operate hand pump repeatedly Increasing and decreasing support: Turn right = More stiff (located on underside of unit) to turn the handwheel while relieving the...
  • Page 43 Seats, restraints Armrest Heating Seat heating is operational when the engine is running. Press the ß button for the respective Armrest can be folded up when not seat. Press the ß button again to required. switch off. Seat heating is thermostatically controlled and switches off automatically when seat temperature is sufficient.

  • Page 44: Rear Seats

    Seats, restraints Rear seats Removable rear seats 9 Warning Removal Removable rear seats are heavy! Rear seat access On some variants, the cargo area can Do not attempt to remove without be increased by removing the rear assistance. seats. Installation Caution The rear seats are not interchangeable and must be fitted...
  • Page 45 Seats, restraints Position the seat guides immediately 9 Warning behind the front floor anchor points, Removal and slide forwards to engage. Removable rear seats are heavy! Using the tool from the tool kit located Do not attempt to remove without in the glovebox, turn levers to unlock assistance.

  • Page 46: Seat Belts

    Seats, restraints Seat belts Seat belts are designed to be used by Belt pretensioners only one person at a time. Child In the event of a head-on or rear-end restraint system 3 52. collision of a certain severity, the front seat belts are tightened.

  • Page 47: Three-Point Seat Belt

    Seats, restraints Three-point seat belt Height adjustment Fastening Loose or bulky clothing prevents the belt from fitting snugly. Do not place 1. Pull belt out slightly. objects such as handbags or mobile 2. Press button. phones between the belt and your Withdraw the belt from the retractor, body.

  • Page 48: Airbag System

    Seats, restraints Airbag system Removing Using the seat belt while pregnant The airbag system consists of a number of individual systems depending on the scope of equipment. When triggered the airbags inflate within milliseconds. They also deflate so quickly that it is often unnoticeable during the collision.
  • Page 49 Seats, restraints Each airbag is triggered only once. sous peine d'infliger des Have deployed airbags replaced by BLESSURES GRAVES, voire a workshop. Furthermore, it may be MORTELLES à l'ENFANT. necessary to have the steering ES: NUNCA utilice un sistema de wheel, the instrument panel, parts of retención infantil orientado hacia the panelling, the door seals,...
  • Page 50 Seats, restraints DA: Brug ALDRIG en bagudvendt mesmo, poderá ocorrer a PERDA DE korunmakta olan bir koltukta autostol på et forsæde med AKTIV VIDA ou FERIMENTOS GRAVES na kullanmayınız. ÇOCUK ÖLEBİLİR AIRBAG, BARNET kan komme I CRIANÇA. veya AĞIR ŞEKİLDE LIVSFARE eller komme ALVORLIGT YARALANABİLİR.
  • Page 51 Seats, restraints BLAZINO, saj pri tem obstaja acest lucru poate duce la DECESUL ET: ÄRGE kasutage tahapoole nevarnost RESNIH ali SMRTNIH sau VĂTĂMAREA GRAVĂ a suunatud lapseturvaistet istmel, mille POŠKODB za OTROKA. COPILULUI. ees on AKTIIVSE TURVAPADJAGA kaitstud iste, sest see võib SR: NIKADA ne koristiti bezbednosni CS: NIKDY nepoužívejte dětský...

  • Page 52: Front Airbag System

    Seats, restraints Front airbag system Side airbag system The inflated airbags cushion the impact, thereby reducing the risk of The front airbag system consists of injury to the upper body and head of one airbag in the steering wheel and the front seat occupants one in the instrument panel on the considerably.

  • Page 53: Airbag Deactivation

    Seats, restraints With the front door open, push switch 9 Warning in and rotate anti-clockwise to the OFF position. Keep the area in which the airbag Front passenger seat airbags are inflates clear of obstructions. deactivated and will not inflate in the event of a collision.

  • Page 54: Child Restraints

    Child restraint systems used on the front passenger seat. the event of a collision. We recommend the Opel child If control indicator A remains Airbag deactivation 3 51. restraint system which is tailored illuminated together with v, this Airbag label 3 46.
  • Page 55 Seats, restraints Ensure that the mounting location of the child restraint system within the vehicle is correct. Allow children to enter and exit the vehicle only on the side facing away from the traffic. When the child restraint system is not in use, secure the seat with a seat belt or remove it from the vehicle.

  • Page 56: Child Restraint Installation Locations

    Seats, restraints Child restraint installation locations Permissible options for fitting a child restraint system Front seats - All variants Weight and age class Single seat - front passenger side Bench seat - front passenger side without airbag with airbag without airbag with airbag centre outer...
  • Page 57 Seats, restraints Crew cab - rear seats Weight and age class 2nd row seats Outer Centre Group 0: up to 10 kg or approx. 10 months Group 0+: up to 13 kg or approx. 2 years Group I: 9 to 18 kg or approx.
  • Page 58 Seats, restraints Combi - rear seats Weight and age class 2nd row seats 3rd row seats Driver side Passenger side outer seat Centre seat outer seat Group 0: up to 10 kg or approx. 10 months , < Group 0+: up to 13 kg or approx.
  • Page 59 Seats, restraints Bus - rear seats Weight and age class Rear seats Group 0: up to 10 kg or approx. 10 months Group 0+: up to 13 kg or approx. 2 years Group I: 9 to 18 kg or approx. 8 months to 4 years Group II: 15 to 25 kg or approx.
  • Page 60 Seats, restraints Permissible options for fitting an ISOFIX child restraint system Combi Weight class Size class Fixture Front seats 2nd row seats 3rd row seats Driver side Passenger side outer seat Centre seat outer seat Group 0: up to 10 kg ISO/R1 X or approx.
  • Page 61 Seats, restraints ISOFIX size class and seat device A - ISO/F3 = Forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kg. B - ISO/F2 = Forward-facing child restraint system for smaller children in the weight class 9 to 18 kg. B1 - ISO/F2X = Forward-facing child restraint system for smaller children in the weight class 9 to 18 kg.

