Page 1 ® Intel Server Board S2600CP Family ® Intel Server System P4000CP Family Service Guide ® A Guide for Technically Qualified Assemblers of Intel identified Subassemblies/Products Order Number: G54899-001...
Page 2 Intel’s own chassis are designed and tested to meet the intended thermal requirements of these components when the fully integrated system is used together. It is the responsibility of the system integrator that chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of airflow required for their specific application and environmental conditions.
Page 3: Safety Information
Instrucciones de seguridad importantes Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en ® el Intel Server Deployment & Management DVD y/o en http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
Page 4 Take care to grip with, but not squeeze, the pliers or other tool you use to remove a jumper, or you may bend or break the pins on the board. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 5: Preface
® and instructions on how to add and replace components on the Intel Server Chassis P4000M family. For the latest version of this manual, refer to http://www.intel.com/p/en_US/support.
Page 6: Additional Information And Software
See the section on the web page titled, “Document and Guides”. ® If you just received this product and need Intel Server Board S2600CP Quick Start User’s Guide to install it. ® Intel Server System P4000CP Family Quick Installation User’s Guide ®...
Page 7: Table Of Contents
Removing a PCI Add-in Card..................... 33 Design A GPGPU Card Extender ......................34 Installing and Removing an Optical Drive ................... 35 Installing an Optical Drive......................35 ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 8 Installing the Fron Panel Tray ....................66 Replacing the Front Panel Board ......................68 Installing Alternate Serial Port ......................69 Installing and/or Removing a Expander card ..................70 ® ® viii Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 9 Appendix C: LED Decoder ........................165 Appendix D: Getting Help ........................170 Warranty Information ....................... 170 ® Appendix E: Intel Server Issue Report Form ..................171 ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 10 Figure 14. 8 x 2.5 backplane - Rear View ....................12 l® Figure 15. Internal Inte RAID Expander Cards Components ..............12 ® Figure 16. Cable connections for Intel Server System P4308CP4MHEN ..........15 ® Figure 17. Cable routing for Intel Server System P4308CP4MHEN ............16 ®...
Page 11 Figure 93. Removing the Hot-swap HDD EMI Shield ................57 Figure 94. Installing the Hot-swap HDD EMI Shield................. 58 Figure 95. Removing 3.5” hard drive backplane – remove the hard drive cage ......... 58 ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 12 Figure 143. Delete EFI Boot Option Screen ..................... 158 Figure 144. Boot Manager Screen ......................159 Figure 145. Error Manager Screen ......................159 Figure 146. Exit Screen ..........................160 ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 13 List of Figures Figure 147. Diagnostic LED Placement Diagram ..................165 ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide xiii...
Page 14 ..................162 Table 9. Over Current Protection ......................163 Table 10. System Environmental Limits Summary .................. 163 Table 11. POST Progress Code LED Example ..................166 ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 15: Server System Features
O. 8x3.5” Hot-swap HDD Cage ® Intel RAID C600 Upgrade Key Q. PCI-e Retainer ® Figure 1. Intel Server System P4308CP4MHEN NOTE: Airduct is not shown ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 16: Intel ® Server System P4308Cp4Mhgc View
O. 8x3.5” Hot-swap HDD Cage ® Intel RAID C600 Upgrade Key Q. PCI-e Retainer ® Figure 2. Intel Server System P4308CP4MHGC NOTE: Airduct is not shown. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 17: Intel ® Server System P4208Cp4Mhgc View
NOTE: Airduct is not shown. Hot Swap Hard Drive Bay and Front Panel Options ® The figure below shows the 8x3.5” drive bay for Intel Server System P4308CP4MHEN and P4308CP4MHGC, and 8x2.5” drive bay for Intel ® Server System P4208CP4MHGC.
Page 18: Front Control Panel
Figure 4. Hot Swap Hard Drive Bay and Front Panel Options Front Control Panel Below figure show the layout of components on Front Control Panel. Figure 5. Front Control Panel ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 19: Back Panel
Kensington* Cable Lock Mounting Hole Power Supply Padlock Loop IO Connectors RMM4 NIC Port (Optional) RMM4 NIC Port (Optional) Figure 7. Back Panel with 750-W PSU ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 20: Server Board Components
Server System Features Server Board Components ® This section helps you identify the components and connectors on the Intel Server Board S2600CP. Callout Description Callout Description Slot 1, PCI Express* Gen3 System Fan 4 connector RMM4 LITE Internal eUSB SSD...
Page 21: Intel ® Light-Guided Diagnostics
Chassis Intrusion Figure 8. Server Board Connector and Component Locations ® Intel Light-Guided Diagnostics ® The figure in below shows the locations of Diagnostic LEDs on Intel Server Board S2600CP. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 22: Figure 9. Intel Light-Guided Diagnostic Leds - Server Board
DIMM Fault LEDs on the server board help identify failed and failing DIMM slots. The DIMM fault LEDs turn on (amber) if there is a DIMM fault. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 23: System Jumpers
Server System Features System Jumpers ® The figure below shows the locations of System Jumpers on Intel Server Board S2600CP. Jumper Name Pins System Results Pins 1-2 should be connected for normal system operation. (Default) BIOS Recovery The main system BIOS does not boot with pins 2-3 connected. The system only boots from EFI- bootable recovery media with a recovery BIOS image present.
