Please refer to the complete "user's guide" on the installation disc to guide you
through any question you may have while using the eDoc Manager.
Information
Setting up the eDoc Manager in your network
Follow the steps below to set up the eDoc Manager in your LAN environment:
1. Plug the RJ-45 connectors into the eDoc Manager's LAN port and the Switch's LAN port.
2. Plug the AC adapter into the DC-Jack of the eDoc Manager. Plug the other end of the power
cable into a standard AC power outlet. After the eDoc Manager has booted, it will beep two
times and the System and Network LEDs will turn on (green) to indicate that the eDoc Manager
has successfully booted and established a network connection.
3. Connect a PC or Laptop to the Switch's LAN port.
Q
G
UICK
UIDE
1
Advertisement
Related Manuals for Plustek eDoc N600
Summary of Contents for Plustek eDoc N600
- Page 1 UICK UIDE Please refer to the complete “user’s guide” on the installation disc to guide you through any question you may have while using the eDoc Manager. Information Setting up the eDoc Manager in your network Follow the steps below to set up the eDoc Manager in your LAN environment: 1.
- Page 2 Connecting to the eDoc Manager using UDID The eDoc Manager uses Plustek’s Unique Device Identification (UDID) feature so you can connect to the eDoc Manager without the need for configuration. Since the eDoc Manager’s default connection method is DHCP and you may not know its IP address, it is recommended to use the eDoc Manager’s UDID to connect to it.
- Page 3 Connecting to the eDoc Manager from any computer using UDID 1. Please use the USB drive method described above to obtain the program required to connect to the eDoc Manager using UDID. 2. Start the “UDID_Loader.exe” file in the “UDIDLoader” folder on your USB drive. The UDID should already be loaded.
- Page 4 The UDID_Loader program has to be kept open when using this method to connect to your eDoc Manager. If you accidently close the UDID_Loader program, just launch it again and click on the Connect button to continue using your eDoc Manager. If the eDoc Manager times out due to inactivity, you need to close and re-launch the UDID_Loader program.
- Page 5 Changing the eDoc Manager’s connection method via USB Since the eDoc Manager’s default connection method is DHCP and you may not know its IP address, there is a way to change its connection method from DHCP to static using the built-in USB port.
- Page 6 6. Change the line [option ‘proto’ ‘dhcp’] to [option ‘proto’ ‘static’]. 7. Add the following lines under the [option ‘proto’ ‘static’] line. Alter the IP address and netmask lines according to your network environment (the IP address used here is an example). If you do not know the correct connection information, please consult your network administrator.
- Page 7 Configuring the eDoc Manager for the first time Before the eDoc Manager can be used in your network environment, there are some settings on the administrator side of things to take care of in addition to creating the necessary user accounts and groups.
- Page 8 Changing the connection method (IP address) Depending on your network environment, you may not wish to use the eDoc Manager’s default connection method of obtaining an IP address from a DHCP server. If you do wish to use DHCP as connection method, skip this part.
- Page 9 2b. If you select PPPoE from the Connection method drop-down list, enter the PPPoE account and PPPoE password for the eDoc Manager to use. 3. Click on the Apply button to save the changes. Creating user accounts Before the eDoc Manager can be accessed by your users, you need to create user accounts for them.
- Page 10 3. You only need to enter the Account name, Nickname and Mailbox of the new user account. You can leave the Password and Quota fields empty to use the default values. The default password is 123456 and you should advise your users to change it after they log on. The preset Quota is 10000 MB (10 GB) and can be adjusted at any time by opening the Space allocation page.
- Page 11 Logging on to the eDoc Manager as user Now that you know your eDoc Manager’s IP address and have created a couple of user accounts, the core functions are ready to be used by your users. The following steps describe how to log on to the eDoc Manager as a user and change the password.
- Page 12 5. Enter a new password into the Password field to change it. You can also change your Nickname and your file preview options. 6. Click on the Edit button to save the changes. 7. Click on the home button in the upper right corner of the eDoc Manager interface to return to the main interface.
