ELECTRIC DRYER

USE & CARE GUIDE
FOR QUESTIONS ABOUT FEATURES, OPERATION/PERFORMANCE, PARTS, ACCESSORIES OR SERVICE CALL: 1.800.688.9900
VISIT OUR WEBSITE AT WWW.MAYTAG.COM
PARA OBTENER ACCESO AL MANUAL DE USO Y CUIDADO EN ESPAÑOL, O PARA OBTENER INFORMACIÓN ADICIONAL DE SU PRODUCTO, VISITE: WWW.MAYTAG.COM
TENGA LISTO SU NÚMERO DE MODELO COMPLETO. PUEDE ENCONTRAR EL NÚMERO DE MODELO Y DE SERIE DENTRO DE LA CAVIDAD SUPERIOR DE LA PUERTA.
W10155107A

Advertisement

Table of Contents
loading

Related Manuals for Maytag MED5801TW

Summary of Contents for Maytag MED5801TW

  • Page 1: Electric Dryer

    VISIT OUR WEBSITE AT WWW.MAYTAG.COM PARA OBTENER ACCESO AL MANUAL DE USO Y CUIDADO EN ESPAÑOL, O PARA OBTENER INFORMACIÓN ADICIONAL DE SU PRODUCTO, VISITE: WWW.MAYTAG.COM TENGA LISTO SU NÚMERO DE MODELO COMPLETO. PUEDE ENCONTRAR EL NÚMERO DE MODELO Y DE SERIE DENTRO DE LA CAVIDAD SUPERIOR DE LA PUERTA.

  • Page 2: Table Of Contents

    DRYER SAFETY... 3 INSTALLATION INSTRUCTIONS ... 4 Tools and Parts... 4 Location Requirements ... 4 Electrical Requirements... 5 Electrical Connection ... 7 Venting Requirements ...12 Plan Vent System... 14 Install Vent System ... 15 Install Leveling Legs ... 15 Connect Vent ... 16 Level Dryer ...

  • Page 3: Dryer Safety

    DRYER SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”...

  • Page 4: Installation Instructions

    Tools and Parts Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. Flat-blade screwdriver #2 Phillips screwdriver Adjustable wrench that opens to 1" (2.54 cm) or hex-head socket wrench (for adjusting dryer feet) Wire stripper (for direct wire installations)

  • Page 5: Electrical Requirements

    Dryer Dimensions 43 ½" (110.5 cm) *29 ¼" (74.3 cm) 27" (68.6 cm) *Most installations require a minimum 5" (12.7 cm) clearance behind the dryer for the exhaust vent with elbow. See “Venting Requirements.” Installation spacing for recessed area or closet installation The following spacing dimensions are recommended for this dryer.
  • Page 6 If using a power supply cord: Use a UL listed power supply cord kit marked for use with clothes dryers. The kit should contain: A UL listed 30-amp power supply cord, rated 120/240 volt minimum. The cord should be type SRD or SRDT and be at least 4 ft (1.22 m) long.

  • Page 7: Electrical Connection

    Power Supply Cord WARNING Fire Hazard Use a new UL listed 30 amp power supply cord. Use a UL listed strain relief. Disconnect power before making electrical connections. Connect neutral wire (white or center wire) to center terminal (silver). Ground wire (green or bare wire) must be connected to green ground connector.
  • Page 8 Put power supply cord through the strain relief. Be sure that the wire insulation on the power supply cord is inside the strain relief. The strain relief should have a tight fit with the dryer cabinet and be in a horizontal position. Do not further tighten strain relief screws at this point.
  • Page 9 4-wire connection: Power supply cord IMPORTANT: A 4-wire connection is required for mobile homes and where local codes do not permit the use of 3-wire connections. A. 4-wire receptacle (NEMA type 14-30R) B. 4-prong plug C. Ground prong D. Neutral prong E.
  • Page 10 When connecting to the terminal block, place the hooked end of the wire under the screw of the terminal block (hook facing right), squeeze hooked end together and tighten screw, as shown. 1. Remove center silver-colored terminal block screw. 2. Remove neutral ground wire from external ground conductor screw. Connect neutral ground wire and place the hooked end (hook facing right) of the neutral wire (white or center wire) of direct wire cable under the center screw of the terminal block.
  • Page 11 3-wire connection: Power supply cord Use where local codes permit connecting cabinet-ground conductor to neutral wire. A. 3-wire receptacle (NEMA type 10-30R) B. 3-wire plug C. Neutral prong D. Spade terminals with upturned ends E. " (1.9 cm) UL listed strain relief F.

