  • Page 1 2015 G R A N D C A R A V A N USER GUIDE...
  • Page 2 I M P O R T A N T T hi s Us e r G u id e i s in ten de d to familiarize you with the i mportant fe ature s o f yo u r v eh ic l e. T he D VD e nc lo s e d contains your Own er’s Manual , N a vi g a t i on / U c on ne ct Ma nuals , Warranty B ooklets, Tire Warranty and ®...

  • Page 3: Table Of Contents

    T A B L E O F C O N T E N T S INTRODUCTION/WELCOME UNIVERSAL GARAGE DOOR OPENER (HomeLink ® ....72 WELCOME FROM FCA US LLC .

  • Page 4: Introduction/Welcome

    I N T R O D U C T I O N / W E L C O M E WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC (“FCA US”) vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles.
  • Page 5 If your symptoms persist, please see an authorized dealer. When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained technicians and genuine MOPAR parts, and cares about your ® satisfaction. DODGE is a registered trademark of FCA US LLC.

  • Page 6: Controls At A Glance

    C O N T R O L S A T A G L A N C E DRIVER COCKPIT 1. Headlight Switch pg. 33 2. Electronic Vehicle Information Center (EVIC) Controls pg. 70 3. Turn Signal/Wiper/Washer/High Beams Lever (behind steering wheel) pg. 31 4.
  • Page 7 C O N T R O L S A T A G L A N C E 11. Glove Compartment 12. Switch Panel • ParkSense ® pg. 38 • ECO On pg. 35 • Electronic Stability Control (ESC) OFF pg. 81 13.

  • Page 8: Instrument Cluster

    C O N T R O L S A T A G L A N C E INSTRUMENT CLUSTER 1. Tachometer 2. Temperature Gauge 3. Electronic Vehicle Information Center (EVIC) (See page 77 for more Instrument Cluster Warning Light information.)
  • Page 9 C O N T R O L S A T A G L A N C E 4. Speedometer 5. Fuel Gauge 6. Fuel Filler Door Location (See page 81 for more Instrument Cluster Indicator Light information.)

  • Page 10: Getting Started

    G E T T I N G S T A R T E D KEY FOB Locking And Unlocking The Doors And Liftgate Lock The Doors And Liftgate Push and release the LOCK button on the RKE transmitter to lock all doors and liftgate. The turn signal lights will flash, and the horn will chirp to acknowledge the signal.

  • Page 11: Remote Start

    G E T T I N G S T A R T E D Emergency Key Should the battery in the vehicle or the Key Fob transmitter go dead, there is an emergency key located in the Key Fob that can be used for locking and unlocking the doors. •...

  • Page 12: Keyless Enter-N-Go

    G E T T I N G S T A R T E D KEYLESS ENTER-N-GO™ The Keyless Enter-N-Go™ system is an enhancement to the vehicle’s Remote Keyless Entry (RKE) feature. This feature allows you to lock and unlock the vehicle's door(s) and liftgate without having to push the Key Fob LOCK or UNLOCK buttons, as well as starting and stopping the vehicle with the push of a button.
  • Page 13 G E T T I N G S T A R T E D NOTE: • If “Unlock All Doors 1st Press” is programmed, all doors will unlock when you grab hold of the front driver's door handle. To select between “Unlock Driver Door 1st Press” and “Unlock All Doors 1st Press,”...
  • Page 14 G E T T I N G S T A R T E D Installing And Removing The ENGINE START/STOP Button Installing The Button • Remove the Key Fob from the ignition switch. • Insert the ENGINE START/STOP button into the ignition switch with the lettering facing up and readable.

  • Page 15: Vehicle Security Alarm

    G E T T I N G S T A R T E D Accessory Positions With Engine Off NOTE: The following functions are with the driver’s foot off of the Brake Pedal (transmission in PARK or NEUTRAL). Beginning With The Ignition Switch In The OFF Position: 1.

  • Page 16: Seat Belt Systems

    G E T T I N G S T A R T E D To Disarm The System: Push the Key Fob UNLOCK button or cycle the ignition to the ON/RUN position. The Vehicle Security Alarm is designed to protect your vehicle. However, you can create conditions where the Vehicle Security Alarm will give you a false alarm.