  • Page 62: Isofix Child Restraint

    Seats, restraints ISOFIX child restraint Top-tether fastening eyes systems Top-Tether fastening eyes are located on the back of the seat. Fasten vehicle-approved ISOFIX In addition to the ISOFIX mounting, child restraint systems to the ISOFIX fasten the Top-Tether strap to the mounting brackets.

  • Page 63: Storage

    Storage Storage Storage compartments Storage compartments, pockets and trays are located in the instrument panel. 9 Warning A phone holder and/or a coin holder Storage compartments ....61 with a clip for holding tickets is located Do not store heavy or sharp on the top of the instrument panel.

  • Page 64: Glovebox

    Storage To fold away, raise the base until the The cupholders can also be used to The swivelling shelf, which can be document holder is horizontal, then hold the portable ashtray unit 3 73. used for writing or documents, must push fully in.

  • Page 65: Overhead Console

    Storage Overhead console Underseat storage Overcab storage Using the two loops on the passenger The total weight in this compartment The total weight in these seat cushion, pull the cushion must not exceed 35 kg. compartments must not exceed 5 kg. forwards to gain access to the storage Rear storage under the seat.

  • Page 66: Load Compartment

    Storage Load compartment Removable lashing eyes Lashing eyes To move, pull down on the latch to release and position the wall as To reposition, press down on the required. Ensure the latch engages centre cap and slide to the desired fully and the partition wall is upright.
  • Page 67 Storage Store the partition wall to one side of Ratchet straps the load compartment when not in Using the appropriate ratchet straps, use. objects can be secured to the removable lashing eyes in the side or Telescopic blocking bars floor load rails. The maximum loading for the side rails is 100 daN/700mm.

  • Page 68: Safety Net

    Storage Safety net Underseat storage 3 63. First aid kit The first aid kit can be accommodated in the space under the front seats or in the overhead console. A label is located on the overhead console should the first aid kit be stored there.

  • Page 69: Roof Rack System

    Storage Roof rack system Loading information An additional extinguisher may be located in the front door panel. Roof rack As a visible indication of this, a label ■ Heavy objects in the load is located on the overhead console. compartment should be evenly For safety reasons and to avoid distributed and placed as far damage to the roof, the vehicle...
  • Page 70 Storage effect on vehicle handling due to 9 Warning the vehicle's higher centre of gravity. Distribute the load evenly Always make sure that the load in and secure it properly with retaining the vehicle is securely stowed. straps. Adjust the tyre pressure and Otherwise objects can be thrown vehicle speed according to the load around inside the vehicle and...

  • Page 71: Instruments And Controls

    Instruments and controls Instruments and Controls Steering wheel controls controls Steering wheel adjustment Controls ........69 Warning lights, gauges and indi‐ cators ........... 74 Information displays ..... 84 Vehicle messages ......84 Trip computer ....... 86 Tachograph ........87 The cruise control and speed limiter can be operated via the controls on the steering wheel.

  • Page 72: Controls

    Instruments and controls Horn Windscreen wiper/washer Automatic wiping with rain sensor Windscreen wiper K = Automatic wiping with rain Press j. sensor The horn will sound regardless of K = timed interval wipe The rain sensor detects the amount of ignition switch position.

  • Page 73: Outside Temperature

    Instruments and controls Outside temperature Adjustable sensitivity of the rain Windscreen washer sensor Turn the adjuster wheel to adjust the sensitivity: = turn adjuster wheel sensi‐ downwards tivity High = turn adjuster wheel sensi‐ upwards tivity Pull lever. Washer fluid is sprayed A drop in temperature is indicated onto the windscreen.

  • Page 74: Power Outlet

    Instruments and controls Hours and minutes can be adjusted ■ Press top button to change hours 9 Warning by pressing the appropriate buttons ■ Press and hold bottom button to set by the display or with the Infotainment hours The road surface may already be system controls.

  • Page 75: Cigarette Lighter

    Instruments and controls Cigarette lighter Portable ashtray Connecting electrical accessories while the engine is off will discharge Ashtray container for mobile use in Press in cigarette lighter. It switches the vehicle battery. the vehicle. To use, open cover. off automatically once the element is Do not exceed the maximum power glowing.

  • Page 76: Warning Lights, Gauges And Indicators

    Instruments and controls Warning lights, gauges Trip odometer Maximum speed may be restricted by a speed regulator. As a visible and indicators The trip odometer displays the indication of this, a warning label is distance travelled since the last reset. located on the instrument panel.

  • Page 77: Engine Coolant Temperature Gauge

    Instruments and controls Displays the engine speed. Control indicator Y illuminates if the left area = engine operating level in the tank is low. Refuel temperature not yet Drive in a low engine speed range for immediately 3 128. reached each gear as much as possible.

  • Page 78: Transmission Display

    Instruments and controls Service display If the engine oil level is correct when for approx. 10 seconds until the the ignition is switched on OIL LEVEL distance before service is displayed When the ignition is switched on, the CORRECT appears briefly in the continuously.

  • Page 79: Control Indicators

    Instruments and controls kg = Laden mode V = Winter mode T = Apply footbrake W = Transmission electronics Manual transmission automated 3 115. Control indicators The control indicators described are not present in all vehicles. The description applies to all instrument versions.
  • Page 80 Instruments and controls Control indicators in the instrument cluster...

  • Page 81: Turn Signal

    Instruments and controls Turn signal When the ignition is switched on, the If control indicator A is illuminated in control indicator illuminates briefly. If combination with v, seek the O flashes green. it does not illuminate or illuminates assistance of a workshop. Flashes if a turn signal or the hazard whilst driving, there is a fault in the warning flashers are activated.

  • Page 82: Service Vehicle Soon

    Instruments and controls Illuminates when the engine is Flashes when the engine is Illuminates for a few seconds when the ignition is switched on. running running If C illuminates (possibly in Stop, switch off engine. Vehicle Fault that could lead to catalytic combination with W and/or R), stop battery is not charging.

