EMAC PCM-9580F-00A1 User Manual

Emac pcm-9580 series single board socket 478 pentium iv sbc with vga, lvds, ethernet, audio, & usb 2.0
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PCM-9580
Socket 478 Pentium IV SBC with
VGA, LVDS, Ethernet, Audio, &
USB 2.0
Users' Manual
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCM-9580F-00A1 and is the answer not in the manual?

Questions and answers

Related Manuals for EMAC PCM-9580F-00A1

Summary of Contents for EMAC PCM-9580F-00A1

  • Page 1 PCM-9580 Socket 478 Pentium IV SBC with VGA, LVDS, Ethernet, Audio, & USB 2.0 Users’ Manual...
  • Page 2 Copyright This document is copyrighted, © 2003. All rights are reserved. The orig- inal manufacturer reserves the right to make improvements to the prod- ucts described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 3: Packing List

    • 1 Mini Jumper*10 PCS Package (p/n: 9689000002) If any of these items are missing or damaged, contact your distributor or sales representative immediately. Model No. List Description PCM-9580F-00A1 W/ 100 BASE-T Ethernet PCM-9580FG-00A1 W/ 1000 BASE-T Ethernet Caution! Possible danger of explosion if batteries (if any) are incorrectly replaced.
  • Page 4 Additional Information and Assistance 1. Visit the distributator web site at www.emacinc.com where you can find the latest information about the product. 2. Contact your distributor, sales representative, or customer service center for technical support if you need additional assistance. Please have the following information ready before you call: •...

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction ............2 Introduction ............... 2 Highly integrated multimedia SBC......... 2 Features ................3 Specifications ..............3 Board layout: dimensions..........6 Figure 1.1:Board layout: dimensions......6 Chapter 2 Installation ............8 Jumpers................8 Table 2.1:Jumpers............8 Connectors................. 9 Table 2.2:Connectors ............9 Locating jumpers and Connectors........
  • Page 6 2.17.1 CRT display connector (CN9) ........17 2.17.2 LVDS LCD panel connector (CN5) ......17 2.17.3 Panel type selection (S1)..........18 2.18 TV-out interface (optional) (CN20) ........ 18 2.19 Ethernet configuration............. 18 2.19.1 100Base-T connector (CN3, PCM-9580F)....19 2.19.2 1000Base-T connector (CN8, PCM-9580FG) ....19 2.19.3 Network boot ..............
  • Page 7 4.2.10 Load Optimized Defaults..........38 4.2.11 Set Password ..............38 4.2.12 Save & Exit Setup............39 4.2.13 Exit Without Saving............39 Chapter 5 PCI SVGA Setup ..........42 Introduction ..............42 5.1.1 Chipset ................42 5.1.2 Display memory............42 5.1.3 Display types..............42 5.1.4 Dual/Simultaneous Display ..........
  • Page 8 Appendix C System Assignments ........116 System I/O Ports............116 Table C.1:System I/O Ports ........116 1st MB memory map............. 117 Table C.2:1st MB memory map ......... 117 DMA channel assignments..........117 Table C.3:DMA channel assignments ......117 Interrupt assignments ............ 118 Table C.4:Interrupt assignments .........

  • Page 9: General Information

    General Information This chapter gives background information on the PCM-9580. Sections include: • Introduction • Features • Specifications • Board layout and dimensions Chapter 1...

  • Page 10: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Introduction The PCM-9580 is a Socket 478 Pentium IV single board computer (SBC) with Gigabit, USB 2.0, 2channel 48-bit LVDS, audio controller, a 4X AGP SVGA controller, one PCI slot and TV-out function. It supports Pentium IV up to 3.06 GHz. The PCM-9580’s design is based on the 5.25"...