  • Page 12: Venting Requirements

    3. Place the hooked ends of the other direct wire cable wires under the outer terminal block screws (hooks facing right). Squeeze hooked ends together. Tighten screws. 4. Tighten strain relief screw. 5. Insert tab of terminal block cover into slot of dryer rear panel. Secure cover with hold- down screw.
  • Page 13 4" 10.2 cm 4" (10.2 cm) heavy metal exhaust vent Vent products can be purchased from your dealer or by calling Maytag Services. For more information, see the “Assistance or Service” section. Rigid metal vent For best drying performance, rigid metal vents are recommended.

  • Page 14: Plan Vent System

    Choose your exhaust installation type Recommended exhaust installations Typical installations vent the dryer from the rear of the dryer. Other installations are possible. A. Dryer E. Clamps B. Elbow F. Rigid metal or flexible metal vent C. Wall G. Vent length necessary to connect elbows D.

  • Page 15: Install Vent System

    Special provisions for mobile home installations The exhaust vent must be securely fastened to a noncombustible portion of the mobile home structure and must not terminate beneath the mobile home. Terminate the exhaust vent outside. Determine vent path Select the route that will provide the straightest and most direct path outdoors. Plan the installation to use the fewest number of elbows and turns.

  • Page 16: Connect Vent

    3. Examine the leveling legs. Find the diamond marking. 4. Screw the legs into the leg holes by hand. Use a wrench to finish turning the legs until the diamond marking is no longer visible. 5. Place a carton corner post from dryer packaging under each of the 2 dryer back corners. Stand the dryer up.

  • Page 17: Dryer Use

    WARNING Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from dryer. Do not dry anything that has ever had anything flammable on it (even after washing). Failure to follow these instructions can result in death, explosion, or fire. WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance.

  • Page 18: Drying Rack

    The drying rack is useful for machine drying items you would not necessarily want to tumble dry (for example, sweaters). If your model does not have a drying rack, you may be able to purchase one for your model. To find out whether your model allows drying rack usage and for information on ordering, please refer to the front page of the manual or contact the dealer from whom you purchased your dryer.

  • Page 19: Cleaning The Dryer Interior

    2. Push the lint screen firmly back into place. As Needed Cleaning 1. Roll lint off the screen with your fingers. 2. Wet both sides of lint screen with hot water. 3. Wet a nylon brush with hot water and liquid detergent. Scrub lint screen with the brush to remove residue buildup.

  • Page 20: Troubleshooting

    When balled up, the load will bounce, causing the dryer to vibrate. Separate the load items and restart the dryer. TROUBLESHOOTING In U.S.A. www.maytag.com/help - In Canada www.maytag.ca Timer does not noticeably advance Is the dryer set to Timed Dry? The timer moves slowly and continuously for the time setting.
  • Page 21 Is the exhaust vent diameter the correct size? Use 4" (10.2 cm) diameter vent material. WARNING Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from dryer. Place dryer at least 18 inches (46 cm) above the floor for a garage installation.

  • Page 22: Assistance Or Service

    To locate factory specified parts in your area, call the following customer assistance telephone number or your nearest designated service center. In the U.S.A. Call Maytag Services, LLC Customer Assistance toll free: 1-800-688-9900, or vist our website at www.maytag.com Our consultants provide assistance with: Features and specifications on our full line of appliances.
  • Page 23 Notes...

  • Page 24: Warranty

    MAYTAG CORPORATION MAJOR APPLIANCE WARRANTY For one year from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or furnished with the product, Maytag Corporation or Maytag Limited (hereafter “Maytag”) will pay for Factory Specified Parts and repair labor to correct defects in materials or workmanship. Service must be provided by a Maytag designated service company.