Page 24: Hot-Swap Sas/Sata Backplane
The following diagrams show the location for each connector found on the backplane. 8 x 3.5-inch Hard Drive Backplane SAS/SATA Hot-swap Connectors Figure 11. 8x3.5-inch backplane – Front View ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 25: Figure 12. 8X3.5 Backplane - Rear View
C In Connector Figure 12. 8x3.5-inch backplane – Rear View 8 x 2.5-inch Hard Drive Backplane SAS/SATA Hot-swap Connectors Figure 13. 8x2.5-inch backplane - Front View ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 26: Intel Raid Expander Cards (Upgrade Option)
Figure 14. 8x2.5-inch backplane - Rear View ® Intel RAID Expander Cards (Upgrade Option) Intel provides two types of internal RAID expander cards: 36 ports and 24 ports. Power Connector Mini-SAS Connector A Mini-SAS Connector B Mini-SAS Connector G (36 port sku only)
Page 27: Advanced Management Options
It also provides Remote KVM Redirection and USB Media Redirection allowing USB devices attached to the remote system to be used on the managed server. “Installing and ® For instructions on installing the Intel Remote Management Module 4, see ® Removing the Intel Remote Management Module 4”.
Page 28: Hardware Installations And Upgrades
All references to left, right, front, top, and bottom assume the reader is facing the front of the chassis as it would be positioned for normal operation. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 29: Cable Routing Recommendations
Use the figures below to determine the correct cable routing. NOTE: ® To activate the port SATA/SAS 4-7 on the server board, a proper Intel RAID C600 Upgrade Key ® must be installed. For instructions, see Intel RAID C600 Upgrade Key Installation Guide.
Page 30: Figure 17. Cable Routing For Intel
  Hot-swap Backplane I2C Cable System Fan 1 Cable   System Fan 2 Cable ® Figure 17. Cable routing for Intel Server System P4308CP4MHEN ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 31: Figure 18. Cable Connections For Intel Server System P4308Cp4Mhgc And P4208Cp4Mhgc
Hardware Installations and Upgrades ® Cable connections for Intel Server System P4308CP4MHGC and P4208CP4MHGC: ® Figure 18. Cable connections for Intel Server System P4308CP4MHGC and P4208CP4MHGC ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 32: Figure 19. Cable Routing For Intel
System FAN 2 System FAN 3     System FAN 4 System FAN5 ® Figure 19. Cable routing for Intel Server System P4308CP4MHGC and P4208CP4MHGC ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 33: Removing And Installing The System Side Cover
4. Remove the screws (see letter "A"). 5. Slide the side cover back (see letter "B") and lift the cover outward to remove it. Figure 20. Removing the Side Cover ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 34: Installing The System Side Cover
(see letter “A”) no more than 40 degrees outward. 5. At a 40-degree angle, push the bezel assembly away from the chassis (see letter “B”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 35: Installing The Front Bezel
4. Latch the two plastic tabs (see letter “B”) on the left side of the bezel assembly to the chassis. Figure 23. Installing the Front Bezel ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 36: Removing And/Or Installing Airduct
Remove the chassis cover. For instructions, see “Removing the Chassis Cover”. Install the airduct by matching the alignment tabs on airduct and the alignment holes on chassis bracket. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 37: Removing And Installing Processor
Similarly, loosen screws 3 and 4. Repeat steps A and B by giving each screw two rotations each time until all screws are loosened. 3. Lift the heatsink straight up (see letter “C”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 38: Installing The Processor
2. Open the Load Plate. Press the locking lever slightly to raise the load plate (see letter “A”). Open the load plate all the way (see letter “B”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 39: Figure 28. Installing Processor - Open The Load Plate
4. Remove the Cover. Press the cover to remove it. Save the protective cover. Figure 30. Installing Processor – Remove the Cover 5. Close the Load Plate. Carefully lower the load plate over the processor. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 40: Installing Processor Heatsink(S)
5. Repeat these steps on each screw with two rotations each time until each screw is lightly tightened up to a maximum of 8 inch-lbs torque. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 41: Installing And Removing Memory
DIMM until the retaining clips snap into place (see letter “D”). Make sure the clips are firmly in place (see letter “E”). Figure 34. Installing Memory ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 42: Removing Memory
3. Install the hard disk drive using the same four screws as shown. Make sure the connector end of the drive matches the backplane connector (see letter “D”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 43: Figure 37. Installing Hard Disk Drive - Installing 3.5" Hdd
4. With the lever open, insert the hard disk drive assembly into the chassis (see letter “A”). Push in the lever to lock it into place (see letter “B”). Figure 39. Installing Hard Disk Drive – Inserting 3.5” HDD assembly ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 44: Installing A Hard Disk Drive Into 2.5" Hard Drive Carrier
4. With the lever open, insert the hard disk drive assembly into the chassis (see letter “G”), then push in the lever to lock it into place (see letter “H”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 45: Installing And Removing A Pci Add-In Card
5. Remove the PCI slot shield from the chassis rear end. See letter A. Figure 44. Remove PCI slot shield 6. Open the PCI card retainer. See letter B. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 46: Figure 45. Open Pci Card Retainer
7. Open the PCI card retention device. See letter C. Figure 46. Open PCI card retention device 8. Align the PCI card and insert into place. See letter D. Figure 47. Install PCI card ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 47: Removing A Pci Add-In Card
4. Remove the airduct by gentlely lifting the airduct out of chassis. 5. Open the PCI card retainer. 6. Release PCI card retention device, remove screw if there is. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 48: Design A Gpgpu Card Extender
Users need to design a GPGPU card extender to make a non-full length GPGPU card to be full length, in order to take advandage of the GPGPU card bracket. Figure 51. Secure the GPGPU card with GPGPU bracket ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 49: Installing And Removing An Optical Drive
To maintain proper system cooling, a filler panel must be installed if you do not install a device at this location. Installing an Optical Drive 1. Remove the O filler (see letter “A”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 50: Removing An Optical Drive
2. Press the latching end of optical drive rails (see letter “A”) and pull the optical drive out (see letter “B”). 3. Remove the optical drive rail from the drive (see letter “C”). Figure 56. Remove an Optical Drive ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 51: Installing And Removing The Intel
® Installing the Intel RAID C600 Upgrade Key ® Locate the white 4-pin key header. Carefully pickup the Intel RAID C600 Upgrade Key. Match the Key and connector orientation and press down to install. ® Figure 58. Installing the Intel RAID C600 Upgrade Key ®...
