LG LHX-557 Quick Setup Manual

Speaker Positions
The normal setup uses 6 speakers (2 front speakers, center speaker, 2 rear speakers and subwoofer).
• Front Speakers
From your listening poition, place the speakers an equal distance away and with an interval of 45 degrees between
speakers.
• Center Speaker
It is ideal if the center speaker and front speakers at the same height. You would normally place the center speaker
above or below the television as shown below.
• Rear Speakers
Place the rear surround speakers to the left and right behind the primary listening area. These speakers recreate
sound motion and atmosphere required for surround playback. For best results, do not install the rear speakers too far
behind the listening position, install them at or above the level of the listener's ears. It is also effective to direct the
rear speakers towards a wall or ceiling to further disperse the sound.
For smaller room sizes, if the audience is near to the rear wall, place the rear speakers opposite each other, and
24 - 36 inches above the listeners' ears.
• Subwoofer
This can be placed in any front position.
Subwoofer
Front Speaker
(Left)
Rear Speaker
(Left)
P/N: 3840R-Q046M
Center
Front Speaker
Speaker
(Right)
Rear Speaker
(Right)
Q u i c k S e t u p
Q u i c k S e t u
MODEL: LHX-557
5 DVD Combi Home Theater System
Please read this manual first!
Congratulations on purchasing this LG product.
We've included everything you need to get started.
If you have any problems, LG Representatives are
resource for answering your questions and helping you get
the most from your new product.
Please read this manual before attempting to return this
product to the store.
Thank you for making ZENITH a part of your home!
G u i d e
p G u i d e
For fast help, call us first!
1-877-993-6484