  • Page 11: Features

    1.2 Features • Socket 478 up to 3.06 Ghz Intel Pentium 4 • Supports Gigabit Ethernet (PCM-9580FG) • Supports Embedded USB, 4 USB 2.0 ports • Supports 2-channel 48-bit LVDS interface • Optional Audio Module 1.3 Specifications Standard SBC Functions •...
  • Page 12 VGA/LCD Interface • Chipset: Intel 845GV +Chrontel CH7017 • Frame buffer: Supports 8 MB to 64 MB frame buffer with system memory • Interface: 4x AGP VGA/LVDS interface • Display mode: CRT Modes: 1280 x 1024@16bpp (60Hz), 1024 x 768@16bpp, , 1600 x 1200@32bpp (85Hz) •...
  • Page 13 • Max : 0.4 A @ +5 V, 6.0 A @ +12 V ,12.51 A@3.3 V • (within 5 ms after power on) • Typical: 0.25 A @ +5 V, 0.145 A @ +12 V, 2.4 A @ +3.3 V •...

  • Page 14: Board Layout: Dimensions

    1.4 Board layout: dimensions Figure 1.1: Board layout: dimensions PCM-9580 User’s Manual...
  • Page 15 Installation This chapter explains the setup proce- dures of PCM-9580 hardware, includ- ing instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the instal- lation procedure. Chapter 2...

  • Page 16: Chapter 2 Installation

    Chapter 2 Installation 2.1 Jumpers The PCM-9580 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function LCD power select PCM-9580 User’s Manual...

  • Page 17: Connectors

    2.2 Connectors On-board connectors link the PCM-9580 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the func- tion of each of the board’s connectors. Table 2.2: Connectors Label Function USB channel 3, 4 connector TV-out connector (optional) Backlight control connector AC97 (Audio) connector...

  • Page 18: Locating Jumpers And Connectors

    2.3 Locating jumpers and Connectors Figure 2.1: Jumper & Connector (component side) PCM-9580 User’s Manual...

  • Page 19: Setting Jumpers

    2.4 Setting Jumpers You may configure your card to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric cir- cuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 20: Clear Cmos (Sw1)

    2.5 Clear CMOS (SW1) Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS.” Before turning on the power supply, set the jumper back to “3.0 V Battery On.” This jumper is used to erase CMOS data and reset system BIOS informa- tion.

  • Page 21: Ide, Cdrom Hard Drive Connector (Cn15, Cn13)

    2.7 IDE, CDROM hard drive connector (CN15, CN13) The PCM-9580 provides 2 IDE channels which you can attach up to four Enhanced Integrated Device Electronics hard disk drives or CDROM to the PCM-9580’s internal controller. The PCM-9580's IDE controller uses a PCI interface.

  • Page 22: Floppy Drive Connector (Cn12)

    2.9 Floppy drive connector (CN12) You can attach up to two floppy drives to the PCM-9580’s on-board con- troller. You can use any combination of 5.25” (360 KB and 1.2 MB) and/ or 3.5” (720 KB, 1.44 MB, and 2.88 MB) drives. A 34-pin daisy-chain drive connector cable is required for a dual-drive system.

  • Page 23: Parallel Port Connector (Cn11)

    2.10 Parallel port connector (CN11) Normally, the parallel port is used to connect the card to a printer. The PCM-9580 includes a multi-mode (ECP/EPP/SPP) parallel port accessed via CN11 and a 26-pin flat-cable connector. You will need an adapter cable if you use a traditional DB-25 connector. The adapter cable has a 26-pin connector on one end, and a DB-25 connector on the other.

  • Page 24: Power Connectors (Cn7, Cn9, Fan1)

    2.13 Power connectors (CN7, CN9, FAN1) 2.13.1 ATX power connector, +3.3V, +5V, +12V (CN8) Supplies main power to the PCM-9580 (+12V, +5V, +3.3V) and to devices that require. 2.13.2 ATX power connector, +12 V (CN10) Supplies ATX +12V power to the PCM-9580s Vcore of the CPU 2.13.3 CPU Fan power supply connector (FAN1) Provides power supply +12V to CPU cooling fan, and fan speed detects signal input.

  • Page 25: Pcm-231Av

    2.15.1 PCM-231AV The PCM-231AV provides CD audio input connector, microphone in (mono), line in (stereo) and line out (stereo), standard connector and S- video, composite-video connector for TV-out function on the PCM- 231AV. 2.15.2 CD audio input connector (CN3 on the PCM- 231AV) All CD-ROM drives can provide analog audio signal output when used as a music CD player.

