Majestic fireplaces UV36 Homeowner's Installation And Operating Instructions Manual

Vent-free gas fireboxes
Hide thumbs Also See for UV36:
Table of Contents

Advertisement

Quick Links

INSTALLER/CONSUMER
SAFETY INFORMATION
Read and save
these instructions.
This book contains your installation
instructions and should be kept in a
safe place. For you to realize all the
advantages and use of the reliable ser-
vice that has been engineered into your
fireplace, you must carefully follow all of
the instructions contained in this book
regarding installation and operation of
the fireplace.
These instructions should be read care-
fully in their entirety before beginning
installation of the fireplace.
It is suggested that you wear work
gloves and safety glasses to protect
your hands and eyes when installing
your fireplace. NOTE: Authorities having
jurisdiction (i.e. building inspectors, fire
marshals, etc.) should be consulted be-
fore installation to determine the need
to obtain a permit.
When installing the Blower Kit, it is
necessary to bring the power source to
the fireplace before walls are enclosed.
Refer to Blower Kit instructions.
These fireboxes are approved as uni-
versal fireboxes and can be paired
with any ANSI Z21.11.2 approved
vent-free log set. The vent-free log
manufacturer's instructions - in-
cluding their required dimensional
clearances for firebox size, - must be
followed.
Refer to the manual that is packed with
the log set for operating instructions.
CFM Specialty Home Products Unvented
Gas Logs VL24MN, VL24MP, VL24RN,
VL24RP, VFL34MN, VFL34MP, VFL34RN,
VFL34RP may be used with this firebox.
(Refer to Page 4)
INSTALLER: DO NOT DISCARD THIS MANUAL - Leave in fireplace for homeowner.
Vent-Free Gas Fireboxes
Model: UV36
Homeowner's Installation and
Operating Instructions
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
78647
ADC36-3 cover
2/04
™
20007446 6/05 Rev. 4

Advertisement

Table of Contents
loading

Related Manuals for Majestic fireplaces UV36

Summary of Contents for Majestic fireplaces UV36

  • Page 1 VL24RP, VFL34MN, VFL34MP, VFL34RN, VFL34RP may be used with this firebox. (Refer to Page 4) INSTALLER: DO NOT DISCARD THIS MANUAL - Leave in fireplace for homeowner. Vent-Free Gas Fireboxes Model: UV36 Homeowner’s Installation and Operating Instructions 78647 ADC36-3 cover...

  • Page 2: Table Of Contents

    UV36 Vent-Free Firebox This book contains your operating instructions and should be kept in a safe place. For you to realize all the advan- tages and use of the reliable service that has been engineered into your fireplace, you must carefully follow all of the instructions contained in this book regarding installation and operation of the fireplace.

  • Page 3: Important Information

    Rooms com- municating directly with the space in which the appliances are installed, through openings not furnished with doors, are considered a part of the unconfined space. UV36 Vent-Free Firebox per kw) of the aggregate input...

  • Page 4: Fireplace Dimensions

    (Not used on this model) Gas Line Access 8���" 8���" 3���" 11���" Outside Air Access 7446 Fig. 1b UV36 specifications and framing. Fig. 1a Firebox dimensions. Fireplace Dimensions Rough Opening 21���" Depth 14���" Rough Opening Width 36���" 1/2” Clearance to combustibles not required at this point.

  • Page 5: Installation Instructions

    12” above the fireplace opening. C. A combustible mantel must fall within the profile that is shown in Figure 3. 4. Floor Clearances: No clearance is required if the appliance is installed per these instructions. UV36 Vent-Free Firebox Framing Clearances Clearances...

  • Page 6: Installing The Firebox

    UV36 Vent-Free Firebox Combustible Mantel Clearances 8" 6" 1" Noncombustible or Void 12" Standoff 9" 17" Fig. 3 Combustible mantel clearances. 21���" 14���" 36" 2” Minimum Clearance to Side Wall or Mantel Leg 36" Fig. 4 Framing dimensions. T143 framing dimension...

  • Page 7: Finishing The Fireplace

    firebox. It acts as a support/firestop. It should be attached to the face of the fireplace with screws and sealed to the fireplace with a heat-resistant sealer. FP1532 Refer to Figure 6 for finishing options. UV36 Vent-Free Firebox...

  • Page 8: Install Optional Outside Air Kit

    UV36 Vent-Free Firebox 6a Wallboard with Marble, Slate or Tile Facing Finished Wall Stud Header Noncombustible Must be enclosed with a Decorative Covering noncombustible material. T234 6b Brick or Stone Facing finishing w/facing 2/04 Finished Wall Stud Brick or Stone Facing...
  • Page 9 flapper valve. Periodically inspect the duct termination for any block- age. Correct if necessary. KT143 KT143 AKU cover plate 9/5/00 djt UV36 Vent-Free Firebox KT145 Duct Ter- AKU reinstall mination cover plate 9/6/00 djt...

  • Page 10: Replacement Parts

    UV36 Vent-Free Firebox CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. UV36 Vent-Free Firebox Ref. Description Refractory Side Brick (2 per fireplace) Refractory Back Brick Screen Panel Assy (2 per fireplace)

  • Page 11: Warranty

    IF WARRANTY SERVICE IS NEEDED… 1) Contact your supplier. Make sure you have your warranty, your sales receipt, and the model/serial number of your CFM Specialty Home Products product. 2) DO NOT ATTEMPT TO DO ANY SERVICE WORK YOURSELF. UV36 Vent-Free Firebox...
  • Page 12 CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com • www.vermontcastings.com...