  • Page 83: Brake Pad Wear

    Instruments and controls fault in the ABS. The brake system Flashing during driving 9 Warning remains operational but without ABS The system is actively engaged. regulation. Engine output may be reduced and Stop. Do not continue your the vehicle may be braked If control indicators u, A, R and journey.

  • Page 84: Low Fuel

    Instruments and controls Illuminates when the engine is Check oil level before seeking Caution assistance of a workshop 3 135. running Coolant temperature too high. Low fuel Caution Check coolant level 3 136. Y illuminates yellow. Engine lubrication may be If there is sufficient coolant, consult a Illuminates when the ignition is interrupted.

  • Page 85: High Beam

    Instruments and controls High beam Illuminates when the engine is U illuminates yellow when the system is on. running P illuminates blue. Cruise control, Speed limiter 3 122. Indicates the presence of water in the Illuminated when high beam is on and diesel.

  • Page 86: Driver Information Centre

    Instruments and controls Information displays Vehicle messages Triple-Info-Display Driver Information Centre Messages appear in the Driver Information Centre, in combination with control indicator A or C. Information messages Information messages BATTERY MODE: ECONOMY ESP OFF AUTO LIGHTS DEACTIVATED Displays time, outside temperature and date when the ignition is on.

  • Page 87: Warning Chimes

    Instruments and controls remains illuminated. The fault will ■ If the vehicle speed briefly exceeds Warning messages then be stored in the on board a set limit. INJECTION FAULT system. ■ During closing of the power sliding door. Fault messages ENGINE OVERHEATING ■...

  • Page 88: Trip Computer

    Instruments and controls Trip computer ■ Distance travelled Instantaneous consumption The value is displayed after reaching ■ Average speed a speed of 30 km/h. The trip computer provides ■ Distance before service information on driving data, which is ■ Clock Range continually recorded and evaluated ■...

  • Page 89: Tachograph

    Instruments and controls Tachograph The measurement can be restarted at Interruption of power supply any time. If the power supply has been interrupted or if the vehicle battery Interruptions in the journey with the voltage has dropped too low, the ignition off are not included in the values stored in the trip computer will calculations.

  • Page 90: Lighting

    Lighting Lighting Exterior lighting Automatic light control Light switch Exterior lighting ......88 Interior lighting ......91 Lighting features ......93 When the automatic light control function is switched on and the engine is running, the system Turn light switch: switches between daytime running = Off lights (where fitted) and headlights,...

  • Page 91: Headlight Range Adjustment

    Lighting High beam Headlight range Headlights when driving adjustment abroad The asymmetrical headlight beam Manual headlight range extends visibility at the edge of the adjustment road at the passenger side. However, when driving in countries where traffic drives on the opposite side of the road, adjust the headlights to prevent dazzling of oncoming traffic.

  • Page 92: Turn And Lane-Change Signals

    Lighting Adaptive forward lighting Turn and lane-change If the lever is moved past the first stop, the indicator is switched on signals constantly. Switch the indicator off Cornering light manually by moving the lever to its Depending on the steering angle, original position.

  • Page 93: Rear Fog Light

    Lighting Interior lighting Rear fog lights Misted light covers The inside of the light covers may mist Interior lights up briefly in poor, wet and cold weather conditions, in heavy rain or With the switch in its central position, after washing. The mist disappears the light functions as a courtesy light quickly by itself;...

  • Page 94: Load Compartment Lighting

    Lighting Load compartment lighting Reading lights The courtesy light extinguishes immediately when the ignition is Load compartment lighting can be set switched on. Front reading light to illuminate when the side and rear Rear courtesy lights doors are opened, or switched on constantly.

  • Page 95: Exit Lighting

    Lighting Lighting features Rear reading lights Exit lighting Each reading light can then be operated individually and directed as required. Operate rocker switch on the Headlights come on for approx. instrument panel: 1 minute after the vehicle is parked press l = on.
  • Page 96 Lighting This action can be repeated up to four times to a maximum period of 4 minutes. The lighting is turned off immediately by turning the light switch to any position and returning to 7.

  • Page 97: Climate Control

    Climate control Climate control Climate control systems Temperature = warm Heating and ventilation blue = cold system Heating will not be fully effective until Climate control systems ....95 the engine has reached normal Air vents ........104 operating temperature. Maintenance ......

  • Page 98: Air Conditioning System

    Climate control ■ Switch on heated rear window Ü. Heated rear window Ü 3 34, Heated Stop-start system 3 109. seats ß 3 41. ■ Open side air vents as required and Air recirculation system direct them towards door windows. Cooling (AC) Operated with the u button.

  • Page 99: Electronic Climate Control

    Climate control Electronic climate control Demisting and defrosting the The preselected temperature is automatically regulated. In the windows system automatic mode the fan speed and air ■ Switch cooling n on. distribution automatically regulate the ■ Set temperature control to warmest air flow.

  • Page 100: Rear Heating System

    Climate control = warm To return to automatic mode: press of the passenger compartment air blue = cold button V or AUTO. deteriorates, which may cause the vehicle occupants to feel drowsy. Heating will not be fully effective until Air distribution the engine has reached normal Press s or K repeatedly.
  • Page 101 Climate control During operation, power from the The time is set when the displayed Programming the heating mode vehicle battery is used. For short time stops flashing. It is possible to store up to three journey times, check the vehicle programmes which allow the heating The display for the day will then flash: battery regularly and recharge if...

  • Page 102: Rear Air Conditioning

    Climate control Neutral position or no stored Fan speed programme activated Rear air vents Press P button until their is no stored programme number visible in the display. Adjusting the temperature To adjust the temperature of the heating, turn the rotary knob located on the control panel.

  • Page 103: Auxiliary Heater

    Climate control With the front passenger Before starting or programming the Timer compartment air conditioning system system to start, turn the vehicle's switched on, adjust the air flow to climate control system to heat and the select the desired speed. air distribution to V.
  • Page 104 Climate control Remote control In addition to the remote control unit, 9 Warning the heating can also be switched on for 30 minutes, or off, using the button When refuelling, switch off the on the instrument panel. remote control unit as well as the heater! Battery replacement Replace the battery when the range...
  • Page 105 Climate control Batteries do not belong in household AddE teaches the current remote To switch off, select x in the menu bar waste. They must be disposed of at control unit exclusively and blocks all again and confirm. an appropriate recycling collection previously configured units.

