Model DV9600 User Guide
Super Audio CD/DVD Player

Advertisement

Table of Contents
loading

Related Manuals for Marantz DV9600

Summary of Contents for Marantz DV9600

  • Page 1: Home Theater Video Connections

    CLASS 1 LASER PRODUCT LUOKAN 1 LASERLAITE KLASS 1 LASERAPPARAT Model DV9600 User Guide Super Audio CD/DVD Player...

  • Page 2: Important Safety Instructions

    CONGRATULATIONS ON YOUR PURCHASE OF THIS FINE MARANTZ PRODUCT. MARANTZ is on the leading edge of Super Audio CD, DVD research for consumer products and this unit incorporates the latest technological developments. We are sure you will be fully satisfied with the Super Audio CD, DVD player.
  • Page 3 • This unit can be used only where the power supply is AC 120V, 60Hz. It cannot be used elsewhere. • This DVD player is designed and manufactured to respond to the Region Management Information. If the Region number of a DVD disc does not correspond to the Region number of this DVD player, the DVD player cannot play the disc.

  • Page 4: Handling Cautions

    Handling Cautions • Before connecting other components to this player, be sure to turn them all off. • Do not move the player while a disc is being played, or the disc may be scratched or broken, and the player’s internal parts may be damaged.

  • Page 5: Table Of Contents

    Table Of Contents 1 Before You Start Features ... 6 What’s in the box ... 7 Putting the batteries in the remote control ... 7 Using the remote control ... 7 Discs compatible with this player ... 8 DVD-Video regions ... 9 MP3 compatibility information ...

  • Page 6: Before You Start

    Audio CD that was formerly impossible by converting it to PCM (see page 44). Superlative audio performance with Super Audio CD, DVD-Audio, Dolby* Digital and DTS Logos: The DV9600 delivers breathtaking sound quality with Super Audio CD, DVD-Audio, Dolby Digital and DTS discs. software...

  • Page 7: What's In The Box

    SRS Labs, Inc. TruSurround technology is incorporated under license from SRS Labs, Inc. What’s in the box Thank you for buying this MARANTZ prod- uct. Please confirm that the following accessories are in the box when you open it. • Remote control •...

  • Page 8: Discs Compatible With This Player

    CD standards. They are special discs and may not play on the DV9600. *The audio side of dual discs does not conform to CD standards and may not play on the DV9600. Video CD compatibility: • Logo: • 12cm (5in.) or 8cm (3in.) discs •...

  • Page 9: Dvd-Video Regions

    All DVD-Video discs carry a region mark on the case somewhere that indicates which region(s) of the world the disc is compatible with. Your DVD player also has a region mark, which you can find on the rear panel. Discs from incompatible regions will not play in this player.

  • Page 10: Connecting Up

    Remote switch When using this DVD player independently, set this switch to INT. (INTERNAL). When using this DVD player in a system with a Marantz receiver equipped with a remote sensor, set the switch to EXT. (EXTERNAL).

  • Page 11: Home Theater Video Connections 1

    Connecting Up Home theater video connections This player outputs video in a number of different ways. Choose the one most suit- able for your system using the guide below. If your TV and projector have a HDMI terminal for Video and Audio Input, we recommend using it to connect directly to the HDMI out of this player.

  • Page 12: Home Theater Audio Connections

    Connecting Up Home theater audio connections This player outputs multi-channel audio in both analog and digital form. Check the manual for your amplifier/receiver to see what equipment it is compatible with (especially which digital formats—Dolby Digital, DTS, etc.—it can decode). If your amplifier has 5.1 channel analog inputs, connect them here.

  • Page 13: Controls & Displays

    Controls & Displays Front panel 1 STANDBY indicator • Lights when the unit is in standby. 2 Disc tray • Place the disc here. 3 3 (PLAY) • Begin the disc play. 4 7 (STOP) • Stops the disc play. 5 8 (PAUSE) •...

