Page 1: Table Of Contents
Ice Maker Instruction Manual Model:IM-01 TABLE OF CONTENTS IMPORTANT SAFEGUARDS SAFETY INSTRUCTIONS DESCRIPTION OF PARTS BEFORE FIRST USE USE YOUR ICE MAKER CARE AND CLEANING TROUBLESHOOTING GUIDE Before using your new product, please read these instructions to prevent any damage... -
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed: WARNING 1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this appliance near water. 6 Clean only with a damp cloth. 7 Do not block any ventilation openings. -
Page 3: Safety Instructions
22 Do not use your ice maker outdoors. Place the ice maker away from direct sunlight and make sure that there is at least four inches of space between the back of your unit and wall. Keep a minimum distance of four inches on each side of your unit free. - Page 4 WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death. 1 WARNING–Keep ventilation openings in the ice maker clear of obstruction. 2 WARNING–Do not damage the refrigerant tubing when handling, moving, or using the ice maker. 3 WARNING–DANGER—Never allow children to play with or operate the ice maker.
- Page 5 Attempting any maintenance or cleaning: To minimize the possibility of electric shock, unplug this appliance from the power supply or disconnect at the household distribution panel by removing the fuse or switching off the circuit breaker, before attempting any maintenance or cleaning.
-
Page 6: Description Of Parts
DESCRIPTION OF PARTS Control panel water Ice full Maximum shortage indicator water level indicator (under ice Ice size basket) indicators Select ice cube size Power button Ice scoop Ice full sensor Top cover with transparent window basket Air vent Water drain cap (located at front bottom of the ice maker) -
Page 7: Before First Use
BEFORE FIRST USE This portable ice maker uses a fully-automatic control system, with an advanced microcomputer for easy and convenient ice making. Making ice is simple and fast. Just add water, plug into an outlet, and press the ON/OFF button. You can select one of the two ice cube sizes with the touch of a button. When first turning on the unit or during ice-making cycles, the compressor will stay idle for 3 minutes, while energizing. -
Page 8: Use Your Ice Maker
USE YOUR ICE MAKER Making ice Prior to using your ice maker each time, wipe out the interior with a clean, damp cloth Making Ice Ensure that the drain plug underneath the front of the unit is closed and the water tube screen is in place. Plug the ice maker into the wall outlet and the green power indicator light Open the cover and remove the ice basket. - Page 9 NOTE: Do not fill above the MAX water level mark at the back of the Water Reservoir. Replace the ice basket, and close the Cover. IMPORTANT: Wait 3 minutes then press the Power Button to restart the ice making function. When you have finished making ice, transfer the ice to a freezer.
-
Page 10: Care And Cleaning
CARE AND CLEANING Stop the ice-making cycle by pressing the POWER button. the green LED light will go out, indicating the ice maker is off. Unplug the Ice Maker from the wall outlet and allow the unit to warm up to room temperature. If the Water Tray is not in the vertical position behind the Evaporator Fingers, gently push the Water Tray back so that all water drains into the Water Reservoir. - Page 11 Move the ice maker to a darker The ice maker won’t Direct or reflected sunlight can stop making ice GUARANTEE AND SERVICE If you need service or information or if you have a problem, please contact us by the E-mail:euhomy@hotmail.com Euhomy@hotmail.com...
