Version 2.0
DELUXE TABLE RADIO
With docking for iPod and iPhone
DAB | DAB+ | FM | Internet Radio | Audio Streaming
Owner's Manual
Bedienungsanleitung
Manuel de l'utilisateur
Manuale dell'utente

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the heritage and is the answer not in the manual?

Questions and answers

Summary of Contents for Revo heritage

  • Page 1 Version 2.0 DELUXE TABLE RADIO With docking for iPod and iPhone DAB | DAB+ | FM | Internet Radio | Audio Streaming Owner’s Manual Bedienungsanleitung Manuel de l’utilisateur Manuale dell’utente...
  • Page 2: Technical Support

    WARRANTY Should you encounter problems using this product, please refer to the Revo Technologies Ltd warrants to the end user that this product will troubleshooting section on page 39 of this owner’s guide. be free from defects in materials and workmanship in the course of Alternatively, call Revo technical support on : normal use for a period of one year from the date of purchase.
  • Page 3: Table Of Contents

    CONTENTS WELCOME Thank you for purchasing our Heritage radio, we are sure that it will Technical Support provide you with many years of enjoyment and reliable service. This guide has been designed to quickly get you up-and-running Environmental Info with your radio, offer guidance on the more complex features of...
  • Page 4: Anatomy

    ANATOMY OF HERITAGE Snooze/Sleep Bar Play/Pause iPod/iPhone Dock Skip Back Skip Forward Feedback OLED Cursor Control Mode Menu Info Alarm Volume Dial Station Presets 1 - 5 iPod Video Out Telescopic Antenna Power/Standby DC Power Socket Digital Optical Out Wired LAN Aux-In 3.5 Headphone Connector...
  • Page 5: Remote Control

    18 - Skip Forward (Fast Forward) 19 - Feedback (Love/Ban) BATTERY REPLACEMENT The Heritage remote control is powered by a single 3V lithium battery. Depending on usage, the battery should happily run for between 1 and 2 years. Replace the battery when button presses seem sluggish, or when the operating range appears to have reduced signifi...
  • Page 6: Power Supply

    Using the PSU supplied, connect one end to the DC power socket found on the rear of Heritage, then plug the opposite end into the mains socket on the wall. Press the POWER button once to start the initialisation process.
  • Page 7: Controlling Heritage / Menu Structure

    ‘PRESS’ (TO SELECT) Pressing the MODE button will sequentially cycle through each of ‘DOWN’ Heritage’s modes of operation. It is also possible to move between modes of operation via the MAIN MENU (see below). MENU STRUCTURE EXPLAINED MAIN MENU MODE MENUS...
  • Page 8: Dab Mode

    MAIN MENU, radio then DAB from menu option list. Scanning On power-up, Heritage will automatically perform a full scan to see Stations : 21 what stations are being broadcast in your area, before storing them Scanning alphabetically in the radio’s memory.
  • Page 9: Dab Radio Mode

    BBC 6Mus BBC Gael FAVOURITE STATION PRESETS Heritage allows you to store your favourite stations as presets, either via its 5 front panel mounted ‘hot-keys’, or 10 preset buttons located on the Heritage remote control. To store the station you are currently listening to as a preset, simply BBC Radio 6Music press and hold a preset button until “Preset Stored”...
  • Page 10: Dab Mode Menu Options

    DAB MODE MENU OPTIONS STATION INFO In DAB MODE, Heritage is capable of displaying various pieces of information on its screen. By pressing the button, you can sequentially cycle through the following types of information. BBC Radio 6Music STANDARD DAB SCREEN...
  • Page 11 DAB MODE MENU OPTIONS DYNAMIC RANGE COMPRESSION (DRC) If you are listening to music with a high dynamic range in a noisy environment (for example, classical music while cooking), you may DRC Low wish to compress the audio’s dynamic range. This has the effect of DRC High DRC Off making quiet sounds louder, and loud sounds quieter.
  • Page 12: Fm Mode.

