Summary of Contents for Dodge 2015 Journey

Page 1 Journey 2 0 1 5 O W N E R ’ S M A N U A L I n f o r ma t i o n P r o v i d e d b y :...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and the features and equipment that are either standard or op- name Chrysler Canada Inc.
Page 3: Introduction
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 4 I n f o r ma t i o n P r o v i d e d b y :...
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 VEHICLE IDENTIFICATION NUMBER ..6 HOW TO USE THIS MANUAL ....4 VEHICLE MODIFICATIONS/ALTERATIONS .
Page 6: Introduction
4 INTRODUCTION When it comes to service, remember that your authorized INTRODUCTION dealer knows your vehicle best, has factory-trained tech- Congratulations on selecting your new Chrysler Group nicians and genuine parts, and cares about your satisfac- LLC vehicle. Be assured that it represents precision tion.
Page 7 INTRODUCTION 5 I n f o r ma t i o n P r o v i d e d b y :...
Page 8: Vehicle Identification Number
6 INTRODUCTION The VIN is also stamped on either right or left hand side WARNINGS AND CAUTIONS of the engine block. This Owners Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Stamped VIN Location NOTE: It is illegal to remove or alter the VIN. I n f o r ma t i o n P r o v i d e d b y :...
Page 10 I n f o r ma t i o n P r o v i d e d b y :...
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A WORD ABOUT YOUR KEYS ... . .11 ▫ To Arm The System .....17 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ General Information ....24 OCCUPANT RESTRAINT SYSTEMS ..44 REMOTE STARTING SYSTEM —...
Page 13: A Word About Your Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 The Keyless Ignition Node (KIN System) has four oper- A WORD ABOUT YOUR KEYS ating positions, three of which are labeled and will Your vehicle uses a keyless ignition system. This system illuminate when in position.
Page 14: Key Fob
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key Fob The Key Fob also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle should the battery in the vehicle or the Key Fob go dead.
Page 15: Ignition Or Accessory On Message
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Ignition Or Accessory On Message Opening the driver’s door when the ignition is in ACC or ON (engine not running), a chime will sound to remind you to cycle the ignition to OFF. In addition to the chime, the ignition or accessory on message will display in the cluster.
Page 16 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Do not leave the Key Fob in or near the vehicle, or • Before exiting a vehicle, always apply the parking in a location accessible to children, and do not brake, shift the transmission into PARK, and push leave the ignition of a vehicle equipped with ignition button to place ignition in OFF mode.
Page 17: Sentry Key
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 it indicates that someone used an invalid Key Fob to start SENTRY KEY® the engine. Either of these conditions will result in the The Sentry Key® Immobilizer system prevents unauthor- engine being shut off after two seconds. ized vehicle operation by disabling the engine.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE All of the Key Fobs provided with your new vehicle have Keep the PIN in a secure location. This number is been programmed to the vehicle electronics. required for authorized dealer replacement of Key Fobs. Duplication of Key Fobs may be performed at an autho- Replacement Keys rized dealer.
Page 19: Vehicle Security Alarm - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 • This device must accept any interference that may be Rearming Of The System received, including interference that may cause unde- If something triggers the alarm, and no action is taken to sired operation.
Page 20: To Disarm The System
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Push the LOCK button on the exterior Passive Entry door handle (if equipped, refer to Keyless Enter-N- Door Handle with a valid Key Fob available in the Go™ in Things To Know Before Starting Your Ve- same exterior zone (refer to Keyless Enter-N-Go™...
Page 21: Security System Manual Override
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 The Vehicle Security Alarm is designed to protect your Security System Manual Override vehicle; however, you can create conditions where the The Vehicle Security Alarm will not arm if you lock the system will give you a false alarm.
Page 22: Remote Keyless Entry (Rke)
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: NOTE: Driving at speeds 5 mph (8 km/h) and above disables the system from responding to all RKE transmit- • The front courtesy overhead console and door cour- ter buttons for all RKE transmitters. tesy lights will turn on if the dimmer control is in the Dome ON position (extreme top position).
Page 23: To Unlock The Doors And Liftgate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 Flash Lamps With Lock To Unlock The Doors And Liftgate Push and release the UNLOCK button on the RKE This feature will cause the turn signal lights to flash when transmitter once to unlock the driver’s door or twice the doors are locked or unlocked with the RKE transmit- within five seconds to unlock all doors and liftgate.
Page 24: To Lock The Doors And Liftgate
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE second and release. When the Panic Alarm is activated, To Lock The Doors And Liftgate the turn signals will flash, the horn will pulse on and off, Push and release the LOCK button on the RKE transmit- and the interior lights will turn on.
Page 25: Programming Additional Transmitters
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 1. Remove the emergency key by sliding the mechanical Programming Additional Transmitters latch on the back of the RKE transmitter sideways Programming Key Fobs or RKE transmitters may be with your thumb and then pull the key out with your performed at an authorized dealer.
Page 26: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE of the RKE transmitter apart. Make sure not to damage on the battery to the + sign on the inside of the battery the seal during removal. clip, located on the back cover. Avoid touching the new battery with your fingers.
Page 27: Remote Starting System - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 NOTE: Changes or modifications not expressly approved NOTE: by the party responsible for compliance could void the • The vehicle must be equipped with an automatic user’s authority to operate the equipment. transmission to be equipped with Remote Start.
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Battery at an acceptable charge level Remote Start Abort Message On Electronic Vehicle Information Center (EVIC) — If Equipped • RKE PANIC button not pushed The following messages will display in the EVIC if the •...
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 To Enter Remote Start Mode • The engine can be started two consecutive times (two 15-minute cycles) with the RKE transmitter. However, the ignition must be cycled to the RUN position before Push and release the REMOTE START button you can repeat the start sequence for a third cycle.
Page 30: Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE equipped). Then, prior to the end of the 15-minute cycle, DOOR LOCKS push and release the START/STOP button. Manual Door Locks NOTE: The message “Push Start Button” will display in To lock each door, push the door lock knob on each door the EVIC until you push the START button.
Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 WARNING! • For personal security and safety in the event of a collision, lock the vehicle doors before you drive as well as when you park and leave the vehicle. • When leaving the vehicle, always remove the Key Fob from the vehicle and lock your vehicle.
Page 32: Power Door Locks
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks WARNING! (Continued) A power door lock switch is on each front door trim • Do not leave the Key Fob in or near the vehicle or panel. Use this switch to lock or unlock the doors and in a location accessible to children, and do not liftgate.
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 The doors can also be locked and unlocked with the auto door lock feature can be enabled or disabled by your Keyless Enter-N-Go™ (Passive Entry) system. For further authorized dealer or through the Uconnect® Settings in information, refer to “Keyless Enter-N-Go™”...
Page 34: Child-Protection Door Lock System - Rear Doors
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To change the current setting, refer to “Uconnect® Set- tings” in “Understanding Your Instrument Panel” for further information. NOTE: Use the Automatic Unlock Doors On Exit feature in accordance with local laws. Child-Protection Door Lock System —...
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the Child-Protection locks are engaged. Failure to follow this warning may result in serious injury or death.
Page 36: Keyless Enter-N-Go
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Disengage The Child-Protection Door Lock System 3. Repeat steps 1 and 2 for the opposite rear door. 1. Open the rear door. NOTE: After disengaging the Child-Protection Door Lock system, always test the door from the inside to 2.
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 • If wearing gloves on your hands, or if it has been raining on the Passive Entry door handle, the unlock sensitivity can be affected, resulting in a slower re- sponse time. •...
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Settings (Customer-Programmable Features)” in “Under- Preventing Inadvertent Locking Of Passive Entry RKE standing Your Instrument Panel” for further information. Transmitter In Vehicle To Unlock From The Passenger Side: To minimize the possibility of unintentionally locking a Passive Entry RKE transmitter inside your vehicle, the With a valid Passive Entry RKE transmitter within 5 ft Passive Entry system is equipped with an automatic door...
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 To Enter The Liftgate To Lock The Vehicle’s Doors With a valid Passive Entry RKE transmitter within 3 ft With one of the vehicle’s Passive Entry RKE transmitters (1.0 m) of the liftgate, push the button underneath the left within 5 ft (1.5 m) of the driver or passenger front door side of the accent bar, which is located on the liftgate handle, push the door handle LOCK button to lock all...
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Do NOT grab the door handle, when pushing the door NOTE: handle button. This could unlock the door(s). • After pushing the door handle button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle.
Page 41: Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 There are single window controls on each passenger door WINDOWS trim panel, which operate the passenger door windows. Power Windows The window controls will operate when the ignition is in The window controls on the driver’s door trim panel the ON/RUN or ACC position.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To stop the window from going all the way down during WARNING! (Continued) the Auto-down operation, pull up on the switch briefly. ignition of a vehicle equipped with Keyless Enter-N- Auto-Up Feature With Anti-Pinch Protection Go™...
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 NOTE: Reset Auto-Up Should the Auto Up feature stop working, the window • If the window runs into any obstacle during Auto- probably needs to be reset. To reset Auto Up: closure, it will reverse direction and then go back down.
Page 44: Wind Buffeting
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the down position). To enable the window controls, push ears. Your vehicle may exhibit wind buffeting with the and release the window lockout button again (setting it in windows down, or the sunroof (if equipped) in certain the up position).
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 For further information on Keyless Enter-N-Go™ (Pas- • If liftgate is left open for an extended period of time, sive Entry), refer to “Keyless Enter-N-Go™” in “Things the liftgate may need to be closed manually to reset To Know Before Starting Your Vehicle”.
Page 46: Occupant Restraint Systems
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Because the gas pressure drops with temperature, • Supplemental Restraint Systems (SRS) Air Bags it may be necessary to assist the props when opening the • Supplemental Active Head Restraints liftgate in cold weather. •...
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 3. Children that are not big enough to wear the vehicle 8. Do not lean against the door or window. If your seat belt properly (Refer to Child Restraints ) should vehicle has side air bags, and deployment occurs, the be secured in a vehicle with a rear seat in child side air bags will inflate forcefully into the space restraints or belt-positioning booster seats.
Page 48: Seat Belt Systems
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE switch is in the START or ON/RUN position. If the Seat Belt Systems driver or outboard front seat passenger is unbelted, Buckle up even though you are an excellent driver, even the Seat Belt Reminder Light will turn on and remain on short trips.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 The outboard front passenger seat BeltAlert® is not Lap/Shoulder Belts active when the outboard front passenger seat is unoc- All seating positions in your vehicle are equipped with cupied. BeltAlert® may be triggered when an animal or lap/shoulder belts.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • In a collision, you and your passengers can suffer • Wearing your seat belt incorrectly could make your much greater injuries if you are not properly buck- injuries in a collision much worse.
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 WARNING! (Continued) WARNING! (Continued) • A twisted seat belt may not protect you properly. In • A seat belt that is worn under your arm is danger- a collision, it could even cut into you. Be sure the ous.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • A frayed or torn seat belt could rip apart in a collision and leave you with no protection. Inspect the seat belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be re- placed immediately.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Inserting Latch Plate Into Buckle Positioning The Lap Belt 4. Position the lap belt so that it is snug and lies low 5. Position the shoulder belt across the shoulder and across your hips, below your abdomen. To remove chest with minimal, if any slack so that it is comfort- slack in the lap belt portion, pull up on the shoulder able and not resting on your neck.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE stowed position. If necessary, slide the latch plate Adjustable Upper Shoulder Belt Anchorage down the webbing to allow the seat belt to retract In the driver and front passenger seats, the top of the fully.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 As a guide, if you are shorter than average, you will Seat Belt Extender. The Seat Belt Extender should be used prefer the shoulder belt anchorage in a lower position, only if the existing seat belt is not long enough. When the and if you are taller than average, you will prefer the Seat Belt Extender is not required for a different occu- shoulder belt anchorage in a higher position.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belts And Pregnant Women NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be We recommend that pregnant women use the seat belts worn snugly and positioned properly.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Automatic Locking Retractor (ALR) — If Equipped The seat belts in the passenger seating positions may be equipped with a Switchable Automatic Locking Retrac- tors (ALR) which is used to secure a child restraint system.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE as to not activate the ALR. If the ALR is activated, you WARNING! will hear a clicking sound as the seat belt retracts. Allow the webbing to retract completely in this case and then •...
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 How To Disengage The Automatic Locking Mode WARNING! (Continued) Unbuckle the combination lap/shoulder belt and allow it • Do not use the Automatic Locking Mode to restrain to retract completely to disengage the Automatic Locking occupants who are wearing the seat belt or children Mode and activate the vehicle sensitive (emergency) who are using booster seats.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How The Active Head Restraints (AHR) Work The Occupant Restraint Controller (ORC) determines whether the severity, or type of rear impact will require the Active Head Restraints (AHR) to deploy. If a rear impact requires deployment, both the driver and front passenger seat AHRs will be deployed.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 1. Grasp the deployed AHR from the rear seat. WARNING! All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a collision.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism. Review Table Below A — Downward Movement B — Rearward Movement C — Final Downward Movement To Engage Locking Mechanism I n f o r ma t i o n P r o v i d e d b y :...
Page 63: Supplemental Restraint System (Srs)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 4. The AHR front soft foam and trim half should lock • For safety reasons, have the Active Head Restraints into the back decorative plastic half. checked by a qualified specialist at an authorized dealer.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Supplemental Knee Air Bags • Front and Side Impact Sensors • Seat Belt Pretenioners • Seat Belt Buckle Switch • Seat Track Position Sensors Advanced Front Air Bags This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems.
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 output appropriate to the severity and type of collision as WARNING! determined by the Occupant Restraint Controller (ORC), which may receive information from the front impact • Being too close to the steering wheel or instrument sensors or other system components.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Relying on the air bags alone could lead to more • No objects should be placed over or near the air severe injuries in a collision. The air bags work bag on the instrument panel or steering wheel, with your seat belt to restrain you properly.
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 On the other hand, depending on the type and location of way as the air bags inflate to their full size. The Advanced impact, Advanced Front Air Bags may deploy in crashes Front Air Bags fully inflate in less time than it takes to with little vehicle front-end damage but that produce a blink your eyes.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Driver Knee Air Bag This vehicle is equipped with a Supplemental Driver Knee Air Bag mounted in the instrument panel below the steering column. The Supplemental Driver Knee Air Bag provides enhanced protection during a frontal impact by working together with the seat belts, pretensioners, and Advanced Front Air Bags.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 When the SAB deploys, it opens the seam on the out- board side of the seatback’s trim cover. The inflating SAB deploys through the seat seam into the space between the occupant and the door. The SAB moves at a very high speed and with such a high force that it could injure you if you are not seated properly, or if items are positioned in the area where the SAB inflates.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE rollover events, in addition to the injury reduction poten- WARNING! tial provided by the seat belts and body structure. • Your vehicle is equipped with left and right The SABICs deploy downward, covering the side win- Supplemental Side Air Bag Inflatable Curtains dows.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 The SABICs and SABs (“Side Air Bags”) are designed to Seat belts (and child restraints where appropriate) are activate in certain side impacts and certain rollover necessary for your protection in all collisions. They also events.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE deploys the left Side Air Bags only and a right side WARNING! (Continued) impact deploys the right Side Air Bags only. • Relying on the Side Air Bags alone could lead to The Side Air Bags will not deploy in all side collisions, more severe injuries in a collision.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 event may be in progress and whether deployment is • The air bag material may sometimes cause abrasions appropriate. A slower-developing event may deploy the and/or skin reddening to the occupants as the air bags seat belt pretensioners on both sides of the vehicle.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Do not drive your vehicle after the air bags have de- Enhanced Accident Response System ployed. If you are involved in another collision, the air In the event of an impact, if the communication network bags will not be in place to protect you.
