2. Hardware – A. Parts Identification
The parts of the StreetStrider Eclipse are listed and labeled in the following table and figures. The parts of the
StreetStrider JET (not shown) are identical to the Eclipse.
Table 2A-1. StreetStrider Parts List. Parts are numbered in subsequent figures.
PART NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
4 StreetStrider Eclipse and JET Owner's Manual
Main frame
Head tube
Crossbar
Front beam
Fold joint, quick release
Strider pole, upper
Strider pole, lower
Strider ski, left
Strider ski, right, telescoping quick release
Foot platform
Seat stay
Chain stay
Rear wheel fender
Pivot joint #1, 6 mm hex screw
Pivot joint #2, 6 and 5 mm hex screws
Pivot joint #3, 8 mm hex screw
Hand grip
Brake lever
Rear cantilever brake
Strider pole adjuster, quick release
Front wheel
Front wheel hub, 19 mm axle bolt nuts
Steering linkage, 14 mm jam nuts
Crank arm, 8 mm hex screw
Rear wheel
Chainless internal gear hub
Brake lever locking pin
Brake cable adjuster
Brake lever locking pin
Reflector
Bottle cage
Front beam pivot, 8 mm hex screw
Rod end, LH thread inboard and RH thread outboard
Velcro wrapping strap
Axle bolt with 19 mm lock nuts
King pin bolt with 19 mm lock nut
Steering arm clamped to king pin with 3 mm hex screw
Steering stop screw, 10 mm head and jam nut
Brake pad adjuster screw, 5 mm hex
Fender mounting screws, 4 mm hex
Drop out
Drop out lock plate, 4 mm hex screws
Crank bolt, 8 mm hex
Bumper for folded cross bar
Telescoping ski lock pin locations
PART DESCRIPTION