  • Page 106: Centre Air Vents

    Climate control Air vents To delete a preset departure time, ■ Change minutes and confirm follow the steps for programming until ■ Change the default heating heating symbol Y flashes. Press Adjustable air vents duration and confirm button q or r until oFF appears in At least one air vent must be open the display and confirm.

  • Page 107: Fixed Air Vents

    Climate control Maintenance Fixed air vents Side air vents Additional air vents are located Air intake beneath the windscreen and door windows and in the foot wells. Glovebox cooler The air conditioning system can also keep the contents of the glovebox cool.

  • Page 108: Air Conditioning Regular

    Climate control Air conditioning regular operation In order to ensure continuously efficient performance, cooling must be operated for a few minutes once a month, irrespective of the weather and time of year. Operation with cooling is not possible when outside temperature is too low.

  • Page 109: Driving And Operating

    Driving and operating Driving and operating Driving hints Starting and operating Control of the vehicle New vehicle running-in Do not brake unnecessarily hard for Driving hints ....... 107 Never coast with engine not the first few journeys and after new running (except during Starting and operating ....

  • Page 110: Ignition Switch Positions

    Driving and operating Ignition switch positions Starting the engine The increased engine speed automatically returns to normal idling speed as the engine temperature rises. Start attempts should not last longer than 15 seconds. If engine does not start, wait 15 seconds before repeating starting procedure.

  • Page 111: Idle Speed Control

    Driving and operating Idle speed control Overrun cut-off Deactivation The fuel supply is automatically cut off during overrun, i.e. when the vehicle is driven with a gear engaged but accelerator is released. Stop-start system The stop-start system helps to save fuel and to reduce the exhaust emission.
  • Page 112 Driving and operating The engine will be switched off while ■ The stop-start system is not Certain settings of the climate control the ignition stays on if the required manually deactivated system may inhibit an Autostop. See conditions are met. Climate control chapter for further ■...

  • Page 113: Air Suspension

    Driving and operating If the selector lever is shifted out of If an electrical accessory, e.g. a ■ Switch off the engine and ignition. N before depressing the clutch first, a portable CD player, is connected to Turn the steering wheel until the restart will not take place.

  • Page 114: Remote Control

    Driving and operating Master switch Remote control Handle with care, protect from moisture and high temperatures and avoid unnecessary operation. Caution Pre-programmed settings The air suspension system must Adjusts the suspension height to one be switched off when the vehicle is of three pre-programmed positions.

  • Page 115: Engine Exhaust

    Driving and operating Engine exhaust Service mode process takes place automatically and the emission of smells and Press button i for 5 seconds to put smoke during this process is normal. the vehicle into service mode. The 9 Danger indicator light will illuminate. When Under certain driving conditions, e.g.

  • Page 116: Manual Transmission

    Driving and operating Manual transmission Malfunction indicator light 3 80. Caution Fuel grades other than those listed on page 3 128, 3 175 could damage the catalytic converter or electronic components. Unburnt petrol will overheat and damage the catalytic converter. Therefore avoid excessive use of the starter, running the fuel tank dry and starting the engine by...

  • Page 117: Manual Transmission Automated

    Driving and operating Manual transmission Starting the engine Caution automated Depress the foot brake when starting It is inadvisable to drive with hand the engine. If the foot brake is not resting on the selector lever. depressed, T illuminates in the The manual transmission automated transmission display and the engine (MTA) permits manual (manual...
  • Page 118 Driving and operating Always move the selector lever in the start off quickly, release the foot brake warning may sound as a signal to appropriate direction as far as it will and accelerate immediately after depress the foot brake or apply the go.

  • Page 119: Manual Mode

    Driving and operating Rocking the vehicle shift is not executed. This prevents Activate the Winter mode if you have the engine from running at too low or problems starting off on a slippery Rocking the vehicle is only too high an engine speed. road surface.

  • Page 120: Interruption Of Power Supply

    Driving and operating Interruption of power Laden mode kg Deactivation The Laden mode is switched off by: supply ■ pressing the kg button again, The clutch is not disengaged if there ■ turning off the ignition. is an interruption of the power supply when a gear is engaged.

  • Page 121: Brakes

    Driving and operating Brakes Antilock brake system 9 Warning Antilock brake system (ABS) The brake system comprises two prevents the wheels from locking. If there is a fault in the ABS, the independent brake circuits. wheels may be liable to lock due ABS starts to regulate brake pressure to braking that is heavier than If a brake circuit fails, the vehicle can...

  • Page 122: Traction Control System

    Driving and operating Ride control systems Parking brake Brake assist If the brake pedal is depressed Traction Control system quickly and forcefully, maximum brake force is automatically applied The Traction control system (TC) is a (full braking). component part of the Electronic stability program (ESP®...

  • Page 123: Electronic Stability Program

    Driving and operating Press the v button. Control indicator ESP® Plus is operational as soon as 9 Warning v illuminates in the instrument the ignition is switched on and control cluster. indicator v extinguishes in the Do not let this special safety instrument cluster.

  • Page 124: Cruise Control

    Driving and operating Driver assistance Deactivation When vehicle speed reaches 50 km/h the ESP® Plus function will be systems restored automatically. Fault 9 Warning If the system detects a fault, control indicator A illuminates in the Driver assistance systems are instrument cluster and the message developed to support the driver CHECK ESP appears in the Driver...
  • Page 125 Driving and operating Do not use the cruise control if it is not Cruise control is now in standby mode advisable to maintain a constant and a corresponding message speed. appears in the Driver Information Centre. With manual transmission automated, only activate cruise control in automatic mode.
  • Page 126 Driving and operating Increase speed Automatic deactivation: Activation With cruise control active, the vehicle ■ Vehicle speed drops below speed can be increased continuously 30 km/h, or in small increments by holding ■ The brake pedal is depressed, down or tapping switch < repeatedly. ■...