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 System Reset Procedure The ORC contains a backup power supply system that may deploy the air bags even if the battery loses power or In order to reset the Enhanced Accident Response System it becomes disconnected prior to deployment.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE free, if any of the following occurs, have an authorized WARNING! dealer service the air bag system immediately. Ignoring the Air Bag Warning Light in your instru- • The Air Bag Warning Light does not come on during ment panel could mean you won’t have the air bags the four to eight seconds when the ignition switch is to protect you in a collision.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Maintaining Your Air Bag System WARNING! (Continued) • Do not attempt to modify any part of your air bag WARNING! system. The air bag may inflate accidentally or may • Modifications to any part of the air bag system not function properly if modifications are made.
Page 78: Child Restraints
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE bag deployment or hitting a road obstacle, data that will the EDR under normal driving conditions and no per- assist in understanding how a vehicle’s systems per- sonal data (e.g., name, gender, age, and crash location) formed.
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 Every state in the United States, and every Canadian There are different sizes and types of restraints for children from newborn size to the child almost large province, requires that small children ride in proper enough for an adult seat belt.
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Infants and Tod- Children who are two years old or Either an Infant Carrier or a Convertible dlers younger and who have not reached the Child Restraint, facing rearward in the rear...
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Infants And Child Restraints WARNING! Safety experts recommend that children ride rear-facing • Never place a rear-facing child restraint in front of in the vehicle until they are two years old or until they an air bag.
Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE remain in a forward-facing child seat with a harness for WARNING! (Continued) as long as possible, up to the highest weight or height directions exactly when installing an infant or allowed by the child seat. child restraint.
Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 Integrated Child Booster Seat — If Equipped 2. Pull the release loop forward to release the latch and seat cushion. The Integrated Child Booster Seat is located in each outboard second-row passenger seat. The Booster Seat is designed for children weighing between 48 and 85 lbs (22 and 39 kg) and between 47 in (119 cm) and 57 in (145 cm) tall.
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Lift the seat cushion up and push back to lock it in the 4. Place the child upright in the seat with their back booster seat position. firmly against the seatback. 5.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 WARNING! Securely lock the seat cushion into position before using the seat. Otherwise, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat cushion could cause serious injury.
Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Do the child’s knees bend comfortably over the front WARNING! of the vehicle seat – while they are still sitting all the way back? Never allow a child to put the shoulder belt under an arm or behind their back.
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 Recommendations For Attaching Child Restraints Restraint Type Combined Use any attachment method shown with an “X” Below Weight of the LATCH – Seat Belt Only LATCH – Seat Belt + Top Child + Child Lower Anchors Lower Anchors Tether Anchor...
Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lower Anchors And Tethers For Children (LATCH) Anchors and Tethers for CHildren. The LATCH system Restraint System has three vehicle anchor points for installing LATCH- equipped child seats. There are two lower anchorages located at the back of the seat cushion where it meets the seatback and one top tether anchorage located behind the seating position.
Page 89 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 LATCH Positions For Installing Child Restraints In This Vehicle Lower Anchor / Top Tether Locations (Third Row Shown – If Equipped) Lower Anchorage Symbol 2 anchorages per • seating position Top Tether Anchorage Symbol •...
Page 90 88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Restraint LATCH Positions What is the weight limit (child’s weight 65 lbs (29.5 kg) Use the LATCH anchorage system un- + weight of the child restraint) for using til the combined weight of the child the LATCH anchorage system to attach and the child restraint is 65 lbs the child restraint?
Page 91 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 Can two child restraints be attached Never “share” a LATCH anchorage using a common lower LATCH anchor- with two or more child restraints. If age? the center position does not have dedi- cated LATCH lower anchorages, use the seat belt to install a child seat in the center position next to a child seat...
Page 92 90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 93 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91 Locating The Tether Anchorages LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each side. Each will have a hook or connector to attach to the lower There are tether strap anchors located behind anchorage and a way to tighten the connection to the each second row rear seatback, near the floor.
Page 94 92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE You can install up to two child seats using the LATCH Options for installing two child seats using the LATCH system at the same time. If you are installing three child anchorages in this vehicle: restraints, you must use the seatbelt to install the center 1.
Page 95 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93 center child restraint will block the seat belt buckle for WARNING! (Continued) this position. • If you are installing three child restraints next to each other, you must use the seat belt and the center WARNING! tether anchor for the center position.
Page 96 94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE “Installing Child Restraints Using the Vehicle Seat 5. If the child restraint has a tether strap, connect it to the Belt” to check what type of seat belt each seating top tether anchorage. See the section “Installing Child position has.
Page 97 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 95 with it and accidentally lock the seatbelt retractor. Before WARNING! (Continued) installing a child restraint using the LATCH system, • Child restraint anchorages are designed to with- buckle the seat belt behind the child restraint and out of stand only those loads imposed by correctly-fitted the child’s reach.
Page 98 96 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE make a clicking noise while the webbing is pulled back Lap/Shoulder Belt Systems For Installing Child into the retractor. For additional information on ALR, Restraints In This Vehicle refer to the “Automatic Locking Mode” description un- der “Occupant Restraints.”...
Page 99 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 97 What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child re- using the seat belt to install a for- straint) for using the Tether Anchor ward facing child restraint, up to with the seat belt to attach a forward...
Page 100 98 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing A Child Restraint With A Switchable 4. Pull on the webbing to make the lap portion tight Automatic Locking Retractor (ALR) against the child seat. 1. Place the child seat in the center of the seating 5.
Page 101 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 99 the tether strap to the anchorage and tighten the tether rear-most position to make room for the child seat. strap. See the section “Installing Child Restraints You may also move the front seat forward to allow Using the Top Tether Anchorage”...
Page 102 100 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE strap. See the section “Installing Child Restraints If the belt still cannot be tightened after you shorten the Using the Top Tether Anchorage” for directions to buckle, disconnect the latch plate from the buckle, turn attach a tether anchor.
Page 103 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 101 between the two posts. If not possible, lower the head restraint and pass the tether strap around the outboard side of the head restraint. 3. Attach the tether strap hook of the child restraint to the top tether anchorage as shown in the diagram.
Page 104: Transporting Pets
102 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Remove slack in the tether strap according to the child Transporting Pets restraint manufacturer’s instructions. Air Bags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly WARNING! injured, or injure a passenger during panic braking or in a collision.
Page 105: Safety Tips
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 103 While cruising, brief full-throttle acceleration, within the SAFETY TIPS limits of local traffic laws contributes to a good break-in. Transporting Passengers Wide-open throttle acceleration in low gear can be detri- NEVER TRANSPORT PASSENGERS IN THE CARGO mental and should be avoided.
Page 106: Exhaust Gas
104 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas WARNING! (Continued) • Be sure everyone in your vehicle is in a seat and WARNING! using a seat belt properly. Exhaust gases can injure or kill. They contain carbon • On seven passenger models, do not drive the monoxide (CO), which is colorless and odorless.
Page 107: Safety Checks You Should Make Inside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 105 Safety Checks You Should Make Inside The WARNING! (Continued) Vehicle • If it is necessary to sit in a parked vehicle with the Seat Belts engine running, adjust your heating or cooling controls to force outside air into the vehicle.
Page 108 106 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE not lit during starting, or if the light stays on, flickers, or WARNING! turns on while driving, have the system checked by an authorized dealer. Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious per- Defroster sonal injury.
Page 109: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 107 Periodic Safety Checks You Should Make Outside WARNING! (Continued) The Vehicle • Check mounting of mats on a regular basis. Always Tires properly reinstall and secure floor mats that have been removed for cleaning. Examine tires for excessive tread wear and uneven wear •...
Page 110 108 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks. Also, if gasoline fumes are detected or if fuel, power steering fluid (if equipped), or brake fluid leaks are suspected, the cause should be located and corrected immediately.
Page 111: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS MIRRORS ......115 Uconnect® PHONE (4.3) ....120 ▫...
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect® PHONE (8.4/8.4N) ... . .146 SEATS ......197 ▫...
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 ▫ 50/50 Split Third-Row Passenger Seats With ▫ Turn Signals ......226 Fold-Flat Feature —...
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT/TELESCOPING STEERING COLUMN . . .234 ▫ ParkSense® Warning Display ... . .241 HEATED STEERING WHEEL — ▫ ParkSense® Display ....241 IF EQUIPPED .
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 GARAGE DOOR OPENER — IF EQUIPPED . . .253 ▫ Closing Sunroof — Manual Mode ..265 ▫ Before You Begin Programming HomeLink® . .255 ▫...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Floor Console Storage ....275 CARGO AREA FEATURES ....280 ▫...
Page 117: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 MIRRORS Inside Day/Night Mirror — If Equipped A single ball joint mirror is provided in the vehicle. It is a twist on mirror that has a fixed position at the wind- shield. The mirror installs on the windshield button with a counterclockwise rotation and requires no tools for mounting.
Page 118: Automatic Dimming Mirror - If Equipped
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped CAUTION! This mirror automatically adjusts for headlight glare To avoid damage to the mirror during cleaning, never from vehicles behind you. This feature will be defaulted spray any cleaning solution directly onto the mirror. on, and only be disabled when the vehicle is moving in Apply the solution onto a clean cloth and wipe the reverse.
Page 119: Power Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object.
Page 120: Power Folding Mirrors - If Equipped
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Models With Express Window Feature Press and release the mirror select button marked L (left) or R (right) and then press one of the four arrow buttons to move the mirror in the direction the arrow is pointing. The selection times out after 30 seconds of inactivity in order to guard against accidentally changing a mirror position following an adjustment.
Page 121: Manual Folding Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Resetting the Power Folding Outside Mirrors Manual Folding Mirrors — If Equipped You may need to reset the power folding mirrors if the Some models have exterior mirrors that are hinged. The following occurs: hinge allows the mirror to pivot forward and rearward to resist damage.
Page 122: Illuminated Vanity Mirrors - If Equipped
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sun Visor “Slide-On Rod” Feature — If Equipped Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on each sun visor. To use This feature allows for additional flexibility in position- the mirror, rotate the sun visor downward and swing the ing the visor to block out the sun.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Uconnect® Phone supports the following features: • Viewing and Calling contacts from Phonebooks dis- played on the touchscreen Voice Activated Features: • Setting Favorite Contact Phone numbers so they are • Hands Free dialing via Voice (“Call John Smith Mo- easily accessible on the Main Phone screen bile”...
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Canadian Residents - visit UconnectPhone.com or WARNING! (Continued) call, 1-800-465-2001 (English) or 1-800-387-9983 laws, including laws regarding phone use. Your at- (French). tention should be focused on safely operating the If your mobile phone only supports the Headset Profile vehicle.
Page 125: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 phone and one audio device can be used with the system can be adjusted either from the radio volume control at a time. The system is available in English, Spanish, or knob or from the steering wheel radio control (right French languages.
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For certain operations, compound commands can be Natural Speech used. For example, instead of saying “Call” and then Your Uconnect® Phone Voice system uses a Natural “John Smith” and then “mobile,” the following com- Language Voice Recognition (VR) engine.
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 question to which the user can respond without pushing Cancel Command the “Voice Command” button on your steering At any prompt, after the beep, you can say “Cancel” and wheel. you will be returned to the main menu. Voice Command Tree You can also push the button on your...
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: appear. If you select Yes you will go the Paired Phones screen, if you select No you will return to • You must have Bluetooth® enabled on your phone to the Uconnect® Phone main menu. complete this procedure.
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Pair A Bluetooth® Streaming Audio Device NOTE: If No is selected, device priority is determined by the order in which it was paired. The latest device paired 1. Push the PLAYER button on the faceplate to begin. will have the higher priority.
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Press to select the particular Phone or the “Phone/ Deleting A Phone Or Audio Device Audio” button on the touchscreen and then an Audio 1. Push the SETTINGS button on the faceplate. Device.
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 4. At the Options pop-up screen press the “Make Favor- • Automatic download and update of a phone book, if ite” button on the touchscreen; you will see the chosen supported, begins as soon as the Bluetooth® wireless device move to the top of the list.
Page 132: Phone Call Features
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE edited on the mobile phone. The changes are trans- Phone Call Features ferred and updated to Uconnect® Phone on the next The following features can be accessed through the phone connection. Uconnect® Phone if the feature(s) are available on your mobile service plan.
Page 133 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 NOTE: All of the above operations except Redial can be Call Controls done with one call or less active. The touchscreen allows you to control the following call features: Dial By Saying A Number •...
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Touch-Tone Number Entry • Missed Calls 1. Press the “Phone” button on the touchscreen. • All Calls 2. Press the “Dial” button on the touchscreen. These can be accessed by touching the recent calls button on the touchscreen on the Phone main screen.
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Ignore. Press the Answer button on the touchscreen or Making A Second Call While Current Call Is In push the button on the steering wheel to accept the Progress call. To make a second call while you are currently on a call, push the button and say “Dial”...
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE hold at a time. Also you can press the “Swap” button Redial on the touchscreen, on the Phone main screen. 1. Press the “Redial” button on the touchscreen, or push Join Calls button and after the “Listening” prompt and the following beep, say “Redial.”...
Page 137: Uconnect® Phone Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 NOTE: Uconnect® Phone Features Emergency Assistance • The emergency number dialed is based on the country where the vehicle is purchased (911 for the U.S. and If you are in an emergency and the mobile phone is Canada and 060 for Mexico).
Page 138 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Roadside Assistance/Towing Assistance Voice Mail Calling If you need roadside/towing assistance: To learn how to access your voice mail, refer to “Working with Automated Systems.” • Push the button to begin, Working With Automated Systems •...
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 example, if required to enter your PIN followed with NOTE: a pound, (3 7 4 6 #), you can push the button and • The first number encountered for that contact will be say, “Send 3 7 4 6 #.”...
Page 140 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Barge In — Overriding Prompts 2. Press the “Display” button on the touchscreen, then scroll down to Voice Response Length. button can be used when you wish to skip part of a prompt and issue your voice command 3.
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 Dialing Using The Mobile Phone Keypad You can dial a phone number with your mobile phone keypad and still use the Uconnect® Phone (while dialing WARNING! via the mobile phone keypad, the user must exercise caution and take precautionary safety measures).
Page 142: Advanced Phone Connectivity
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mute/Un-Mute (Mute OFF) Connect Or Disconnect Link Between the Uconnect® Phone And Mobile Phone When you mute the Uconnect® Phone, you will still be able to hear the conversation coming from the other If you would like to connect or disconnect the Bluetooth®...
Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 • Speak normally without pausing, just as you would NOTE: speak to a person sitting a few feet/meters away from • Even though the system is designed for users speaking you. in North American English, French, and Spanish ac- •...
Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Numbers must be spoken in single digits. “800” must • Low Road Noise be spoken “eight-zero-zero” not “eight hundred.” • Smooth Road Surface • You can say “O” (letter “O”) for “0” (zero). •...
Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 Bluetooth® Communication Link Mobile phones have been found to lose connection to the Uconnect® Phone. When this happens, the connection can generally be reestablished by switching the phone off/on. Your mobile phone is recommended to remain in Bluetooth®...
Page 146 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Tree I n f o r ma t i o n P r o v i d e d b y :...
Page 147: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 NOTE: • You can replace “4” with any message number shown on the screen. • You can replace “John Smith” with any name in your mobile or favorite phone book. You can also say “Send •...
