- Page 1 Owner’s manual Manuel du propriétaire Manual del propietario 32MF330B 26MF330B LCD TV 1-866-341-3738 Quick Use Guide Inside! Guide d’usage Rapide Incluse! Guía de Uso Rápido Incluida! MODEL NUMBER 1-866-341-3738 1-866-341-3738 SERIAL NUMBER...
- Page 2 Return your Product Registration Card or register online at www.magnavox.com/support today to get the very most from your purchase. Registering your model with MAGNAVOX makes you eligible for all of the valuable benefits listed below, so don’t miss out. Complete and return your Product Registration Card at once,...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 4: Trademark Information
DECLARATION OF CONFORMITY Trade Name: MAGNAVOX Model: 32MF330B / 26MF330B This Class B digital apparatus complies with Canadian ICES-003. Standard Television Receiving Apparatus, Canada BETS-7 / NTMR-7 CAUTION : Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. -
Page 5: Table Of Contents
• Fun-Link via HDMI Link (HDMI Cable not Included) Fun-Link allows your other HDMI link devices (such as Magnavox DVD) to be controlled by the HDMI cable connected to your TV. • HDMI Input When using HDMI1 Input, you can enjoy this unit as a PC monitor if your PC has a DVI output terminal. -
Page 6: Supplied Accessories
Supplied Accessories Owner’s manual Quick Start (1EMN25839) 32MF330B: 1EMN25840 26MF330B: 1EMN26281 Remote control Registration card (NF804 UD) (1EMN 24699 ) Batteries Screw kit for attaching the base (AAA, 1.5V x 2) 32MF330B: 1ESA19881 26MF330B: 1ESA23705 • If you need to replace these accessories, please refer to the part No. -
Page 7: Control Panel
Control Panel 32MF330B VOLUME MENU CHANNEL 26MF330B STAND BY POWER ON VOLUME MENU CHANNEL POWER 2 CHANNEL +/ - Press to select channels or move up ( + ) / down (–) through the main menu items. 3 MENU 4 VOLUME +/ - Press to adjust the volume or move right ( + ) / left (–) -
Page 8: Terminals
Terminals 32MF330B 26MF330B 8 S-Video / Composite Video / Audio (L/R) Input jacks for VIDEO 9 HDMI 2 Input jack Rear Panel 10 AC power cord 11 Cable management 12 Component Video and Audio (L/R) Input jacks 13 Audio (L/R) Output jacks 14 Audio (L/R) Input jacks for HDMI 1 Audio cable connection from a DVI device. -
Page 9: Remote Control Function
Remote Control Function When using a universal remote control to operate this unit. • Make sure the component code on your universal remote control is set to our brand. Refer to the manual accompanying your remote control for more details. •... -
Page 10: Preparation
DTV antenna RF coaxial cable cable TV signal RF coaxial cable 26MF330B rear of this unit Once connections are completed, turn on the unit and begin initial setup. Channel scanning is necessary for the unit to memorize all available channels in your area. [Initial Setup] ➠ p. 15 Note •... -
Page 11: External Device Connection
26MF330B satellite dish RF coaxial cable ANT IN cable receiver / satellite box cable TV signal including PPV HDMI OUT (green) HDMI cable component video cables component video cables (red/ blue/green) and audio ca blue/green) side or rear of this unit... - Page 12 AUDIO OUT AUDIO OUT audio cables HDMI-DVI HDMI-DV conversion cable conversion cable 26MF330B To HDMI1 T T o o HDMI1 o HDMI1 Input jack only nput jack o put jack only Note • The unit accepts 480i / 480p / 720p and 1080i of video signals for this connection.
- Page 13 CR with the S-Video out CR with the S-Video out CR with the S-Video out CR with the S-Video out 26MF330B B B B B B B B B B B B B B B audio cables S-Video cable side of this unit...