  • Page 17: Supplemental Restraint System (Srs) - Air Bags

    G E T T I N G S T A R T E D WARNING! • In a collision, you and your passengers can suffer much greater injuries if you are not properly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle.
  • Page 18 G E T T I N G S T A R T E D Advanced Front Air Bags • This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems. The Advanced Front Air Bags will not deploy in every type of collision.
  • Page 19 G E T T I N G S T A R T E D • After any collision, the vehicle should be taken to an authorized dealer immediately. • Do not drive your vehicle after the air bags have deployed. If you are involved in another collision, the air bags will not be in place to protect you.

  • Page 20: Child Restraints

    G E T T I N G S T A R T E D WARNING! • Side Air Bags need room to inflate. Do not lean against the door or window. Sit upright in the center of the seat. • Being too close to the Side Air Bags during deployment could cause you to be severely injured or killed.
  • Page 21 G E T T I N G S T A R T E D LATCH System Weight Limit You may use the LATCH anchorage system until the combined weight of the child and the child restraint is 65 lbs (29.5 kg). Use the seat belt and tether anchor instead of the LATCH system once the combined weight is more than 65 lbs (29.5 kg).
  • Page 22 G E T T I N G S T A R T E D Installing The Child Restraint Using The LATCH Lower Anchors NOTE: Never “share” a LATCH anchorage with two or more child restraints. 1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so that you can more easily attach the hooks or connectors to the vehicle anchorages.
  • Page 23 G E T T I N G S T A R T E D 7. If the child restraint has a top tether strap and the seating position has a top tether anchorage, connect the tether strap to the anchorage and tighten the tether strap. See below for directions to attach a tether anchor.
  • Page 24 G E T T I N G S T A R T E D Tether Strap Installation 1. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. 2. If your vehicle is equipped with adjustable rear head restraints, raise the head restraint, and where possible, route the tether strap under the head restraint and between the two posts.

  • Page 25: Head Restraints

    G E T T I N G S T A R T E D WARNING! • In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are.
  • Page 26 G E T T I N G S T A R T E D To raise the head restraint, pull upward on the head restraint. To lower the head restraint, push the adjustment button, located at the base of the head restraint, and push downward on the head restraint.

  • Page 27: Front Seats

    G E T T I N G S T A R T E D FRONT SEATS Power Seat The power seat switch controls forward/back, up/down, and tilt adjustment. The recline switch, located on the outboard side of the seat, controls seatback adjustment. Power Lumbar •...
  • Page 28 G E T T I N G S T A R T E D NOTE: Before programming your RKE transmitters you must select the select “RKE Linked to Memory” in the Electronic Vehicle Information Center (EVIC). Refer to “Programmable Features” in “Electronics” for further information. To program a Key Fob to the memory position: 1.

  • Page 29: Heated Seats

    G E T T I N G S T A R T E D HEATED SEATS Front Heated Seats The controls for front heated seats are lo- cated on the center instrument panel area. • Push the switch once to select HI-level heating.

  • Page 30: Heated Steering Wheel

    G E T T I N G S T A R T E D WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical conditions must exercise care when using the seat heater.

  • Page 31: Tilt/Telescoping Steering Column

    G E T T I N G S T A R T E D TILT/TELESCOPING STEERING COLUMN The tilt steering column tilt lever is located below the steering wheel. • Push down on the tilt lever to unlock the steering column. •...

  • Page 32: Operating Your Vehicle

    O P E R A T I N G Y O U R V E H I C L E ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km).

  • Page 33: Turn Signal/Wiper/Washer/High Beam Lever

    O P E R A T I N G Y O U R V E H I C L E TURN SIGNAL/WIPER/WASHER/HIGH BEAM LEVER Multifunction Lever 1 — Mist (Push To First Detent) 2 — Rear Wiper/Washer 3 — Push Lever For High Beams 4 —...
  • Page 34 O P E R A T I N G Y O U R V E H I C L E Mist • Push the end of the lever inward to the first detent when a single wipe is desired. NOTE: The mist feature does not activate the washer pump;...

