Vortex Kaibab HD Manual

Download this manual

Adjustable Eyecup

Diopter Ring

Neckstrap

Attachment Point

Roof Prism Housing

Caution:

Binoculars are not intended for looking at the sun,

or any other intense light source. Such viewing

could damage the retina and cornea of your

eyes—even to the point of causing blindness.

Kaibab

VORTEX

THE FORCE OF OPTICS

Kaibab

The

Congratulations on your purchase of a

Kaibab HD. Waterproof, fog proof, and

rugged enough for the most extreme

conditions, the Kaibab HD binocular features

ultra-high definition optics for superb

viewing.

Using the Kaibab HD_______________4

Tips for Care and Handling___________8

Service and Repair Policy____________9

www.vortexoptics.com

Center Focus

Center Hinge

Objective Lenses

www.vortexoptics.com

BINOCUL AR

Tripod Adapter Socket

Need help?

Do you have a question about the Kaibab HD and is the answer not in the manual?

Page 1 VORTEX THE FORCE OF OPTICS Kaibab BINOCUL AR Congratulations on your purchase of a Kaibab HD. Waterproof, fog proof, and rugged enough for the most extreme conditions, the Kaibab HD binocular features ultra-high definition optics for superb viewing. Using the Kaibab HD_______________4...
Page 2 Adjusting the Eyecups With eyeglasses or sunglasses, The eyecups on the Kaibab HD retract the eyecups. binocular are built on a solid frame and Without eyeglasses or sunglasses, covered with rubber. They twist up and extend the eyecups.
Page 3 Keeping the lenses clean Maintain the optical brilliance of the Kaibab HD binocular by keeping the lens surfaces free of dust, dirt, and oils. 1. Remove dust or grit with pressurized air—or use a soft camel hair or optical brush.