  • Page 14: Display

    Controls & Displays Display 2 3 4 5 6 7 8 9 RNDM ¡ DOFF TITLE PROG ™ £ ¢ – Lights during a camera-angle section of a DVD-Video disc PRGSVE – Lights when unit is outputting progres- sive scan (non-interlaced) video GRP –...

  • Page 15: Remote Control

    Controls & Displays Remote control OPEN/ POWER CLOSE VIDEO DISPLAY ON/OFF DIMMER MARKER PROGRAM SEARCH STOP PLAY PAUSE NEXT PREV. VIDEO ADJ. ZOOM TOP MENU MENU ENTER RETURN SET UP ANGLE SUBTITLE AUDIO CLEAR A - B RANDOM REPEAT PAGE CONDITION S.

  • Page 16: Getting Started

    Getting Started OPEN/ CLOSE STOP PLAY NEXT PREV. Playing discs The basic playback controls for playing discs are covered here. Further functions are detailed in the next chapter. POWER Throughout this manual, the term ‘DVD’ means DVD- Video, DVD-Audio and DVD-R/RW. If a function is specific to a particular kind of DVD disc, it is specified.

  • Page 17: Navigating Dvd Disc Menus

    Getting Started TOP MENU MENU ENTER RETURN SET UP Button What it does TOP MENU Displays the ‘top menu’ of a DVD disc—this varies with the disc. MENU Displays a DVD disc menu—this varies with the disc and may be the same as the ‘top menu’...

  • Page 18: Playing Discs

    Playing Discs ENTER SET UP Introduction • Many of the functions covered in this chapter apply to DVD discs, Video CDs, Super Audio CDs and CDs, although the exact operation of some varies slightly with the kind of disc loaded. •...

  • Page 19: Using The Info Menu

    Playing Discs Using the INFO menu 1 During play, press the DISPLAY button on the remote control. 2 Use the cursor buttons (5/∞) to select the desired item. 3 Use the cursor buttons (2/3) to make the desired setup, then press ENTER. •...

  • Page 20: Still Frame/Slow Play/Frame Advance Playback

    Playing Discs PLAY PAUSE Still Frame/Slow Play/Frame Advance Playback The video images on DVD and Video CD can be viewed as a still frame, played back at slow speeds and even advanced frame by frame (Forward only). Viewing a Pausing Picture Press 8 (PAUSE).

  • Page 21: Using The Page

    Playing Discs CLEAR PAGE CONDITION Using the Page Press the PAGE button on the remote control during playback. You may select the image you want by moving the cursor button (2/3). Note Some discs don’t allow the Page function. Memorizing disc settings (CONDITION MEMORY) If you have a particular set of preferences for a disc, you can memorize them using the Condition Memory function.

  • Page 22: Using The Random Play

    Playing Discs SEARCH STOP PLAY NEXT PREV. RANDOM Using the Random Play Use the random play function to play tracks in a random order. You can’t use random play with DVD-RW discs, DVD-Video or Video CD playing in PBC mode. 1 Press RANDOM during the Stop mode.

  • Page 23: Using The Repeat Play

    Playing Discs ENTER A - B REPEAT Using the Repeat Play You can set the player to repeat individual tracks on CDs or Video CDs, Super Audio CDs, chapters/tracks or titles/group on DVD discs, or the whole disc. It's also possible to loop a section of a disc.

  • Page 24: Bookmarking A Place In A Disc

    Playing Discs MARKER PLAY ENTER CLEAR Bookmarking a place in a disc This feature lets you bookmark sections of a DVD so you can quickly find them at a later time. Using the Bookmark Function 1 During play, press the MARKER button on the remote control. The Bookmark icons will be displayed.

  • Page 25: Making A Program List

    Playing Discs PROGRAM STOP PLAY ENTER CLEAR Making a program list This feature lets you program the play order of groups/chap- ters/tracks on a disc. You make a program list via an on-screen display, using the cursor buttons to navigate to enter groups/ chapters/tracks.

  • Page 26: Switching Camera Angles

    Playing Discs ENTER ANGLE SUBTITLE Switching Camera Angles Some DVD-Video discs feature scenes shot from two or more angles—check the disc box for details: it should be marked with icon if it contains camera-angle scenes. • To display the camera angle, press ANGLE. •...