-
Page 14: Cable Management
HDMI-DVI conversion cable should be with ferrite core. HDMI-DVI conversion cable 26MF330B rear of this unit The following video signals can be displayed: Format Resolution 640 x 480 SVGA 800 x 600... -
Page 15: Initial Setup
These operations are accessible by remote control. Some may also be accessible by controls on the main unit. Initial Setup This section will guide you through the unit’s initial setting which includes selecting a language for your on-screen menu and autoprogram, which automatically scans and memorizes viewable channels. -
Page 16: Watching Tv
WATCHING TV Sleep Timer can be set to automatically turn off the unit after an incremental period of time. Press SLEEP repeatedly to change the amount of time (increases the time by 30 minutes up to 120 minutes) until shut off. Press SLEEP once to call up the display for checking the remaining time. -
Page 17: Tv Screen Display Mode
TV Screen Display Mode 5 types of display modes can be selected when the broadcasting station is sending 16:9 or 4:3 video signal. And 3 types of display modes can be selected for PC input signal. Press FORMAT repeatedly to switch the TV aspect ratio. For 16:9 video signal Normal Wide... -
Page 18: Tv Screen Information
You must set [On] in [Device Control] and [Fun-Link Control]. ➠ p. 29 Otherwise, FUN-LINK OPTIONS you connected our brand devices to this unit. To enjoy Fun-Link, verified and recommended devices are as follows; MAGNAVOX NB530MGX NB500MG1F ➠ MBP1100 / F7 p. 17 Press FUN-LINK OPTIONS [Fun-Link Options] menu. -
Page 19: Optional Setting
OPTIONAL SETTING Main Menu This section describes the overview of the main menu displayed when you press MENU. The main menu consists of the function setting items below. Press MENU. Picture [Picture Adjustment] Sound [Sound Adjustment] Setup [Autoprogram] • You can automatically scan the viewable channels. [Channel List] •... -
Page 20: Channel List
Channel List The channels selected here can be skipped when selecting the channels using CH + / – . Those channels can still be selected with the Number buttons. Press MENU to display the main menu. Use ▲/▼ to select [Setup], then press OK. Use ▲/▼... -
Page 21: Antenna Confi Rmation
Antenna Confi rmation ATSC This function lets you check the digital signal strength of each channel. Press MENU to display the main menu. Use ▲/▼ to select [Setup], then press OK. Use ▲/▼ to select [Antenna], then press OK. Use the Number buttons or CH + / – to select the channel for which you want to check the digital signal strength. -
Page 22: Picture Adjustment
Picture Adjustment You can adjust picture mode, or customize the picture quality as your preference. Before you begin: You must set [Home] in [Location]. ➠ p. 30 Otherwise, the settings you adjusted will not be memorized after you turn off the unit. Press MENU to display the main menu. -
Page 23: Smart Sound
Smart Sound Use ▲/▼ to select the desired setting, then press OK. ([Personal], [Standard], [Movie], [Music], and [News]) Smart Sound Picture Equalizer Sound Setup Virtual Surround Sound Auto Volume Leveling Features TV Speakers Language Primary MTS Equalizer Adjust tonal quality for each frequencies. Use ◄/► to select the specifi... -
Page 24: Closed Caption
Closed Caption You can view closed captioning (CC) for TV programs, movies and news. Closed caption refers to text of dialogue or descriptions displayed on-screen. Press MENU to display the main menu. Use ▲/▼ to select [Features], then press OK. Use ▲/▼... - Page 25 B. Digital Caption Service B. Digital Caption Service ATSC In addition to the basic closed caption, DTV has its own closed caption called digital caption service. Use this menu to change the settings for digital caption service. Use ▲/▼ to select [Digital Caption Service], then press Use ▲/▼...
-
Page 26: Font Style
Font Style Closed Captioning font style can be changed as illustrated. Font Size Font size of the displayed caption can be switched as illustrated. Font Color Font color of the displayed caption can be switched as illustrated. Font Opacity Font opacity of the displayed caption can be switched as illustrated. -
Page 27: Child Lock
Child Lock Child lock reads the ratings for programs, then denies access to the programs which exceed the rating level you set. With this function, you can block certain programs inappropriate for children and any channels or external input modes can be invisible. - Page 28 C. Setting TV ratings C. Setting TV ratings Use ▲/▼ to select [US TV Ratings Lock] k k , then press OK. Use ▲/▼ / ◄/► to select the desired rating, then press OK repeatedly to switch between Picture Sound TV-MA Setup TV-14...
-
Page 29: Fun-Link
Fun-Link This function allows you to operate the linked functions between our brand devices with a Fun-Link feature and this unit connecting through an HDMI cable. Press MENU to display the main menu. Use ▲/▼ to select [Features], then press OK. Use ▲/▼... -
Page 30: Energy Saving Mode
Energy Saving Mode You can set whether the power consumption is saved or not. Press MENU to display the main menu. Use ▲/▼ to select [Features], then press OK. Use ▲/▼ to select [Energy Saving Mode], then press OK. Use ▲/▼ to select the desired mode, then press OK. Picture Sound Setup... -
Page 31: Troubleshooting
TROUBLESHOOTING Question Answer • • • • My remote control does not • work. What should I do? • • • • How come the Initial setup • appears every time I turn on • this unit? • • • •... -
Page 32: Troubleshooting Guide 3
Troubleshooting Guide If the unit does not perform properly when operated as instructed in this manual, check the following chart and all connections once before calling for service. Symptom No power Control button does not work. Power is ON but no screen image. - Page 33 Symptom Remedy • You see "noise" or "trash" on the screen. Different color marks on the TV • screen • You switch to a different input • and the volume changes. You switch to a different input • and the screen size changes. The display image does not cover •...
-
Page 34: Glossary
INFORMATION Glossary ATSC Acronym that stands for Advanced Television Systems Committee and the name of the digital broadcasting standards. Aspect Ratio The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square); widescreen models are 16:9 (the TV screen is almost twice as wide as its height). -
Page 35: General Specifi Cations
30.0 Height 20.5 inches(519.3 mm) 22.2 Depth 4.3 inches(107.0 mm) Weight 18.96 lbs. (8.60 kg) 20.07 lbs. For 26MF330B 26 inches Power consumption (maximum) 110 W Dimensions <without base> <with base> Width 25.9 inches(656.0 mm) 25.9 Height 17.7 inches(448.0 mm) 19.2... -
Page 37: Limited Warranty