Page 148: Uconnect® Phone (8.4/8.4N)
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • This device may not cause harmful interference. • Hands Free text to speech listening of your incoming SMS messages. • This device must accept any interference received, including interference that may cause undesired op- •...
Page 149 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Screen Activated Features NOTE: Your phone must be capable of SMS messaging via Bluetooth® for messaging features to work properly. • Dialing via Keypad using touchscreen. Your mobile phone’s audio is transmitted through your •...
Page 150 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE phone and one audio device can be used with the system WARNING! at a time. The system is available in English, Spanish, or French languages. Any voice commanded system should be used only in safe driving conditions following all applicable Uconnect®...
Page 151: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 your vehicle is equipped. Please see the Uconnect® 2. Say the individual commands and allow the system to Voice Command section for direction on how to use guide you to complete the task. button.
Page 152 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE form voice command “Search for John Smith,” or you The system handles multiple inputs in the same phrase can break the compound command form into two or sentence such as “make a phone call” and “to Kelly voice commands: “Search Contact”...
Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Help Command Pair (Link) Uconnect® Phone To A Mobile Phone If you need assistance at any prompt, or if you want to To begin using your Uconnect® Phone, you must pair know your options at any prompt, say “Help” following your compatible Bluetooth®...
Page 154 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. If there is no phone currently connected with the 3. Select “Yes” to begin the pairing process. Then, search system, a pop-up will appear. for available devices on your Bluetooth® enabled mobile phone. When prompted on the phone, enter the name and PIN shown on the Uconnect®...
Page 155 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Pair Additional Mobile Phones 1. Press the “Settings” button from the Phone main screen. 2. Press the “Add Device” button on the touchscreen. 3. Search for available devices on your Bluetooth® en- abled mobile phone. When prompted on the phone, enter the name and PIN shown on the Uconnect®...
Page 156 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: For phones which are not made a favorite, the NOTE: If there is no device currently connected with the phone priority is determined by the order in which it was system, a pop-up will appear. paired.
Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 You can also use the following VR command to bring up 4. Press the “X” to exit out of the Settings screen. a list of paired audio devices: Disconnecting A Phone Or Audio Device •...
Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Deleting A Phone Or Audio Device 3. Press the settings icon button located to the right of the device name. 1. Press the “Settings” button on the touchscreen. 4. The options pop-up will be displayed. 2.
Page 159 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 • To call a name from a downloaded mobile phone book, • Only the phonebook of the currently connected mobile follow the procedure in the Voice Recognition Quick phone is accessible. Reference section. •...
Page 160 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE appropriate number. Press the “+” next to the selected 3. From the Phone main screen, select Phonebook. From number to display the options pop-up. In the pop-up the Phonebook screen, select the “Favorites” button on select “Add to Favorites.”...
Page 161 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 3. Press the “+” next to the Favorite you would like to remove. Add From Mobile To Remove A Favorite Remove From Favorites 1. To remove a Favorite, select phonebook from the 4. The Options pop-up will display, press “Remove from Phone main screen.
Page 162 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Emergency And Towing Assistance The Emergency and Towing Assistance Favorite numbers can only be altered. These cannot be deleted and the names cannot be changed. To change the Emergency or Towing Assistance numbers follow these steps.
Page 163: Phone Call Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 • Mobile Phonebook Phone Call Features The following features can be accessed through the • Recent Call Log Uconnect® Phone if the feature(s) are available and • SMS Message Viewer supported by Bluetooth® on your mobile service plan. For example, if your mobile service plan provides three- Dial By Saying A Number way calling, this feature can be accessed through the...
Page 164 162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. The Uconnect® Phone will dial the number associated Touch-Tone Number Entry with John Doe, or if there are multiple numbers it will 1. Press the “Phone” button on the touchscreen. ask which number you want to call for John Doe. 2.
Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 These can be accessed by pressing the “recent calls” button on the touchscreen on the Phone main screen. You can also push the button and say “Show my incoming calls” from any screen and the Incoming calls will be displayed.
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Answer Or Ignore An Incoming Call — Call phonebooks. To go back to the first call, refer to “Toggling Currently In Progress Between Calls” in this section. To combine two calls, refer to “Join Calls” in this section. If a call is currently in progress and you have another incoming call, you will hear the same network tones for Place/Retrieve A Call From Hold...
Page 167: Uconnect® Phone Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 Call Termination NOTE: The call will remain within the vehicle audio system until the phone becomes out of range for the To end a call in progress, momentarily press the “Phone” Bluetooth® connection. It is recommended to press the button or the “end”...
Page 168 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. After the “Listening” prompt and the following beep, WARNING! say “Dial Emergency” and the Uconnect® Phone will instruct the paired mobile phone to call the emergency Your phone must be turned on and connected to the number.
Page 169 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 NOTE: The roadside/towing assistance number dialed is or automated customer service line. Some services re- based on the country where the vehicle is purchased quire immediate response selection. In some instances, (1-800-521-2779 for the U.S./Canada, 55-14-3454 for that may be too quick for use of the Uconnect®...
Page 170 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE entries. For example, if you previously created a Phone- • Pauses, wait or other characters that are supported by book entry with First and/or Last Name as “Voicemail some phones are not supported over Bluetooth®. Password”, then if you push the button and say These additional symbols will be ignored in the dialing...
Page 171 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 1. Press the “More” button on the touchscreen (where Dialing Using The Mobile Phone Keypad available), then press the “Settings” button on the touchscreen. WARNING! 2. Press the “Display” button on the touchscreen, then Driving while distracted can result in loss of vehicle scroll down to Voice Response Length.
Page 172: Advanced Phone Connectivity
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE dialing a number with your connected Bluetooth® mo- Advanced Phone Connectivity bile phone, the audio will be played through your Transfer Call To And From Mobile Phone vehicle’s audio system. The Uconnect® Phone will work The Uconnect®...
Page 173: Things You Should Know About Your Uconnect® Phone
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 • Low Road Noise Things You Should Know About Your Uconnect® Phone • Smooth Road Surface Voice Command • Fully Closed Windows • For best performance, adjust the rearview mirror to • Dry Weather Condition provide at least ½...
Page 174 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Even though international dialing for most number com- Performance such as audio clarity, echo, and loudness to binations is supported, some shortcut dialing number a large degree rely on the phone and network, and not combinations may not be supported.
Page 175 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 Read Messages: If you receive a new text message while your phone is connected to Uconnect® Phone, an announcement will be made to notify you that you have a new text message. Voice Text List NOTE: Uconnect®...
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Once a message is received and viewed or listened to, you will have the following options: • Send a Reply • Forward • Call Send Messages Using Buttons On The Touchscreen: You can send messages using Uconnect® Phone. To send a new message: 1.
Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 Send Messages Using Voice Commands: 1. Push the button. 2. After the “Listening” prompt and the following beep, say “Send message to John Smith mobile.” 3. After the system prompts you for what message you want to send, say the message you wish to send or say “List.”...
Page 178 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. I can’t talk right now. 17. I’m lost. 5. Call me. 18. See you later. 6. I’ll call you later. Bluetooth® Communication Link Mobile phones have been found to lose connection to the 7.
Page 179 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Voice Tree I n f o r ma t i o n P r o v i d e d b y :...
Page 180 178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: 5. These commands can be used during a phone call after pushing the Uconnect® Voice Command button on 1. You can replace “John Smith” with any name in your the steering wheel. Please note the call will be muted mobile or favorite phone book.
Page 181 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 9. Emergency and Towing assistance are contacts that have been pre-loaded in the phonebook. Commands such as “Call Emergency” and “Call Towing Assis- tance” will call the corresponding number stored with those contacts. NOTE: Available Voice Commands are shown in bold face and underlined in the gray shaded boxes.
Page 182 180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r ma t i o n P r o v i d e d b y :...
Page 183 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 NOTE: 6. You can replace “4” with any message number shown on the screen. 1. You can replace “John Smith” with any name in your mobile or favorite phone book. You can also say “Send 7.
Page 184 182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r ma t i o n P r o v i d e d b y :...
Page 185: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 NOTE: Available Voice Commands are shown in bold VOICE COMMAND face and underlined in the gray shaded boxes. Uconnect® 8.4/8.4 Nav General Information This device complies with Part 15 of the FCC rules and The Uconnect®...
Page 186 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE what can be said based on the context you are in. After WARNING! (Continued) three consecutive failures of a spoken command the VR laws, including laws regarding phone use. Your at- session will end. tention should be focused on safely operating the Pushing the Uconnect®...
Page 187 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 The system will best recognize your speech if the win- The system handles multiple inputs in the same phrase dows are closed, and the heater/air conditioning fan is or sentence such as “make a phone call” and “to Kelly set to low.
Page 188: Uconnect® Voice Commands
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Changing The Volume Uconnect® Voice Commands The Uconnect® Voice Command system understands 1. Start a dialogue by pushing the Voice Command two types of commands. Universal commands are avail- button. able at all times. Local commands are available if the 2.
Page 189 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 Starting Voice Recognition (VR) Session In Radio/Player Modes In this mode, you can say the following commands: NOTE: The commands can be said on any screen when a call is not active after pushing the Uconnect® Voice Command button.
Page 190 188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Tree I n f o r ma t i o n P r o v i d e d b y :...
Page 191 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 NOTE: • You can replace “950 AM” with any other AM or FM frequency, such as “98.7 FM.” • You can replace “80’s on 8” with any other satellite station name received by the radio. •...
Page 192 190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r ma t i o n P r o v i d e d b y :...
Page 193 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 NOTE: • You can replace the album, artist, song, genre, playlist, podcast and audio book names with any correspond- ing names on the current device that is playing. • You can replace “8” with any track on the CD that is currently playing.
Page 194 192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r ma t i o n P r o v i d e d b y :...
Page 195 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 NOTE: • You can replace “NFL” with any league shown on the sports league screen. For example you can say “Show MLB headlines” or “Show PGA headlines.” • You can replace “Headlines” with any menu items shown on a league screen.
Page 196 194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r ma t i o n P r o v i d e d b y :...
Page 197 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 NOTE: • Only available with Navigation equipped vehicles. • You can replace “Player” with “Radio,” “Navigation,” “Phone,” “Climate,” “More” or “Settings.” • Navigation commands only work if equipped with Navigation. NOTE: Available Voice Commands are shown in bold face and shaded grey.
Page 198 196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r ma t i o n P r o v i d e d b y :...
Page 199: Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 NOTE: SEATS Seats are a part of the Occupant Restraint System of the • You can also say “Find City,” “Find Favorite,” “Find vehicle. Play by Category,” “Find Play by Name,” “Find Re- cently Found,”...
Page 200: Driver's Power Seat - If Equipped
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjusting The Seat Forward Or Rearward Driver’s Power Seat — If Equipped The power seat switch is on the outboard side of the seat The seat can be adjusted both forward and rearward. near the floor.
Page 201 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 WARNING! CAUTION! • Adjusting a seat while driving may be dangerous. Do not place any article under a power seat or Moving a seat while driving could result in loss of impede its ability to move as it may cause damage to control which could cause a collision and serious the seat controls.
Page 202: Power Lumbar - If Equipped
200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Lumbar — If Equipped The Power Lumbar switch is located on the outboard side of the driver’s seat. Push the switch forward to increase the lumbar support. Push the switch rearward to de- crease the lumbar support.
Page 203: Front Heated Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 time, the display will change from HI to LO, indicating Front Heated Seats — If Equipped the change. The LO-level setting will turn OFF automati- The front heated seats control buttons are located within cally after approximately 45 minutes.
Page 204: Manual Front Seat Adjustments
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Front Seat Adjustments WARNING! For models equipped with manual seats, the driver and • Persons who are unable to feel pain to the skin passenger seats can be adjusted forward or rearward by because of advanced age, chronic illness, diabetes, using a bar located by the front of the seat cushion, near spinal cord injury, medication, alcohol use, exhaus-...
Page 205: Recliner Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 While sitting in the seat, lift up on the bar located and Recliner Adjustment move the seat forward or rearward. Release the bar once The recline lever is located on the outboard side of the the desired position has been reached.
Page 206: Driver's Seat Height Adjustment - If Equipped
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Driver’s Seat Height Adjustment — If Equipped WARNING! The seat height control lever is located on the outboard • Adjusting a seat while the vehicle is moving is side of the seat. Raise the lever to raise the seat. Lower the dangerous.
Page 207: Fold-Flat Front Passenger Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 Fold-Flat Front Passenger Seat — If Equipped This feature allows for extended cargo space. When the seat is folded flat, it is an extension of the load floor surface (allowing long cargo to fit from the rear hatch up to the instrument panel).
Page 208: Head Restraints
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! WARNING! Adjusting a seat while the vehicle is moving is The head restraints for all occupants must be prop- dangerous. The sudden movement of the seat could erly adjusted prior to operating the vehicle or occu- cause you to lose control.
Page 209 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 When AHRs deploy during a rear impact, the front half of the head restraint extends forward to minimize the gap between the back of the occupant’s head and the AHR. This system is designed to help prevent or reduce the extent of injuries to the driver and front passenger in certain types of rear impacts.
Page 210 208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For comfort, the Active Head Restraints can be tilted forward and backward. To tilt the head restraint closer to the back of your head, pull forward on the bottom of the head restraint. Push rearward on the bottom of the head restraint to move the head restraint away from your head.
Page 211 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 NOTE: WARNING! • The head restraints should only be removed by quali- • Do not place items over the top of the Active Head fied technicians, for service purposes only. If either of Restraint, such as coats, seat covers or portable the head restraints require removal, see your autho- DVD players.
Page 212 210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Head Restraints — Second Row Seats NOTE: The rear seats are equipped with adjustable head re- • The head restraints should only be removed by quali- straints. To raise the head restraint, pull upward on the fied technicians, for service purposes only.
Page 213: Third Row Passenger Seats - Seven Passenger
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 Third Row Passenger Seats — Seven Passenger 60/40 Split Second-Row Passenger Seats Models To provide additional storage area, each second-row These head restraints are non-adjustable and non- passenger seat can be folded flat. This allows for ex- removable.
Page 214 212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts. • Be sure everyone in your vehicle is in a seat and using a seat belt properly.
Page 215 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 Forward And Rearward Adjustment WARNING! The control lever is on the outboard side of the seat. Lift To prevent personal injury or damage to objects, the lever to move the seat forward or rearward. Release keep your head, arms, and objects out of the folding the lever once the seat is in the desired position.
Page 216 214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be adjusted properly and you could be injured. Adjust any seat only while the vehicle is parked.
Page 217 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be adjusted properly and you could be injured. Adjust the seat only while the vehicle is parked.
Page 218 216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Move the control lever on the upper outboard side of the WARNING! seatback forward. Then, in one fluid motion, the seat cushion flips upward and the seat moves forward on its Keep the latch clean and free of objects and be tracks.
Page 219 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 WARNING! Do not drive the vehicle with the seat in this posi- tion, as it is only intended for entering and exiting the third row seats. Failure to follow this warning may result in personal injury. To Unfold And Move The Second-Row Passenger Seat Rearward Move the seatback rearward until it locks in place and...
Page 220: 50/50 Split Third-Row Passenger Seats With
218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Fold The Seatback WARNING! Pull the latch release-loop located at the top of the Be certain that the seatback and seat are locked seatback upward, push the seatback forward slightly, and securely into position. Otherwise, the seat will not release the release-loop.
Page 221 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 To Unfold The Seatback The seatback can also be locked in the reclined position. To do so, pull the latch release-loop located at the top of Grasp the assist strap loop on the seatback and pull it the seatback upward, allow the seatback to recline, and toward you to raise the seatback.
