TABLE OF CONTENTS Safety and Service Instructions..............3 Safety First ....................4 Descriptions ....................5 System Features -SxA360................6 Using SxA360‘s as Floor Monitors .............. 7 Specifications ..................... 16 Dimensions ....................16 Block Diagram .................... 17 FCC INFORMATION (U.S.A) 1. IMPORTANT: Do not modify this unit! Changes or modifications not expressly approved by the manufacturer could void the user`s authority, granted by the FCC, to operate the equipment.
IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated „dangerous voltage“ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons The exclamation point within an equilateral triangle is intended to alert the user to the presence of important...
• The line input utilizes Neutrik “combo” connectors, which will accept either 1⁄4-inch or 3-pin XLR- type connectors. • The SxA360 two-way system is perfect for use as powered floor monitors. System Setup To get your SxA system into operation as quickly as possible, please observe the following steps and precautions.
Page 6
Mains connector is carried out as PowerCon-type socket. A Figure 1: fitting mains cord (5m) with Rear Panel SxA360 PowerCon-type plug is supplied. POWER Mains switch for powering the appliance on or off. With the power amplifier being switched on, the mains switch is backlit.
• The SxA360 is perfect for use as a powered floor monitor. • The F200 adapters are necessary to convert the Sxa360 into a monitor and are shipped with the speaker. To install the adapters, simply insert them into the speaker (see Figure 2 below). The F200 adapters can be easily removed by pulling in the opposite direction.
WICHTIGE SICHERHEITSHINWEISE Das Blitzsymbol innerhalb eines gleichseitigen Drei- ecks soll den Anwender auf nicht isolierte Leitungen und Kontakte im Geräteinneren hinweisen, an denen hohe Spannungen anliegen, die im Fall einer Berührung zu lebensgefährlichen Stromschlägen führen können. Das Ausrufezeichen innerhalb eines gleichseitigen Dreiecks soll den Anwender auf wichtige Bedienungs- sowie Servicehinweise in der zum Gerät gehör- enden Literatur aufmerksam machen.
Page 13
• Der Linepegel-Eingang ist über Neutrik „Combo“-Anschlüsse ausgeführt, die entweder mit 6,3mm Klinken- oder mit 3-Pin XLR-Steckern verbunden werden können. • Das SxA360 Zweiwegsystem eignet sich perfekt zur Verwendung als aktiver Bodenmonitor. System-Setup Beachten Sie bitte die folgenden Bedienungs- und Sicherheitshinweise, um Ihr SxA-System so schnell wie möglich in Betrieb zu nehmen:...
Page 14
MAINS IN Der netzseitige Anschluß ist mit einer PowerCon-Buchse ausge- Abb.: 1: führt. Ein passendes 5m langes Rückseite SxA360 Netzkabel, mit PowerCon-Stecker, ist im Lieferumfang enthalten. POWER Netzschalter zum Ein- und Ausschalten des Gerätes. Der Netzschalter ist beleuchtet, wenn das Gerät einge- schaltet ist.
Page 15
• Das SxA360 eignet sich perfekt zur Verwendung als aktiver Bodenmonitor. • Die zum Lieferumfang gehörenden F200-Adapter werden benötigt, um das SxA360 als Bodenmonitor zu benutzen. Zur Befestigung werden die Adapter, wie in Abbildung 2 unten gezeigt, einfach in das Kabinettchassis eingesteckt.
Page 16
Specifications Internal amplifier at rated conditions, all power ratings at minimum speaker impedance (LO 6 ohms / HI 12 ohms), unless otherwise specified. Freq. Response (-10 dB): 60 Hz - 18 kHz Max. SPL: 126 dB Horizontal Coverage: 65° Vertical Coverage: 65°...
