Kenwood KMC-17 Service Manual

Speaker microphone.
Hide thumbs


Advertisement

SPEAKER MICROPHONE
KMC-17
SERVICE MANUAL
REVISED
Photo is KMC-17 (Type B).
RoHS
This product complies with the
Curl cable
(E30-7659-18)
directive for the European market.
© 2008-5 PRINTED IN JA PAN
B51-8833-10 ( N ) 654
Lever (PTT)
(D10-0655-18)
This product uses Lead Free solder.

Advertisement

   Related Manuals for Kenwood KMC-17

   Summary of Contents for Kenwood KMC-17

  • Page 1

    REVISED © 2008-5 PRINTED IN JA PAN B51-8833-10 ( N ) 654 Curl cable Lever (PTT) (E30-7659-18) (D10-0655-18) Photo is KMC-17 (Type B). RoHS This product complies with the directive for the European market. This product uses Lead Free solder.

  • Page 2

    Kenwood. HOW TO DISTINGUISH BETWEEN DIFFERENT VERSIONS OF THE KMC-17 There are two versions of the KMC-17; one uses Type A and the other uses Type B. The components of each of these parts are not compatible with each other.

  • Page 3

    KMC-17 PARTS LIST ● KMC-17 (Type A) Ref. No. Address Parts No. Description Destination parts KMC-17 A02-0907-08 PLASTIC CABINET (FRONT) A02-0908-08 PLASTIC CABINET (REAR) B09-0316-08 D10-0606-08 LEVER (PTT) E11-0421-15 2.5D PHONE JACK (3P) E30-7504-18 CURL CABLE F07-0889-08 COVER (PTT) G53-0569-08...

  • Page 4

    KMC-17 SPECIFICATIONS ● KMC-17 (Type A/Type B) Microphone Impedance .................... 2.2kΩ (MAX) Sensitivity ...................–46dB±3dB at 1kHz Speaker Impedance ...................10Ω±30% at 1kHz Rating input ......................1W Maximum input ....................1.4W Dimensions (W x H x D) ........ 64.5 x 66 x 36 mm (2.54" x 2.60" x 1.42") Weight .....................Approx.