Page 222: To Open And Close The Hood
220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not allow a passenger to sit in a third row seat with the second row seatback(s) folded flat. In a collision, the passenger could slide underneath the seat belt and be seriously or even fatally injured. TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood.
Page 223 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 Underhood Safety Latch Hood Prop Rod 3. Use the hood prop rod to secure the hood in the open CAUTION! position. Place the upper end of the prop rod in the hole on the underside of the hood. To prevent possible damage: •...
Page 224: Lights
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS CAUTION! (Continued) Headlight Switch • Do not slam the hood to close it. Use a firm downward push at the center front edge of the The headlight switch is located on the left side of the hood to ensure that both latches engage.
Page 225: Automatic Headlights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223 Automatic Headlights — If Equipped This system automatically turns the headlights on or off according to ambient light levels. To turn the system on, rotate the headlight switch counterclockwise to the AUTO position. When the system is on, the headlight time delay feature is also on.
Page 226: Headlight Time Delay
224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE is set to ON. In addition, the headlights will turn off NOTE: The lights must be turned off within 45 seconds when the wipers are turned off if they were turned on by of turning the ignition OFF to activate this feature.
Page 227: Lights-On Reminder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 NOTE: The daytime running lights can be turned on and off using the Uconnect® System, refer to “Uconnect® Settings — Customer Programmable Features” in “Un- derstanding Your Instrument Panel” for further informa- tion. Lights-On Reminder If the headlights or parking lights are on after the ignition is placed in the OFF position, a chime will sound to alert...
Page 228: Multifunction Lever
226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE An indicator light in the instrument cluster illuminates when the fog lights are turned on. NOTE: The fog lights will operate when the low beam headlights or parking lights are on. However, selecting the high beam headlights will turn off the fog lights.
Page 229: Lane Change Assist
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 NOTE: High/Low Beam Switch Push the multifunction lever away from you to switch • If either light remains on and does not flash, or there is the headlights to high beam. Pull the multifunction lever a very fast flash rate, check for a defective outside light toward you to switch the headlights back to low beam.
Page 230 228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE light. To restore interior light operation, either place the ignition in the ON/RUN position or cycle the light switch. Dimmer Controls The dimmer control is part of the headlight switch and is located on the left side of the instrument panel. Rotating the dimmer control upward with the parking lights or headlights on will increase the brightness of the instru- ment panel lights, door map pockets and cupholders (if...
Page 231: Map/Reading Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229 Interior Light Defeat (OFF) WINDSHIELD WIPERS AND WASHERS Rotate the dimmer control to the extreme bottom off The windshield wiper/washer control lever is located on position. The interior lights will remain off when the the left side of the steering column.
Page 232: Intermittent Wiper System
230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the rear window wiper/washer, refer to “Rear Window Features” in “Understanding The Features Of Your Ve- hicle”. Intermittent Wiper System Use the intermittent wiper system when weather condi- tions make a single wiping cycle, with a variable pause between cycles, desirable.
Page 233: Windshield Wiper Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 delay varies from a minimum of one cycle every second to a maximum of approximately 18 seconds between cycles. NOTE: The wiper delay times depend on vehicle speed. If the vehicle is moving less than 10 mph (16 km/h), delay times will be doubled.
Page 234: Windshield Washers
232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washers CAUTION! To use the windshield washer, push the washer knob, • Turn the windshield wipers OFF when driving located on the end of the multifunction lever, inward to through an automatic car wash. Damage to the the second detent.
Page 235: Mist Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233 Headlights On With Wipers (Available With WARNING! (Continued) Automatic Headlights Only) the windshield during freezing weather, warm the When this feature is active, the headlights will turn on windshield with the defroster before and during after the wipers are turned on if the headlight switch is windshield washer use.
Page 236 234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To unlock the steering column, push the control handle TILT/TELESCOPING STEERING COLUMN downward. To tilt the steering column, move the steering This feature allows you to tilt the steering column wheel upward or downward as desired. To lengthen or upward or downward.
Page 237: Heated Steering Wheel - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235 NOTE: The engine must be running for the heated HEATED STEERING WHEEL — IF EQUIPPED steering wheel to operate. The steering wheel contains a heating element that helps warm your hands in cold weather. The heated steering Vehicles Equipped With Remote Start wheel has only one temperature setting.
Page 238: Electronic Speed Control - If Equipped
236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Electronic Speed Control buttons are located on the WARNING! right side of the steering wheel. • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion, or other physical conditions must exercise care when using the steering wheel heater.
Page 239: To Activate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237 NOTE: In order to ensure proper operation, the Elec- WARNING! tronic Speed Control System has been designed to shut down if multiple Speed Control functions are operated at Leaving the Electronic Speed Control system on the same time.
Page 240: To Deactivate
238 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The speed increment shown is dependant on the selected To Deactivate speed unit of U.S. (mph) or Metric (km/h): A soft tap on the brake pedal, pushing the CANCEL button, or normal brake pressure while slowing the U.S.
Page 241: To Accelerate For Passing
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239 To Decrease Speed • If the button is continually pressed, the set speed will continue to decrease until the button is released, then When the Electronic Speed Control is set, you can de- the new set speed will be established.
Page 242: Parksense® Rear Park Assist - If Equipped
240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ParkSense® will retain the last system state (enabled or WARNING! disabled) from the last ignition cycle when the ignition is changed to the ON/RUN position. Electronic Speed Control can be dangerous where the system cannot maintain a constant speed.
Page 243: Parksense® Warning Display
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 241 ParkSense® Warning Display The ParkSense® Warning screen will only be displayed if Sound and Display is selected from the Uconnect® System. Refer to “Uconnect® Settings” in “Understand- ing Your Instrument Panel” for further information. The ParkSense®...
Page 244 242 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Park Assist System Off Slow Tone The system will indicate a detected obstacle by showing three solid arcs and will produce a one-half second tone. As the vehicle moves closer to the obstacle, the EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
Page 245 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 243 Fast Tone Continuous Tone I n f o r ma t i o n P r o v i d e d b y :...
Page 246: Enabling And Disabling Parksense
244 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle: WARNING ALERTS Rear Distance Greater than...
Page 247: Service The Parksense® Rear Park Assist System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 245 and the system is disabled, the EVIC will display the ASSIST , OR SERVICE PARK ASSIST SYSTEM mes- “PARK ASSIST SYSTEM OFF” message for as long as the sages for as long as the vehicle is in REVERSE. Under this vehicle is in REVERSE.
Page 248: Parksense® System Usage Precautions
246 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Clean the ParkSense® sensors regularly, taking care ParkSense® System Usage Precautions not to scratch or damage them. The sensors must not NOTE: be covered with ice, snow, slush, mud, dirt or debris. •...
Page 249 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 247 CAUTION! WARNING! • ParkSense® is only a parking aid and it is unable to • Drivers must be careful when backing up even recognize every obstacle, including small obstacles. when using ParkSense®. Always check carefully Parking curbs might be temporarily detected or not behind your vehicle, look behind you, and be sure detected at all.
Page 250: Parkview® Rear Back Up Camera - If Equipped
248 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the shift lever is put into REVERSE. The ParkView® WARNING! (Continued) camera is located on the rear of the vehicle above the rear • Before using ParkSense®, it is strongly recom- License plate. The image will be displayed in the touch- mended that the ball mount and hitch ball assem- screen display along with a caution note to “check entire bly is disconnected from the vehicle when the...
Page 251 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 249 vehicle to assist with parking or aligning to a hitch/ Different colored zones indicate the distance to the rear of receiver. The static grid lines will show separate zones the vehicle. that will help indicate the distance to the rear of the The following table shows the approximate distances for vehicle.
Page 252: Overhead Console
250 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! CAUTION! (Continued) • To avoid vehicle damage, the vehicle must be Drivers must be careful when backing up even when driven slowly when using ParkView® to be able to using the ParkView® Rear Back Up Camera. Always stop in time when an obstacle is seen.
Page 253: Courtesy/Reading Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 251 courtesy lights also function as reading lights. Press in on each lens to turn these lights on while inside the vehicle. Press the lens a second time to turn each light off. You may adjust the direction of these lights by pressing the outside ring, which is identified with four directional arrows.
Page 254: Sunglasses Storage
252 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunglasses Storage Interior Observation Mirror To access the storage compartment, press on the raised The convex interior observation mirror provides the bars on the compartment door in the center of the console driver and front seat passenger a wide field of view to and release and the door will swing downward.
Page 255: Power Sunroof Switch - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 253 GARAGE DOOR OPENER — IF EQUIPPED HomeLink® replaces up to three remote controls (hand- held transmitters) that operate devices such as garage door openers, motorized gates, lighting or home security systems. The HomeLink® unit operates off your vehicle’s battery.
Page 256 254 UNDERSTANDING THE FEATURES OF YOUR VEHICLE HomeLink® Buttons/Overhead Consoles HomeLink® Buttons/Sunvisor/Headliner NOTE: HomeLink® is disabled when the Vehicle Secu- rity Alarm is active. I n f o r ma t i o n P r o v i d e d b y :...
Page 257: Before You Begin Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255 NOTE: Before You Begin Programming HomeLink® Be sure that your vehicle is parked outside of the garage • Erasing all channels should only be performed when before you begin programming. programming HomeLink® for the first time. Do not erase channels when programming additional buttons.
Page 258: Programming A Rolling Code
256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming A Rolling Code For programming garage door openers that were manu- factured after 1995. These garage door openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener.
Page 259 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) Firmly push and release the “LEARN” or “TRAIN- away from the HomeLink® button you wish to pro- ING” button. On some garage door openers/devices gram while keeping the HomeLink®...
Page 260: Programming A Non-Rolling Code
258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reprogramming A Single HomeLink® Button 2. Place the hand-held transmitter 1 to 3 inches (3 to (Rolling Code) 8 cm) away from the HomeLink® button you wish to program while keeping the HomeLink® indicator To reprogram a channel that has been previously trained, light in view.
Page 261: Canadian/Gate Operator Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259 • To program the two remaining HomeLink® buttons, Canadian/Gate Operator Programming repeat each step for each remaining button. DO NOT For programming transmitters in Canada/United States erase the channels. that require the transmitter signals to “time-out” after several seconds of transmission.
Page 262 260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Place the hand-held transmitter 1 to 3 inches (3 to • If the indicator light stays on constantly, program- 8 cm) away from the HomeLink® button you wish to ming is complete and the garage door/device should program while keeping the HomeLink®...
Page 263: Using Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261 3. Without releasing button proceed with The HomeLink® Universal Transceiver is disabled when “Canadian/Gate Operator Programming” step 2 and the Vehicle Security Alarm is active. follow all remaining steps. Troubleshooting Tips Using HomeLink® If you are having trouble programming HomeLink®, To operate, push and release the programmed here are some of the most common solutions:...
Page 264: General Information
262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! WARNING! (Continued) use a garage door opener without these safety fea- Vehicle exhaust contains carbon monoxide, a danger- tures. Call toll-free 1–800–355–3515 or, on the Internet ous gas. Do not run your vehicle in the garage while at www.HomeLink.com for safety information or programming the transceiver.
Page 265: Power Sunroof - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263 NOTE: POWER SUNROOF — IF EQUIPPED The power sunroof switch is located between the sun • The transmitter has been tested and it complies with visors on the overhead console. FCC and IC rules. Changes or modifications not ex- pressly approved by the party responsible for compli- ance could void the user’s authority to operate the device.
Page 266: Opening Sunroof - Express
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! WARNING! (Continued) • Do not allow small children to operate the sunroof. • Never leave children unattended in a vehicle, or Never allow your fingers, other body parts, or any with access to an unlocked vehicle. Never leave the object, to project through the sunroof opening.
Page 267: Closing Sunroof - Express
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265 movement. The sunroof and sunshade will remain in a Sunroof Fully Closed partially opened condition until the switch is pushed and Press the switch forward and release to ensure that the held rearward again. sunroof is fully closed.
Page 268: Sunshade Operation
266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunshade Operation Sunroof Maintenance The sunshade can be opened manually. However, the Use only a nonabrasive cleaner and a soft cloth to clean sunshade will open automatically as the sunroof opens. the glass panel. NOTE: The sunshade cannot be closed if the sunroof is Ignition Off Operation open.
Page 269 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267 A second 12 Volt (13 Amp) power outlet is located inside the center console storage area. Power is available with the ignition is in the ON/RUN, ACC or LOCK position. Front 12 Volt Power Outlet This power outlet will also operate a conventional cigar lighter unit.
Page 270 268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE A third fused 12 Volt power outlet is located on the back A fourth fused 12 Volt power outlet is located on the left of the center console. This power outlet has power quarter trim panel in the cargo area.
Page 271 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269 NOTE: To ensure proper operation a MOPAR® knob and element must be used. CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced.
Page 272 270 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! CAUTION! To avoid serious injury or death: • Many accessories that can be plugged in draw • Only devices designed for use in this type of outlet power from the vehicle’s battery, even when not in should be inserted into any 12 Volt outlet.
Page 273: Power Inverter - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 271 CAUTION! (Continued) • Power outlets are designed for accessory plugs only. Do not hang any type of accessory or acces- sory bracket from the plug. POWER INVERTER — IF EQUIPPED Your vehicle may be equipped with a 115 Volt AC (150 Watt maximum) power outlet located on the back of the center console.
Page 274: Power Inverter Operation
272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE may have to be reset manually. To reset the inverter Power Inverter Operation manually press the power inverter button OFF and ON. The power inverter is turned on and off using the To avoid overloading the circuit, check the power ratings Uconnect®...
Page 275: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273 When the armrest is folded flat the cupholders are in the CUPHOLDERS back of the Head Restraint. The Head Restraint can be There are two cupholders, located in the center floor adjusted to better position the cupholders. console, for the front passengers.
Page 276: Storage
274 UNDERSTANDING THE FEATURES OF YOUR VEHICLE In addition to cupholders, vehicles may also be equipped WARNING! with bottle holders. The bottle holders are located on the door trim panels. If containers of hot liquid are placed in the bottle holder, they can spill when the door is closed, burn- ing the occupants.
Page 277: Floor Console Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 275 Floor Console Storage An open storage area, or cubby bin, is located in the floor console. Glove Compartment Floor Console Cubby Bin I n f o r ma t i o n P r o v i d e d b y :...
Page 278: Center Console Storage
276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Center Console Storage There is a storage tray and storage compartment located under the center console armrest. Center Console Storage Tray The storage tray can be slid forward and rearward or removed to access the center console storage compart- ment.
Page 279 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277 Sliding Armrest The center console armrest can also be slid rearward for easy access to the storage area. Center Console Storage Compartment WARNING! Do not operate this vehicle with a console compart- Sliding Armrest ment lid in the open position.
Page 280: Flip 'N Stow™ Front Passenger Seat Storage - If Equipped
278 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not operate this vehicle with a console compart- ment lid in the open position. Driving with the console compartment lid open may result in injury in a collision. Flip ’n Stow™ Front Passenger Seat Storage — If Equipped The seat latch release-loop is located in the center of the seat cushion between the seat cushion and the seatback.
Page 281: Second-Row Passenger Seat Temporary Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 279 WARNING! Be certain that the seat cushion is locked securely into position before using the seat. Otherwise, the seat will not provide the proper stability for passen- gers. An improperly latched seat cushion could cause serious injury.
Page 282: Cargo Area Features
280 UNDERSTANDING THE FEATURES OF YOUR VEHICLE cans, plus ice, or other items. The removable bin liner allows for easy filling, emptying, and cleaning. To access the bin, position the floor mat aside (if equipped). Pull the door latch release-loop upward to release the latch and then forward to open the bin door.