  • Page 26: Panel Type Selection (S1)

    2.17.3 Panel type selection (S1) S1 is an 8 segment DIP switch for DSTN/TFT panel type and resolution functions. Table 2.3: S1 Panel Type select Panel Type Resolution LVDS** 640 x 480 LVDS** 800 x 600 LVDS* 1024 x 768 LVDS 1280 x 1024 LVDS**...

  • Page 27: 100Base-T Connector (Cn3, Pcm-9580F)

    2.19.1 100Base-T connector (CN3, PCM-9580F) 10/100Base-T connects to the PCM-9580F via an adapter cable to a 10- pin polarized header (CN3). 2.19.2 1000Base-T connector (CN8, PCM-9580FG) 10/100/1000 Base-T connects to the PCM-9580FG via an adapter cable to a 10-pin polarized header (CN8). 2.19.3 Network boot The Network Boot feature can be utilized by incorporating the Boot ROM image files for the appropriate network operating system.

  • Page 28: Watchdog Timer Configuration

    2.20 Watchdog timer configuration An on-board watchdog timer reduces the chance of disruptions which EMP (electro-magnetic pulse) interference can cause. This is an invalu- able protective device for standalone or unmanned applications. Setup involves one jumper and running the control software (refer to Appendix 2.20.1 Watchdog timer action (JP5) When the watchdog timer activates (CPU processing has come to a halt), it can reset the system or generate an interrupt on IRQ11.

  • Page 29: Embedded Usb Interface

    2.21.1 Embedded USB interface: Overview The Embedded USB interface Specification defines an alternate imple- mentation for small form factor USB Module referred to in this specifica- tion as a Embedded USB Module This specification uses a qualified sub-set of the same signal protocol, electrical definitions, and configuration definitions as the USB 2.0 Speci- fication.

  • Page 30: Table 2.5:Embedded Usb Pin Assignment

    2.21.1.2 Embedded USB Connector dimension and Pin assignment Embedded USB on board connector is used pitch 2 x 9 Pin header with 2.54mm pin Figure 1-1: Embedded USB Connector Dimension Pin Assignment Table 2.5: Embedded USB Pin Assignment Signal Signal GND (USB) GND (USB) Vcc (USB)

  • Page 31: Figure 2.2:Embedded Usb Mod. Type I

    Figure 2.2: Embedded USB Mod. Type I Note: 1. Type I will support Flash memory module only 2. Type I is a vertical assembly with mainboard (SBC) Chapter 2...

  • Page 32: Figure 2.3:Embedded Usb Type Ii/Iii Form Factor

    III. Type II/III Form Factor Figure 2.3: Embedded USB Type II/III Form Factor Notes: 1. Type II/III will support Flash memory Module, Blue-Tooth Module, Wireless LAN Module, and Industrial I/O control module 2. Type II/III is Board to Board horizontal assembly with Mainboard (SBC) PCM-9580 User’s Manual...

  • Page 33: Software Configuration

    Software Configuration This chapter details the software con- figuration information. It shows you how to configure the card to match your application requirements. The AWARD System BIOS is covered in Chapter 4. Sections include: • Introduction • Connections for standard LCDs •...

  • Page 34: Chapter 3 Software Configuration

    Chapter 3 Software Configuration 3.1 Introduction The PCM-9580 system BIOS and custom drivers are located in a 256 Kbyte, Flash ROM device, designated U6. A single Flash chip holds the system BIOS, VGA BIOS and network Boot ROM image. The display can be configured via CMOS settings.
  • Page 35 Table 3.1: Connections to Toshiba LTM10C209A ENAB M/DE +5 V +5 V Chapter 3...
  • Page 36 PCM-9580 User’s Manual...
  • Page 37 Chapter 4 Ducks that Need Love! Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 38: Chapter 4 Award Bios Setup

    Chapter 4 Award BIOS Setup 4.1 System test and initialization These routines test and initialize board hardware. If the routines encoun- ter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal.

  • Page 39: Award Bios Setup

    4.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 4.2.1 Entering setup Power on the computer and press <Del>...

  • Page 40: Standard Cmos Features Setup

    4.2.2 Standard CMOS Features setup When you choose the Standard CMOS Features option from the Initial Setup Screen menu, the screen shown below is displayed. This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is high- lighted, on-line help information is displayed in the left bottom of the Menu screen.