  • Page 27: Switching Audio Language

    Playing Discs ZOOM ENTER AUDIO Switching Audio Language When playing a DVD-Video disc recorded with dialog in two or more languages, you can switch audio language anytime during playback. • To display the audio language, press AUDIO. The current audio language is shown on-screen. To select the audio language, use the cursor buttons (2/3).

  • Page 28: Mp3/Jpeg Play

    Playing Discs MP3/JPEG Play • If MP3 and JPEG files are present, select the media of your choice with the cursor buttons (5/∞) and then press ENTER. • If no button on the remote control is pressed for 30 seconds, the menu will disappear and the selected item will be played.
  • Page 29 Playing Discs Playing JPEG 1 When the JPEG file is loading, the JPEG file menu will appear on the right side of the screen. (Some discs may start play auto- matically.) Up to 6 JPEG files can be displayed at a time.

  • Page 30: Video Adjust

    Playing Discs Video Adjust You can set the picture settings you desire and store them in the player’s memory. Selecting a preset 1 Press the VIDEO ADJ. button on the re- mote control. 2 Select Memory Select Memory Select Memory Select. Memory Select Memory Select 3 Select a preset.
  • Page 31 Playing Discs Film 1: Standard setting Film 2: Setting for moving images Film 3: Setting for still images • DNR – Adjusts the amount of noise reduction (NR) applied to the Y (brightness) component • CNR – Adjusts the amount of noise reduction (NR) applied to the C (color) component •...

  • Page 32: Dvd Setup Menu

    STOP MENU Press ENTER you want to set. The menu select is set. • The DVD player support two remote control SET UP codes: DVD 1 and DVD 2. • Set the remote control code of the Remote Control to the same setting.

  • Page 33: Using The Setup Menu

    DVD Setup Menu MENU ENTER RETURN SET UP Using the Setup Menu Before using the player, you should specify the settings to be used in accordance with the conditions under which the player is to be used. Note that once changed, the settings will be saved and remain the same even after the power has been turned off until the settings are changed again.
  • Page 34 DVD Setup Menu Black dot ( ) indicates the default setting * It can be set only during STOP . Language Setup (page 35) OSD Language (page 35) English Francais Deutsch Espanol Italiano DVD Menu Language (page 35) * English Francais Deutsch Espanol...

  • Page 35: Setting Up The Language Setup

    DVD Setup Menu Setting up the Language Setup If you set the OSD Language, DVD Menu Language, Audio Language and Subtitle Language in advance, they will come up automatically every time you watch a movie. Note DVD Menu Language, Audio Language and Subtitle Language are only selected in the Stop mode.

  • Page 36: Using The Subtitle Language

    DVD Setup Menu 5 Press the cursor buttons (5/∞) to select English English English English. English • Select Original if you want the default soundtrack language to be the original language the disc is recorded in. • Select Others if the language you want is not listed.

  • Page 37: Setting Up The Audio Setup 1

    DVD Setup Menu Setting up the Audio Setup 1 1 Press the SET UP button. 2 Select Setup Setup Setup using the cursor buttons (5/ Setup Setup ∞), then press the cursor (3) or ENTER button. 3 Select Audio Setup 1 Audio Setup 1 Audio Setup 1 Audio Setup 1 using the cursor...
  • Page 38 DVD Setup Menu PCM Down Sample* • Default setting: On If the digital input of your AV amplifier (or other connected component) is compatible with high sampling rates (96kHz), set this to Off, otherwise set it to On (96kHz audio is converted to a more compatible 48kHz).

  • Page 39: Audio Out

    DVD Setup Menu Audio Out • Default setting: 2 Channel If you connected this player to your amplifier using the 5.1 channel analog outputs (front, surround, center and subwoofer outs), set this to 5.1 Channel; if you connected only the stereo outputs, set to 2 Channel.

