W W S S 1 1 8 8 X X
1000 watt vented sub-bass system
features
Q
Direct radiating, long excursion 18" (460mm) driver
Q
High temperature 4" (100mm) voice coil
Q
High power 132dB continuous, 138dB peak
Q
Fitted with integral handles and castors
applications
Q
Theatre sound systems
Q
Small to medium touring systems
Q
Club sound reinforcement
Q
Special effects sub-bass
The WS18X is a high performance sub-bass system designed
for use with small to medium Wavefront systems, in both
touring and install applications. It features a 1000 watt 18"
(460mm) drive unit with magnet structure and suspension
engineered for maximum linear excursion. The birch ply cabinet
is fitted with four pocket handles and four 4" (100mm) castors
for easy deployment. It features large area porting to reduce air
noise. A top hat fitting allows mid-top cabinets to be mounted
on the WS18X using the HAM09015 adjustable pole. WS18X
subwoofers are designed to be powered by Martin Audio
MA9.6K or MA4.2s amplifiers.
overall dimensions
technical specifications
TYPE
Compact, vented sub-bass system
FREQUENCY RESPONSE (1) 35Hz-150Hz ± 3dB, -10dB @ 28Hz
DRIVER
18" (460mm)/4" (100mm) voice coil, ultra-long
excursion, water resistant cone
RATED POWER (2)
1000W AES, 4000W peak
SENSITIVITY (3)
102dB (half space)
MAXIMUM SPL (4)
132dB continuous, 138dB peak (half space)
NOMINAL IMPEDANCE
8 ohms
CROSSOVER
80Hz-150Hz, via DX1 or DX2 controller
ENCLOSURE
160 litre, multi-laminate birch ply
FINISH
Textured black paint
PROTECTIVE GRILLE
Black perforated steel
CONNECTORS
2 x Neutrik NL8
PIN CONNECTIONS
LF+, -: 1+, 1- & 2+, 2-
Link thro': 3+, 3-, 4+, 4-
FITTINGS
4 x 4" (100mm) castors
4 x pocket handles
2 x front lid fittings
1 x mounting pole socket
DIMENSIONS (inc. wheels)
(W) 561mm x (H) 533mm x (D) 780mm (911mm)
(W) 22.1ins x (H) 21ins x (D) 30.7ins (35.9ins)
WEIGHT
52.5kg (116lbs)
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: info@martin-audio.com
All information is Copyright © 2007 Martin Audio Ltd.
www.martin-audio.com