  • Page 127: Parking Assist

    Driving and operating Where the limit speed cannot be Deactivation maintained, e.g. when driving on a Press switch §: speed limiter is steep decline, the limit speed will deactivated and the vehicle can be flash in the Driver Information Centre. driven normally.
  • Page 128 Driving and operating closer to the obstacle. When the Temporary deactivation vans). Object identification in the distance is less than 30 cm, the Temporarily deactivate the system by upper part of these vehicles buzzer is continuous. pressing the r button on the cannot be guaranteed.

  • Page 129: Rear View Camera

    Driving and operating Rear view camera Fault The remaining buttons on the monitor enable the user to select source If the system detects an operating AV1 or AV2 and adjust the brightness fault, a continuous acoustic alarm will and contrast of the display monitor. sound for approx.

  • Page 130: Fuel

    Driving and operating Fuel water emulsions. Diesel fuels must If you can smell fuel in your not be diluted with fuels for petrol vehicle, have the cause of this engines. Fuel for diesel engines remedied immediately by a The flow and filterability of diesel fuels workshop.
  • Page 131 Driving and operating Fuel consumption - CO Furthermore, fuel consumption is dependent on personal driving style Emissions as well as road and traffic conditions. For the values specific to your vehicle, refer to the EEC Certificate of Conformity provided with your vehicle or other national registration documents.

  • Page 132: Trailer Hitch

    Driving and operating Trailer hitch If the trailer starts snaking, drive more level. Since engine power decreases slowly, do not attempt to correct the as altitude increases due to the air steering and brake sharply if becoming thinner, therefore reducing General information necessary.

  • Page 133: Auxiliary Features

    Driving and operating Auxiliary features In the case of trailer loads of The pitch of the audible warning will 1200 kg or more, the vertical coupling change if a turn signal light on the load should not be less than 50 kg. trailer or the towing vehicle fails.
  • Page 134 Driving and operating If the system does not operate, repeat the procedure or gradually release the clutch pedal. To deactivate, depress the clutch pedal and press switch on the instrument panel.

  • Page 135: Vehicle Care

    Vehicle care Vehicle care General Information ■ Change engine oil. ■ Drain washer fluid reservoir. Accessories and vehicle ■ Check coolant antifreeze. modifications ■ Adjust tyre pressure to the value General Information ....133 specified for full load. We recommend the use of genuine Vehicle checks ......

  • Page 136: Vehicle Checks

    Vehicle care Vehicle checks Bonnet ■ Fill up the washer fluid reservoir. ■ Check the engine oil level. Opening Performing work ■ Check the coolant level. ■ Fit the number plate, if necessary. 9 Warning End-of-life vehicle Only perform engine compartment recovery checks when the ignition is off.

  • Page 137: Engine Oil

    Vehicle care Closing Caution Before closing the bonnet, press the support into the holder. It is the owner's responsibility to Lower the bonnet and allow it to drop maintain the proper level of an into the catch. Check that the bonnet appropriate quality oil in the is engaged.
  • Page 138 Vehicle care thousand kilometres. Only then can the actual degree of consumption be established. If consumption exceeds more than 0.5 litres every 1000 km after this running-in period, consult a workshop. Capacities 3 189, Engine oil level monitor 3 75. Fit the cap on straight and tighten it.

  • Page 139: Washer Fluid

    Vehicle care Washer fluid Brakes concentration checked and have the cause of the coolant loss remedied by A squealing noise, or illumination of a workshop. brake pad wear control indicator F If a substantial amount of coolant is indicates that the brake lining is at its required, it will be necessary to bleed minimum thickness.

  • Page 140: Vehicle Battery

    Vehicle care Battery access Batteries do not belong in household waste. They must be disposed of at an appropriate recycling collection point. Laying up the vehicle for more than 4 weeks can lead to battery The brake fluid level must be between discharge.

  • Page 141: Diesel Fuel Filter

    Vehicle care Diesel fuel filter Warning label ■ See the Owner's Manual for further information. ■ Explosive gas may be present in the vicinity of the battery. Battery maintenance 9 Danger Ensure adequate ventilation when charging the battery. There is a risk of explosion if gases generated during charging are allowed to accumulate!

  • Page 142: Diesel Fuel System

    Vehicle care Diesel fuel system 3. Manually operate the in-line Lift wiper arm, press retaining clip supply pump slowly and steadily towards wiper arm and detach wiper bleeding until fuel discharging from the blade. loosened vent screw is free of air Attach the wiper blade slightly angled bubbles.

  • Page 143: Bulb Replacement

    Vehicle care Bulb replacement Headlights High beam Switch off the ignition and turn off the relevant switch or close the doors. Only hold a new bulb at the base. Do not touch the bulb glass with bare hands. Use only the same bulb type for replacement.
  • Page 144 Vehicle care Low beam 3. Release spring clip. 5. Detach bulb from bulb holder and renew the bulb. 4. Withdraw bulb from reflector 1. Remove headlamp protective housing. 6. Insert the bulb holder, engaging cover. the two lugs in the reflector 5.

  • Page 145: Adaptive Forward Lighting

    Vehicle care Adaptive forward lighting Sidelights Cornering light 5. Detach bulb from bulb holder and renew the bulb. 1. Remove protective cover. 6. Insert the bulb holder, engaging 2. Detach wiring connector from the two lugs in the reflector Headlights have separate systems for bulb.

  • Page 146: Front Turn Signal Lights

    Vehicle care Front turn signal lights 5. Detach bulb from bulb holder and 5. Detach bulb from bulb holder and renew the bulb. renew the bulb. 1. Remove protective cover. 6. Insert the bulb holder, engaging 6. Insert the bulb holder, engaging the two lugs in the reflector the two lugs in the reflector 2.

