SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION
INSTRUCTIONS
Model 80575A
For Trimmer T235, T254, T344
WARNING!
Minimize the risk of injury to yourself and others! Read the Owner's/Opera-
tor's manual originally supplied with the unit that is being upgraded and
familiarize yourself with the contents. Always wear eye and hearing protec-
tion when operating your unit.
Advertisement
Related Manuals for Shindaiwa T235
Summary of Contents for Shindaiwa T235
- Page 1 SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION INSTRUCTIONS Model 80575A For Trimmer T235, T254, T344 WARNING! Minimize the risk of injury to yourself and others! Read the Owner's/Opera- tor's manual originally supplied with the unit that is being upgraded and familiarize yourself with the contents. Always wear eye and hearing protec- tion when operating your unit.
-
Page 2: Table Of Contents
The instructions described in this manual are intended to help Always wear a harness when operating this unit you get the most from your Shindaiwa power tool as well as with a blade. A harness to protect you and others from harm. These procedures are is also recommended when using trimmer line. -
Page 3: General Safety Instructions
Immediately replace damaged or missing information labels. A new label is provided in this kit and additional labels are available from your local authorized Shindaiwa dealer. Prior to installing the new label, Remove old label and clean the outer tube with rubbing alcohol or similar cleaner. -
Page 4: Assembly
Assembly Removing the Existing Cutting Attachment Shield If installed, remove nylon line head, adapter plate, shield plate, and plastic shield: a. Align locking hole in adapter plate with notch in edge of gear case and insert locking tool (A). b. Remove line head (B) by turning it clockwise until head is completely off of shaft. - Page 5 1. Install handle and barrier. Install Gear Case IMPORTANT! T235 ONLY: Replace existing gearcase clamping bolts with new 5x35mm torx bolts included in kit. 1. Install gear case onto outer tube. Align locating hole on gear case (A) with locating hole in tube.
-
Page 6: Install Blade
Install plastic blade shield Parts Required: Wide Plastic Shield, Shield Place, 3 - 5 x 25 mm screws (plastic shield to gear case). 5 mm lock nuts Align plastic blade shield (C) with the drive shaft, and install on the bottom of the gear case flange. -
Page 7: Shoulder Strap
IMPORTANT! Discard blades that are bent, warped, cracked, broken or damaged in any way.Use a sharp blade. A dull blade is more likely to snag and thrust. IMPORTANT! Units with adjustable carburetors must be readjusted for blade use, otherwise serious engine damage can occur. WARNING! A standard grass trimmer unit with loop handle should NEVER be operated with blade-type attachments. -
Page 8: Using A Brushcutter Blade
Using A Brushcutter Blade WARNING! Before working with a blade-equipped unit, always inspect and clean the area of objects that could interfere with or damage the blade. Never use a blade near sidewalks, fence posts, buildings or other objects that could cause injury or damage. ... - Page 9 NOTES...
- Page 10 NOTES...
- Page 11 NOTES...
- Page 12 If you require assistance or have questions concerning the application, operation or maintenance of this product you may call the Shindaiwa Consumer Product Support Department at 1-877-986-7783 from 8:30 am to 4:30 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial number of your unit.
