- Page 1 Service Guide Auto Washer Model: DWF-7589/8089 Serise SN SGWF7589001 FEB. 2000...
-
Page 2: Specifications
1. SPECIFICATIONS ITEM DWF-1089 DWF-9289 DWF-8089 DWF-7589 POWER SOURCE AVAILABLE IN ALL LOCAL AC VOLTAGE AND CYCLE 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz POWER CONSUMPTION 430W 480W 430W 480W 400W 460W 400W 460W 55Kg (GROSS : 64Kg) 54Kg (GROSS : 63Kg) - Page 3 è 2. Parts Diagram PARTS DIAGRAM...
-
Page 4: Parts Diagram
PARTS DIAGRAM... - Page 5 PARTS DIAGRAM...
-
Page 6: Parts Name
3-1. DWF-7589, DWF-8089 PART CODE PARTS NAME DESCRIPTION REMARK 3611611400 DECORATOR PANEL F PC FILM 0.188T 3614215520 PANEL F ABS 7589,8089,8059 PRPSSWN500 DWF-1089 NON-PUMP PRPSSWN800 P.C.B ASS'Y DWF-1089CTE NON-PUMP PRPSSWN900 DWF-1089PT PUMP 3614504210 PLATE T ABS , NON METALLIC 3610906700... - Page 7 PART CODE PARTS NAME DESCRIPTION REMARK 3611521700 CUSHION DOOR 3611405101 COVER L LEFT 7121401608 SCREW T2S PAN 4x16 SUS 3612725100 NON-PUMP 3612725110 HARNESS ASS¡fl Y PUMP 3612725120 NON-PUMP, SINGLE VALVE 3615403510 AC 110-130V/60Hz 3615403711 VALVE INLET COLD AC 220-240V/50Hz 3615402010 AC 220V/60Hz 3615403630 AC 110-130V/60Hz...
- Page 8 PART CODE PARTS NAME DESCRIPTION REMARK 3611200200 CLAMP B SW D2.6 ZN8-C PUMP 3618703700 250V/1A PUMP TERMINAL PUMP 3618703720 125V/3.15A PUMP 3611405320 COVER PUMP PUMP 7122501611 SCREW TAPPING T2 TRS 5x16 MFZN PUMP 3963220330 AC 110V/60Hz PUMP 3963821530 AC 120V/60Hz PUMP MOTOR SHADED POLE 3963322730...
- Page 9 PART CODE PARTS NAME DESCRIPTION REMARK 3611502800 CUSHION DOWN POM H=18mm 3964220400 AC 110V/60Hz F34-C 3964820510 AC 127V/60Hz F36-C 3610019700 MOTOR CONDENSER AC 220/60Hz F3A-C 3964310510 AC 220V/50Hz F32-1C 3964610310 AC 240V/50Hz F33-1C 3611502000 CUSHION UPPER 3618401400 ADC-12, DS=10, DP=48.5 60Hz PULLEY MOTOR AS 3618401420...