  • Page 35: Headlight Switch And Halo Light Switch

    O P E R A T I N G Y O U R V E H I C L E HEADLIGHT SWITCH AND HALO LIGHT SWITCH Automatic Headlights/Parking Lights/Headlights • Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent for parking lights and to the second...

  • Page 36: Electronic Range Select (Ers)

    O P E R A T I N G Y O U R V E H I C L E ELECTRONIC RANGE SELECT (ERS) Electronic Range Select (ERS) allows you to limit the highest available transmission gear, and can be activated during any driving condition. When towing a trailer or operating the vehicle in off-road conditions, using ERS shift control will help you maximize both performance and engine braking.

  • Page 37: Fuel Economy (Econ) Mode

    O P E R A T I N G Y O U R V E H I C L E FUEL ECONOMY (ECON) MODE The Fuel Economy (ECON) mode can improve the vehicle’s overall fuel economy during normal driving conditions. •...

  • Page 38: Three Zone Automatic Temperature Controls (Atc)

    O P E R A T I N G Y O U R V E H I C L E THREE ZONE AUTOMATIC TEMPERATURE CONTROLS (ATC) Three Zone Automatic Temperature Controls (ATC) 1 — Push Driver Temp. Control Up 9 — Push Passenger Temp. Control 2 —...
  • Page 39 O P E R A T I N G Y O U R V E H I C L E Air Recirculation • Use Recirculation for maximum A/C operation. • For window defogging, turn the Recirculation button off. • If the Recirculation button is pressed when the system is in Defrost mode the Recirculation LED indicator will flash three times to indicate Recirculation mode is not allowed.

  • Page 40: Parksense® Rear Park Assist

    O P E R A T I N G Y O U R V E H I C L E PARKSENSE® REAR PARK ASSIST If an object is detected behind the rear bumper while the vehicle is in REVERSE, a warning will display in the instrument cluster and a tone will sound, (closer the object the faster the tone) that changes speed depending on the distance of the object from the bumper, will sound.

  • Page 41: Blind Spot Monitoring With Rear Cross Path

    O P E R A T I N G Y O U R V E H I C L E BLIND SPOT MONITORING WITH REAR CROSS PATH The Blind Spot Monitoring (BSM) system uses two radar-based sensors, located inside the rear bumper fascia, to detect Highway licensable vehicles (automobiles, trucks, motor- cycles etc.) that enter the blind spot zones from the rear/front/side of the vehicle.

  • Page 42: Electronics

    E L E C T R O N I C S YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect ® Voice Command Button pg. 65 2. Uconnect ® Phone Button pg. 62 3. Steering Wheel Audio Controls (Left) pg. 61 4. Steering Wheel Audio Controls (Right) pg. 61...
  • Page 43 E L E C T R O N I C S 5. USB port pg. 51 6. Audio Jack pg. 51 7. USB Port (inside upper glove box) pg. 61...

  • Page 44: Uconnect ® 130

    E L E C T R O N I C S Uconnect® 130 Uconnect® 130 1 — CD Eject Button 9 — Set Clock Button 2 — Seek Down Button 10 — Audio Settings/Rotate To Tune 3 — Seek Up Button 11 —...
  • Page 45 E L E C T R O N I C S 5. Push the TUNE/SCROLL control knob to save the changes. 6. Push any button/knob or wait five seconds to exit. Equalizer, Balance And Fade 1. Push the TUNE/SCROLL control knob and “BASS” will display. 2.

  • Page 46: Satellite Radio

    E L E C T R O N I C S Uconnect® 130 WITH SiriusXM SATELLITE RADIO Uconnect® 130 With SiriusXM Satellite Radio 1 — CD Eject Button 12 — Audio Jack 2 — Seek Down Button 13 — Set Preset/CD Random Play 3 —...
  • Page 47 E L E C T R O N I C S Clock Setting 1. Push and hold the TIME button until the hours blink. 2. Turn the TUNE/SCROLL control knob to set the hours. 3. Push the TUNE/SCROLL control knob until the minutes begin to blink. 4.
  • Page 48 E L E C T R O N I C S SiriusXM Satellite Radio SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 to cancel.