  • Page 147: Tail Lights

    Vehicle care Tail lights 7. Push bulb into socket slightly, rotate anti-clockwise, remove and renew bulb. Rear brake, tail, turn signal, reverse and fog tail lights Turn signal light (1) Tail and brake light (2) Reverse light (3) Rear fog light, may be on one side only (4) 8.

  • Page 148: Side Turn Signal Lights

    Vehicle care Side turn signal lights Centre high-mounted 5. Reattach wiring connector. 6. Install lamp assembly into brake light 1. Push the lamp assembly to the aperture and push to the left to right and pull at the left-hand side secure.

  • Page 149: Interior Lights

    Vehicle care Interior lights 8. Replace the nut onto the locating pin on the rear of the lamp assembly. Front courtesy light 9. Install cover on the inside of the rear door. Number plate light 3. Remove the lamp assembly from the aperture on the outer side.

  • Page 150: Instrument Panel

    Vehicle care Instrument panel Load compartment light Front door panel light illumination Have bulbs replaced by a workshop. 1. Remove lamp assembly using a 1. Remove lamp assembly using a flat blade screwdriver. flat blade screwdriver. 2. Detach wiring connector from 2.

  • Page 151: Electrical System

    Vehicle care Electrical system Fuse extractor Fuses Data on the replacement fuse must match the data on the defective fuse. There are two fuse boxes in the vehicle: ■ on the left-hand side of the instrument panel, behind the trim panel.

  • Page 152: Fuse Box

    Vehicle care Instrument panel fuse box Due to restricted accessibility, have fuses replaced by a workshop. Symbol Circuit Right side lights Left side lights Right low beam Left low beam Front fog light > Left high beam To help in replacing fuses, a fuse extractor is located in the instrument Right high beam Located behind the trim panel on the...

  • Page 153: Vehicle Tools

    Vehicle care Vehicle tools Symbol Circuit Symbol Circuit Infotainment system, seat Right heated rear window Tools heating, vehicle display Windscreen washer screen, audio connections, alarm Electronic immobiliser Power outlet Heated seats Cigarette lighter Ì Cornering light Instrument panel Hands-free connection Central locking &...

  • Page 154: Wheels And Tyres

    Vehicle care Wheels and tyres To access this unit, slide the seat fully forwards and fold down the backrest. Tyre repair kit 3 155. Tyre condition, wheel condition Spare wheel 3 160. Drive over edges slowly and at right angles if possible. Driving over sharp edges can cause tyre and wheel damage.

  • Page 155: Tyre Pressure

    Vehicle care Tyre pressure In accordance with country-specific Rear-wheel drive, with twin rear regulations, a notice indicating the wheels Check the pressure of cold tyres at maximum permissible speed for the When inflating the outer tyre, the least every 14 days and before any tyres must be affixed within the inflation tube should be passed long journey.

  • Page 156: Tyre Chains

    Vehicle care Changing tyre and wheel 9 Warning size Use of unsuitable tyres or wheel If tyres of a different size than those covers could lead to sudden fitted at the factory are used, it may be pressure loss and thereby necessary to reprogramme the accidents.

  • Page 157: Tyre Repair Kit

    Vehicle care Always use fine mesh chains that add Tyre damage exceeding 4 mm or that no more than 15 mm to the tyre tread is at the tyre's sidewall near the rim and the inboard sides (including chain cannot be repaired with the tyre repair lock).
  • Page 158 Vehicle care 9. Connect the red < power supply 11. Set the rocker switch on the 7. Screw the sealant filler hose to the lead on the compressor to the compressor to position I. The tyre tyre valve. jump start terminal 3 161. is filled with sealant.
  • Page 159 Vehicle care damaged. Seek the assistance of a workshop. Drain excess tyre pressure with the button beside the pressure indicator. Do not run the compressor for longer than 10 minutes. 15. Detach the tyre repair kit. Screw the sealant filler hose to the free connection on the sealant bottle.

  • Page 160: Wheel Changing

    Vehicle care not be driven. Seek the dinghies etc. They are located on the ■ If the ground on which the vehicle assistance of a workshop. underside of the compressor. To is standing is soft, a solid board remove, screw on compressor air (max.
  • Page 161 Vehicle care jacking hole located nearest the Position the adapter at the jacking wheel concerned. hole located nearest the wheel concerned. Ensure the jack is positioned correctly. The jack base must be Ensure the jack is positioned on the ground directly below the correctly.

  • Page 162: Spare Wheel

    Vehicle care twin rear wheels), 264 Nm (Rear- could affect driveability. Have the Caution wheel drive with single rear defective tyre replaced as soon as wheels). possible. Only use the wheel wrench and 9. Refit wheel cover. adapter to lower the spare wheel. The spare wheel is held under the 10.

  • Page 163: Jump Starting

    Vehicle care Jump starting Twin rear wheel vehicles have an downwards. Tighten cable using the additional mounting plate attached to wheel wrench and adapter until the the spare wheel. Before using the wheel is secured. Do not start with a quick charger. wheel, undo the nut and remove the Summer and winter tyres A vehicle with a discharged battery...
  • Page 164 Vehicle care ■ Use a booster battery with the Jump start terminal Caution same voltage (12 volts). Its capacity (Ah) must not be much less than The air suspension system must that of the discharged vehicle be switched off prior to jump battery.

  • Page 165: Towing

    Vehicle care Towing Jump starting procedure engine mounting bolt. Connect as far away from the discharged vehicle battery as possible, Towing the vehicle however at least 60 cm. The towing eye is stowed with the Route the leads so that they cannot vehicle tools 3 151.

  • Page 166: Towing Another Vehicle

    Vehicle care To prevent the entry of exhaust fumes Caution Caution from the towing vehicle, switch on the air recirculation system and close the Do not tow the vehicle from the Drive slowly. Do not drive jerkily. windows. rear. The front towing eye must Excessive tractive force can Seek the assistance of a workshop.