Page 283 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 281 Rechargeable Flashlight Three-Press Switch To operate the flashlight, press the switch once for high, NOTE: Be sure to return the flashlight to its charging twice for low, and a third time to return to off. station when not in use to ensure it is ready for operation the next time you need it.
Page 284: Cargo Management System
282 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seven Passenger System Features Cargo Management System Five Passenger System Features • A large built-in storage bin with a hinged hardcover located in the floor behind the third-row passenger • A raised load floor that sits on top of a large built-in seats.
Page 285 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 283 Cargo Tie-Downs WARNING! Cargo tie-downs are not safe anchors for a child seat tether strap. In a sudden stop or collision, a tie-down could pull loose and allow the child seat to come loose.
Page 286 284 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • To help protect against personal injury, passengers WARNING! (Continued) should not be seated in the rear cargo area. The rear handling. To avoid loss of control resulting in per- cargo space is intended for load carrying purposes sonal injury, follow these guidelines for loading your only, not for passengers, who should sit in seats and vehicle:...
Page 287 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 285 The cover rolls away neatly inside its housing when not in use. You can also remove the cover from the vehicle to make more room in the cargo area. To install the cover, position it in the vehicle so that the flat side of the housing faces upward.
Page 288: Rear Window Features
286 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the trim panels. Lower the cover to position the posts into WARNING! the bottom of the notches and release the handle. A cargo cover that is unsecured in the vehicle could cause injury in a collision. It could become airborne during a sudden stop and strike someone inside the vehicle.
Page 289 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 287 pump will continue to operate as long as the switch is held. Upon release, the wiper will cycle three times before returning to the set position. Rear Wiper/Washer Rotate the switch upward to the first detent position for rear wiper operation.
Page 290: Rear Window Defroster
288 UNDERSTANDING THE FEATURES OF YOUR VEHICLE wiper will resume function at whichever position the CAUTION! (Continued) switch is set at. • Always remove any buildup of snow that prevents the rear wiper blade from returning to the park CAUTION! position.
Page 291: Roof Luggage Rack - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 289 NOTE: To prevent excessive battery drain, use the rear ROOF LUGGAGE RACK — IF EQUIPPED window defroster only when the engine is operating. The roof rack cross rails and side rails are designed to carry cargo weight.
Page 292 290 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Move The Crossbars the outboard surface of the side rail for proper posi- tioning. There are four frontward marks for the front 1. Loosen the knobs on top of each crossbar approxi- crossbar and four rearward marks for the rear cross- mately six turns to disengage the clamp tooth from the bar.
Page 293 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 291 the eighth position. The tie down holes on the crossbar CAUTION! (Continued) ends should always be used to tie down the load. • To avoid damage to the roof rack and vehicle, do Check the straps frequently to be sure that the load not exceed the maximum roof rack load capacity of remains securely attached.
Page 294 292 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in per- sonal injury or property damage. Follow the roof rack cautions when carrying cargo on your roof rack.
Page 295: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS INSTRUMENT PANEL FEATURES ..296 ▫ Oil Change Due ..... .315 INSTRUMENT CLUSTER .
Page 296 294 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Buttons On The Touchscreen....320 ▫ Important Notes For Single Video Screen System ......351 ▫...
Page 297 UNDERSTANDING YOUR INSTRUMENT PANEL 295 iPod®/USB/MP3 CONTROL ....370 CLIMATE CONTROLS ....373 STEERING WHEEL AUDIO CONTROLS .
Page 298: Instrument Panel Features
296 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Side Window Demist Outlet 6 — Switch Bank 11 — Engine Start/Stop Button 2 — Air Outlet 7 — Uconnect® Hard Controls 12 — Hood Release Lever 3 — Instrument Cluster 8 —...
Page 299: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 297 INSTRUMENT CLUSTER I n f o r ma t i o n P r o v i d e d b y :...
Page 300: Instrument Cluster Descriptions
298 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Malfunction Indicator Light (MIL) INSTRUMENT CLUSTER DESCRIPTIONS 1. Tachometer The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system, called OBD II, that This gauge measures engine revolutions per minute monitors engine and automatic transmission con- (RPM x 1000).
Page 301 UNDERSTANDING YOUR INSTRUMENT PANEL 299 4. Electronic Stability Control (ESC) Activation/ CAUTION! Malfunction Indicator Light — If Equipped Prolonged driving with the Malfunction Indicator If the “ESC Activation/Malfunction Indicator Light (MIL) on could cause damage to the engine Light” comes on continuously with the engine control system.
Page 302 300 UNDERSTANDING YOUR INSTRUMENT PANEL 5. Turn Signal Indicators 8. Electronic Vehicle Information Center (EVIC) Display / Odometer Display The arrow will flash with the exterior turn signal when the turn signal lever is operated. Odometer Display The odometer display shows the total distance the vehicle has been driven.
Page 303 UNDERSTANDING YOUR INSTRUMENT PANEL 301 Electronic Vehicle Information Center (EVIC) Display vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those The Electronic Vehicle Information Center (EVIC) fea- tires.) tures a driver-interactive display that is located in the As an added safety feature, your vehicle has been instrument cluster.
Page 304 302 UNDERSTANDING YOUR INSTRUMENT PANEL Your vehicle has also been equipped with a TPMS CAUTION! malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is The TPMS has been optimized for the original combined with the low tire pressure telltale. When the equipment tires and wheels.
Page 305 UNDERSTANDING YOUR INSTRUMENT PANEL 303 if the driver’s seat belt remains unbuckled, the Seat Belt has been corrected. If the problem is related to the brake Reminder Light will illuminate and the chime will sound. booster, the ABS pump will run when applying the brake Refer to “Occupant Restraints”...
Page 306 304 UNDERSTANDING YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is WARNING! applied with the ignition switch in the ON/RUN posi- tion. Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. NOTE: This light shows only that the parking brake is It will take longer to stop the vehicle.
Page 307 UNDERSTANDING YOUR INSTRUMENT PANEL 305 brakes. If the ABS light does not turn on when the 17. Vehicle Security Light — If Equipped ignition switch is turned to the ON/RUN position, have This light will flash at a fast rate for approxi- the light inspected by an authorized dealer.
Page 308 306 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! WARNING! Driving with a hot engine cooling system could A hot engine cooling system is dangerous. You or damage your vehicle. If the temperature gauge reads others could be badly burned by steam or boiling “H”...
Page 309: Electronic Vehicle Information Center (Evic)
UNDERSTANDING YOUR INSTRUMENT PANEL 307 This system allows the driver to select a variety of useful ELECTRONIC VEHICLE INFORMATION CENTER information by pushing the switches mounted on the (EVIC) steering wheel. The EVIC consists of the following: The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the •...
Page 310 308 UNDERSTANDING YOUR INSTRUMENT PANEL The system allows the driver to select information by • UP Button pushing the following buttons mounted on the steering Push and release the UP button to scroll up- wheel: ward through the main menus and submenus. •...
Page 311: Electronic Vehicle Information Center (Evic) Displays
UNDERSTANDING YOUR INSTRUMENT PANEL 309 • Five Second Stored Messages Electronic Vehicle Information Center (EVIC) Displays When the appropriate conditions occur, this type of The EVIC display consists of three sections: message takes control of the main display area for five seconds and then returns to the previous screen.
Page 312 310 UNDERSTANDING YOUR INSTRUMENT PANEL • Unstored Messages Until RUN When the appropriate conditions exist, the EVIC displays the following messages: These messages deal primarily with the Remote Start feature. This message type is displayed until the ignition • Remote start aborted — Door ajar is in the RUN state.
Page 313 UNDERSTANDING YOUR INSTRUMENT PANEL 311 • Turn Signal On (with a continuous warning chime if • Channel # Transmit the vehicle is driven more than 1 mile [1.6 km] with • Channel # Training either turn signal on) • Channel # Trained •...
Page 314: Evic White Indicators
312 UNDERSTANDING YOUR INSTRUMENT PANEL • Electronic Speed Control SET EVIC White Indicators This area will show reconfigurable white caution tell- This light will turn on when the electronic tales. These telltales include: speed control is SET. For further information, refer to “Electronic Speed Control”...
Page 315: Evic Red Indicators
UNDERSTANDING YOUR INSTRUMENT PANEL 313 • Oil Pressure Warning Light EVIC Red Indicators This area will show reconfigurable red telltales. These This light indicates low engine oil pressure. If the telltales include: light turns on while driving, stop the vehicle and shut off the engine as soon as possible.
Page 316 314 UNDERSTANDING YOUR INSTRUMENT PANEL vehicle is experiencing a problem with the charging If the light remains lit with the engine running, your system. Obtain SERVICE IMMEDIATELY. See an autho- vehicle will usually be drivable. However, see an autho- rized dealer. rized dealer for service as soon as possible.
Page 317: Oil Change Due
UNDERSTANDING YOUR INSTRUMENT PANEL 315 shift the transmission into NEUTRAL and idle the ve- WARNING! hicle. If the temperature reading does not return to normal, turn the engine off immediately and call for If you continue operating the vehicle when the service.
Page 318: Fuel Economy
316 UNDERSTANDING YOUR INSTRUMENT PANEL Unless reset, this message will continue to display each Fuel Economy time you cycle the ignition to the ON/RUN position. To Push and release the UP or DOWN button until “Fuel turn off the message temporarily, push and release the Economy”...
Page 319 UNDERSTANDING YOUR INSTRUMENT PANEL 317 and average fuel economy, according to the current fuel tank level. DTE cannot be reset through the RIGHT arrow button. NOTE: Significant changes in driving style or vehicle loading will greatly affect the actual drivable distance of the vehicle, regardless of the DTE displayed value.
Page 320: Vehicle Speed
318 UNDERSTANDING YOUR INSTRUMENT PANEL selected feature to reset individually. The three features Vehicle Speed can only be reset individually. The following Trip func- Push and release the UP or DOWN button until “Vehicle tions display in the EVIC: Speed” displays highlighted in the EVIC. Push the SE- LECT button to display the current speed in mph or •...
Page 321: Tire Psi
UNDERSTANDING YOUR INSTRUMENT PANEL 319 Elapsed Time Vehicle Info (Customer Information Features) Shows the total elapsed time of travel since the last reset. Push and release the UP or DOWN button until “Vehicle Elapsed time will increment when the ignition is in the Info”...
Page 322: Messages
320 UNDERSTANDING YOUR INSTRUMENT PANEL Messages Uconnect® SETTINGS Push and release the UP or DOWN button until “Mes- The Uconnect® system uses a combination of buttons on sages: XX” displays highlighted in the EVIC. If there is the touchscreen and buttons on the faceplate located on more than one message, pushing the SELECT button will the center of the instrument panel that allows you to display a stored warning message.
Page 323: Customer Programmable Features
UNDERSTANDING YOUR INSTRUMENT PANEL 321 Customer Programmable Features — Uconnect® 4.3 Settings In this mode the Uconnect® system allows you to access programmable features that may be equipped such as Display, Clock, Safety & Driving Assistance, Lights, Doors & Locks, Heated Seats, Engine Off Operation, Compass Settings, Audio, Phone/Bluetooth®...
Page 324 322 UNDERSTANDING YOUR INSTRUMENT PANEL setting buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the touchscreen. Then press the back arrow button on the touchscreen. • Mode Press the “Mode” button on the touchscreen to change this display.
Page 325 UNDERSTANDING YOUR INSTRUMENT PANEL 323 the language preferred. Then press the back arrow button • Touchscreen Beep on the touchscreen. As you continue, the information will Press the “Touchscreen Beep” button on the touchscreen display in the selected language. to turn on or shut off the sound heard when a button on •...
Page 326 324 UNDERSTANDING YOUR INSTRUMENT PANEL • Show Time Status Safety & Driving Assistance • Park Assist Press the “Show Time Status” button on the touchscreen to change this display. When in this display, you may Press the “Park Assist” button on the touchscreen to turn on or shut off the digital clock in the status bar.
Page 327 UNDERSTANDING YOUR INSTRUMENT PANEL 325 Brake Control System” in “Starting And Operating” for • Headlights With Wipers system function and operating information. To make Press the “Headlights With Wipers” button on the touch- your selection, press the “Hill Start Assist” button on the screen to change this display.
Page 328 326 UNDERSTANDING YOUR INSTRUMENT PANEL touchscreen. Refer to “Lights/SmartBeam™ — If the “Steering Directed Lights” button on the touchscreen Equipped” in “Understanding The Features Of Your and select “ON” or ‘OFF.” Then press the back arrow Vehicle” for further information. button on the touchscreen.
Page 329 UNDERSTANDING YOUR INSTRUMENT PANEL 327 Doors & Locks • Flash Lamps With Lock • Auto Unlock On Exit Press the “Flash Lamps With Lock” button on the touch- screen to change this display. When this feature is se- Press the “Auto Unlock On Exit” button on the touch- lected, the exterior lamps will flash when the doors are screen to change this display.
Page 330 328 UNDERSTANDING YOUR INSTRUMENT PANEL • Sounds Horn With Lock passenger’s doors. When Unlock All Doors On 1st Press is selected, all of the doors will unlock on the first press Press the “Sounds Horn With Lock” button on the of the RKE transmitter UNLOCK button.
Page 331 UNDERSTANDING YOUR INSTRUMENT PANEL 329 • Passive Entry (Keyless Enter-N-Go™) Seats” button on the touchscreen and select “ON” or “OFF.” Then press the back arrow button on the touch- Press the “Passive Entry” button on the touchscreen to screen. change this display. This feature allows you to lock and unlock the vehicle’s door(s) without having to press the Engine Off Options RKE transmitter lock or unlock buttons.
Page 332 330 UNDERSTANDING YOUR INSTRUMENT PANEL equipped), power sunroof (if equipped), and power NOTE: Keep magnetic materials away from the top of the outlets will remain active for up to 10 minutes after the instrument panel, such as iPod’s, Mobile Phones, Lap- ignition is cycled to OFF.
Page 333 UNDERSTANDING YOUR INSTRUMENT PANEL 331 • Calibration Audio • Equalizer Press the “Calibration” button on the touchscreen to change this setting. This compass is self-calibrating, Press the “Equalizer” button on the touchscreen to which eliminates the need to manually reset the compass. change this display.
Page 334 332 UNDERSTANDING YOUR INSTRUMENT PANEL • Speed Adjusted Volume “Surround Sound” button on the touchscreen and select “ON” or “OFF.” Then press the back arrow button on the Press the “Speed Adjusted Volume” button on the touch- touchscreen. screen to change this display. This feature increases or decreases volume relative to vehicle speed.
Page 335: Customer Programmable Features - Uconnect® System 8.4 Settings
UNDERSTANDING YOUR INSTRUMENT PANEL 333 • Subscription Info Customer Programmable Features — Uconnect® System 8.4 Settings New vehicle purchasers or lessees will receive a free Press the “More” button on the touchscreen, then press limited time subscription to SIRIUS Satellite Radio with the “Settings”...
Page 336 334 UNDERSTANDING YOUR INSTRUMENT PANEL Once the setting is complete press the Back Arrow button • Display Brightness With Headlights ON on the touchscreen to return to the previous menu or When in this display, you may select the brightness with press the “X”...
Page 337 UNDERSTANDING YOUR INSTRUMENT PANEL 335 functions and the navigation system (if equipped). Press Length, press the “Brief” or “Detailed” button on the the “Set Language” button on the touchscreen and then touchscreen until a check-mark appears next to the press the desired language button on the touchscreen setting, showing that setting has been selected.