  • Page 49: Uconnect® 430/430N

    E L E C T R O N I C S Uconnect® 430/430N Uconnect® 430/430N 1 — Voice Command Button 7 — Audio Jack 2 — Open/Close Display 8 — Radio Sales Code 3 — Menu Button 9 — ON/OFF/Rotate For Volume 4 —...
  • Page 50 E L E C T R O N I C S 4. To adjust the minutes, press either the “Minute Forward” or “Minute Backward” button on the touchscreen. 5. To save the new time setting, press the screen where the word “Save” is displayed. Menu •...
  • Page 51 E L E C T R O N I C S Radio Operation Radio Operation 1 — Radio Tuner Tabs 6 — Station Scan 2 — Individual Presets 7 — Seek Down 3 — Search/Browse 8 — Direct Tune 4 — Radio Station/Track Info 9 —...
  • Page 52 E L E C T R O N I C S • Once the desired station is found, press and hold one of the “PRESETS” buttons on the touchscreen in the list to the right, until the preset key flashes and the station text on the button on the touchscreen changes.
  • Page 53 E L E C T R O N I C S Insert A CD/DVD Disc • To insert a disc, push the LOAD button on the faceplate. • With the printed side upwards, insert the disc into the disc slot of the radio. The radio pulls the disc in automatically and closes the flip screen.
  • Page 54 E L E C T R O N I C S Copying Music From CD • Push the LOAD button on the faceplate. • Insert a disc, then push the MY FILES button on the faceplate. Select the “MY MUSIC” button on the touchscreen.
  • Page 55 E L E C T R O N I C S • Press the desired pictures or press the “All” button on the touchscreen for all pictures. Confirm your selections by pressing the “SAVE” button on the touchscreen. NOTE: The copy progress is shown in the lower left corner of the screen.
  • Page 56 E L E C T R O N I C S Cleaning Your Touchscreen Radio • If necessary, use a dry micro fiber lens cleaning cloth dampened with a cleaning solution such as isopropyl alcohol or an isopropyl alcohol and water solution ratio of 50:50.
  • Page 57 E L E C T R O N I C S Main Navigation Menu Finding Points Of Interest • From the main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Points of Interest” button on the touchscreen. •...
  • Page 58 E L E C T R O N I C S Following Your Route Your route is marked with a magenta line on the map. If you depart from the original route, your route is recalculated. A speed limit icon could appear as you travel on major roadways. Following Your Route 1 —...

  • Page 59: Siriusxm Satellite Radio/Travel Link

    E L E C T R O N I C S Taking A Detour To take a detour you must be navigating a route. • Press the “back arrow” icon button on the touchscreen multiple times to return to the Main Navigation menu.
  • Page 60 E L E C T R O N I C S Search/Browse • Press the “magnifying glass” button on the touchscreen to search/browse the SiriusXM channel listing by Favorites and Categories such as Song, Artist and Channel Name. The Search/Browse also allows you to manage your Favorites. SAT Browse SiriusXM™...
  • Page 61 E L E C T R O N I C S Display SAT Favorites List • Press the “Search/Browse” button on the touchscreen and select “Favorites” from the SAT Browse screen. • Press the desired favorites button on the touchscreen to switch the SAT tuner to the corresponding channel.
  • Page 62 E L E C T R O N I C S SiriusXM Travel Link (Uconnect® 430N Only) • SiriusXM Travel Link brings a wealth of useful information into your vehicle and right to your fingertips. • To access Travel Link, push the MENU button on the faceplate, then the “Travel Link” button on the touchscreen.

  • Page 63: Steering Wheel Audio Controls

    E L E C T R O N I C S STEERING WHEEL AUDIO CONTROLS The steering wheel audio controls are located on the rear surface of the steering wheel. Right Switch • Push the switch up or down to increase or decrease the volume.

