2. Hardware – B. Hardware
The hardware parts of the StreetStrider Eclipse are listed and labeled in the following table and figures. The
hardware parts of the StreetStrider JET (not shown) are identical to the Eclipse.
Table 2B-1. StreetStrider Eclipse Hardware List. Hardware parts are lettered in the following figure.
Dimension
Key
ITEM BOLTS, SCREWS, NUTS,
WASHERS
A Hex bolt on strider pole pivot, joint #1
B Washer under bolt on joint #1
C Hex barrel on lower strider pole clevis,
joint #2
D Screw for hex barrel on joint #2
E Hex shoulder bolt pedal spindle, joint #3
F Hex bolt on crank arm and hub spindle
G Bolt through steering knuckle, king pin
H Nut for king pin
I Washer under nut of king pin
J Hex barrel for head tube fold joint pivot
K Screw for hex barrel of fold joint
L Hex bolt as turning stopper on front beam
M Nut for turning stopper bolt
N Nut for rod end stud, inboard and
outboard
O Nut for steering linkage jam to rod end
P Hex bolt on front beam pivot
Q Nut for front axle
R Hex screw for bottle cage
S Hex screw fixing foot platform
T Hex screw mounting fender
U Hex screw for drop out lock plate
6 StreetStrider Eclipse and JET Owner's Manual
M=OD of threads, mm
P=pitch, threads/mm
DIMENSIONS
M6 x P1.25 x L20 x H12 x W6
OD25 x ID9 x T2
M6 x P1.0 x L50 x H14 x W6
M5 x P1.0 x L12 x W5
M8 x P9/16" x L50 x H25 x W8, 18 mm OD
shoulder
M8 x P1.0 x L15 x H12 x W8, 18 mm flange
M12 x P1.5 x L105 x H25
M12 x P1.5 x L12 x W19, nylon lock
OD24 x ID13 x T1
M5 x P1.0 x L60 x H12 x W5
M5 x P1.0 x L12 x H12 x W5
M5 x P1.0 x L25 x H10 x W10
M5 x P1.0 x L5 x W10
M8 x P1.5 x L10 x W14
M8 x P1.5 x L10 x W14
M10 x P1.5 x L25 x H15 x W8
M12 x P1.5 x L12 x W19, nylon lock
M4 x P0.8 x L12 x H10 x W4
M4 x P0.8 x L12 x H10 x W4
M4 x P0.8 x L12 x H10 x W4
M4 x P0.8 x L12 x H10 x W4
Listi
L=length W=wrench fit, mm
H=OD of head T=washer thickness, mm
.
# MAINTENANCE
ROUTINE
2 Tighten
2
2 Snug but allow joint
movement
2 Snug but allow joint
movement
2 Tighten, left LH,
right RH
2 Tighten
2 Snug but allow
knuckle swivel
2 Snug but allow
knuckle swivel
2
1 Tighten
1 Tighten
2 Tighten
2 Tighten
4 Tighten
4 Tighten, inboard LH,
outboard RH
1 Tighten
2 Snug but allow
wheel rotation
2 Tighten
14 Tighten
7 Tighten
4 Tighten