Page 338 336 UNDERSTANDING YOUR INSTRUMENT PANEL Cluster” button on the touchscreen, until a check-mark • Sync With GPS Time — If Equipped appears next to the setting, showing that setting has been When in this display, you may automatically have the selected.
Page 339 UNDERSTANDING YOUR INSTRUMENT PANEL 337 • Set Time Minutes • Show Time In Status Bar — If Equipped When in this display, you may adjust the minutes. The When in this display, you may turn on or shut off the “Sync with GPS Time”...
Page 340 338 UNDERSTANDING YOUR INSTRUMENT PANEL Assist status, press and release the “OFF,” “Sound Only” of the vehicle above the rear License plate. To make your or “Sounds and Display” button. Then press the back selection, press the “ParkView® Backup Camera” button arrow button on the touchscreen.
Page 341 UNDERSTANDING YOUR INSTRUMENT PANEL 339 Lights transmitter. To change the Illuminated Approach status, press the “+” or “–” button on the touchscreen to select After pressing the Lights button on the touchscreen the your desired time interval. Press the back arrow button following settings will be available.
Page 342 340 UNDERSTANDING YOUR INSTRUMENT PANEL make your selection, press the “Auto High Beams” • Steering Directed Headlights — If Equipped button on the touchscreen, until a check-mark appears When this feature is selected, the headlights turn relative next to setting, showing that setting has been selected. to a change in direction of the steering wheel.
Page 343 UNDERSTANDING YOUR INSTRUMENT PANEL 341 Doors & Locks appears next to setting, indicating that the setting has been selected. Press the back arrow button on the touch- After pressing the Doors & Locks button on the touch- screen to return to the previous menu. screen the following settings will be available.
Page 344 342 UNDERSTANDING YOUR INSTRUMENT PANEL • Sound Horn With Remote Start NOTE: If the vehicle is programmed to Unlock All Doors 1st Press, all doors will unlock no matter which Passive When this feature is selected, the horn will sound when Entry equipped door handle is grasped.
Page 345 UNDERSTANDING YOUR INSTRUMENT PANEL 343 arrow button on the touchscreen to return to the previous • Auto-On Driver Heated Seat With Vehicle Start — If menu. Refer to “Keyless Enter-N-Go™” in “Things To Equipped Know Before Starting Your Vehicle.” When this feature is selected the driver’s heated seat will Auto-On Comfort &...
Page 346 344 UNDERSTANDING YOUR INSTRUMENT PANEL after the ignition is cycled to OFF. Opening either front Compass Settings door will cancel this feature. To change the Engine Off After pressing the Compass Settings button on the touch- Power Delay status press the “0 seconds,” “45 seconds, screen the following settings will be available.
Page 347 UNDERSTANDING YOUR INSTRUMENT PANEL 345 the compass by pressing the “ON” button on the touch- screen and completing one or more 360-degree turns (in an area free from large metal or metallic objects) until the CAL indicator displayed in the EVIC turns off. The compass will now function normally.
Page 348 346 UNDERSTANDING YOUR INSTRUMENT PANEL point on the scale between the “+” and “–” buttons on the Phone/Bluetooth® touchscreen. Then press the back arrow button on the After pressing the “Phone/Bluetooth®” button on the touchscreen. touchscreen the following settings will be available. NOTE: Bass/Mid/Treble allow you to simply slide your •...
Page 349: Uconnect® Multimedia - Video
UNDERSTANDING YOUR INSTRUMENT PANEL 347 touchscreen, select the channels you would like to skip Uconnect® MULTIMEDIA — VIDEO followed by pressing the back arrow button on the ENTERTAINMENT SYSTEM (VES™) — IF touchscreen. EQUIPPED • Subscription Information Your rear seat Video Entertainment System (VES™) is designed to give your family years of enjoyment.
Page 350: Getting Started
348 UNDERSTANDING YOUR INSTRUMENT PANEL • With the ignition switch in the ON or ACC position, Getting Started turn the radio on by pushing the ON/OFF Volume • Screen located in the overhead console: Unfold the Control knob. overhead LCD screen by pushing the button on the overhead console behind the screen.
Page 351: Play Video Games
UNDERSTANDING YOUR INSTRUMENT PANEL 349 2. Insert the DVD with the label facing up. The radio Play Video Games automatically selects the appropriate mode after the Connect the video game console to the Auxiliary RCA disc is recognized and displays the menu screen or input jacks located on the back of the center console.
Page 352: Listen To An Audio Source On Channel 2 While A
350 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Certain high-end video games, such as Playsta- 2. Press the “Rear Entertainment” button on the touch- tion3 and XBox360 will exceed the power limit of the screen to display the Rear Entertainment Controls. vehicle’s Power Inverter. Refer to the Power Inverter 3.
Page 353: Important Notes For Single Video Screen System
UNDERSTANDING YOUR INSTRUMENT PANEL 351 2. While looking at the video screen, either press Up/ Important Notes For Single Video Screen System Down/Left/Right on the Remote Control to highlight • VES™ is able to transmit two channels of stereo audio the desired audio source or repeatedly push the simultaneously.
Page 354: Play A Dvd Using The Touchscreen Radio
352 UNDERSTANDING YOUR INSTRUMENT PANEL be stopped, and the shift lever must be in the PARK Play A DVD Using The Touchscreen Radio position for vehicles with automatic transmission. In 1. Insert the DVD with the label facing up. The radio vehicles with manual transmission the parking brake automatically selects the appropriate mode after the must be engaged even when the vehicle is parked.
Page 355: Ves™ Remote Control - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 353 Controls And Indicators VES™ Remote Control — If Equipped 1. Power – Turns the screen and wireless headphone transmitter for the selected Channel on or off. To hear audio while the screen is closed, push the Power button to turn the headphone transmitter on.
Page 356 354 UNDERSTANDING YOUR INSTRUMENT PANEL switch is in the Channel 2, position the remote controls 10. PROG Up/Down – When listening to a radio mode, the functionality of headphone Channel 2 (left side of pushing PROG Up selects the next preset and push- the screen).
Page 357 UNDERSTANDING YOUR INSTRUMENT PANEL 355 is selected and the disc is stopped, push the SETUP 18. ENTER – Push to select the highlighted option in a button to access the DVD Setup menu. (see the DVD menu. Setup Menu of this manual.) / NEXT –...
Page 358: Remote Control Storage
356 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Control Storage The video screen(s) come with a built in storage compart- ment for the remote control which is accessible when the screen is opened. To remove the remote, use your index finger to pull and rotate the remote towards you. Do not try to pull the remote straight down as it will be very difficult to remove.
Page 359: Locking The Remote Control
UNDERSTANDING YOUR INSTRUMENT PANEL 357 Locking The Remote Control Replacing The Remote Control Batteries All remote control functionality can be disabled as a The remote control requires two AAA batteries for op- parental control feature. eration. To replace the batteries: 1.
Page 360: Replacing The Headphone Batteries
358 UNDERSTANDING YOUR INSTRUMENT PANEL channel. If audio is still not heard, check that fully Replacing The Headphone Batteries charged batteries are installed in the headphones. Each set of headphones requires two AAA batteries for operation. To replace the batteries: •...
Page 361: Unwired® Stereo Headphone Lifetime Limited Warranty
UNDERSTANDING YOUR INSTRUMENT PANEL 359 NOTE: The rear video system must be turned on before 3. If the video screen is displaying a video source (such sound can be heard from the headphones. To conserve as a DVD Video), pushing STATUS shows the status battery life, the headphones will automatically turn off on a popup banner at the bottom of the screen.
Page 362 360 UNDERSTANDING YOUR INSTRUMENT PANEL particular Unwired Technology LLC ( Unwired ) wire- FOR ANY GENERAL, SPECIAL, DIRECT, INDIRECT, less headphone ( Product ). The warranty is not transfer- INCIDENTAL, CONSEQUENTIAL, EXEMPLARY, PU- able. NITIVE OR OTHER DAMAGES OF ANY KIND OR NATURE WHATSOEVER.
Page 363: System Information
UNDERSTANDING YOUR INSTRUMENT PANEL 361 If you have any questions or comments regarding your System Information Unwired® wireless headphones, please phone 1-888-293- Information Mode Display 3332 or email customersupport@unwiredtechnology.com. You may register your Unwired® wireless headphones online at www.unwiredtechnology.com or by phone at 1-888-293-3332.
Page 364 362 UNDERSTANDING YOUR INSTRUMENT PANEL to the items called out by number, the remaining infor- on Channel 2 when Channel 1 is in a video mode. mation displays the current status of the source (such as Mute: when the Mute icon is displayed, the audio for station frequency, name, preset or track number, song Channel 2 has been muted using the remote control’s title, artist name, album name, etc.).
Page 365 UNDERSTANDING YOUR INSTRUMENT PANEL 363 Numeric Keypad Menu When the display for either Channel 1 or Channel 2 shows DIRECT TUNE, pushing the remote control’s ENTER button activates a numeric keypad menu. This screen makes it easy to enter a specific tuner frequency or track number.
Page 366 364 UNDERSTANDING YOUR INSTRUMENT PANEL Station List Menu Options Menu When listening to Satellite audio, pushing the remote control’s MENU button displays a list of all available channels. Navigate this list using the remote control’s navigation buttons to find the desired station, push the remote control’s ENTER button to tune to that station.
Page 367 UNDERSTANDING YOUR INSTRUMENT PANEL 365 Display Settings Listening To Audio With The Screen Closed When watching a video source (DVD Video with the disc To listen to only audio portion of the channel with the in Play mode, Aux Video, etc.), pushing the remote screen closed: control’s SETUP button activates the Display Settings •...
Page 368 366 UNDERSTANDING YOUR INSTRUMENT PANEL Disc Formats DVD Audio Support The DVD player is capable of playing the following types When a DVD-Audio disc is inserted in the DVD player, of discs (12 cm or 8 cm diameter): the DVD-Audio title on the disc is played by default (most DVD-Audio discs also have a Video title, but the •...
Page 369 UNDERSTANDING YOUR INSTRUMENT PANEL 367 If you record a disc using a personal computer, there may • Mixed media recordable DVD formats will only play be cases where the DVD player may not be able to play the Video_TS portion of the disc. some or the entire disc, even if it is recorded in a If you are still having trouble writing a disc that is compatible format and is playable on other players.
Page 370 368 UNDERSTANDING YOUR INSTRUMENT PANEL Windows Media Audio) and ACC (MPEG-4 audio; sam- • Other compression formats such as AAC, MP3 Pro, pling frequencies 8 to 48 kHz; mono and stereo) audio Ogg Vorbis, and ATRAC3 will not play. The DVD files with the from a CD Data disc (usually a CD-R or player will automatically skip the file and begin play- CD-RW).
Page 371 UNDERSTANDING YOUR INSTRUMENT PANEL 369 Disc Errors Product Agreement This product incorporates copyright protection technol- If the DVD player is unable to read the disc, a Disc Error ogy that is protected by U.S. patents and other intellec- message is displayed on the Radio display and the disc is tual property rights.
Page 372: Ipod®/Usb/Mp3 Control
370 UNDERSTANDING YOUR INSTRUMENT PANEL General Information STEERING WHEEL AUDIO CONTROLS The remote sound system controls are located on the rear This device complies with Part 15 of the FCC rules and surface of the steering wheel. The left and right-hand RSS 210 of Industry Canada.
Page 373: Right-Hand Switch Functions
UNDERSTANDING YOUR INSTRUMENT PANEL 371 Right-Hand Switch Functions Left-Hand Switch Functions For Media (i.e., CD) Operation • Push the top of the switch to increase the volume. • Push the top of the switch once to listen to the next •...
Page 374: Cd/Dvd Disc Maintenance
372 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If you experience difficulty in playing a particular CD/DVD DISC MAINTENANCE disc, it may be damaged (e.g., scratched, reflective coat- To keep a CD/DVD in good condition, take the following ing removed, a hair, moisture or dew on the disc) precautions: oversized, or have protection encoding.
Page 375: Climate Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 373 CLIMATE CONTROLS The air conditioning and heating system is designed to make you comfortable in all types of weather. This system can be operated through either the instrument panel or through the Uconnect® system display. When the Uconnect®...
Page 376 374 UNDERSTANDING YOUR INSTRUMENT PANEL Buttons On The Touchscreen Buttons on the touchscreen are accessible on the Uconnect® system screen. Manual Temperature Controls — Buttons On The Faceplate Uconnect® 4.3 Manual 3 — Zone Temperature Controls — Buttons On The Touchscreen I n f o r ma t i o n P r o v i d e d b y :...
Page 377 UNDERSTANDING YOUR INSTRUMENT PANEL 375 this function again will cause the MAX A/C operation to switch into manual mode and the MAX A/C indicator will turn off. 2. A/C Button Press and release to change the current setting, the indicator illuminates when A/C is ON. Performing this function again will cause the A/C operation to switch into manual mode and the A/C indicator will turn off.
Page 378 376 UNDERSTANDING YOUR INSTRUMENT PANEL with maximum temperature settings for best windshield CAUTION! (Continued) and side window defrosting and defogging. Performing • Use care when washing the inside of the rear this function will cause the ATC to switch into manual window.
Page 379 UNDERSTANDING YOUR INSTRUMENT PANEL 377 7. Passenger Temperature Control Button when this feature is enabled. Sync is used to synchronize (Uconnect® 8.4 Only) the passenger temperature setting with the driver tem- perature setting. Changing the passenger temperature Provides the passenger with independent temperature setting while in Sync will automatically exit this feature.
Page 380 378 UNDERSTANDING YOUR INSTRUMENT PANEL Button On The Touchscreen • Bi-Level Mode Air comes from the instrument panel outlets Use the small blower icon to reduce the blower setting and floor outlets. A slight amount of air is and the large blower icon to increase the blower setting. directed through the defrost and side window Blower can also be selected by pressing the blower bar demister outlets.
Page 381 UNDERSTANDING YOUR INSTRUMENT PANEL 379 12. Climate Control OFF Button 15. Temperature Control (Uconnect® 4.3 Only) Press and release this button to turn the Climate Control Press the driver or passenger temperature button on the ON/OFF. touchscreen to regulate the temperature of the air inside the passenger compartment.
Page 382 380 UNDERSTANDING YOUR INSTRUMENT PANEL adjust the blower and airflow mode settings. Also, make MAX A/C sure to select only Panel, Bi-Level or Floor modes. MAX A/C sets the control for maximum cooling perfor- mance. NOTE: Press and release to toggle between MAX A/C and the •...
Page 383: Rear Manual Temperature Control (Mtc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 381 selected. Push the button a second time to turn off the Rear Manual Temperature Control (MTC) — If Recirculation mode and allow outside air into the vehicle. Equipped The rear MTC system has floor air outlets at the rear right NOTE: In cold weather, use of Recirculation mode may side of the 3rd Row seats and overhead outlets at each lead to excessive window fogging.
Page 384 382 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® 4.3 Manual Rear Climate Buttons On The Uconnect® 8.4 Manual Rear Climate Button On The Touchscreen Controls Screen Touchscreen Controls Screen 1 — Blower Up Button On The 5 — Done Button On The Touch- 1 —...
Page 385 UNDERSTANDING YOUR INSTRUMENT PANEL 383 Controlling The Rear Climate Controls From The Rear Lock Front Uconnect® Touchscreen • Pressing the Rear Temperature Lock button on the The Three-Zone climate control system allows for adjust- touchscreen on the Uconnect® touchscreen, illumi- ment of the rear climate controls from the front ATC panel.