  • Page 40: Speaker Size

    DVD Setup Menu Speaker Size • Default setting: Front L/R: Large | Center: Large | LFE: On | Surround L/R: Large You only need to make this setting if you connected this player to your amplifier using the 5.1 channel analog outputs.
  • Page 41 DVD Setup Menu Level • Default setting: Fix You may want to make this setting if you connected this player to your amplifier using the 5.1 channel analog outputs. Under the default setting, all channels are output at the relative volumes they were recorded at. Change the setting to Variable, if you want to adjust the relative volume levels of any of the speakers.

  • Page 42: Setting Up The Audio Setup 2

    DVD Setup Menu Setting up the Audio Setup 2 1 Press the SET UP button. 2 Select Setup Setup using the cursor buttons (5/ Setup Setup Setup ∞), then press the cursor (3) or ENTER button. 3 Select Audio Setup 2 Audio Setup 2 using the cursor Audio Setup 2 Audio Setup 2...
  • Page 43 DVD Setup Menu CD Play Back • Default setting: CD Replay DTS CD? (CD replay settings) Use the cursor buttons (2/3) to select either CD or DTS CD. • CD Should be selected whenever listening to a regular music CD. •...

  • Page 44: Audio Drc

    HDMI audio setting. (pages 54, 55) TruSurround • Default setting: Off If you connected your DVD player using only the stereo analog outputs and set Audio Out to 2 Channel (page 39), you can simulate surround sound by setting TruSurround to On.

  • Page 45: Setting Up The Video Setup

    DVD Setup Menu Setting up the Video Setup 1 Press the SET UP button. 2 Select Setup Setup using the cursor buttons (5/ Setup Setup Setup ∞), then press the cursor (3) or ENTER button. 3 Select V i d e o V i d e o V i d e o Setup V i d e o...
  • Page 46 DVD Setup Menu When viewing on a standard TV or monitor Screen format of disc 16:9 When viewing on a widescreen TV or monitor Screen format of disc 16:9 Choose this setting if you have a progressive scan-compatible TV and the aspect ratio cannot be changed. Setting 4:3 L - Box 4:3 Pan Scan...
  • Page 47 DVD Setup Menu Components Out • Default setting: Interlace Compared to a standard interlaced TV picture, a progressive scan TV is capable of stable, flicker- free images. Set only if you connected the COMPONENT VIDEO OUT to a progressive scan-compatible TV or monitor.

  • Page 48: Screen Saver

    DVD Setup Menu Back Ground • Default setting: Logo This specifies what the screen shows when the player is stopped. Note If Capture is selected, a picture taken in by Capture is displayed. (page 29) Screen Saver • Default setting: On If a constant image is displayed on a conventional CRT-type TV, it can “burn in”...

  • Page 49: Setting Up The Parental Setup

    DVD Setup Menu Setting up the Parental Setup The Parental Control function works in conjunction with DVDs that have been assigned a rating - which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. Use Password 1 Press the SET UP button.

  • Page 50: Setting Up The Others Setup

    DVD Setup Menu Setting up the Others Setup 1 Press the SET UP button. 2 Select Setup Setup Setup using the cursor buttons (5/ Setup Setup ∞), then press the cursor (3) or ENTER button. 3 Select Other Others s s s s Setup Other Other Setup...