  • Page 41: Advanced Bios Features Setup

    4.2.3 Advanced BIOS Features setup By choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9580 Series. Figure 4.3: Advanced BIOS Features setup...

  • Page 42: Advanced Chipset Features Setup

    4.2.4 Advanced Chipset Features setup By choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9580 Series. Figure 4.4: Advanced Chipset Features setup 4.2.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below.

  • Page 43: Power Management Setup

    4.2.6 Power Management Setup By choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9580 Series. Figure 4.6: Power Management Setup 4.2.7 PnP/PCI Configurations By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed.

  • Page 44: Pc Health Status

    4.2.8 PC Health Status The PC Health Status option displays information such as CPU and moth- erboard temperatures, fan speeds, and core voltage. Figure 4.8: PC Health Status PCM-9580 User’s Manual...

  • Page 45: Frequency/Voltage Control

    4.2.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9580 Figure 4.9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.

  • Page 46: Pcm-9580 User's Manual

    4.2.10 Load Optimized Defaults Load Optimized Defaults loads the default system values directly from ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load auto- matically when you turn the PCM-9580 Series system on. 4.2.11 Set Password Note To enable this feature, you should first go to the...

  • Page 47: Save & Exit Setup

    At the “Confirm Password” prompt, retype the new password, and press <Enter>. Select Save to CMOS and EXIT, type <Y>, then <Enter>. To Disable Password Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,”...
  • Page 48 PCM-9580 User’s Manual...

  • Page 49: Pci Svga Setup

    PCI SVGA Setup Introduction Installation of SVGA drivers -for Windows 98/2000/XP -for Windows NT Further information Chapter 5...

  • Page 50: Chapter 5 Pci Svga Setup

    Chapter 5 PCI SVGA Setup 5.1 Introduction The PCM-9580 has an onboard AGP flat panel/VGA interface. The spec- ifications and features are described as follows: 5.1.1 Chipset The PCM-9580 uses a Intel 845GV + Chrontel 7017 chipset. for its AGP/ SVGA controller.

  • Page 51: Dual/Simultaneous Display

    5.1.4 Dual/Simultaneous Display The PCM-9580 uses a Intel 845GV + Chrontel 7017 controller that is capable of providing simultaneous dual view display of the same content on a flat panel and CRT. To set up dual view (simultaneus mode) under Windows 9x, Windows ME, Windows NT/2000/XP, follow these steps: Step 1.

  • Page 52: Installation Of The Svga Driver

    5.2 Installation of the SVGA Driver Complete the following steps to install the SVGA driver. Follow the pro- cedures in the flow chart that apply to the operating system that you are using within your PCM-9580. Notes: 1. The windows illustrations in this chapter are intended as examples only.
  • Page 53 Choose the "Adapter" tab, then press the "Change..." button. Press the "Have Disk" button. Chapter 5...
  • Page 54 Type in the path: D:\pcm-9580\drivers\VGA\Win9x_Me 9580 Select the highlighted item, and click the "OK" button. PCM-9580 User’s Manual...
  • Page 55 "S3 GraphicsTwister" appears under the adapter tab. Click the "Apply" button, then the "OK" button. Press “Yes” to reboot. Chapter 5...

  • Page 56: Installation For Windows 98/Me

    5.2.2 Installation for Windows 98/Me Select "Start", "Settings", "Control Panel", "Display", and "Set- tings," then press the "Advanced..." button. PCM-9580 User’s Manual...
  • Page 57 Select “Adapter,” then “Change.” Chapter 5...
  • Page 58 Press “Next,” then “Display a list..” Press the “Have disk...” button. PCM-9580 User’s Manual...
  • Page 59 Insert the CD into the CD-ROM drive. Type in the path D:\pcm-9580\drivers\VGA\Win9x_Me Then press “OK” 9580 Select the highlighted item, then click “OK.” Chapter 5...
  • Page 60 "S3 Graphics Twister"appears under the adapter tab. Click the "Apply" button. Press “Yes” to reboot. PCM-9580 User’s Manual...