  • Page 167: Appearance Care

    Vehicle care Appearance care If using a vehicle wash, comply with Thoroughly rinse and leather-off the the vehicle wash manufacturer's vehicle. Rinse leather frequently. Use instructions. The windscreen wipers separate leathers for painted and Exterior care must be switched off. Remove glass surfaces: remnants of wax on antenna and external accessories the windows will impair vision.

  • Page 168: Interior Care

    Vehicle care Interior care Windows and windscreen wiper Paintwork damage blades Rectify minor paintwork damage with Interior and upholstery a touch-up pen before rust forms. Use a soft lint-free cloth or chamois Have more extensive damage or rust Only clean the vehicle interior, leather together with window cleaner areas repaired by a workshop.
  • Page 169 Vehicle care Caution Close Velcro fasteners as open Velcro fasteners on clothing could damage seat upholstery. The same applies to clothing with sharp-edged objects, like zips or belts or studded jeans. Plastic and rubber parts Plastic and rubber parts can be cleaned with the same cleaner as used to clean the body.

  • Page 170: Service And Maintenance

    Service and maintenance Service and General information European service intervals - Bus only maintenance Service information Maintenance of your vehicle is required every 30,000 km or after In order to ensure economical and 1 year, whichever occurs first, unless safe vehicle operation and to otherwise indicated by the service General information ....

  • Page 171: Recommended Fluids

    Service and maintenance Recommended fluids, Russia, Ukraine and Turkey Make sure that the Service and Warranty Booklet is completed service intervals lubricants and parts correctly as continuous proof of Maintenance of your vehicle is service is essential if any warranty or required every 20,000 km or after Recommended fluids and goodwill claims are to be met, and is...
  • Page 172 Service and maintenance aging control, whereas viscosity Additional engine oil additives protection down to approx. -28 °C. grade gives information on the oil's This concentration should be The use of additional engine oil thickness over a temperature range. maintained all year round. The use of additives could cause damage and additional coolant additives that invalidate the warranty.

  • Page 173: Technical Data

    Technical data Technical data Vehicle identification Vehicle Identification Number Vehicle identification ....171 Vehicle data ....... 174 The VIN is also displayed behind a removable plastic cover on the front right hand door step. Unclip the covers using a flat blade screwdriver to access.

  • Page 174: Identification Plate

    Technical data Identification plate = Additional equipment specification = Fabrication number 10 = Interior trim code The combined total of front and rear axle loads must not exceed the permissible gross vehicle weight. For example, if the front axle is bearing its maximum permissible load, the rear axle can only bear a load that is equal to the gross vehicle weight minus the...

  • Page 175: Engine Identification

    Technical data Engine identification The technical data tables show the engine identifier code. Engine data 3 175. To identify the respective engine, refer to the engine power in the EEC Certificate of Conformity provided with your vehicle or other national registration documents.

  • Page 176: Vehicle Data

    Technical data Vehicle data Recommended fluids and lubricants Required engine oil quality Engine oil quality dexos 2 ✔ In case dexos quality is unavailable you may use max. 1 litre engine oil quality ACEA C3 once between each oil change. In case dexos quality is unavailable in International countries you may use the oil qualities listed below: Engine oil quality GM-LL-A/B-025...

  • Page 177: Engine Data

    Technical data Engine data Sales designation 2.3 CDTI 2.3 CDTI 2.3 CDTI Engine identifier code Number of cylinders Piston displacement [cm 2299 2299 2299 Engine power [kW] (brake horse power) 74 (100) 92 (125) 107 (146) at rpm 3500 3500 3500 Torque [Nm] at rpm...

  • Page 178: Vehicle Weight

    Technical data Vehicle weight Kerb weight, basic model Model Drive wheels Length Roof height Gross vehicle weight Kerb weight 3)4) Front-wheel drive 2800 1806 3300 1811 3500 1816 2800 1834 3300 1839 3500 1844 3300 1885 3500 1890 3300 1921 3500 1931 3500...
  • Page 179 Technical data Model Drive wheels Length Roof height Gross vehicle weight Kerb weight 3)4) Rear-wheel drive 3500 2110 2246 3500 4500 2246 2148 3500 2279 3500 4500 2279 2324 3500 4500 2324 2366 3500 4500 2366 Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to identification plate. Minimum vehicle weight according to type approval, including all fluids, vehicle tools and a 90% fuel load.
  • Page 180 Technical data Model Drive wheels Length Roof height Gross vehicle weight Kerb weight 3)4) Platform Cab Front-wheel drive 3500 1570 3500 1578 3500 1593 3500 1599 3500 1613 Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to identification plate. Minimum vehicle weight according to type approval, including all fluids, vehicle tools and a 90% fuel load.
  • Page 181 Technical data Model Drive wheels Length Roof height Gross vehicle weight Kerb weight 3)4) Chassis Cab Rear-wheel drive 3500 1835 1860 3500 1975 3500 4500 1975 3500 2005 2005 4500 Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to identification plate. Minimum vehicle weight according to type approval, including all fluids, vehicle tools and a 90% fuel load.
  • Page 182 Technical data Model Drive wheels Length Roof height Gross vehicle weight Kerb weight 3)4) Crew Cab Rear-wheel drive 3500 2037 2068 3500 2154 3500 4500 2154 3500 2223 2223 4500 Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to identification plate. Minimum vehicle weight according to type approval, including all fluids, vehicle tools and a 90% fuel load.