  • Page 51: Auto Power Off

    DVD Setup Menu Pure Mode • Default setting: Off If you play a CD or Super Audio CD while Pure Mode, Mode1 or Mode2 is selected, then Display, Video Out and Digital Out shut off automatically. And if you push the DIMMER button on the remote control during the Pure Mode ON, for three sec- onds, only Display is displayed.
  • Page 52 DVD Setup Menu HDMI This setting is used when the unit is con- nected by HDMI or DVI with a TV or projec- tor. This setting can be toggled On and Off by pressing the HDMI/DVI RESOLUTION button on the front panel for three seconds or more.
  • Page 53 DVD Setup Menu • When black rise to the surface depending on the display, black Setup in the Video Adjust- ment set to OIRE. • Eight-bit data is sent when YCbCr-1 (4:4:4) is selected. Ten-bit data is sent when YCbCr-2 (4:2:2) is selected.
  • Page 54 DVD Setup Menu 4 Select A u d i o A u d i o A u d i o A u d i o A u d i o HDMI Audio Auto Multi PCM 2ch PCM ENTER RETURN • Auto (default setting) In this mode, when discs recorded in Dolby Digital, DTS, or MPEG are played, the respective bit stream signal...
  • Page 55 DVD Setup Menu Note • Audio signals are not output from DVD-Audio discs with CPPM copyright protection when using components that do not support HDMI standard Ver. 1.1. • Multi-channel and stereo audio is not output from Super Audio CDs. Use the analog audio outputs or i.LINK.
  • Page 56 Select one of the options with the cursor buttons (5/∞) and press the ENTER button. 3 Select Output Format Output Format Output Format Output Format Output Format SR9600 Marantz Dolby Digital Out : Bit Stream DTS Out : Bit Stream MPEG Out : Bit Stream...
  • Page 57 DVD Setup Menu About i.LINK By simply connecting a single i.LINK cable between components with i.LINK ports, you can get direct digital transfers of not only DVD-Video audio but also multi-channel audio such as Super Audio CD or DVD-Audio, which previously could only be connected in analog with five audio cords, as well as 2- channel audio like conventional CDs.
  • Page 58 DVD Setup Menu • i.LINK can transport three formats: “i.LINK AUDIO (A&M protocol)” used by this unit, “MPEG-2 TS” for BS digital, and “DV” used by DVD recorders and digital video players. Data cannot be forwarded correctly when this unit is connected to components or computer peripherals that do not support the i.LINK AUDIO format. Furthermore, such connections may cause the unit to operate incorrectly.

  • Page 59: Resetting The Player

    This will usually reset the unit for proper operation. If this does not correct the problem, please consult your nearest MARANTZ service center. • If this operation is performed, all memories in...

  • Page 60: Additional Information

    Use of shaped discs is not recommended for this product. Cleaning the pickup lens The DVD player’s lens should not become dirty in normal use, but if for some reason it should malfunction due to dust or dirt, consult your nearest MARANTZ-authorized service center.

  • Page 61: Hints On Installation

    A damaged power cord can cause a fire or give you an electric shock. Check the power cord once in a while. If you find it damaged, ask your nearest MARANTZ authorized service center or your dealer for a replacement.

  • Page 62: Troubleshooting

    Inspect the other components and electrical appliances being used. If the trouble cannot be rectified after checking the items below, ask your nearest MARANTZ authorized service center or your dealer to carry out repair work. The disc is ejected automatically after loading.
  • Page 63 Additional Information The remote control doesn't seem to work. • The remote control is too far from the player, or the angle with the remote sensor is too wide. Use the remote control within its operating range (page 7). • The batteries are exhausted. Put in new batteries (page 7).
  • Page 64 Additional Information The disc containing the MP3 tracks won’t play. • If the disc is a recordable CD, make sure that the disc is finalized. Check that the track(s) are in the MPEG1 Audio Layer 3 format. Check that the sampling rate of the track(s) are 44.1 or 48kHz.
  • Page 65 Additional Information i.LINK related display messages NODE OVER LOOP CONNECTOR HOP OVER BUS FULL LINK CHECK CANNOT LINK Meaning Correction The number of connected Reduce the number of components, including this connected components to 63 unit, is more than 63. or less.

  • Page 66: Specifications

    Additional Information Specifications General System DVD-Video, DVD-Audio, DVD-R/RW, Video CD, Super Audio CD, CD, MP3 files and JPEG files Power requirements ... 120 V, 60Hz Power consumption ... 35 W Power consumption in standby mode ... 0.4W Weight ... 8.6 kg (18 lb 14 oz) Dimensions ...
  • Page 67 Additional Information...
  • Page 68 You can find your nearest authorized distributor or dealer on our website. U.S.A. Marantz America, Inc. EUROPE Marantz Europe B.V. Printed in Japan 1100 Maplewood Drive, Itasca, IL 60143, U.S.A. P.O. Box 8744, 5605 LS Eindhoven, The Netherlands is a registered trademark.
