TV
Zusätzlich erforderliche Unterlagen für den Komplettservice
Additionally required Service Documents for the Complete Service
Service
Manual
Sicherheit
Safety
Materialnr./Part No.
720108000001
Materialnummer/Part Number 720100488000
Änderungen vorbehalten/Subject to alteration
H-S43 0105
• 8002/8012 oUKIRL, 8003/8013 oD, 8005/8015
http://www.grundig.com
• Printed in Germany ...
Service Manual
1. Ergänzung / Supplement 1
Chassis D5
DVD Combo TV
Davio 14
TVD 37-2401 Text
GBC3200
Elegance 21 Flat
TVD 55-2401/5 Top
GBC3300
Advertisement
Table of Contents
Related Manuals for Grundig Chassis D5
Summary of Contents for Grundig Chassis D5
- Page 1 Service Manual 1. Ergänzung / Supplement 1 Chassis D5 DVD Combo TV Davio 14 TVD 37-2401 Text GBC3200 Elegance 21 Flat TVD 55-2401/5 Top GBC3300 Zusätzlich erforderliche Unterlagen für den Komplettservice Additionally required Service Documents for the Complete Service Service...
-
Page 2: Table Of Contents
GRUNDIG Service Chassis D5 Es gelten die Vorschriften und Sicherheitshinweise The regulations and safety instructions shall be valid gemäß dem Service Manual "Sicherheit", Material- as provided by the "Safety" Service Manual, part nummer 720108000001, sowie zusätzlich die eventu- number 720108000001, as well as the respective ell abweichenden, landesspezifischen Vorschriften! national deviations. -
Page 3: Technische Daten
GRUNDIG Service Chassis D5 Technische Daten / Technical Data Davio 14 Elegance 21 Davio 14 Elegance 21 TVD 37-2401 Text TVD 55-2401/5 Top TVD 37-2501 FR/Text TVD 55-2501 FR/Top Order Number GBC3200 GBC5900 GBC3300 GBC6000 40 13833-59703 2 40 13833-59798 8... - Page 4 GRUNDIG Service Chassis D5 Davio 14 Elegance 21 Davio 14 Elegance 21 TVD 37-2401 Text TVD 55-2401/5 Top TVD 37-2501 FR/Text TVD 55-2501 FR/Top Manual fine tuning Direct chanal selection PAL/BG SECAM/L´/L NTSC-Playback via Scart (3,58/4,43) Cable TV / Hyperband (S1-S41)
-
Page 5: Bedienhinweise
Bedienhinweise Dieses Kapitel enthält Auszüge aus der Bedienungsanleitung. Weitergehende Informationen entnehmen Sie bitte der gerätespezifischen Bedienungsanleitung, deren Materialnummer Sie in der entsprechenden Ersatzteilliste finden. -
Page 7: Operating Hints
Operating Hints This chapter contains excerpts from the operating instructions. For further particulars please refer to the appropriate user instructions the part number of which is indicated in the relevant spare parts list. -
Page 9: Service- Und Sonderfunktionen
GRUNDIG Service Chassis D5 Service- und Sonderfunktionen Service and Special Functions Service Mode aktivieren: Taste " " (Hauptmenü) drücken –> Ser- Start of the Service Mode: Press button " " (Main Menu) –> Enter vice Code "8500" eingeben. Service Code "8500". -
Page 10: Netzteil
GRUNDIG Service Chassis D5 Menüpunkt Einstellung SERVICE Hinweis Point of Menu Adjustment P– Hint P– 16:9 TEST siehe Abgleich / see Adjustment automatische AV-Umschaltung automatic AV switching nur PAL / PAL only andere Versionen / other versions EWP1 siehe Abgleich / see Adjustment 16:9 Ost/West Parabel (für 4:3 Geräte) -
Page 11: Ic Data Sheet & Specification
GRUNDIG Service Chassis D5 IC Data Sheets & Specifications • Stand-by, Idle and Power Down modes. • 14 bits PWM for Voltage Synthesis Tuning. • 8-bit A/D converter with 4 multiplexed inputs. IC 101 - OM 8365 • 5 PWM (6-bits) outputs for control of TV analogue signals. - Page 12 GRUNDIG Service Chassis D5 MSP 34x0G Multistandard Sound Processor Family TDA 7442 Digitally Controlled Audio Processor The MSP 3410G family of single-chip Multistandard Sound Pro- The TDA7442/42D is volume tone (bass and treble) balance (Left/ cessors covers the sound processing of all analog TV-Standards Right) processors for quality audio applications in TV and Hi-Fi sy- worldwide, as well as the NICAM digital sound standards.