  • Page 183: Vehicle Dimensions

    Technical data Vehicle dimensions Van, Doublecab Front-wheel drive 2800, 3300, 3300, Gross vehicle weight 3500 3500 3500 Size Length [mm] 5048 5548 6198 Width without mirrors [mm] 2070 2070 2070 Width with mirrors [mm] 2470 2470 2470 Height - unladen (without antenna) [mm] 2303 2496/2500 2496/2499...
  • Page 184 Technical data Van, Doublecab Rear-wheel drive 3500, 3500, 3500, Gross vehicle weight 4500 4500 4500 Size Length [mm] 6198 6198 6848 Width without mirrors [mm] 2070 2070 2070 Width with mirrors [mm] 2470 2470 2470 Height - unladen (without antenna) [mm] 2549 2557 2527...
  • Page 185 Technical data Combi Front-wheel drive 2800, 2800, Gross vehicle weight 3500 3500 Size Length [mm] 5048 5548 Width without exterior mirrors [mm] 2020 2020 Width with mirrors [mm] 2470 2470 Height - unladen (without antenna) [mm] 2303 2502 Wheelbase [mm] 3182 3682 Track width [mm]...
  • Page 186 Technical data Chassis Cab Front-wheel drive Rear-wheel drive 3500 3500 3500 Gross vehicle weight 3500 3500 3500 3500 4500 4500 4500 Size Length [mm] 5643 6293 5643 6293 5819 6192 6842 Width without mirrors [mm] 2070 2070 2070 2070 2070 2070 2070 Width with mirrors [mm]...
  • Page 187 Technical data Crew Cab Front-wheel drive Rear-wheel drive 3500 3500 Gross vehicle weight 3500 3500 3500 3500 4500 4500 Size Length [mm] 5643 6293 5643 6293 6192 6842 Width without mirrors [mm] 2070 2070 2070 2070 2070 2070 Width with mirrors [mm] 2470 2470 2470...
  • Page 188 Technical data Platform Cab Front-wheel drive Gross vehicle weight 3500 3500 Size Length [mm] 5530 6180 Width without mirrors [mm] 2070 2070 Width with mirrors [mm] 2470 2470 Height - unladen (without antenna) [mm] 2270 2264 2463 2457 Wheelbase [mm] 3682 4332 Track width [mm]...
  • Page 189 Technical data Front-wheel drive Rear-wheel drive Gross vehicle weight 3900 4500 Size Length [mm] 6198 6848 Width without mirrors [mm] 2070 2070 Width with mirrors [mm] 2470 2470 Wheelbase [mm] 4332 4332 Height - unladen (without antenna) [mm] 2488 2808 Track width [mm] 1750 1750...
  • Page 190 Technical data Loadspace dimensions Front-wheel drive Length Roof height 3300, Gross vehicle weight 3500 3500 3500 3500 Maximum rear door aperture height [mm] 1820 1820 1820 1820 Rear door aperture width (at floor) [mm] 1580 1580 1580 1580 Maximum load area height [mm] 1894 2144 1894...
  • Page 191 Technical data Rear-wheel drive Length Roof height Gross vehicle weight 3500 4500 3500 4500 4500 4500 Maximum rear door aperture height [mm] 1724 1724 1724 1724 1724 1724 Rear door aperture width (at floor) [mm] 1580 1580 1580 1580 1580 1580 Maximum load area height [mm] 1798...

  • Page 192: Tyre Pressures

    Technical data Tyre pressures Front-wheel drive Tyre pressure with full load Engine Gross Vehicle Weight Tyre Front Rear [kPa/bar] (psi) [kPa/bar] (psi) 2800 215/65 R16 C 340/3.4 (49) 360/3.6 (52) 3300 215/65 R16 C 360/3.6 (52) 430/4.3 (62) 3500 225/65 R16 C 380/3.8 (55) 460/4.6 (68) The spare wheel should be set to the highest applicable pressure shown in the table.
  • Page 193 Technical data Rear-wheel drive, with twin rear wheels Tyre pressure with full load Engine Gross Vehicle Weight Tyre Front Rear [kPa/bar] (psi) [kPa/bar] (psi) 3500 195/75 R16 C 420/4.2 (61) 420/4.2 (61) 4500 195/75 R16 C 420/4.2 (61) 420/4.2 (61) The spare wheel should be set to the highest applicable pressure shown in the table.

  • Page 194: Customer Information

    Customer information Customer information Customer information Vehicle data recording and privacy Declaration of conformity Event data recorders This vehicle has systems that Customer information ....192 transmit and/or receive radio waves Vehicle data recording and pri‐ Data storage modules in the subject to Directive 1999/5/EC.
  • Page 195 After an error has been openers. RFID technology in Opel corrected, the data are deleted from vehicles does not use or record the error storage module or they are personal information or link with any constantly overwritten.

  • Page 196: Index

    Index Accessories and vehicle Battery, jump starting....161 modifications ......133 Belts..........44 Adaptive forward lighting ..90, 143 Bonnet ........134 Adjustable air vents ....104 Brake assist ....... 120 Airbag and belt tensioners ... 79 Brake fluid ......137, 169 Airbag deactivation ....
  • Page 197 Climate control systems....95 Clock ..........72 Electric adjustment ...... 31 Fault ........... 118 Control indicators......77 Electrical system......149 Fire extinguisher......66 Control of the vehicle ....107 Electronic climate control system 97 First aid......... 66 Controls........69 Electronic driving programmes . . 117 First aid kit ........
  • Page 198 Interior lighting......91 Manual transmission automated 115 Interior lights ......91, 147 Manual windows ......33 Hand brake - see Parking brake. 120 Interior mirrors......32 Messages........84 Hazard warning flashers ....90 Interruption of power supply ..118 Mirror adjustment ......8 Headlight flash ......
  • Page 199 Pollen filter ......... 105 Roof..........35 Steering wheel controls ....69 Power door locks......23 Roof load........67 Stop engine........80 Power outlets ....... 72 Roof rack ........67 Stop-start system....83, 109 Power side step......25 Storage......... 61 Power sliding door......25 Storage compartments....

  • Page 200: Ultrasonic Parking Assist

    Tread depth ....... 153 Vehicle jack........ 151 Trip computer ......86 Vehicle messages ....... 84 Triple-Info-Display ....... 84 Vehicle security......28 Trip odometer ......74 Vehicle specific data ...... 3 Turn and lane-change signals ..90 Vehicle storage......133 Turn signal ........79 Vehicle tools.......
  • Page 201 Copyright by ADAM OPEL AG, Rüsselsheim, Germany. The information contained in this publication is effective as of the date indicated below. Adam Opel AG reserves the right to make changes to the technical specifications, features and design of the vehicles relative to the information in this publication as well as changes to the publication itself.

Table of Contents
