S u b C o m p a c t B o a r d
37 DE
39 N.C.

2.25 Serial Port #2 (CN13)

COM2/ RS-232 Mode
Pin Signal
1 DCDB
3 TXB
5 Ground
7 RTSB
9 RIB (+5V/ +12V)
COM2/ RS-422 Mode
Pin Signal
1 TXD-
3 TXD+
5 Ground
7 N.C.
9 N.C.
COM2/ RS-485 Mode
Pin Signal
1 TXD-
3 TXD+
5 Ground
7 N.C.
9 N.C.

2.26 Fan Connector (CN14)

Pin
1
Chapter 2 Quick Installation Guide
Signal
FAN Sense
2 - 24
P C M - 5 3 1 5
38 HSYNC
40 N.C.
Pin Signal
2 RXB
4 DTRB
6 DSRB
8 CTSB
10 N.C.
Pin Signal
2 RXD+
4 RXD-
6 N.C.
8 N.C.
10 N.C.
Pin Signal
2 N.C.
4 N.C.
6 N.C.
8 N.C.
10 N.C.