Page 52: Installing And Removing The Intel
® Installing the Intel RMM4 Lite ® Locate the RMM4 Lite connector next to RISER SLOT_1, carefully pickup the Intel RMM4 Lite module, match the alignment pin of the module and the connector on server board, then press to install.
Page 53: Removing The Intel Rmm4 Lite
® Installing the Intel RAID Smart Battery ® 1. Connect the cable between the BBU and the RAID card. For details, see Intel RAID Smart Battery User’s Guide. 2. Locate the mounting holes inside the chassis. 3. Align the tabs on the plastic battery holder with the mounting holes in the chassis and slide the plastic battery holder until the tabs engage with the mounting holes.
Page 54: Removing The Intel Raid Smart Battery
5. Disconnect all internal power cables from chassis components and server board. 6. Rotate the power supply locking device counter-clockwise (see letter “A”) and remove the fixed power supply (see letter “B”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 55: Installing The Fixed Power Supply
4. Install the chassis cover. For instructions, see “Installing the Chassis Cover”. 5. Plug all peripheral devices and the AC power cable into the server. 6. Power up the server. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 56: Installing An Additional Hot-Swap Power Supply Module
2. Remove power cable from defective power supply. 3. Press up on green latch in the direction shown while pulling on handle to remove hot swap power supply from chassis. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 57: Replacing The Power Distribution Board
6. If present, press on green latch in the direction shown while pulling on handle to remove power supply from chassis. Repeat this step for the second hot-swap power supply if it is installed. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 58: Figure 70. Removing Hot-Swap Power Supply Module From Chassis
Figure 71. Loosing the Bracket with Power Distribution Board from Chassis 8. Push the bracket forward to release the latch which secure the bracket then pull out the bracket from the chassis (see letter “C”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 59: Figure 72. Removing The Bracket With Power Distribution Board From Chassis
10. Slide the new power distribution board to the bracket (see letter “E”) and secure the new power distribution board to the bracket using the same screws (see letter “F”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 60: Figure 74. Sliding The New Power Distribution Board In Bracket
Figure 75. Securing the New Power Distribution Board in Bracket 11. Slide the bracket with the new power distribution board all the way into the power supply cage (see letter “G”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 61: Figure 76. Sliding The Bracket Into Power Supply Cage
(see letter “H”). And then secure the bracket with the screws (see letter “I” and “J”). Figure 77. Secruing the Bracket into Power Supply Cage 13. Reconnect the power cables as appropriate. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 62: Installing And Removing The Server Board
3. Lift the airduct side wall to remove from the server board. 4. Remove the nine screws from the server board (see letter “A”). 5. Lift the server board from the server system (see letter “B”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 63: Installing The Server Board
2. Place the server board into the server system (see letter “A”). 3. Secure the server board with nine screws (see letter “B”). Figure 80. Installing the Server Board ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 64: Replacing A Fixed Fan
2 bracket and the fan with white connector should be installed in fan 1 bracket. The fan numbering is inscribed on the chassis. ® This procedure applies only to the Intel Server Chassis P4000M family with fixed fan configuration.
Page 65: Installing The Fixed Fan
Install the fixed fan in the corresponding fan bracket (see letter “B”). Figure 84. Installing the Fixed Fan 7. Connect fan power cable to the server/workstation board. See the Quick Start User’s Guide or Service Guide provided with your Intel server/workstation board for appropriate connection location. ®...
Page 66: Replacing A Hot-Swap Fan
Hardware Installations and Upgrades Replacing a Hot-swap Fan NOTE ® This procedure applies only to the Intel Server Chassis P4000M family with hot-swap fan configuration. Removing the Hot-swap Fan 1. Observe the safety and ESD precautions at the beginning of this book.