Page 386 384 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Blower Control The rear blower control knob can be manually set to off, or any fixed blower speed, by rotating the knob from low to high. This allows the rear seat occupants to control the volume of air circulated in the rear of the vehicle.
Page 387 UNDERSTANDING YOUR INSTRUMENT PANEL 385 Rear Temperature Control Rear Mode Control Headliner Mode To change the temperature in the rear of the vehicle, rotate the temperature knob counterclockwise to lower Air comes from the outlets in the headliner. Each the temperature, and clockwise to increase the tempera- of these outlets can be individually adjusted to ture.
Page 388: Automatic Temperature Control (Atc) With Touchscreen - If Equipped
386 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control (ATC) With Touchscreen — If Equipped Buttons On The Faceplate Buttons on the faceplate are located on the left and right side of the Uconnect® 4.3 screen in the center of the instrument panel.
Page 389 UNDERSTANDING YOUR INSTRUMENT PANEL 387 Buttons On The Touchscreen Buttons On The Touchscreen are accessible on the Uconnect® system screen. Automatic Temperature Controls — Buttons On The Faceplate Uconnect® 4.3 Automatic 3 — Zone Temperature Controls — Buttons On The Touchscreen I n f o r ma t i o n P r o v i d e d b y :...
Page 390 388 UNDERSTANDING YOUR INSTRUMENT PANEL this function again will cause the MAX A/C operation to switch into manual mode and the MAX A/C indicator will turn off. 2. A/C Button Press and release to change the current setting, the indicator illuminates when A/C is ON. Performing this function again will cause the A/C operation to switch into manual mode and the A/C indicator will turn off.
Page 391 UNDERSTANDING YOUR INSTRUMENT PANEL 389 5. Front Defrost Button CAUTION! Press and release to change the current airflow setting to Failure to follow these cautions can cause damage to Defrost mode. The indicator illuminates when this fea- the heating elements: ture is ON.
Page 392 390 UNDERSTANDING YOUR INSTRUMENT PANEL 7. Rear Climate Button — If Equipped NOTE: Pressing this button while in Sync mode will automatically exit Sync. Press and release this button to turn on the rear climate 10. SYNC controls. The indicator will illuminate when the rear climate controls are ON.
Page 393 UNDERSTANDING YOUR INSTRUMENT PANEL 391 Blower Control Knob On The Faceplate • Panel Mode Air comes from the outlets in the instrument The blower speed increases as you turn the blower panel. Each of these outlets can be individu- control knob clockwise from the lowest blower setting. ally adjusted to direct the flow of air.
Page 394 392 UNDERSTANDING YOUR INSTRUMENT PANEL • Floor Mode NOTE: In Sync mode, this button will also automatically Air comes from the floor outlets. A slight adjust the passenger temperature setting at the same amount of air is directed through the defrost time.
Page 395 UNDERSTANDING YOUR INSTRUMENT PANEL 393 Climate Control Functions Press and release to toggle between MAX A/C and the prior settings. The button on the touchscreen illuminates A/C (Air Conditioning) when MAX A/C is ON. The Air Conditioning (A/C) button allows the operator In MAX A/C, the blower level and mode position can be to manually activate or deactivate the air conditioning adjusted to desired user settings.
Page 396 394 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: In cold weather, use of Recirculation mode may buttons on the faceplate. Once the desired temperature lead to excessive window fogging. The Recirculation is displayed, the system will achieve and automati- mode is not allowed in Defrost mode to improve window cally maintain that comfort level.
Page 397: Rear Automatic Temperature Control (Atc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 395 To provide you with maximum comfort in the Automatic NOTE: Each of these features operates independently mode, during cold start-ups the blower fan will remain from each other. If any feature is controlled manually, on low until the engine warms up. The blower will temperature control will continue to operate automati- increase in speed and transition into Auto mode.
Page 398 396 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® 4.3 Automatic Rear Climate Button On The Uconnect® 8.4 Automatic Rear Climate Button On The Touchscreen Controls Screen Touchscreen Controls Screen 1 — Blower Up Button On The 5 — Done Button On The Touch- 1 —...
Page 399 UNDERSTANDING YOUR INSTRUMENT PANEL 397 Controlling The Rear Climate Controls From The Rear second row occupants can only adjust the rear ATC Front ATC Panel control when the Rear Temperature Lock button is turned off. The Three-Zone ATC system allows for adjustment of the rear climate controls from the front ATC panel.
Page 400 398 UNDERSTANDING YOUR INSTRUMENT PANEL level, it is not necessary to change the settings. You will experience the greatest efficiency by simply allowing the system to function automatically. NOTE: It is not necessary to move the temperature settings for cold or hot vehicles. The system automati- cally adjusts the temperature, mode and fan speed to provide comfort as quickly as possible.
Page 401 UNDERSTANDING YOUR INSTRUMENT PANEL 399 to high. This allows the rear seat occupants to control the the temperature, and clockwise to increase the tempera- volume of air circulated in the rear of the vehicle. ture. The rear temperature settings are displayed in the Uconnect®...
Page 402 400 UNDERSTANDING YOUR INSTRUMENT PANEL Bi-Level Mode A solution of 50% OAT (Organic Additive Technology) coolant that meets the requirements of Chrysler Material Air comes from both the headliner outlets and the Standard MS-12106 and 50% water is recommended. floor outlets. Refer to “Maintenance Procedures”...
Page 403 UNDERSTANDING YOUR INSTRUMENT PANEL 401 Window Fogging Outside Air Intake Interior fogging on the windshield can be quickly re- Make sure the air intake, located directly in front of the moved by turning the mode selector to Defrost. The windshield, is free of obstructions such as leaves. Leaves Defrost/Floor mode can be used to maintain a clear collected in the air intake may reduce airflow, and if they windshield and provide sufficient heating.
Page 404 402 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Control Setting Suggestions For Various Weather Conditions I n f o r ma t i o n P r o v i d e d b y :...
Page 405: Starting And Operating
STARTING AND OPERATING CONTENTS STARTING PROCEDURES ....408 ▫ Key Ignition Park Interlock....415 ▫...
Page 406 404 STARTING AND OPERATING ▫ Traction ......426 ▫ Electronic Stability Control (ESC) ..439 DRIVING THROUGH WATER .
Page 407 STARTING AND OPERATING 405 ▫ Radial Ply Tires ..... .460 TIRE CHAINS (TRACTION DEVICES) ..468 ▫...
Page 408 406 STARTING AND OPERATING ▫ Carbon Monoxide Warnings ... . .484 ▫ Loose Fuel Filler Cap Message ... .491 FLEXIBLE FUEL (3.6L ENGINE ONLY) — IF VEHICLE LOADING .
Page 409 STARTING AND OPERATING 407 ▫ Towing Requirements ....499 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) ....507 ▫...
Page 410: Starting Procedures
408 STARTING AND OPERATING STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust the • Do not leave the Key Fob in or near the vehicle (or inside and outside mirrors, fasten your seat belt, and if in a location accessible to children), and do not present, instruct all other occupants to buckle their seat leave the ignition (of a vehicle equipped with...
Page 411: Keyless Enter-N-Go
STARTING AND OPERATING 409 Keyless Enter-N-Go™ CAUTION! Damage to the transmission may occur if the follow- This feature allows the driver to oper- ing precautions are not observed: ate the ignition switch with the push • Do not shift from REVERSE, PARK, or NEUTRAL of a button, as long as the Remote into any forward gear when the engine is above Start/Keyless Enter-N-Go™...
Page 412 410 STARTING AND OPERATING 4. If you wish to stop the cranking of the engine prior to position. If the shift lever/gear selector is not in PARK the engine starting, push the button again. and the ENGINE START/STOP button is pressed once, the EVIC (if equipped) will display a “Vehicle NOTE: Normal starting of either a cold or a warm engine Not In Park”...
Page 413: Extreme Cold Weather
STARTING AND OPERATING 411 and START. To change the ignition positions without Extreme Cold Weather (Below –20°F Or −29°C) starting the vehicle and use the accessories follow these To ensure reliable starting at these temperatures, use of steps: an externally powered electric engine block heater (avail- able from your authorized dealer) is recommended.
Page 414 412 STARTING AND OPERATING Clearing A Flooded Engine (Using ENGINE WARNING! (Continued) START/STOP Button) • Do not attempt to push or tow your vehicle to get it If the engine fails to start after you have followed the started. Vehicles equipped with an automatic trans- “Normal Starting”...
Page 415: After Starting
STARTING AND OPERATING 413 After Starting WARNING! The idle speed is controlled automatically and it will Remember to disconnect the engine block heater decrease as the engine warms up. cord before driving. Damage to the 110-115 Volt electrical cord could cause electrocution. ENGINE BLOCK HEATER —...
Page 416 414 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Unintended movement of a vehicle could injure • Never leave children alone in a vehicle, or with those in or near the vehicle. As with all vehicles, access to an unlocked vehicle. Allowing children to you should never exit a vehicle while the engine is be in a vehicle unattended is dangerous for a running.
Page 417: Key Ignition Park Interlock
STARTING AND OPERATING 415 before the engine can be turned OFF. This helps the CAUTION! driver avoid inadvertently leaving the vehicle without placing the transmission in PARK. Damage to the transmission may occur if the follow- ing precautions are not observed: This system also locks the transmission in PARK when- •...
Page 418 416 STARTING AND OPERATING out of PARK (refer to “Brake/Transmission Shift Inter- (+/-) position (below the Drive position) activates lock System” in this section). To drive, move the shift Autostick® mode, providing manual shift control and lever from PARK or NEUTRAL to the DRIVE position. displaying the current gear in the instrument cluster.
Page 419: Gear Ranges
STARTING AND OPERATING 417 the transmission locking mechanism may make it diffi- Gear Ranges cult to move the shift lever out of PARK. As an added DO NOT race the engine when shifting from PARK or precaution, turn the front wheels toward the curb on a NEUTRAL into another gear range.
Page 420 418 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • It is dangerous to shift out of PARK or NEUTRAL • Unintended movement of a vehicle could injure if the engine speed is higher than idle speed. If those in or near the vehicle. As with all vehicles, your foot is not firmly pressing the brake pedal, the you should never exit a vehicle while the engine is vehicle could accelerate quickly forward or in re-...
Page 421 STARTING AND OPERATING 419 WARNING! (Continued) CAUTION! • Never leave children alone in a vehicle, or with • Before moving the shift lever out of PARK, you access to an unlocked vehicle. Allowing children to must turn the ignition switch from the LOCK/OFF be in a vehicle unattended is dangerous for a position to the ON/RUN position, and also press number of reasons.
Page 422 420 STARTING AND OPERATING • Look at the transmission gear position display and WARNING! verify that it indicates the PARK position. Do not coast in NEUTRAL and never turn off the • With brake pedal released, verify that the shift lever ignition to coast down a hill.
Page 423 STARTING AND OPERATING 421 DRIVE (D) transmission shift schedule and expand the range of torque converter clutch engagement. This is done to This range should be used for most city and highway prevent transmission damage due to overheating. driving. It provides the smoothest upshifts and down- shifts, and the best fuel economy.
Page 424 422 STARTING AND OPERATING Transmission Limp Home Mode 3. Turn the ignition switch to the LOCK/OFF position. Transmission function is monitored electronically for 4. Wait approximately 10 seconds. abnormal conditions. If a condition is detected that could 5. Restart the engine. result in transmission damage, Transmission Limp Home Mode is activated.
Page 425 STARTING AND OPERATING 423 Overdrive Operation Torque Converter Clutch The automatic transmission includes an electronically A feature designed to improve fuel economy has been controlled Overdrive (top gear). The transmission will included in the automatic transmission on your vehicle. automatically shift into Overdrive if the following con- A clutch within the torque converter engages automati- ditions are present: cally at calibrated speeds.
Page 426: Autostick
424 STARTING AND OPERATING (+) or left (-), unless an engine lugging or overspeed AUTOSTICK® condition would result. It will remain in the selected gear AutoStick® is a driver-interactive transmission feature until another upshift or downshift is chosen, except as providing manual shift control, giving you more control described below.
Page 427: All Wheel Drive (Awd) - If Equipped
STARTING AND OPERATING 425 • If a requested downshift would cause the engine to WARNING! over-speed, that shift will not occur. Do not downshift for additional engine braking on a • Avoid using speed control when AutoStick® is en- slippery surface. The drive wheels could lose their gaged.
Page 428: Driving On Slippery Surfaces
426 STARTING AND OPERATING sent to the rear in a pre-emptive effort to improve vehicle WARNING! launch and performance characteristics. Rapid acceleration on slippery surfaces is dangerous. CAUTION! Unequal traction can cause sudden pulling of the front wheels. You could lose control of the vehicle All wheels must have the same size and type tires.
Page 429: Driving Through Water
STARTING AND OPERATING 427 2. Slow down if the road has standing water or puddles. Flowing/Rising Water 3. Replace the tires when tread wear indicators first WARNING! become visible. Do not drive on or across a road or path where water 4.
Page 430 428 STARTING AND OPERATING WARNING! CAUTION! • Driving through standing water limits your vehi- • Always check the depth of the standing water cle’s traction capabilities. Do not exceed 5 mph before driving through it. Never drive through (8 km/h) when driving through standing water. standing water that is deeper than the bottom of •...
Page 431: Power Steering
STARTING AND OPERATING 429 POWER STEERING CAUTION! (Continued) The standard power steering system will give you good • Driving through standing water may cause damage vehicle response and increased ease of maneuverability to your vehicle’s drivetrain components. Always in tight spaces. The system will provide mechanical inspect your vehicle’s fluids (i.e., engine oil, trans- steering capability if power assist is lost.
Page 432: Power Steering Fluid Check
430 STARTING AND OPERATING system. This noise should be considered normal, and it WARNING! does not in any way damage the steering system. Fluid level should be checked on a level surface and CAUTION! with the engine off to prevent injury from moving parts and to ensure accurate fluid level reading.
Page 433: Parking Brake
STARTING AND OPERATING 431 PARKING BRAKE Before leaving the vehicle, make sure that the parking brake is fully applied. Also, be certain to leave the transmission in PARK. The foot operated parking brake is located below the lower left corner of the instrument panel. To apply the park brake, firmly push the park brake pedal fully.
Page 434 432 STARTING AND OPERATING NOTE: WARNING! • When the parking brake is applied and the transmis- • Never use the PARK position as a substitute for the sion is placed in gear, the “Brake Warning Light” will parking brake. Always apply the parking brake flash.
Page 435: Brake System
STARTING AND OPERATING 433 BRAKE SYSTEM WARNING! (Continued) • Be sure the parking brake is fully disengaged Your vehicle is equipped with dual hydraulic before driving; failure to do so can lead to brake brake systems. If either of the two hydraulic failure and a collision.
Page 436: Electronic Brake Control System
434 STARTING AND OPERATING ELECTRONIC BRAKE CONTROL SYSTEM WARNING! Your vehicle is equipped with an advanced electronic • Riding the brakes can lead to brake failure and brake control system commonly referred to as ESC. This possibly a collision. Driving with your foot resting system includes Anti-Lock Brake System (ABS), Brake or riding on the brake pedal can result in abnor- Assist System (BAS), Traction Control System (TCS),...
Page 437 STARTING AND OPERATING 435 related motor noises. These noises are the system per- These are all normal characteristics of ABS. forming its self check cycle to ensure that the ABS is working properly. This self check occurs each time the WARNING! vehicle is started and accelerated past 7 mph (11 km/h).