  • Page 64: Uconnect® Phone

    E L E C T R O N I C S Touchscreen Radios: To hear audio from devices connected to the USB port, Push the “MEDIA” button on the faceplate, then press the “AUX” or “iPod ® ” button on the touchscreen.
  • Page 65 E L E C T R O N I C S NOTE: The Uconnect Phone requires a mobile phone equipped with the Bluetooth ® ® Hands-Free Profile, Version 1.0 or higher. For Uconnect ® Customer Support: U.S. resi- dents - visit UconnectPhone.com or call 1-877-855-8400. Canadian residents - visit UconnectPhone.com or call, 1-800-465-2001 (English) or 1-800-387-9983 (French).
  • Page 66 E L E C T R O N I C S Phonebook Phonebook Download — Automatic Phonebook Transfer From Mobile Phone If equipped and specifically supported by your phone, Uconnect Phone automatically ® downloads names (text names) and number entries from your mobile phone’s phonebook. Specific Bluetooth ®...

  • Page 67: Uconnect® Voice Command

    E L E C T R O N I C S Transfer Ongoing Call Between Handset And Vehicle • During a call, push the “Voice Command” button • After the BEEP, say “transfer call.” Changing The Volume • Start a dialogue by pushing the “Phone” button , then adjust the volume during a normal call.
  • Page 68 E L E C T R O N I C S • Start a dialogue by pushing the “Voice Command” button , you will hear a beep. The beep is your signal to give a command. Below are a list of voice commands for each of the different modes.
  • Page 69 E L E C T R O N I C S While In: Voice Command Example: To switch to the voice recorder mode, say “Memo.” The follow- ing are common voice commands for this mode: “New Memo” (to record a new memo) — During the recording, you may push the Voice Command button to stop recording.

  • Page 70: Bluetooth® Streaming Audio

    E L E C T R O N I C S Bluetooth® STREAMING AUDIO If equipped with Uconnect Voice Command, your Bluetooth -equipped iPod devices, ® ® ® cell phones or other media players, may also be able to stream music to your vehicles speakers.
  • Page 71 E L E C T R O N I C S Operation Of The Touchscreen Radio/DVD Player/Blu-Ray® Player To view a DVD/Blu-ray, push the OPEN/CLOSE or LOAD button on the faceplate and insert the disc or insert the disc into the optional DVD/Blu-ray player. Playback will begin automatically after the DVD/Blu-ray is recognized by the disc drive.

  • Page 72: Electronic Vehicle Information Center (Evic)

    E L E C T R O N I C S ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) The EVIC features a driver interactive display that is located in the instrument cluster. Pushing the controls on the left side of the steering wheel allows the driver to select vehicle information and Personal Settings.
  • Page 73 E L E C T R O N I C S • Auto Unlock Doors • Flashers with Sliding Door • Remote Unlock Sequence • Calibrate Compass • Remote Start Comfort Sys. • Compass Variance • Horn with Remote Lock •...

  • Page 74: Universal Garage Door Opener (Homelink®)

    E L E C T R O N I C S UNIVERSAL GARAGE DOOR OPENER (HomeLink®) HomeLink replaces up to three hand-held transmitters that operate devices such as ® garage door openers, motorized gates, lighting or home security systems. The HomeLink ®...
  • Page 75 E L E C T R O N I C S 3. Push and hold the HomeLink ® button you want to program while you push and hold the hand-held transmitter button. 4. Continue to hold both buttons and observe the indicator light. The HomeLink ®...
  • Page 76 E L E C T R O N I C S Using HomeLink® To operate, push and release the programmed HomeLink ® button. Activation will now occur for the programmed device (e.g., garage door opener, gate operator, security system, entry door lock, home/office lighting, etc.). The hand-held transmitter of the device may also be used at any time.

  • Page 77: Utility

    U T I L I T Y...

  • Page 78: Recreational Towing (Behind Motorhome, Etc.)

    U T I L I T Y RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing Condition Wheels OFF the Ground All Models NOT ALLOWED Flat Tow NONE Front Dolly Tow Rear NOT ALLOWED On Trailer Recreational Towing — All Models Recreational towing is allowed ONLY if the front wheels are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer.