Page 67: Removing And Installing 8X3.5" Hot-Swap Hard Drive Cage Assembly
3. Remove the chassis cover. For instructions, see “Removing the Chassis Cover”. 4. Remove the front bezel if it is installed. For instructions, see “Removing the Front Bezel (Pedestal Only)”. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 68: Figure 88. Installing The 8X3.5" Hot-Swap Hard Drive Cage Assembly
C. Connect power cable (letter “C”). Figure 89. 8x3.5” Hot Swap Backplane Cable Connections 8. Install the front bezel. For instructions, see “Installing the Front Bezel (Pedestal Only)”. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 69: Removing And Installing 8X2.5" Hot-Swap Hard Drive Cage Assembly
1. Observe the safety and ESD precautions at the beginning of this book. 2. Power down the server and unplug all peripheral devices and the AC power cable. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 70: Figure 91. Installing The 8X2.5" Hot-Swap Hard Drive Cage Assembly
8. Install the airduct if the airduct is removed. For instructions, see “Installing the Airduct” 9. Install the chassis cover. For instructions, see “Installing the Chassis Cover”. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 71: Removing And Installing The Hot-Swap Hdd Emi Shiled
NOTE ® Server Chassis P4000M family with 8x2.5” hot-swap This procedure applies only to the Intel hard disk drive cage configuration. Removing the Hot-swap HDD EMI Shiled 1. Observe the safety and ESD precautions at the beginning of this book.
Page 72: Replacing The Backplane
C. Remove the screw as shown (see letter “A”); D. Slide the backplane (see letter “B”); E. Remove the backplane from the server chassis (see letter “C”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 73: Figure 96. Removing 3.5" Hard Drive Backplane - Remove The Backplane
D. Slide the backplane board to release it (see letter “B”); E. Remove the backplane board from the four hooks and pull out of the hard drive cage (see letter “C”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 74: Installing The Backplane
A. Align the backplane board with the hooks on the hard drive cage (see letter “A”); B. Slide the backplane into the drive cage (see letter “B”); C. Secure the backplane with screws (see letter “C”); ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 75: Figure 99. Installing 3.5" Hard Drive Backplane - Install The Backplane
B. Slide the backplane board in the direction shown to lock it in place (see letter “B”); C. Secure the backplane with the screw as shown (see letter “C”); ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 76: Removing And Installing The Top Cosmetic Cover
Observe the safety and ESD precautions at the beginning of this book. Slide the top cosmetic cover towards front panel direction until the latches on top cosmetic cover are released from the chassis. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 77: Installing The Top Cosmetic Cover
Removing the Chassis Feet 1. Observe the safety and ESD precautions at the beginning of this book. 2. Lay the chassis down on its right side. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 78: Installing The Chassis Feet (Pedestal Configuration Only)
Installing the Chassis Feet (Pedestal Configuration Only) NOTE ® Do not install feet on your Intel Server Chassis P4000M family if it is to be installed in a rack. Only install feet on a pedestal-configured chassis. 1. Observe the safety and ESD precautions at the beginning of this book.
Page 79: Removing And Installing The Front Panel Tray
CAUTION Do not slide the front panel out far from the front of the chassis before you disconnect the instruction cable from the front panel board. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 80: Installing The Fron Panel Tray
5. Remove the airduct if it is installed. 6. Attach the front panel cable and the chassis intrusion cable (see Letter “A”) to the front panel board. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 81: Figure 110. Connecting The Cables To The Front Panel Board
7. Slide the front panel tray in chassis Figure 111. Installing the Front Panel Tray in Chassis 8. Connect the front panel and USB cables to server board. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 82: Replacing The Front Panel Board
8. Attach the new front panel board in the front panel tray (see letter “A”) and secure the new front panel board with the screw (see letter “B”). ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 83: Installing Alternate Serial Port
Figure 116. Removing the Alternate Serial Port Knockout 5. Install the serial port on the rear panel of the chassis. And connect the cable to the Serial B Connector on your motherboard. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 84: Installing And/Or Removing A Expander Card
Hard Drives”, or “Remove 8x3.5 Hotswap Drive Cage Assemble”, or “Remove 8x2.5 Hotswap Drive Cage Assemble” 6. Locate the expander card bracket in the chassis. Mount the expander card to the bracket with screws. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 85: Removing The Expander Card
Hotswap Drive Cage Assemble” 6. Unplug all the cables connected to the expander card. 7. Remove the expander card from expander card bracket by releasing the securing screws. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 86: Figure 119. Removing The Expander Card
9. Install the fans. For instructions, see “Install the Fixed Fan” or “Install the Hot-swap Fans”. 10. Install the chassis cover. For instructions, see “Install the Chassis Cover”. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 87: Server Utilities
To enter the BIOS Setup using a keyboard (or emulated keyboard); press the <F2> function key ® during boot time when the OEM or Intel logo is displayed. The following message is displayed on the diagnostics screen and under the Quiet Boot logo screen: Press <F2>...
Page 88: Setup Screen Menu Selection Bar
The text shown in the Option Values and Help Text entries in each Field Description are the actual text and values are displayed on the BIOS Setup screens. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 89: Map Of Screens And Functionality
Advanced Screen (Tab)  Processor Configuration  Memory Configuration Memory RAS and Performance  Configuration Mass Storage Controller  Configuration  PCI Configuration  Serial Port Configuration ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 90 Add EFI Boot Option  Delete EFI Boot Option  Boot Manager Screen (Tab) Error Manager Screen (Tab) [Non-BMC Only] View Event Log Screen Exit Screen (Tab) ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 91: Main Screen (Tab)
Information only. Displays password level that setup is running in: Administrator or User. With no passwords set, Administrator is the default mode. Back to [Main Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 92 BIOS ID String, with the timestamp segment dropped off. The segments displayed are: Platform: Identifies that this is the correct platform BIOS 86B: Identifies this BIOS as being an Intel Server BIOS Major Revision level of the BIOS Release Revision level for this BIOS zzzz: Release Number for this BIOS...