- Page 13 GRUNDIG Service Chassis D5 LA7840 Vertical Deflection Output Circuit Features • Low power dissipation due to built-in pump-up circuit • Vertical output circuit • Thermal protection circuit built in • Excellent crossover characteristics • DC coupling possible General Description The LA7840 is a vertical deflection output IC for TVs and CRT dis- plays with excellent image quality that use a BUS control system si- gnal processing IC.
-
Page 14: Adjustment
GRUNDIG Service Chassis D5 Abgleich Adjustment Messgeräte: Digitalvoltmeter, Farbbildgenerator. Measuring instruments: Digital voltmeter, colour video generator. Servicearbeiten nach Austausch bzw. Reparatur: Service works after replacement or repair of the following modules: – Netzteil: Abgleich 1, 3 – Power supply: adjustment 1, 3 –... -
Page 15: Deflection
TDA 6108Q Triple Video Output Amplifier IR RECEIVER KEYBOARD KEYBOARD 14" ONLY AUDIO PROCESSOR IC 203 TDA 7442 TUNER POWER AMP. IC 301 MUTE TDA 7266S for 14" 21" ONLY SCLSDA IF1 IF1 TDA 7266 for 21" IC 101 AUDIO AOUT PROCESSOR IC202 MSP3410G... - Page 17 Bildröhre / CRT C524 FR521 R505 R506 TR501 TR602 A33EKC01X01 111V 6.8NF 0.47R 3.9R 3.3R 759551053200 759551053500 A33EKC02X01 111V 6.8NF 0.47R 3.9R 3.3R 759551053200 759551053500 A34EAC01X06 DY-BRZ 111V 6.8NF 1.5R 3.3R 3.9R 759551053200 759551053500 A34EJL02X31 111V 6.8NF 1.5R 3.9R 3.9R 759551053200 759551053500 A34KPU02XXB 111V...
-
Page 18: Af Amplifier
GRUNDIG Service Chassis D5 ZL6.190-03 - NF-Endstufe, AF Amplifier Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos. No. Coordinates Pos. No. Coordinates J306 R627 J307 R628 J308 R629 J309 R630 J310 R631 R632 J311 J501 R633 J502 R634 J503 R635 J504 R636 J505... -
Page 20: Zl5.190-03 - Signal Processing
GRUNDIG Service Chassis D5 ZL5.190-03 - Signalverarbeitung / Signal Processing 3 - 6... - Page 21 GRUNDIG Service Chassis D5 17 16 & & 3 - 7...
- Page 22 GRUNDIG Service Chassis D5 ™ £ ≤ ∞ § ≥ 25 26 27 23 ¡ 0V(0V) 4,4V(0V) 0V(0V) 4,4V(0V) 0V(0V) 4,4V(0V) 4,7V(5,0V) & 4,6V(5,0V) 0V(0V) 4,4V(0V) 3,1V(0V) 0V(0V) 4,4V(0V) 8,9V(0V) 3 - 8...
- Page 25 GRUNDIG Service Chassis D5 Koordinaten für die Bauteile der Bestückungsseite (Ansicht von oben) Coordinates of the Components on the component side (top view) Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos. No. Coordinates Pos. No.
- Page 26 GRUNDIG Service Chassis D5 Koordinaten für die Bauteile der Lötseite (Ansicht von unten) Coordinates of the Components on the solder side (bottom view) Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos.-Nr./ Koordinaten/ Pos. No. Coordinates Pos. No. Coordinates Pos. No.
