- Page 1 (NS-PB120: NS-B120 + NS-C120) SPEAKER PACKAGE PACKAGE ENCEINTES OWNER'S MANUAL MODE D'EMPLOI MANUAL DE INSTRUCCIONES ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ...
-
Page 2: Table Of Contents
Precautions Please read the following operating precautions before use. Yamaha will not be held responsible for any damage and/or injury caused by not following the cautions below. 1. To assure the finest performance, please read this manual Information for Users on Collection and Disposal of carefully. -
Page 3: Package Contents
Package contents Thank you for choosing the Yamaha NS-PB120 Speaker Package. Make sure the package contains the following items. Front and surround speakers (NS-B120) x 4 Center speaker (NS-C120) x 1 Fastener x 2 Non-skid pads (4 pcs) x 4 Speaker cable 24.5 m (80 ft.) x1... -
Page 4: Installing The Center Speaker
Installing the speakers Installing the center speaker Place the center speaker centrally between the front speakers, facing directly forward. Fastener When placing it on a flat surface (TV rack, Peel of the seal. etc), affix the supplied fasteners to bottom of the speaker as shown left. -
Page 5: Wall-Mounting The Speakers
Installing the speakers Wall-mounting the speakers You can mount the speakers on the wall as Surround speaker Wall/wall support follows. 26 mm (1") Install screws into a solid wall or wall support as shown left. Use 3.5 to 4 mm 3 mm (1/8") diameter self-tapping screws. -
Page 6: Connecting The Speakers
Connecting the speakers Caution: Make sure the power cables for your AV components are disconnected from the AC wall outlets before making any connections. Connection diagram Center speaker Amplifier ANTENNA HDMI OUT (BD/DVD) HDMI 1 HDMI 2 HDMI 3 HDMI 4 GND AM COMPONENT AUDIO 2... -
Page 7: Connecting To An Amplifier
(–) terminals to negative (–) terminals. If you get them crossed over, the sound will be unnatural and lack bass. In your AV receiver’s speaker size settings, specify small (or “S”) for all of the NS-PB120 speakers. Once you have connected all of the speakers, plug the amplifier and other AV components into suitable AC wall outlets. - Page 8 1. The original invoice or sales receipt (showing date of purchase, product code and dealer’s name) MUST accompany the defective product, along with a statement detailing the fault. In the absence of this clear proof of purchase, Yamaha reserves the right to refuse to provide free of charge service and the product may be returned at the customer’s expense.