Page 93 BIOS Recovery Flash Update, or other method, the date will be the earliest date in the allowed range – Saturday 01/01/2005. Back to [Main Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 94 BIOS Recovery Flash Update, or other method, the time will be the earliest time of day in the allowed range – 00:00:00 (although the time will be updated beginning from when it is reset early in POST). Back to [Main Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 95: Advanced Screen (Tab)
Comments: Selection only. Position to this line and press the <Enter> key to go to the Processor Configuration group of configuration settings. Back to [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 96 Selection only. Position to this line and press the <Enter> key to go to the Serial Port Configuration group of configuration settings. Back to [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 97: Processor Configuration
To access this screen from the Main screen, select Advanced > Processor Configuration. To move to another screen, press the <Esc> key to return to the Advanced screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 98: Figure 122. Processor Configuration Screen
DCU Data Prefetcher Enabled/Disabled DCU Instruction Prefetcher Enabled/Disabled Direct Cache Access (DCA) Enabled/Disabled Enhanced Error Containment Mode Enabled/Disabled SMM Wait Timeout [0 – 3000ms, 3 is default] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 99 Single socket boards have a single processor display, 2 sockets or 4 sockets boards have a display column for each socket, showing “N/A” for empty sockets where processors are not installed. Screen] — Back to [Processor Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 100 Single socket boards have a single processor display, 2 sockets or 4 sockets boards have a display line for each socket, showing “N/A” for empty sockets where processors are not installed. Screen] — Back to [Processor Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 101 Help Text: ® Allows for selecting the Intel QuickPath Interconnect Frequency. Recommended to ® leave in [Auto Max] so that BIOS can select the highest common Intel QuickPath Interconnect frequency. Comments: Lowering the QPI frequency may improve performance per watt for some processing loads and on certain benchmarks.
Page 102 Comments: When Disabled, the processor setting reverts to running at Max TDP Core Frequency (rated frequency). ® This option is only visible if all processors installed in the system support Enhanced Intel ® ® SpeedStep Technology. In order for the Intel Turbo Boost option to be available, Enhanced ®...
Page 103 Execute Disable Bit. The OS and applications installed must support this feature in order for it to be enabled. Screen] — Back to [Processor Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 104 Disabled Help Text: ® ® Enable/Disable Intel Virtualization Technology for Directed I/O (Intel VT-d). Report the I/O device assignment to VMM through DMAR ACPI Tables. Comments: This option is only visible if all processors installed in the system support ®...
Page 105 Option Values: Enabled Disabled Help Text: ® Enable/Disable Intel VT-d Coherency support. ® Comments: This option only appears when Intel Virtualization Technology for Directed I/O is Enabled. Screen] — Back to [Processor Configuration [Advanced Screen] 24. ATS Support Option Values:...
Page 106 Hardware Installations and Upgrades ® Comments: Intel TXT only appears when Intel Virtualization Technology is enabled. This option appears only on models equipped with a TPM. The TPM must be active in order to ® support Intel TXT. NOTE ®...
Page 107 Cache and Memory Channel use, but disabling it may improve performance for some processing loads and on certain benchmarks. Screen] — Back to [Processor Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 108: Memory Configuration
To access this screen from the Main screen, select Advanced > Memory Configuration. To move to another screen, press the <Esc> key to return to the Advanced screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 109: Figure 123. Memory Configuration Screen
Information only. Displays the amount of memory available in the system in the form of installed DDR3 DIMMs, in units of GB. Screen] — Back to [Memory Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 110 The supported memory speeds are 800 MT/s, 1066 MT/s, 1333 MT/s, and 1600 MT/s. The actual memory speed capability depends on the memory configuration. Screen] — Back to [Memory Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 111 When enabled, Demand Scrub automatically corrects a Correctable ECC Error encountered during a fetch from memory by writing back the corrected data to memory. Screen] — Back to [Memory Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 112 Selection only. Position to this line and press the <Enter> key to go to the Memory RAS and Performance Configuration group of configuration settings. Screen] — Back to [Memory Configuration [Advanced Screen]] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 113: Memory Ras And Performance Configuration
Performance Configuration. To move to another screen, press the <Esc> key to return to the Memory Configuration screen, if necessary press the <Esc> key again to return to the Advanced screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 114: Figure 124. Memory Ras And Performance Configuration Screen
(Mirroring Domain). Screen] — Back to [Memory RAS and Performance Configuration [Memory Configuration Screen] — [Advanced Screen] 2. Memory Rank Sparing Possible Option Values: Help Text: <None> ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 115 Memory Lockstep. For Memory Lockstep to be possible, DIMM configurations on all paired channels must be identical between the channel pair. Screen] — Back to [Memory RAS and Performance Configuration [Memory Configuration Screen] — [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 116 Screen] — Back to [Memory RAS and Performance Configuration [Memory Configuration Screen] — [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 117: Mass Storage Controller Configuration
Storage Control Unit (SCU) with SATA or SAS drive support and RAID support. There are also informational displays of AHCI and SCU controller configuration, and SATA Drive Information when ® applicable. If the presence of an Intel Storage Module is detected, the type of Storage Module is displayed as information-only.
Page 118 SCU controller, and whether they are configured for SATA or SAS. This information is also displayed during POST in the POST Diagnostic Screen. ® Various SATA/SAS Capable Controller configurations require the installation of Intel RAID C600 Upgrade Keys:...