  • Page 79: What To Do In Emergencies

    W H A T T O D O I N E M E R G E N C I E S ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling.
  • Page 80 W H A T T O D O I N E M E R G E N C I E S – Electronic Throttle Control (ETC) Indicator Light This light informs you of a problem with the system. If a problem is detected, the light will come on while the engine is running. Cycle the ignition when the vehicle has completely stopped and the shift lever is placed in the PARK position;...
  • Page 81 W H A T T O D O I N E M E R G E N C I E S TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly.
  • Page 82 W H A T T O D O I N E M E R G E N C I E S – Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on, it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the anti-lock brake system reservoir.

  • Page 83: Instrument Cluster Indicator Lights

    W H A T T O D O I N E M E R G E N C I E S – Malfunction Indicator Light (MIL) Certain conditions, such as a loose or missing gas cap, poor fuel quality, etc., may illuminate the MIL after engine start.
  • Page 84 W H A T T O D O I N E M E R G E N C I E S – Electronic Speed Control ON Indicator This indicator will illuminate when the electronic speed control has been activated to the “ON”...

  • Page 85: If Your Engine Overheats

    W H A T T O D O I N E M E R G E N C I E S Vehicles Not Equipped With Keyless Enter-N-Go™ 1. Turn the ignition switch to the ON/RUN position (do not start the engine). 2.

  • Page 86: Tire Service Kit

    W H A T T O D O I N E M E R G E N C I E S TIRE SERVICE KIT Your vehicle may be equipped with a Tire Service Kit. Small punctures up to 1/4” (6 mm) in the tire tread can be sealed with the Tire Service Kit. Foreign objects (e.g., screws or nails) should not be removed from the tire.
  • Page 87 W H A T T O D O I N E M E R G E N C I E S Tire Service Kit Usage Precautions • Replace the Tire Service Kit Sealant Bottle (1) and Sealant Hose (6) prior to the expiration date (printed on the bottle label) to assure optimum operation of the system.
  • Page 88 W H A T T O D O I N E M E R G E N C I E S 5. Uncoil the Power Plug (8) and insert the plug into the vehicle’s 12 Volt power outlet. 6. Do not remove foreign objects (e.g., screws or nails) from the tire. (C) Injecting Tire Service Kit Sealant Into The Deflated Tire: Always start the engine before turning ON the Tire Service Kit.
  • Page 89 W H A T T O D O I N E M E R G E N C I E S NOTE: If the tire becomes over-inflated, push the Deflation Button to reduce the tire pressure to the recommended inflation pressure before continuing. If the tire inflates to the recommended pressure or is at least 26 psi (1.8 Bar) pressure within 15 minutes: 1.
  • Page 90 W H A T T O D O I N E M E R G E N C I E S NOTE: • If the tire becomes over-inflated, push the Deflation Button to reduce the tire pressure to the recommended inflation pressure before continuing. •...
  • Page 91 W H A T T O D O I N E M E R G E N C I E S WARNING! • Do not attempt to seal a tire on the side of the vehicle closest to traffic. Pull far enough off the road to avoid the danger of being hit when using the Tire Service Kit.

