Summary of Contents for Astroflex VKE-103
- Page 1 VKE-103 REMOTE KEYLESS ENTRY ’ WNER S MANUAL © 2006 Astroflex Electronics, Inc. - All rights reserved ® 2006 ASTROFLEX ELECTRONICS...
-
Page 2: Table Of Contents
What is included... 1 Important information ... 1 System maintenance ... 1 FCC/ID notice... 1 Transmitter functions ... 2 Standard configuration ... 2 Using your system ... 2 Locking ... 2 Unlocking... 3 Disabling the AED without a transmitter... 3 Silent mode... -
Page 3: What Is Included
What is included The control module Super heterodyne receiver Two three-button transmitters A status LED indicator light A push-button Valet Important information Congratulations on the purchase of your keyless entry system. Due to the complexity of this system, it must be installed by an authorized dealer only. Installation of this product by anyone other than an authorized dealer voids the warranty. -
Page 4: Transmitter Functions
Transmitter functions The receiver uses a computer-based learn routine to learn the transmitter buttons. This makes it possible to assign any specific transmitter button, or combination of buttons, to any receiver function. The transmitter initially comes programmed with the Standard Configuration, but may also be customized by an authorized dealer. -
Page 5: Unlocking
off. After the ignition has been turned off, the status LED flashes slowly to indicate that the AED will be activated then, the LED flashes normally when AED has been activated. NLOCKING Pressing for one second unlocks the doors (if connected). The horn will honk twice (if connected) and the parking lights will flash twice to confirm reception of the command. -
Page 6: Panic Mode
To enter or exit Valet 1. Turn the ignition on. 2. Turn the ignition off. 3. Press and release the Valet The status LED will light steadily if you are entering Valet Mode. ANIC MODE If you are threatened in or near your vehicle, you can attract attention by triggering the system with your transmitter. -
Page 7: Glossary Of Terms
Dome light Supervision Activated or Deactivated: The dome light will illuminate for 30-seconds after turning the ignition off or when disarming the system with the remote transmitter. Glossary of terms Control Unit: The “brain” of your system. Usually hidden under the dash area of the vehicle. It houses the microprocessor that monitors your vehicle and controls all system functions. -
Page 8: Quick Reference Guide
QUICK REFERENCE GUIDE To lock the system press flash. The Failsafe® Starter Kill will prevent the vehicle’s starter from cranking if it has been installed. Locking (1) The vehicle’s horn (if connected) will honk and the parking lights will flash once to confirm locking of the system.