Page 119 - Intel ESRT2 (Powered By LSI*): Supports RAID 0/1/10 and optional RAID 5 with ® Intel RAID C600 Upgrade Keys. Uses Intel ESRT2 drivers (based on LSI* MegaSR). ® - Intel RSTe: Provides pass-through drive support. Also provides host based RAID ®...
Page 120 ® Intel RSTe provides pass-through drive support and provides host based RAID 0/1/10 support, and RAID 5 (in SATA mode only). Uses Intel RSTe drivers in Windows, and MDRAID stack in ® Linux. The Intel RSTe RAID stack is required if it is necessary to provide pass-through support for non-RAID drives, or if support is needed for more than 8 drives.
Page 121: Pci Configuration
The PCI Configuration screen allows the user to configure the PCI memory space used for onboard and add-in adapters, configure video options, and configure onboard adapter options. It also includes a selection option to go to the NIC Configuration screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 122: Figure 126. Pci Configuration Screen
64-bit addressing is allocated to address space above 4GB, in order to allow larger allocations and avoid impacting address space below 4G. Screen] — Back to [PCI Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 123 NOTE This option does not appear on some models. Screen] — Back to [PCI Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 124: Nic Configuration
To move to another screen, press the <Esc> key to return to the PCI Configuration screen, if necessary press the <Esc> key again to return to the Advanced screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 125: Figure 127. Nic Configuration Screen
PXE 1GbE Option ROM is selected by Disabled. Back to [NIC Configuration Screen] — [PCI Screen] — Configuration [Advanced Screen] Enabled / Disabled ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 126 3. PXE 1GbE Option ROM Option Values: Enabled Disabled Help Text: Enable/Disable Onboard/IOM NIC PXE Option ROM Load. Screen] — Screen] — Back to [NIC Configuration [PCI Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 127 Address display will not appear when this option is disabled. This option will not appear when NIC<n> is disabled. Screen] — Screen] — Back to [NIC Configuration [PCI Configuration [Advanced Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 128: Serial Port Configuration
To access this screen from the Main screen, select Advanced > Serial Port Configuration. To move to another screen, press the <Esc> key to return to the Advanced screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 129: Figure 128. Serial Port Configuration Screen
Select Serial port A base I/O address. Comments: Legacy I/O port address. Back to [Serial Port Configuration] 3. IRQ Option Values: Help Text: Select Serial port A interrupt request (IRQ) line. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 130: Usb Configuration
Each USB Mass Storage device may be set to allow the media emulation for which it is formatted, or an emulation may be specified. For USB Flash Memory devices in particular, there are some restrictions: ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 131: Figure 129. Usb Configuration Screen
Help Text: <None> Comments: Information only. Displays the total number of USB devices of all types which have been detected in POST. Back to [USB Configuration] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 132 Exclude USB in Boot Table. [Enabled]- This will remove all USB Mass Storage devices as Boot options. [Disabled] - This will allow all USB Mass Storage devices as Boot options. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 133: System Acoustic And Performance Configuration
To access this screen from the Main screen, select Advanced > System Acoustic and Performance Configuration. To move to another screen, press the <Esc> key to return to the Advanced screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 134: Figure 130. System Acoustic And Performance Configuration
 DCLTT is the expected mode for a board in an Intel chassis with inlet and outlet air temperature sensors and TSOD. The firmware can update the offset registers for closed loop during runtime, as BIOS sends the dynamic CLTT offset temperature data.
Page 135 This is a percentage by which the calculated fan speed will be increased. The user can apply positive offsets that result in increasing the minimum fan speeds. Back to [System Acoustic and Performance Configuration] 5．Quiet Fan Idle Mode ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 136: Security Screen (Tab)
Trusted Platform Module (TPM) security settings on those boards that support TPM. ® Note that it is necessary to activate the TPM in order be able to enable Intel Trusted Execution Technology (TXT) on boards that support it. Changing the TPM state in Setup will require a Hard Reset ®...
Page 137: Figure 131. Security Screen
Setup options, including setting the Administrator and User passwords. When Power On Password protection is enabled, the Administrator password may be used to allow the BIOS to complete POST and boot the system. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 138 The password format and entry rules and popup error and warning message are the same for the User password as for the Administrator password (see above). Back to [Security Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 139 NMI Diagnostic Interrupt is not available. Comments: This option does not appear on all boards. Back to [Security Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 140: Server Management Screen (Tab)
The Server Management screen allows the user to configure several server management features. This screen also provides an access point to the screens for configuring Console Redirection, displaying system information, and controlling the BMC LAN configuration. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 141 To access this screen from the Main screen or other top-level “Tab” screen, press the right or left arrow keys to traverse the tabs at the top of the Setup screen until the Server Management screen is selected. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 142: Figure 132. Server Management Screen
Note: This option is noly active if the Assert NMI on SERR OPTION HAS [Enabled] selected. Back to [Server Management Screen] 2. PCIe AER Support Option Values: Enabled ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 143 ► BMC LAN Configuration Screen Field Descriptions: 3. Assert NMI on SERR Option Values: Enabled Disabled Help Text: On SERR, generate an NMI and log an error. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 144 “Catastrophic Error” CATERR# signal is held asserted, rather than just pulsed to generate an SMI. This indicates that the processor has encountered a fatal hardware error. Back to [Server Management Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 145 This option is active only when the Resume on AC Power Loss is selected as Power On. Back to [Server Management Screen] 8. Clear System Event Log ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 146 BIOS programs the watchdog timer with the timeout value selected, If the OS does not complete booting before the time expires, the BMC will reset the system and an error will be logged. Requires OS support or Intel Management Software Support. Back to...