  • Page 61: Installation For Windows Nt

    5.2.3 Installation for Windows NT Note: Service Pack X (X = 3, 4, 5, 6,...) must be installed first, before you install the Windows NT VGA driver. Select "Start", "Settings", "Control Panel" and double click the "Display" icon. Chapter 5...
  • Page 62 Choose the "Settings" tab, and press the "Display Type" button. PCM-9580 User’s Manual...
  • Page 63 Press the "Change..." button. Chapter 5...
  • Page 64 Click the "Have Disk..." button. Type the path: D:\pcm-9580\drivers\VGA\WinNT Press the "OK" button. PCM-9580 User’s Manual...
  • Page 65 Select the highlighted item, and click the "OK" button. Press "Yes" to proceed. Press "OK" to reboot. Chapter 5...

  • Page 66: Installation For Windows 2000

    5.2.4 Installation for Windows 2000 Select "System", "Settings", "Control Panel" and double click the "system" icon. PCM-9580 User’s Manual...
  • Page 67 Choose the "Video Controller (VGA Compatible)” button. Chapter 5...
  • Page 68 Choose the "Drive" button, press “Update Driver...” button. PCM-9580 User’s Manual...
  • Page 69 Choose "Display a list of..." , then press “Next” button. Choose “Display adapters”, press “Next” button. Chapter 5...
  • Page 70 Click the “Have Disk” button. Type the path D:\pcm-9580\drivers\VGA\Win2000 press the “OK” but- ton. D:\Biscuit\9580\VGA\WIN2000 PCM-9580 User’s Manual...

  • Page 71: Installation For Windows Xp

    Press “Finish" to reboot. 5.2.5 Installation for Windows XP Select "System", "Settings", "Control Panel" and double click the "system" icon. Chapter 5...
  • Page 72 Choose “Hardware” and “Device Manager”, press “OK” button. PCM-9580 User’s Manual...
  • Page 73 Choose “Video Controller (VGA Compatible), press “OK” button. Chapter 5...
  • Page 74 Choose "Driver”, “Update Driver”, press “OK” button. Choose “Install from a list..” , press “Next”. PCM-9580 User’s Manual...
  • Page 75 Choose “Don’t search. I will..”, press “Next” button. Choose “Display adapters”, press “Next” button. Chapter 5...
  • Page 76 Type the path D:\pcm-9580\drivers\VGA\WinXP then press “OK” but- ton. 9580 Choose “S3 Graphics Twister + S3 Hotkey” then press “Next” but- ton. PCM-9580 User’s Manual...

  • Page 77: Further Information

    Press “Finish" to reboot. 5.3 Further Information For further information about the AGP/VGA installation in your PCM- 9580, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: VIA website: www.via.com.tw EMAC website: www.emacinc.com Chapter 5...
  • Page 78 PCM-9580 User’s Manual...

  • Page 79: Audio Setup

    Audio Setup The PCM-9580F is equipped with an audio interface that records and plays back CD-quality audio. This chapter provides instructions for installing the software drivers included on the audio driver diskettes. Chapter 6...

  • Page 80: Chapter 6 Audio Setup

    Chapter 6 Audio Setup 6.1 Introduction The PCM-9580F can receive audio by connecting with PCM-231AV (AC97 Link). PCM-231AV provides high-quality stereo sound and FM music synthesis (ESFM) by using the Realtek ALC201 Audio Codec from Realtek. The audio interface can record, compress, and play back voice, sound, and music with built-in mixer control.
  • Page 81 6.2.2 Windows 9x/2000/Me/XP drivers Step 1. Click "Start" and select "Settings". Click "Control Panel" and double-click Multimedia" icon and press " Reinstall Driver..." to do audio driver installation.. Chapter 6...
  • Page 82 Step 2. In the Hardware Update Wizard window, click "Next". Step 3. In the following Hardware Update Wizard window, click "Fin- ish" for Windows to complete audio driver installation. PCM-9580 User’s Manual...
  • Page 83 6.2.3 Windows NT drivers Step 1. Click "Start" and select "Settings". Click "Control Panel" and double-click "Multimedia". Step 2. In the Multimedia Properties window, select the "Devices" tab. Then select the "Audio Devices" item, and click "Add...". Chapter 6...
  • Page 84 Step 3. In the Add window, select the "Unlisted..." item and click "OK". Step 4. When the Install Driver window appears, insert the utility disc into the CD-ROM drive. Type: D:\Audio\ALC201\WinNT\ Then click "OK". D:\Audio\ALC201\WinNT\ PCM-9580 User’s Manual...
  • Page 85 Step 5. In the Add Unlisted or Updated Driver window, select the "Avance AC'97 Audio Driver" item. Then click "OK". Step 6. In the System Setting Change window, click "Restart Now". Chapter 6...
  • Page 86 PCM-9580 User’s Manual...