    MAIN MENU, radio then FM from menu option list. If this is the fi rst time that Heritage has been used in FM MODE, 87.50 MHz scanning will start at the beginning of the frequency range - otherwise Heritage will default to the station you were listening to last.
  • Page 13: Fm Mode / Aux-In Mode

    MP3 player) through your radio. To do so, connect your external audio source to the 3.5mm AUX IN connector on the rear of Heritage. Turn the volume down low on both Heritage and, if adjustable, the external device. Now press...
  • Page 14: Ipod Mode

    MODE FITTING A DOCK ADAPTOR Adaptor No. iPod Model Heritage is supplied with a selection of dock adaptors to fi t most iPod classic 80GB iPod/iPhone models. iPod classic 120GB iPhone Select the adaptor that is compatible with your iPod/iPhone using the...
  • Page 15 Lastly, it is possible to control the iPod/iPhone by using the controls on the iPod/iPhone itself. VIDEO Heritage is equipped with a set of composite video-out connectors, making it possible to view iPod/iPhone movies, slideshows etc. on your television - all directly from your radio.
  • Page 16 (if this information is stored on your iPod/iPhone). Heritage is capable of displaying various pieces of information about the current track and the iPod/iPhone that is connected. By pressing the button, it is possible to sequentially cycle through the following types of information.
  • Page 17 INTERNET SETUP USING THE INTERNET RADIO SETUP WIZARD The fi rst time you use Heritage in INTERNET RADIO MODE, you will be asked whether you would like to run the SETUP WIZARD. The ‘WIZARD’ will run through a series of questions, and is the simplest way to get internet radio up and running on your device.
  • Page 18: Internet Setup

    F G H I J K L M N O P Q Select (back space) if you have entered an incorrect BK S P character. Heritage will save the password into its memory. There will be no need to re-enter the password again.
  • Page 19: Internet Radio Mode

    INTERNET RADIO MODE GETTING STARTED To enter INTERNET RADIO MODE, press the button until the INTERNET RADIO MODE intro screen is displayed, alternatively press Internet radio then select MAIN MENU, then INTERNET RADIO from the menu option list. The INTERNET RADIO MENU comprises of the following options: My Favourites: Used to navigate to your favourite stations.
  • Page 20 TUVWXYZ CANCEL If your station is found, simply select to listen. If you searched for a keyword, Heritage will list all the stations found that contain that particular keyword. Scroll through the list and select your station. CHOOSING A PODCAST BBC Radio 1 Podcasts (also referred to as ‘Listen Again’) are searched and...
  • Page 21 INTERNET RADIO MODE MY FAVOURITES It is possible to compile a list (or lists) of your favourite stations, allowing quick and easy access to a number of stations from different countries and genres. To do this you must fi rst register your radio with the Frontier Silicon Radio Portal.
  • Page 22 INTERNET RADIO MODE HELP Get access code Access code The HELP option can be found in the STATIONS LIST MENU. Under HELP , HEBZM0Z you will fi nd the ACCESS CODE that you require to register your radio on the Frontier Silicon Radio Portal (see page 23 for full instructions). A helpful FAQ audio track can also be found under the HELP heading.
  • Page 23: Internet Radio Portal

    INTERNET RADIO PORTAL ACCESSING ADDITIONAL FEATURES Some of Heritage’s more advanced internet radio features can only be accessed by visiting the Frontier Silicon Radio Portal. In order to access these features you must fi rst register your radio. REGISTERING YOUR RADIO In order to register your radio, you will need your radio’s unique...
  • Page 24: Setting Up A Music Server

    SETTING UP A MUSIC SERVER In order for Heritage to be able to play music fi les from a connected computer, the computer must fi rst be set up for media sharing. UPnP media sharing allows devices like Heritage to play music from a shared media library, navigating through tag menus such as Artist, Album or Genre.
  • Page 25 SETTING UP A MUSIC SERVER SHARING MEDIA WITH A MAC In order to connect Heritage to your Apple Mac, a third party UPnP server application is required. There are a number of applications available to download from the Internet. One such application is EyeConnect. This is an easy to install media sharing application that enables Heritage to stream audio.
  • Page 26: Music Player Mode

    MUSIC PLAYER MODE PLAYING AUDIO TRACKS IN THE MUSIC PLAYER MUSIC PLAYER MODE allows you to play audio fi les such as MP3s, AACs, WMAs or FLACs directly from a computer or music server on your local network. To enter MUSIC PLAYER MODE, press until the MUSIC PLAYER MODE intro screen is displayed, alternatively press then select...
  • Page 27 (typically Windows Media Player). The fi rst menu shows a list of media types, for example music, video, pictures and playlists. Heritage can only play music and playlists. There is also a search function, which fi nds tracks in a similar way to Internet radio search, as described on page 20.
  • Page 28 MUSIC PLAYER MODE PLAYLISTS Heritage is capable of holding a queue of up to 500 tracks in its playlist. Playlist tracks can be mixed from multiple UPnP servers and USB devices. To manage the playlist, select MY PLAYLIST from the MUSIC PLAYER MENU.
  • Page 29: Last.fm Mode

