- Page 1 ULTI ORMAT RESENTATION WITCH BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2013 Broadata Communications, Inc.
- Page 2 This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment. Broadata Technical Support, Sales@Broadatacom.com...
-
Page 3: Table Of Contents
7.0 SPECIFICATIONS ............22 8.0 SERVICE PROCEDURE ..........23 8.1 REPLACEMENT POLICY ..........23 8.2 RETURN AND REPAIR SERVICE ......... 23 9.0 LIMITED WARRANTY ............ 24 10.0 APPENDIX A ..............25 11.0 APPENDIX B ..............28 Broadata Technical Support, (800) 214-0222... -
Page 4: Product Description
• Supports distances of up to 100 meters on the output and 100m on the input over industry standard CAT5e/6/7 cable • Supports scaling of any input signals to a wide range of HDTV and PC output resolutions up to 1080p and WUXGA (RB) Broadata Technical Support, Sales@Broadatacom.com... - Page 5 • 1 x 8 by 4 Presentation Switch w/ Scaler • 1 x IR Extender cable • 1 x IR Receiver cable • 1 x Remote Control w/ battery • 1 x 24v/2.7A DC Power Adapter • 1 x Power Cord • User’s Manual Broadata Technical Support, (800) 214-0222...
-
Page 6: Operation Controls And Functions
CV output port. The LED will illuminate according to the selection. 8. MENU: Press this wheel to enter into the menu and press it again to confirm the selection. Broadata Technical Support, Sales@Broadatacom.com... -
Page 7: Rear Panel
OSD. If in ‘Auto’ mode then the source audio is derived from the input HDMI embedded audio. If in ‘EXT’ mode the audio is sourced from the external input audio. Broadata Technical Support, (800) 214-0222... - Page 8 16. POWER Toggle: Switch this toggle to turn ON and OFF the device’s power 17. DC 24V: Connect the adaptor with power cord included in the package and connect to AC wall outlet for power supply. Broadata Technical Support, Sales@Broadatacom.com...
-
Page 9: Remote Control
The device will auto adjust the image to full screen. 8. RESET: Press this button to set the device back into the factory default setting. 9. BYPASS: Press these buttons to select an input source for Bypass output port to display. Broadata Technical Support, (800) 214-0222... -
Page 10: On Screen Display
MODE INFO: INFO, ON, OFF INPUT HDCP: OFF, ON PC (PC Mode Only): AUTO SETUP, PC MODE ONLY 0 ~ 60, V_POSITION 0 ~ 60, PHASE 0 ~ 31, CLOCK, XGA/WXGA (Factory default), DEFAULT Yes/No (Factory default). Broadata Technical Support, Sales@Broadatacom.com... -
Page 11: Color
0 ~ 1023 of Blue Color Level HUE: 0 ~ 60 of Hue Level SATURATION: 0 ~ 60 of Saturation Level SHARPNESS: 0 ~ 30 of Sharpness Level OFF (Factory Default upon reset), LOW, MIDDLE, HIGH Broadata Technical Support, (800) 214-0222... -
Page 12: Audio
Note: AUTO mode sources the primary output audio from the input audio embedded on the HDMI video. EXT mode sources the primary output audio from the external input audio connections. These modes do not apply to the Bypass Output. Broadata Technical Support, Sales@Broadatacom.com... -
Page 13: Setup
IP MODE: DHCP, STATIC SET STATIC IP: ADDRESS: 0.0.0.0 255.255.255.255 (192.168.0.1) default SUBNET MASK: 0.0.0.0 ~ 255.255.255.255 (default) DEFAULT GATEWAY: 0.0.0.0 ~ 255.255.255.255 (192.168.0.254) default FREERUN COLOR: BLUE, BLACK MISC: HDBT OUT: HDBT1 (default), HDBT2 Broadata Technical Support, (800) 214-0222... -
Page 14: Information
LBC-PSW84 User’s Manual Link Bridge Multi-format Presentation Switch INFORMATION: Input, Output, Revision, IP Address INPUT: Input Resolution Displayed OUTPUT: Output Resolution Displayed REVISION: Firmware Revision Displayed IP ADDRESS: Current IP Address Displayed Broadata Technical Support, Sales@Broadatacom.com... -
Page 15: Connector Pin Assignment
LBC-PSW84 User’s Manual Link Bridge Multi-format Presentation Switch 4.0 CONNECTOR PIN ASSIGNMENT 4.1 IR Pin Assignment Figure 4-1 IR Blaster and IR Extender Pin Assignment Broadata Technical Support, (800) 214-0222... -
Page 16: Rs-232 Pin Assignment
Multi-format Presentation Switch 4.2 RS-232 Pin Assignment Table 1 RS-232 Pin Assignment Baud Rate: 9600bps Data Bit: 8 bits Parity: None Flow Control: None Stop Bit: 1 Note: Refer to Appendix A for the Telnet Command Set Broadata Technical Support, Sales@Broadatacom.com... -
Page 17: Dc Power Connection
Listed ITE Power Supply marked/rated as LPS or Limited Power Source. Note 2: The installation shall be in accordance with the applicable provisions of the National Electrical Code ANSI/NFPA 70, Article 725 and the Canadian Electrical Code, Part 1, Section 16. Broadata Technical Support, (800) 214-0222... - Page 18 Note 5: The power supply is to be located within the same vicinity as the A/V processing equipment in an ordinary location, Pollution Degree 2, secured to the equipment rack within the dedicated closet, podium or desk Broadata Technical Support, Sales@Broadatacom.com...
-
Page 19: Maintenance And Troubleshooting
For each unit, the transmit (TX) cable is connected to the other unit’s receiver (RX). 3. If the POWER indicator and Link indicator are ON, but the channels are not operating, then: a. Check to see that the attached user equipment is turned Broadata Technical Support, (800) 214-0222... - Page 20 Both ends of the link are connected to the corresponding equipment and to the same corresponding channel port. c. Cable connections at both channels are securely fastened to each connector. Turn the power off, then back on to reset the link. Broadata Technical Support, Sales@Broadatacom.com...
-
Page 21: Specifications
44mm, 1.73" (H) Chassis material Metal Box Color Black Operating Temperature C~40 C / 32 F~104 Relative Humidity 20 ~ 90 % RH (non-condensing) Power Supply 110–240v AC 50/60 @ 2.7 A DC Power Consumption Broadata Technical Support, (800) 214-0222... -
Page 22: Service Procedure
The LBC-H/V-T-SCL System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/ repair processing please contact Broadata Communications, Inc. to obtain a Return Material Authorization (RMA). Please include the following information: •... -
Page 23: Limited Warranty
Multi-format Presentation Switch 9.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s election, by replacement, any said products that in our sole... -
Page 24: Appendix A
LBC-PSW84 User’s Manual Link Bridge Multi-format Presentation Switch 10.0 APPENDIX A: RS-232 COMMANDS Broadata Technical Support, Sales@Broadatacom.com... - Page 25 LBC-PSW84 User’s Manual Link Bridge Multi-format Presentation Switch Broadata Technical Support, (800) 214-0222...
- Page 26 LPCM 2 channel audio in order to avoid unnecessary audio noise. 4. RS-232 commands will be not executed unless followed with a carriage return and LF. Commands are case sensitive. Broadata Technical Support, Sales@Broadatacom.com...
-
Page 27: Appendix B
LBC-PSW84 User’s Manual Link Bridge Multi-format Presentation Switch 11.0 APPENDIX B: SUPPORTED INPUT RESOLUTIONS Broadata Technical Support, (800) 214-0222... - Page 28 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBC-PSW84...