  • Page 87: Lan Configuration

    LAN Configuration • Introduction • Features • Installation of Ethernet Driver for - Windows 2000 Drivers Setup Steps - Windows NT Drivers Setup Steps -Windows Wake-on-LAN Setup Chapter 7...

  • Page 88: Chapter 7 Pci Bus Ethernet Interface

    Chapter 7 PCI Bus Ethernet Interface 7.1 Introduction The PCM-9580F is equipped with a high-performance 32-bit Ethernet chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/CD standards. It is supported by major network operating systems. It is also both 100Base-T and 10Base-T compatible.

  • Page 89: Installation For Windows 2000

    7.3.1 Installation for Windows 2000 Note: The CD-ROM drive is designated as"D" throughout this section. Click "Setup" icon in path "D:\LAN\" Chapter 7...
  • Page 90 Choose "Modify" item and click "Next" to go next step. Highlight "Drivers for wired Ethernet adapters" and click "Next". PCM-9580 User’s Manual...
  • Page 91 Click "Install" to begin the installation. Click "Finish" to exit the wizard. Chapter 7...
  • Page 92 Then the Installer will show the result after driver installed. PCM-9580 User’s Manual...

  • Page 93: Installation For Windows Nt

    7.3.2 Installation for Windows NT 1. Select "Start", "Settings", "Control Panel" and double click "Network" icon. 2. Then this menu will show on the screen. And click "Yes" to install net- work driver. Chapter 7...
  • Page 94 3. Select "Wired to the network" and click "Next" 4. Click "Start Search" to searh a Network Adapter. Then click "Next" to go next step PCM-9580 User’s Manual...
  • Page 95 5. Base on current network environment to modify the Network Protocol then Click "Next" Chapter 7...
  • Page 96 6.Click "Next" to go to next step 7. Click "Next" to install Network Adapter driver. PCM-9580 User’s Manual...
  • Page 97 8. Check the Licemse Agreement first then select "I accept the terms in the license agreement" and click "Next". 9. Select "Typical" and Click "Next". Chapter 7...
  • Page 98 10. Click "Install" to start to install driver. 11. Click "Finish" to finish install driver. PCM-9580 User’s Manual...

  • Page 99: Further Information

    7.4 Further information Realtek website: www.intel.com EMAC website: www.emacinc.com Chapter 7...
  • Page 100 PCM-9580 User’s Manual...
  • Page 101 Programming the Watchdog Timer The PCM-9580 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments. Appendix A...

  • Page 102: Appendix A Programming The Watchdog Timer

    Appendix A Programming the Watchdog Timer A.1 Supported Input Timing Modes In order to program the watchdog timer, you must write a program which writes I/O port address 443 (hex). The output data is a value of time inter- val. The value range is from 01 (hex) to 3E (hex), and the related time interval is 1 sec.
  • Page 103 The following example shows how you might program the watchdog timer in BASIC: REM Watchdog timer example program OUT &H443, data REM Start and restart the watchdog GOSUB 1000 REM Your application task #1 OUT &H443, data REM Reset the timer GOSUB 2000 REM Your application task #2 OUT &H443, data...
  • Page 104 PCM-9580 User’s Manual...

  • Page 105: Pin Assignments

    Pin Assignments This appendix provides specialized information regarding: • CPU Fan Power Connector • Ethernet 10/100Base-T Connector • Ethernet 100/1000Base-T Connector • Audio Connector • CD Drive Connector • Main Power Connector • Keyboard and PS/2 Mouse Connector • Floppy Drive Connector •...