    To turn SCROBBLING ON or OFF, select LAST.FM SETUP , then User Accounts > Scrobbling: on SCROBBLING, now select ON or OFF. Note : if you intend to let other people use Heritage in LAST.FM MODE, you may want to turn SCROBBLING OFF. Alternatively, you could switch to another account.
  • Page 30 LAST.FM MODE While listening to LAST.FM you can choose to LOVE or BAN tracks (which SCROBBLES them even if SCROBBLING is set to OFF). Telling LAST.FM that you LOVE a track will add that particular track to your Last.fm YOUR LOVED TRACKS list, allowing playback at a future time. BANNING a track will mean it will never be played again.
  • Page 31 LAST.FM MODE PLAYING MUSIC (continued) ARTIST RADIO Plays a selection of tracks by a certain artist, together with tracks by Artist radio Search: artists that have a similar musical style. Pick an artist by entering their Rolling The Rolling Stones Rolling Stones name or part of their name (you don’t have to enter the full name, 0 1 2 3 4 5...
  • Page 32: Alarm Clock

    ALARM CLOCK SETTING AN ALARM Heritage is able to store two individual alarm settings. To set or Alarms Alarm 1: Off [06:55AM] change an alarm, either press the button, or select MENU, Alarm 2: Off [07:50AM] then MAIN MENU, then ALARM. Select which of the ALARM SETTINGS (Alarm 1 or Alarm 2) you would like to modify or enable.
  • Page 33 Alternatively, press then select MAIN MENU, then SLEEP . You can now set the SLEEP timer to any one of the following pre-sets. When you have selected a sleep duration, Heritage will return to the MAIN MENU. Press to return to the NOW PLAYING screen.
  • Page 34: System Settings

    SYSTEM SETTINGS EQUALISER Heritage provides the user with a signifi cant degree of control over its standard (factory default) audio settings. This includes control over BASS and TREBLE, LOUDNESS and the ability to use one of a number of preset EQ settings. It is also possible to create your own personalised EQ setting - known as “My EQ”.
  • Page 35 MANUAL SETTINGS : Detailed control of Wired and Wireless connections. NETWORK PROFILE : Shows the names of the last four wireless networks Heritage has been connected to. NOTE: Heritage remembers the last four wireless networks it has connected to, and automatically tries to connect to whichever one of them it can fi...
  • Page 36 Takes time/date from your internet connection. BRIGHTNESS Heritage allows a degree of control over the brightness of its OLED display, meaning that both its STANDBY and POWER ON brightness levels can be independently set to either HIGH, MEDIUM or LOW brightness levels.
  • Page 37 Software updates are carried out ‘over-the-air’, via your broadband connection. Heritage will to check for software updates each time it is switched on, and if an update is available, will ask you to confi rm that you’d like to go ahead and commence the download.
  • Page 38 To manually check for updates, select CHECK NOW from the SOFTWARE UPDATES menu. CAUTION : Before commencing a software upgrade, ensure that Heritage is plugged into a stable mains power connection. Disconnecting power during a software update may permanently System settings damage your radio.
  • Page 39: Troubleshooting

    MAC addresses. NETWORK > VIEW SETTINGS and add to router list NOTE: Heritage has separate MAC addresses for wired and wireless networks; only the current net- work adaptor method address is displayed, but the other address can be obtained by changing the fi...
  • Page 40 TROUBLESHOOTING PROBLEM CAUSE SOLUTIONS Cannot connect to Internet Internet connection down Check that the Internet is working for a computer connected to the same network. Firewall preventing access Check the following ports are open: UDP and TCP ports 80 and 123 DNS port 53.
  • Page 41: Error Messages

    No UPnP media found No UPnP servers found. Service not available (DAB) No DAB reception. Unauthorised Access not grated by UPnP server. Allow access for Heritage in UPnP server settings. Update failed Software upgrade failed. Network not ready problem with connection to router.
  • Page 42 NOTES...
  • Page 44 TECHNICAL SUPPORT TEL - + 44 (0) 1555 666161 E-MAIL - support@revo.co.uk WEB - www.revo.co.uk/support “Made for iPod”, and “Made for iPhone”, means that an electronic accessory has been designed to connect specifi cally to iPod or iPhone, respectively, and has been certifi ed by the developer to meet Apple performance standards.