Page 147: Console Redirection
To access this screen from the Main screen, select Server Management > Console Redirection. To move to another screen, press the <Esc> key to return to the Server Management screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 148: System Information
To access this screen from the Main screen, select Server Management > System Information. To move to another screen, press the <Esc> key to return to the Server Management screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 149: Bmc Lan Configuration
To access this screen from the Main screen, select Server Management > System Information. To move to another screen, press the <Esc> key to return to the Server Management screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 150: Figure 135. Bmc Lan Configuration Screen
[0.0.0.0 IP display/edit] Subnet Mask [0.0.0.0 IP display/edit] Gateway IP [0.0.0.0 IP display/edit] Baseboard LAN IPV6 configuration IPV6 Enable/Disabled Intel (R) RMM4 IPV4 LAN configuration Intel (R) RMM4 <Present/Not Present> IP Source Static/Dynamic IP Address [0.0.0.0 IP display/edit] Subnet Mask [0.0.0.0 IP display/edit]...
Page 151 This specifies the IPv4 addressing Subnet Mask for the Baseboard LAN. ® There is a separate IPv4 Subnet Mask field for the Intel RMM4 LAN configuration. When IPv4 addressing is used, the initial value for this field is acquired from the BMC. The setting of IP Source determines whether this field is display-only (when Dynamic) or can be edited (when Static).
Page 152 This specifies the IP Source for IPv6 addressing for the Baseboard LAN ® configuration. There is a separate IPv6 Source field for the Intel RMM4 LAN configuration. This option is only visible when the IPv6 option is set to Enabled.
Page 153 Comments: This specifies the Gateway IPv6 Address for the Baseboard LAN. There ® is a separate Gateway IPv6 Address field for the Intel RMM4 LAN configuration. This option is only visible when the IPv6 option is set to Enabled. When IPv6 addressing is used, the initial value for this field is acquired from the BMC. The setting of IPv6 Source determines whether this field is display-only (when Dynamic or Auto) or can be edited (when Static).
Page 154 IP address is acquired automatically (DHCP). ® Comments: This specifies the IP Source for IPv4 addressing for the Intel RMM4 DMN LAN connection. There is a separate IP Source field for the Baseboard LAN configuration. When IPv4 addressing is used, the initial value for this field is acquired from the BMC, and its ®...
Page 155 View/Edit Subnet Mask. Press <Enter> to edit. ® Comments: This specifies the IPv4 addressing Subnet Mask for the Intel RMM4 DMN LAN. There is a separate IPv4 Subnet Mask field for the Baseboard LAN configuration. When IPv4 addressing is used, the initial value for this field is acquired from the BMC. The setting of IP Source determines whether this field is display-only (when Dynamic) or can be edited (when Static).
Page 156 Hardware Installations and Upgrades ® Comments: This specifies the IP Source for IPv6 addressing for the Intel RMM4 DMN LAN configuration. There is a separate IPv6 Source field for the Baseboard LAN configuration. This option is only visible when the IPv6 option is set to Enabled.
Page 157 Hardware Installations and Upgrades ® Comments: This specifies the IPv6 Prefix Length for the Intel RMM4 DMN LAN. There is a separate IPv6 Prefix Length field for the Baseboard LAN configuration. This option is only visible when the IPv6 option is set to Enabled.
Page 158 User Name can only be edited for users other than “anonymous” and Comments: “root”. Those two User Names may not be changed. Back to [BMC LAN Configuration] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 159: Boot Options Screen (Tab)
CDROM Drive, it will not be detected as such. It will be treated as a Hard Disk and will appear in the list of available Hard Drives. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 160: Figure 136. Boot Options Screen
After entering the desired timeout, press the <Enter> key to register that timeout value to the system. These settings are in seconds. The timeout value entered will take effect on the next boot. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 161 This option appears when one or more bootable CDROM drives are available in the system. This includes USB CDROM devices, but not USB Keys formatted for CRDOM emulation, which are seen as Hard Disk drives. Back to [Boot Options Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 162 Selection only. Position to this line and press the <Enter> key to go to the BEV Device Order Screen. This option appears when one or more bootable BEV Devices are available in the system. Back to [Boot Options Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 163 If enabled, the BIOS uses the legacy video ROM instead of the EFI video ROM. Comments: This option appears only when EFI Optimized Boot is enabled. Back to [Boot Options Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 164 When the option changes from “Enabled” to “Disabled”, this will disable SBO and the SBO template will be cleared. Otherwise it will retain the current Enabled/Disabled state. Back to [Boot Options Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 165: Cdrom Order
To access this screen from the Main screen, select Boot Options > CDROM Order. To move to another screen, press the <Esc> key to return to the Boot Options screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 166: Hard Disk Order
To access this screen from the Main screen, select Boot Options > Hard Disk Order. To move to another screen, press the <Esc> key to return to the Boot Options screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 167: Floppy Order
To access this screen from the Main screen, select Boot Options > Floppy Order. To move to another screen, press the <Esc> key to return to the Boot Options screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 168: Network Device Order
To access this screen from the Main screen, select Boot Options > Network Device Order. To move to another screen, press the <Esc> key to return to the Boot Options screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 169: Bev Device Order