-
Page 27: Zl5.194 Crt Board
GRUNDIG Service Chassis D5 ZL5.194 - Bildrohrplatte / CRT Board 28 29 30 25 26 27 º ⁄ ¤ ∞ § ≥ • ª 3 - 13... -
Page 28: Zl6.194 Crt Board
GRUNDIG Service Chassis D5 ZL6.194 - Bildrohrplatte / CRT Board 155V CRT BOARD D701 X703 CRT SOKET C702 1N4007 10u/250V 155V R710 n.c. BLUE T701 BF422 D702 1N4148 R713 2.7k R725 C701 R702 220R C705 1.5K R714 C703 390p GREEN... -
Page 29: Zl5.192-01 Av Board
GRUNDIG Service Chassis D5 ZL5.192-01 - AV-Platte / AV Board LEFT SVHS VI DEO RIGHT JAC K VI DEO RIGHT LEFT R198 R197 390R R193 R194 390R R192 240K 240K C193 C194 ZD192 ZD193 ZD194 ZD191 R190 R191 R196 C192... -
Page 30: Zl6.192-02 Av Board
GRUNDIG Service Chassis D5 ZL6.192-02 - AV-Platte / AV Board X902 X905 SVHS X903 X904 VI DEO RIGHT LEFT R193 R194 R192 240K 240K ZD192 ZD193 ZD194 ZD191 R190 R191 C192 C191 R199 R200 470R 1/4W 470R C195 1/4W C196... -
Page 31: Zl5.191 Keyboard
GRUNDIG Service Chassis D5 ZL5.191 - Bedienplatte / Keyboard X402-1 PR/VOL MENU TACT TACT TACT TACT SWITCH SWITCH SWITCH SWITCH LED1 R6 2 C102M 100U/16V 100R 100U/16V JUMPER ZL5.195 - Bedienplatte / Keyboard REWIND STOP TV/DVD TACT TACT TACT SWITCH... -
Page 32: Zl6.191 Keyboard
GRUNDIG Service Chassis D5 ZL6.191 - Bedienplatte / Keyboard REWIND STOP TV/DVD TACT TACT TACT SWITCH SWITCH SWITCH FORWARD PLAY/ PAUSE EJECT JUMPER X402 TACT SWITCH TACT SWITCH TACT SWITCH JUMPER PR/VOL MENU TACT TACT SWITCH TACT SWITCH TACT SWITCH... -
Page 33: Exploded Views And Spare Parts Lists
Explosionszeichnungen und Ersatzteillisten / Exploded Views and Spare Parts Lists Davio 14... - Page 34 Elegance 21...
-
Page 35: Spare Parts Lists
720117082200 BEDIENUNGSANLEITUNG E/P/FIN INSTRUCTION MANUAL E/P/FIN 720117081600 BEDIENUNGSANLEITUNG DK/S/N INSTRUCTION MANUAL DK/S/N 720100488000 SERVICE MANUAL CHASSIS D5 D/GB REPAIR MANUAL CHASSIS D5 D/GB 720117081700 BEDIENUNGSANLEITUNG E/P/FIN INSTRUCTION MANUAL E/P/FIN 720100488000 SERVICE MANUAL CHASSIS D5 D/GB REPAIR MANUAL CHASSIS D5 D/GB... - Page 36 POS. NR. MATERIAL-NR. BEZEICHNUNG POS. NR. MATERIAL-NR. BEZEICHNUNG POS. NO. PART NUMBER DESCRIPTION POS. NO. PART NUMBER DESCRIPTION Ersatzteilliste Spare Parts List X 601 759550966400 STECKER 2 POL. X 901 759551054300 KOPFHOERERBUCHSE ZD 194 759540390700 Z-DIODE BZX55-C6V2 ZD 301 759540390700 Z-DIODE BZX55-C6V2 1 / 2005 CHASSISMODUL D5 14"...
- Page 37 Ersatzteilliste Ersatzteilliste Spare Parts List Spare Parts List 10 / 2004 12 / 2004 LP-CHASSISMODUL D5 21 LP-VIDEOMODUL D5 14" CHASSISBOARD D5 21 VIDEOBOARD D5 14" MATERIAL-NR. / PART NO.: 275990132400 MATERIAL-NR. / PART NO.: 275990135200 POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION POS.
- Page 38 Ersatzteilliste Ersatzteilliste Spare Parts List Spare Parts List 1 / 2005 LP-BILDROHRMODUL D5 14" 1 / 2005 LP-VIDEOMODUL D5 21" CRT-BOARD D5 14" VIDEO BOARD D5 21" MATERIAL-NR. / PART NO.: 275990135300 MATERIAL-NR. / PART NO.: 275990135100 POS. NR. ABB. MATERIAL-NR.