  • Page 92: Jacking And Tire Changing

    W H A T T O D O I N E M E R G E N C I E S JACKING AND TIRE CHANGING Jack Location Your vehicle may be equipped with jacking and tire changing equipment. The jack, jack handle and winch handle tools are stowed behind the rear left side trim panel in the rear cargo area.
  • Page 93 W H A T T O D O I N E M E R G E N C I E S Super Console For vehicles equipped with the Super Console, the spare tire winch assembly drive nut is located beneath the console. 1.
  • Page 94 W H A T T O D O I N E M E R G E N C I E S 3. Remove the liner from the console's storage compartment to access the spare tire winch drive nut. Winch Drive Nut Location Premium/Base/Cargo Center Console Pull the Winch Cover assembly plug (if equipped) to access the winch drive nut.
  • Page 95 W H A T T O D O I N E M E R G E N C I E S Spare Tire Tools The tool pouch contains three pieces and can be assembled into a spare tire hook; to remove the compact spare tire/cover assembly from under the vehicle, or a Winch T-handle;...
  • Page 96 W H A T T O D O I N E M E R G E N C I E S Spare Tire Removal Instructions The spare tire is located under the vehicle beneath the center console area. 1. Assemble the spare tire tools into a T-handle and place the square end over the spare tire winch drive nut.
  • Page 97 W H A T T O D O I N E M E R G E N C I E S Preparations For Jacking 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. 2. Turn on the Hazard Warning flasher. 3.
  • Page 98 W H A T T O D O I N E M E R G E N C I E S Jacking Instructions 1. Loosen (but do not remove) the wheel lug nuts by turning them to the left one turn while the wheel is still on the ground.
  • Page 99 W H A T T O D O I N E M E R G E N C I E S Rear jack locations are between a pair of down-facing tabs on the sill flange of the vehicle side body. Rear Jacking Location Engaged Front jack location is on the sill flange of the vehicle body and is located 6 in (150 mm) from door edge.
  • Page 100 W H A T T O D O I N E M E R G E N C I E S 6. Install the compact spare tire. Lightly tighten the lug nuts. NOTE: • Do not install the wheel cover on the compact spare.
  • Page 101 W H A T T O D O I N E M E R G E N C I E S 4. Using the winch T-handle, rotate the drive nut to the right until the compact spare tire/cover assembly is drawn into place against the underside of the vehicle. 5.
  • Page 102 W H A T T O D O I N E M E R G E N C I E S Vehicles Without Wheel Covers 1. Mount the road tire on the axle. 2. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel. Lightly tighten the lug nuts.
  • Page 103 W H A T T O D O I N E M E R G E N C I E S WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.

  • Page 104: Jump-Starting

    W H A T T O D O I N E M E R G E N C I E S JUMP-STARTING If your vehicle has a discharged battery it can be jump-started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack. Jump-starting can be dangerous if done improperly so please follow the procedures in this section carefully.
  • Page 105 W H A T T O D O I N E M E R G E N C I E S 3. Disconnect the positive (+) end of the jumper cable from the positive (+) post of the booster battery. 4.

  • Page 106: Shift Lever Override

    W H A T T O D O I N E M E R G E N C I E S SHIFT LEVER OVERRIDE If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to tem- porarily move the shift lever: 1.

  • Page 107: Towing A Disabled Vehicle

    W H A T T O D O I N E M E R G E N C I E S TOWING A DISABLED VEHICLE Wheels OFF the Towing Condition ALL MODELS Ground If transmission is operable: Flat Tow NONE •...

  • Page 108: Event Data Recorder (Edr)

    W H A T T O D O I N E M E R G E N C I E S EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.

  • Page 109: Maintaining Your Vehicle

    M A I N T A I N I N G Y O U R V E H I C L E OPENING THE HOOD 1. Pull the hood release lever located on the instrument panel, below the steering column. 2.

  • Page 110: Engine Compartment

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT 3.6L Engine 1. Air Cleaner Filter 2. Brake Fluid Reservoir 3. Integrated Power Module (Fuses) 4. Battery 5.
  • Page 111 M A I N T A I N I N G Y O U R V E H I C L E 6. Engine Oil Dipstick 7. Engine Oil Fill 8. Engine Coolant Pressure Cap 9. Washer Fluid Reservoir 10. Power Steering Fluid Reservoir...

  • Page 112: Fluid Capacities

    M A I N T A I N I N G Y O U R V E H I C L E FLUID CAPACITIES U.S. Metric Fuel (Approximate) 20 Gallons 76 Liters Engine Oil with Filter 3.6L Engine (SAE 5W-20, 6 Quarts 5.6 Liters API Certified).
  • Page 113 M A I N T A I N I N G Y O U R V E H I C L E CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.

  • Page 114: Maintenance Procedures

    M A I N T A I N I N G Y O U R V E H I C L E MAINTENANCE PROCEDURES For information on the maintenance procedures for your vehicle, please refer to “Main- tenance Procedures” in “Maintaining Your Vehicle” in your Owner’s Manual or applicable supplement on the DVD for further details.
  • Page 115 M A I N T A I N I N G Y O U R V E H I C L E Once A Month Or Before A Long Trip: • Check engine oil level. • Check windshield washer fluid level. •...
  • Page 116 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 117 M A I N T A I N I N G Y O U R V E H I C L E...

  • Page 118: Maintenance Record

    M A I N T A I N I N G Y O U R V E H I C L E...