  • Page 106: Appendix B Pin Assignments

    Appendix B Pin Assignments B.1 CPU Fan Power Connector (FAN 1) Table B.1: IR connector (FAN 1) Signal Fan speed signal input +12 V B.2 Ethernet 10/100Base-T Connector (CN25) Table B.2: Ethernet 10/100Base-T connector (C25) Signal CRS LED RCV+ RCV- BNC LED XMT+ XMT-...

  • Page 107: Ethernet 10/100/1000 Base-T Connector (Cn26)

    B.3 Ethernet 10/100/1000 BASE-T connector (CN26) Table B.3: Ethernet 100/1000-T connector (CN26) Signal MDI_3+ signal MDI_3- signal MDI_2+ signal MDI_2- signal MDI_1+ signal MDI_1- signal MDI_0+ signal MDI_0- signal1 Appendix B...

  • Page 108: Ethernet Led Connector

    B.4 Ethernet LED connector Table B.4: Giga bit Ethernet LED (CN27) Signal LINK ACT. LINK100 LINK1000 B.5 ACLink audio connector (CN4) Table B.5: Table A-15: Audio connector Signal Signal Bit clock signal SDATIN SYNC Signal S DATOUT Reset N.C. PCM-9580 User’s Manual...

  • Page 109: Atx Main Power Connector (Cn6)

    B.6 ATX Main Power Connector (CN6) Table B.6: ATX power connector (CN6) Pin name Pin name 3.3V 3.3V 3.3V -12V PSON* PWROK +5VSB +12V B.7 ATX 12V power connector (CN10) Table B.7: ATX 12 V power connector Signal +12V +12V Appendix B...
  • Page 110 B.8 Keyboard and PS/2 Mouse Connector (CN17) Table B.8: Keyboard and mouse connector (CN17) Signal KB CLOCK KB DATA MS CLOCK +5V (KB VCC) MS DATA PCM-9580 User’s Manual...
  • Page 111 B.9 Floppy Disk Drive Connector (CN12) Table B.9: Floppy Disk Drive Connector (CN12) Signal Signal DENSITY SELECT* DRIVE TYPE INDEX* MOTOR O* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE*...
  • Page 112 B.10 IDE Hard Drive Connector (CN15, CN13) Table B.10: IDE HDD connector (CN15, CN13) Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14...
  • Page 113 B.11 Parallel Port Connector (CN11) Table B.11: Parallel Port Connector (CN11) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active Appendix B...
  • Page 114 B.12 Front Panel (CN14) Table B.12: 1 HDD LED + Signal HDD LED + HDD LED - Power Good + GND (Power Good –) LAN Act. + LAN Act. - LAN Link + LAN Link - ATX Power Button ATX Power Button GND (Reset ) Reset PCM-9580 User’s Manual...

  • Page 115: Embedded Usb Connector (Cn23)

    B.13 USB Connector (CN1) Table B.13: USB Connector (CN1) Signal Signal +5 V +5 V Chassis GND B.14 Embedded USB Connector (CN23) Table B.14: USB Connector (CN23) Signal Signal GND (USB) GND (USB) Vcc (USB) Vcc (USB) Data 1- Data 2- Data 1+ Data 2+ GND (USB)
  • Page 116 B.15 LCD Inverter Backlight Connector (CN3) Table B.15: LCD Inverter Backlight Connector (CN3) Signal +12 V ENABKL +5 V B.16 CRT Display Connector (CN9) Table B.16: CRT Display Connector (CN9) Signal Signal VGA G +5 V H-sync signal GREEN VGA G VGA G V-sync signal BLUE...
  • Page 117 B.17 TV (video) Out Connector (CN2) Table B.17: TV (video) Out Connector (CN2) Signal Luminance out (S-Video Y output, brightness) Chrominance out (S-Video C output, color) Composite video out Appendix B...
  • Page 118 B.18 LVDS Connector (CN5) Table B.19: LVDS Connector (CN5) Ping Signal Signal Ping-1 VDDSAFE (Select Pin-2 VDDSAFE (Select by JP2) by JP2) Pin-3 Pin-4 Pin-5 VDDSAFE (Select Pin-6 VDDSAFE (Select by JP2) by JP2) Pin-7 LVDS-0N Pin-8 LVDS_4N Pin-9 LVDS_0P Pin-10 LVDS-4P Pin-11...
  • Page 119 B.19 COM Port Connector (CN7) Table B.18: COM Port Connector (CN7) Signal Signal RLSD1 (DCD1) DSR1 RTS1 CTS1 DTR1 RLSD2 (DCD2) DSR2 RTS2 CTS2 DTR2 RLSD3 (DCD3) DSR3 RTS3 CTS3 DTR3 RLSD4 (DCD4) DSR4 RTS4 CTS4 DTR4 Appendix B...
  • Page 120 B.20 CompactFlash Card Connector (CN19) Table B.19: CompactFlash Card Connector (CN19) Signal Signal *CS0 *ATA SEL +5 V -IOCS16 *CD2 -CD1 -CS1 *VS1 -IORD *IOWR INTRQ +5 V *CSEL -VS2 *RESER IORDY *INPACK -REG *DASP -PDIAG * low active PCM-9580 User’s Manual...