To access this screen from the Main screen, select Boot Options > BEV Device Order. To move to another screen, press the <Esc> key to return to the Boot Options screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 170: Add Efi Boot Option
To access this screen from the Main screen, select Boot Options > Add EFI Boot Option. To move to another screen, press the <Esc> key to return to the Boot Options screen, then select the desired screen. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 171: Figure 142. Add Efi Boot Option Screen
This will be the Boot Path, residing on the filesystem chosen, which will entered into the Boot Order with the Label entered above. Screen] — Back to [Add EFI Boot Option [Boot Options Screen] ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 172: Delete Efi Boot Option
To access this screen from the Main screen or other top-level “Tab” screen, press the right or left arrow keys to traverse the tabs at the top of the Setup screen until the Boot Manager screen is selected. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 173: Error Manager Screen (Tab)
To access this screen from the Main screen or other top-level “Tab” screen, press the right or left arrow keys to traverse the tabs at the top of the Setup screen until the Exit screen is selected. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 174: Figure 146. Exit Screen
Discard Changes Load Default Values Save as User Default Values Load User Default Values *Certain brands and names may be claimed as the property of others. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 175: Appendix A: Technical Reference
19 A 30 A 16 A 30 A +12V1,2 29 A 36 A +12V3 (240VA limited) 18.5 A 20 A -12V No damage 5Vstby No damage ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 176: 750-W Redundant Power Supply Input/Output Voltages
This requirement is not to be used for determining agency input current markings. 750-W Redundant Power Supply Input Voltage Table 8. Over Voltage Protection (OVP) Limits Output voltage Min (v) Max (v) ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 177: System Environmental Specifications
Non-palletized free fall in height 24 inches (≧40 lbs to < 80 lbs) Vibration, unpackaged 5 Hz to 500 Hz, 2.20 g RMS random ® +/-15 KV except I/O port +/- 8 KV per Intel Environmental test specification 460 Watt Max – 1570 BTU/hour System Cooling Requirement in BTU/Hr 750 Watt Max –...
Page 178: Appendix B: Regulatory And Compliance Information
Appendix B: Regulatory and Compliance Information Please refer to the Server Products Regulatory and Safety document for the product regulatory compliance reference. The document can be downloaded from http://www.intel.com/support/motherboards/server/. ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 179: Appendix C: Led Decoder
The diagnostic LED #7 is labeled as “MSB”, and the diagnostic LED #0 is labeled as “LSB”. System Status LED System Identification LED LSB 123456 MSB POST Code Diagnostic LEDs Figure 147. Diagnostic LED Placement Diagram ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 180: Table 11. Post Progress Code Led Example
PEI Phase PEI Core CPU PEIM NB PEIM SB PEIM MRC Process Codes – MRC Progress Code Sequence is executed - See Table 63 PEI Phase continued… ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 181 DXE PCI Bus enumeration DXE PCI Bus resource requested DXE PCI Bus assign resource DXE CON_OUT connect DXE CON_IN connect DXE SIO Init DXE USB start ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 182 INT19 S3 Resume S3 Resume PEIM (S3 started) S3 Resume PEIM (S3 boot script) S3 Resume PEIM (S3 Video Repost) S3 Resume PEIM (S3 OS wake) ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 183 BIOS Recovery PEIM which detected forced Recovery condition PEIM which detected User Recovery condition Recovery PEIM (Recovery started) Recovery PEIM (Capsule found) Recovery PEIM (Capsule loaded) ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 184: Appendix D: Getting Help
 A searchable knowledgebase to search for product information throughout the su.pport site. If you are still unable to obtain a solution to your issue, send an email to Intel’s technical support center using the online form available at http://www.intel.com/support/feedback.htm?group=server.
Page 185: Appendix E: Intel Server Issue Report Form
Has the latest IMM BMC been tried? (Yes/No): Has the latest RMM Firmware been tried? (Yes/No): Has the latest FRU/SDR been tried? (Yes/No): Has the latest HSC been tried? (Yes/No): ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 186 Adapters, RAID Controllers, SCSI Controllers, and so on): Type Slot Manufacturer Model Firmware Other third part hardware (Example: Example: KVM, Chassis, and so on): Description/Use Manufacturer Model Firmware ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 187 RAID volumes configuration (disks & RAID level): RAID volume use (Boot device/Data Volume): Is BBU (Battery Backup Unit) installed? (Yes/No): BBU part number: Detailed description of issue: ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 188 ® Appendix E: Intel Server Issue Report Form Troubleshooting tried: Steps to replicate the issue: ® ® Intel Server Board S2600CP Family Intel Server System P4000CP Family Service Guide...
Page 189 Server Issue Report Form Issue impact statements: Do you have any potential Intel system, or component purchases that this issue is holding up? If yes, please provide a brief description below. Do you have systems already purchased that are not being delivered to your customers because of this issue? If yes, please provide a brief description below.

This manual is also suitable for:

P4000cp

Intel S2600CP Service Manual

Safety Information

Preface

Server System Features

Hardware Installations and Upgrades

Server Utilities

Appendix A: Technical Reference

Quick Links

Related Manuals for Intel S2600CP

Summary of Contents for Intel S2600CP

This manual is also suitable for:

Table of Contents