  • Page 119: Fuses

    M A I N T A I N I N G Y O U R V E H I C L E FUSES WARNING! • When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating.
  • Page 120 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Mini-Fuse Description Partial Zero Emissions Vehicle Motor/ 40 Amp Green – Flex Fuel – If Equipped Headlamp Wash/Manifold Tuning Valve 30 Amp Pink –...
  • Page 121 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Mini-Fuse Description Rear View Mirror, Instrument Cluster, Multi-Function Control Switch, Tire – 20 Amp Yellow Pressure Monitor, Glow Plug Module –...

  • Page 122: Tire Pressures

    M A I N T A I N I N G Y O U R V E H I C L E TIRE PRESSURES Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle. The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...

  • Page 123: Spare Tires - If Equipped

    M A I N T A I N I N G Y O U R V E H I C L E SPARE TIRES — IF EQUIPPED NOTE: For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to “Tire Service Kit”...
  • Page 124 M A I N T A I N I N G Y O U R V E H I C L E Full Size Spare — If Equipped The full size spare is for temporary emergency use only. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not.

  • Page 125: Adding Fuel

    M A I N T A I N I N G Y O U R V E H I C L E ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle.

  • Page 126: Wheel And Wheel Trim Care

    M A I N T A I N I N G Y O U R V E H I C L E WHEEL AND WHEEL TRIM CARE All wheels and wheel trim, especially aluminum and chrome plated wheels, should be cleaned regularly with a mild soap and water to prevent corrosion.

  • Page 127: Consumer Assistance

    Booklet. United States customers may visit the Dodge Contact Us page at www.dodge.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Box Material” from the left menu. You may also obtain a complimentary copy by calling 1-800-423-6343 (U.S.) or 1-800-387-1143...

  • Page 128: Reporting Safety Defects In The United States

    C O N S U M E R A S S I S T A N C E WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain, or emit, chemicals known to the State of California to cause cancer and birth defects, or other reproductive harm.

  • Page 129: Mopar® Accessories

    M O P A R ® A C C E S S O R I E S AUTHENTIC ACCESSORIES BY MOPAR® The following highlights just some of the many Authentic Dodge Accessories by Mopar ® featuring a fit, finish, and functionality specifically for your Dodge Grand Caravan.

  • Page 130: Frequently Asked Questions

    • How do I use my USB port to listen to audio through my touch-screen radio? pg. 61 • How do I configure my Universal Garage Door Opener (HomeLink ® ) ? pg. 72 UTILITY • How do I know how much I can tow with my Dodge Grand Caravan? pg. 75...
  • Page 131 F R E Q U E N T LY A S K E D Q U E S T I O N S WHAT TO DO IN EMERGENCIES • What do I do if my TPMS warning light is blinking? pg. 78 •...

  • Page 132: Index

    I N D E X Adding Engine Coolant (Antifreeze) . .112 Break-In Recommendations, New Adding Washer Fluid..112 Vehicle ....30 Air Bag Bulbs, Light .
  • Page 133 I N D E X Drain, Flush, And Refill ..112 Exhaust System ... .112 Inspection ... . .112 Exterior Lights .
  • Page 134 I N D E X Instrument Panel Cover ..112 Malfunction Indicator Light Instrument Panel Lens Cleaning . . .112 (Check Engine) ... .81 Integrated Power Module (Fuses) .
  • Page 135 I N D E X Rain Sensitive Wiper System ..31 Steering Rear Camera ....38 Tilt Column ... . .29 Rear Cross Path .
  • Page 136 I N D E X Wheel And Wheel Trim Care. . .112, 124 Windshield Washers ...31 Windshield Wiper Blades ..112 Windshield Wipers ... .31 Wiper Blade Replacement .
  • Page 137 N O T E S...
  • Page 138 N O T E S...
  • Page 139 , v i s i t www.mopar.com (U.S.), www.mopar.ca (Canada) or your local Dodge dealer.
  • Page 140 D O W N L O A D A F R E E E L E C T R O N I C C O P Y O F T H E O W N E R ’ S M A N U A L A N D W A R R A N T Y B O O K L E T B Y V I S I T I N G : W W W .

Table of Contents