  • Page 121: Gpio Connector (Cn16)

    B.21 GPIO Connector (CN16) Table B.20: GPIO Connector (CN16) Signal DIO IN 0 DIO OUT 0 DIO IN 1 DIO OUT 1 DIO IN 2 DIO OUT 2 DIO IN 3 DIO OUT3 Appendix B...
  • Page 122 PCM-9580 User’s Manual...
  • Page 123 System Assignments This Appendix contains information of a detailed nature: It includes: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments Appendix C...

  • Page 124: Appendix C System Assignments

    Appendix C System Assignments C.1 System I/O Ports Table C.1: System I/O Ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2...

  • Page 125: 1St Mb Memory Map

    Table C.1: System I/O Ports Addr. range (Hex) Device MPU-401 select from 300 ~ 330H (2 bytes) C.2 1st MB memory map Table C.2: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM *CC000h - EFFFFh Unused (reserved for Ethernet ROM) C0000h - CBFFFh Expansion ROM (for VGA BIOS)

  • Page 126: Interrupt Assignments

    C.4 Interrupt assignments Table C.4: Interrupt assignments Interrupt# Interrupt source IRQ 0 Interval timer IRQ 1 Keyboard IRQ 2 Interrupt from controller 2 (cascade) IRQ 3 COM2 IRQ 4 COM1 IRQ 5 COM4 IRQ 6 IRQ 7 LPT1 IRQ 8 IRQ 9 Reserved (audio) IRQ 10...
  • Page 127 Optional Extras for the PCM-9580 Appendix D...

  • Page 128: Appendix D Optional Extras

    Appendix D Optional Extras The PCM-9580F requires several cables for normal operation. You can make them yourself or purchase an optional cable kit assembly, which includes the following: D.1 PCM-10586-6000 Cable kit for PCM-9580F Table D.1: PCM-10586-6000 wiring kit for PCM-9580F Part No.

  • Page 129: Pcm-10586-6G00 Cable Kit For Pcm-9580Fg-00A1

    D.2 PCM-10586-6G00 Cable kit for PCM-9580FG-00A1 Table D.2: PCM-10586-6000 wiring kit for PCM-9580F Part No. Cable PCM-9580F Terminating Description Connector Connector 1701440350 2.5" and 1.8" CN13 2 x 8 pin header (2 mm) 15-pin DSUB 1701400452 3.5" IDE DMA/ CN15 40pin, 2.54 mm, 66 (40pin) female IDC (450...

  • Page 130: Atx Power Control Cable (Cn10)

    D.4 ATX Power Control Cable (CN10) part no.: 1703070101 PCM-9580 User’s Manual...

  • Page 131: Mechanical Drawings

    Mechanical Drawings Appendix E...

  • Page 132: Appendix E Mechanical Drawings

    Appendix E Mechanical Drawings E.1 Mechanical Drawings Figure E.1: PCM-9580 Mechanical Drawing (component side) PCM-9580 User’s Manual...
  • Page 133 Figure E.2: PCM-9580 Mechanical Drawing (solder side) Appendix E...
  • Page 134 PCM-9580 User’s Manual...

This manual is also suitable for:

Pcm-9580fg-00a1

Table of Contents
