Introducing the FireWire 800+GigaLAN
The FireWire 800+GigaLAN Combo features the latest
technology in FireWire 800 and Gigabit Ethernet.
Features and Benefits
Combo card design adds FireWire 800 (800 Mbps)
•
and Gigabit (10/100/1000 Mbps) Ethernet interface
to your computer at once
Fully compliant with PCI specification 2.3
•
Built-in 4-pin power connector provides extra power
•
when connected to the system's power supply
Hot-swapping feature allows you to
•
connect/disconnect 1394 devices without
powering down your system
FireWire 800 (1394b):
Adds two FireWire 800 (1394b) ports (1 int. + 1 ext.)
•
and two 1394a (400 Mbps) ports (1 int. + 1 ext.). The
internal Firewire ports share one bus and cannot be used
at the same time.
Supports IEEE 1394b and backwards compatible
•
with 1394a-2000 and 1394-1995 standards
Supports data transfer rates of 100, 200, 400, and
•
800 Mbps
04-0363A
FireWire 800+GigaLAN Combo
Quick Installation Guide
1
Advertisement
Related Manuals for SIIG FireWire 800+GigaLAN Combo
Summary of Contents for SIIG FireWire 800+GigaLAN Combo
- Page 1 FireWire 800+GigaLAN Combo Quick Installation Guide Introducing the FireWire 800+GigaLAN The FireWire 800+GigaLAN Combo features the latest technology in FireWire 800 and Gigabit Ethernet. Features and Benefits Combo card design adds FireWire 800 (800 Mbps) • and Gigabit (10/100/1000 Mbps) Ethernet interface to your computer at once Fully compliant with PCI specification 2.3...
- Page 2 Supports IEEE 802.1Q VLAN tagging • System Requirements Pentium II or equivalent computer with an available • PCI slot Windows 98SE/ME/2000/XP/Server 2003 • Package Contents (1) FireWire 800+GigaLAN Combo adapter • (1) Driver CD • This quick installation guide •...
- Page 3 Layout FireWire FireWire 800 (1394a) (1394b) FireWire 800 (1394b) FireWire (1394a) LED (10/100) Gigabit Ethernet LED (Gigabit) Power connector (optional) Figure 1. Board Layout Important: A) Two connection/activity LEDs are mounted next to the Gigabit Ethernet port. One LED indicates Gigabit connection while the other indicates 10/100 connection.
-
Page 4: Hardware Installation
Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Turn OFF the power to your computer. Unplug the power cord and remove your computer's cover. -
Page 5: Software Installation
Software Installation To ensure proper installation of this board, please follow these instructions step-by-step. Windows 98SE Install the board, boot up your system, and insert the driver CD. At the Add New Hardware Wizard, when PCI-to-PCI bridge is detected, click Next. Select Search for the best driver for your device. - Page 6 13. Select The Updated driver (Recommended), click Next, click Next again. 14. At the insert disk box, click OK, type D:, click OK, then click Finish. (Change D: to match your CD-ROM drive letter) 15. Click Yes to restart to complete the installation. Windows ME Install the board, boot up your system, and insert the driver CD.
- Page 7 Windows 2000 Install the board, boot up your system, and insert the driver CD. When the Ethernet Controller is detected, at the Found New Hardware Wizard, click Next. Select Search for a suitable driver for my device (recommended), then click Next. Check Specify a location, uncheck the other boxes, then click Next.
- Page 8 Windows XP Install the board, boot up your system, and insert the driver CD. When the Ethernet Controller is detected, choose Install from a list or specific location (Advanced), then click Next. Check Include this location in the search, uncheck the other box, type D:\LAN\XP, click Next, then Finish.
- Page 9 Windows Server 2003 Install the board, boot up your system, and insert the driver CD. When the Ethernet Controller is detected, choose Install from a list or specific location (Advanced), then click Next. Check Include this location in the search, uncheck the other box, type D:\LAN\2003, click Next, then Finish.
- Page 10 To Verify Successful Driver Installation Check Device Manager to verify successful driver installation. Windows 98SE/ME: From the main desktop, right click My Computer, then click Properties. Click Device Manager tab. Windows 2000/XP/Server 2003: Right click My Computer, then click Manage. Click Device Manager.
-
Page 11: Technical Support
The 5-year manufacturer warranty supplied with this product is offered by SIIG, Inc. If you should happen to encounter any problems with this product, please follow the procedures below. - Page 12 Fremont, CA 94538-3152 FireWire 800+GigaLAN Combo is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in publication are for identification only and may be trademarks of their respective companies.