Page 438 436 STARTING AND OPERATING Anti-Lock Brake Light WARNING! (Continued) • The ABS cannot prevent the natural laws of phys- The Anti-Lock Brake Light monitors the ABS. ics from acting on the vehicle, nor can it increase The light will turn on when the ignition switch braking or steering efficiency beyond that afforded is turned to the ON position and may stay on by the condition of the vehicle brakes and tires or...
Page 439: Brake Assist System (Bas)
STARTING AND OPERATING 437 If both the Brake System Warning Light and the ABS WARNING! Light remain on, the ABS and Electronic Brake Force Distribution (EBD) systems are not functioning. Immedi- BAS cannot prevent the natural laws of physics from ate repair to the ABS system is required.
Page 440: Electronic Roll Mitigation (Erm)
438 STARTING AND OPERATING differential and controls the wheel spin across a driven ERM can only reduce the chance of wheel lift occurring axle. If one wheel on a driven axle is spinning faster than during severe or evasive driving maneuvers. It cannot the other, the system will apply the brake of the spinning prevent wheel lift due to other factors, such as road wheel.
Page 441: Electronic Stability Control (Esc)
STARTING AND OPERATING 439 Electronic Stability Control (ESC) WARNING! This system enhances directional control and stability of Electronic Stability Control (ESC) cannot prevent the the vehicle under various driving conditions. ESC cor- natural laws of physics from acting on the vehicle, rects for over-steering and under-steering the vehicle by nor can it increase the traction afforded by prevailing applying the brake of the appropriate wheel.
Page 442 440 STARTING AND OPERATING ESC Operating Modes The ESC system has two available operating modes. Full On This is the normal operating mode for ESC. Whenever the vehicle is started the system will be in this mode. This mode should be used for most driving situations. ESC should only be turned to “Partial Off”...
Page 443: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
STARTING AND OPERATING 441 pressing the “ESC OFF” button. This may be done while ESC Activation/Malfunction Indicator Light And the vehicle is in motion. ESC OFF Indicator Light WARNING! The “ESC Activation/Malfunction Indicator Light” in the instrument cluster will come on •...
Page 444: Trailer Sway Control (Tsc)
442 STARTING AND OPERATING flashes when TCS is active. If the “ESC Activation/ when ESC becomes inactive following the maneuver Malfunction Indicator Light” begins to flash during ac- that caused the ESC activation. celeration, ease up on the accelerator and apply as little throttle as possible.
Page 445: Hill Start Assist (Hsa)
STARTING AND OPERATING 443 during this short period of time, the system will release WARNING! brake pressure and the vehicle will roll down the hill. The system will release brake pressure in proportion to the • TSC cannot stop all trailers from swaying. Always amount of throttle applied as the vehicle starts to move in use caution when towing a trailer and follow the the intended direction of travel.
Page 446 444 STARTING AND OPERATING HSA will work in REVERSE and all forward gears when Towing With HSA the activation criteria have been met. The system will not HSA will provide assistance when starting on a grade activate if the vehicle is placed in NEUTRAL or PARK. when pulling a trailer.
Page 447 STARTING AND OPERATING 445 NOTE: The HSA system may also be turned on and off WARNING! (Continued) if the vehicle is equipped with the Electronic Vehicle • HSA is not a parking brake. Always apply the Information Center (EVIC). Refer to “Electronic Vehicle parking brake fully when leaving your vehicle.
Page 448: Tire Safety Information
446 STARTING AND OPERATING NOTE: TIRE SAFETY INFORMATION Tire Markings • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 449 STARTING AND OPERATING 447 • Temporary spare tires are designed for temporary • High flotation tire sizing is based on U.S. design emergency use only. Temporary high pressure com- standards and it begins with the tire diameter molded pact spare tires have the letter “T” or “S” molded into into the sidewall.
Page 450 448 STARTING AND OPERATING EXAMPLE: R = Construction code – R means radial construction, or – D means diagonal or bias construction 15, 16, 18 = Rim diameter in inches (in) Service Description: 95 = Load Index – A numerical code associated with the maximum load a tire can carry H = Speed Symbol –...
Page 451: Tire Identification Number (Tin)
STARTING AND OPERATING 449 EXAMPLE: Load Identification: Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL) tire: • XL = Extra load (or reinforced) tire, or • LL = Light load tire or •...
Page 452 450 STARTING AND OPERATING EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation – This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire safety standards and is approved for highway use MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits)
Page 453: Tire Terminology And Definitions
STARTING AND OPERATING 451 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.
Page 454: Tire Loading And Tire Pressure
452 STARTING AND OPERATING Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. Example Tire Placard Location (Door) I n f o r ma t i o n P r o v i d e d b y :...
Page 455 STARTING AND OPERATING 453 Tire And Loading Information Placard Example Tire Placard Location (B-Pillar) Tire And Loading Information Placard This placard tells you important information about the: 1. Number of people that can be carried in the vehicle. 2. Total weight your vehicle can carry. I n f o r ma t i o n P r o v i d e d b y :...
Page 456 454 STARTING AND OPERATING 3. Tire size designed for your vehicle. To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of 4. Cold tire inflation pressures for the front, rear, and occupants and cargo should never exceed XXX lbs or spare tires.
Page 457 STARTING AND OPERATING 455 “XXX” amount equals 1,400 lbs (635 kg) and there will NOTE: be five 150 lb (68 kg) passengers in your vehicle, the • If your vehicle will be towing a trailer, load from your amount of available cargo and luggage load capacity trailer will be transferred to your vehicle.
Page 458 456 STARTING AND OPERATING I n f o r ma t i o n P r o v i d e d b y :...
Page 459: Tires - General Information
STARTING AND OPERATING 457 Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 460: Tire Inflation Pressures
458 STARTING AND OPERATING Economy WARNING! (Continued) Under-inflated tires will increase tire rolling resistance • Unequal tire pressures from one side of the vehicle resulting in higher fuel consumption. to the other can cause the vehicle to drift to the right or left.
Page 461 STARTING AND OPERATING 459 judgement when determining proper inflation. Tires The cold tire inflation pressure must not exceed the may look properly inflated even when they are under- maximum inflation pressure molded into the tire side- inflated. wall. Check tire pressures more often if subject to a wide range •...
Page 462: Radial Ply Tires
460 STARTING AND OPERATING Tire Pressures For High Speed Operation Radial Ply Tires The manufacturer advocates driving at safe speeds and WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 463: All Season Tires - If Equipped
STARTING AND OPERATING 461 Consult an authorized tire dealer for tire repairs and on ice. If your vehicle is equipped with summer tires, be additional information. aware these tires are not designed for winter or cold driving conditions. For more information, contact a au- Damaged Run Flat tires, or Run Flat tires that have thorized dealer.
Page 464: Snow Tires
462 STARTING AND OPERATING While studded tires improve performance on ice, skid Snow Tires and traction capability on wet or dry surfaces may be Some areas of the country require the use of snow tires poorer than that of non-studded tires. Some states pro- during the winter.
Page 465: Full Size Spare - If Equipped
STARTING AND OPERATING 463 the Tire and Loading Information Placard located on the WARNING! driver’s side door opening or on the sidewall of the tire. Compact spare tire descriptions begin with the letter “T” Compact spares are for temporary emergency use or “S”...
Page 466: Limited-Use Spare - If Equipped
464 STARTING AND OPERATING your original equipment tire, replace (or repair) the WARNING! original equipment tire and reinstall on the vehicle at the first opportunity. Limited-use spares are for emergency use only. In- stallation of this limited-use spare tire affects vehicle Limited-Use Spare —...
Page 467: Tread Wear Indicators
STARTING AND OPERATING 465 Refer to “Freeing A Stuck Vehicle” in “What To Do In Emergencies” for further information. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one.
Page 468: Life Of Tire
466 STARTING AND OPERATING tread wear indicators, the tire should be replaced. Refer tread life. Rotation of these tires per the vehicle main- to “Replacement Tires” in this section for further infor- tenance schedule is highly recommended. mation. WARNING! Life Of Tire Tires and the spare tire should be replaced after six The service life of a tire is dependent upon varying years, regardless of the remaining tread.
Page 469 STARTING AND OPERATING 467 wear and correct cold tire inflation pressures. The manu- you may have on tire specifications or capability. Failure facturer strongly recommends that you use tires equiva- to use equivalent replacement tires may adversely affect lent to the originals in size, quality and performance the safety, handling, and ride of your vehicle.
Page 470: Tire Chains (Traction Devices)
468 STARTING AND OPERATING TIRE CHAINS (TRACTION DEVICES) WARNING! (Continued) Use of traction devices require sufficient tire-to-body • Never use a tire with a smaller load index or clearance. Follow these recommendations to guard capacity, other than what was originally equipped against damage.
Page 471: Tire Rotation Recommendations
STARTING AND OPERATING 469 CAUTION! CAUTION! (Continued) • Observe the traction device manufacturer’s instruc- To avoid damage to your vehicle or tires, observe the tions on the method of installation, operating following precautions: speed, and conditions for use. Always use the •...
Page 472: Tire Pressure Monitor System (Tpms)
470 STARTING AND OPERATING tires. Rotation will increase tread life, help to maintain mud, snow and wet traction levels, and contribute to a smooth, quiet ride. Refer to the “Maintenance Schedule” for the proper maintenance intervals. The reasons for any rapid or unusual wear should be corrected prior to rotation being performed.
Page 473 STARTING AND OPERATING 471 The tire pressure will vary with temperature by about The TPMS will continue to warn the driver of low tire 1 psi (7 kPa) for every 12°F (6.5°C). This means that when pressure as long as the condition exists, and will not turn the outside temperature decreases, the tire pressure will off until the tire pressure is at or above the recommended decrease.
Page 474 472 STARTING AND OPERATING pressure is low enough to turn ON the “Tire Pressure CAUTION! Monitoring Telltale Light.” Driving the vehicle may cause the tire pressure to rise to approximately 28 psi (193 kPa), • The TPMS has been optimized for the original but the “Tire Pressure Monitoring Telltale Light”...
Page 475: Base System
STARTING AND OPERATING 473 Under-inflation also reduces fuel efficiency and tire CAUTION! (Continued) tread life, and may affect the vehicle’s handling and • After inspecting or adjusting the tire pressure, stopping ability. always reinstall the valve stem cap. This will •...
Page 476 474 STARTING AND OPERATING monitor tire pressure levels. Sensors, mounted to each road tires. An Inflate to XX message will also be wheel as part of the valve stem, transmit tire pressure displayed. Should this occur, you should stop as soon as readings to the receiver module.
Page 477 STARTING AND OPERATING 475 exists. The “Tire Pressure Monitoring Telltale Light” will • If you install the compact spare tire in place of a road turn off when the fault condition no longer exists. A tire that has a pressure below the low-pressure warn- system fault can occur due to any of the following: ing limit, a chime will sound and the “Tire Pressure Monitoring Telltale Light”...
Page 478: Premium System - If Equipped
476 STARTING AND OPERATING Pressure Monitoring Telltale Light” will turn off, as long as no tire pressure is below the low-pressure warning limit in any of the four active road tires. The vehicle may need to be driven for up to 20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this information.
Page 479 STARTING AND OPERATING 477 • Various Tire Pressure Monitoring System messages, which display in the Electronic Vehicle Information Center (EVIC) • Tire Pressure Monitoring Telltale Light Tire Pressure Monitoring Low Pressure Warnings The “Tire Pressure Monitoring Telltale Light” will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires.
Page 480 478 STARTING AND OPERATING update, the graphic display in the EVIC will change color Light” will no longer flash, and the SERVICE TPM back to the original color, and the “Tire Pressure Moni- SYSTEM message will no longer display, and a pressure toring Telltale Light”...
Page 481 STARTING AND OPERATING 479 detected. In this case, the SERVICE TPM SYSTEM EVIC will still display a pressure value in a different message is then followed with a graphic display with color. An Inflate to XX message will also be dis- pressure values still shown.
Page 482: General Information
480 STARTING AND OPERATING the TPMS will update automatically. In addition, the The tire pressure sensors are covered under one of the “Tire Pressure Monitoring Telltale Light” will turn off following licenses: and the graphic in the EVIC will display a new United States MRXSSW4 pressure value instead of dashes (- -), as long as no tire...
Page 483: Reformulated Gasoline
STARTING AND OPERATING 481 required. Poor quality gasoline can cause problems such The manufacturer supports the use of reformulated gaso- as hard starting, stalling, and hesitations. If you experi- line. Properly blended reformulated gasoline will pro- ence these symptoms, try another brand of gasoline vide excellent performance and durability of engine and before considering service for the vehicle.
Page 484: E-85 Usage In Non-Flex Fuel Vehicles
482 STARTING AND OPERATING Problems that result from using gasoline containing To fix a Non-FFV vehicle inadvertently fueled once with Methanol or gasoline containing more than 10% Ethanol E-85 perform the following: are not the responsibility of the manufacturer and may •...
Page 485: Materials Added To Fuel
STARTING AND OPERATING 483 without MMT be used in your vehicle. The MMT content Fuel System Cautions of gasoline may not be indicated on the gasoline pump, therefore, you should ask your gasoline retailer whether CAUTION! the gasoline contains MMT. MMT is prohibited in Federal Follow these guidelines to maintain your vehicle’s and California reformulated gasoline.
Page 486: Carbon Monoxide Warnings
484 STARTING AND OPERATING CAUTION! (Continued) WARNING! (Continued) • The use of fuel additives, which are now being sold as • Do not inhale exhaust gases. They contain carbon octane enhancers, is not recommended. Most of these monoxide, a colorless and odorless gas, which can products contain high concentrations of methanol.
Page 487: Flexible Fuel (3.6L Engine Only) - If Equipped
STARTING AND OPERATING 485 FLEXIBLE FUEL (3.6L ENGINE ONLY) — IF EQUIPPED E-85 General Information The information in this section is for Flexible Fuel ve- hicles only. These vehicles can be identified by a unique fuel filler door label that states Ethanol (E-85) or Un- leaded Gasoline Only.
Page 488: Ethanol Fuel (E-85)
486 STARTING AND OPERATING WARNING! Ethanol vapors are extremely flammable and could cause serious personal injury. Never have any smok- ing materials lit in or near the vehicle when remov- ing the fuel filler tube cap (gas cap) or filling the tank.
Page 489: Selection Of Engine Oil For Flexible Fuel Vehicles (E-85) And Gasoline Vehicles
STARTING AND OPERATING 487 When you do switch fuel types it is recommended that: engine. To eliminate driveability issues that may be caused by these deposits, a supplemental gasoline • You do not add less than 5 gallons (19 Liters) when additive, such as MOPAR®...
Page 490: Starting
488 STARTING AND OPERATING Starting Replacement Parts The characteristics of E-85 fuel make it unsuitable for use Many components in your Flexible Fuel Vehicle (FFV) are when ambient temperatures fall below 0°F (-18°C). In the designed to be compatible with ethanol. Always be sure range of 0°F (-18°C) to 32°F (0°C), you may experience an that your vehicle is serviced with correct ethanol com- increase in the time it takes for your engine to start, and...
Page 491: Adding Fuel
STARTING AND OPERATING 489 ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap has been designed for use with this vehicle.
Page 492 490 STARTING AND OPERATING WARNING! CAUTION! • Never have any smoking materials lit in or near the • Damage to the fuel system or emissions control vehicle when the gas cap is removed or the tank is system could result from using an improper fuel being filled.
Page 493: Loose Fuel Filler Cap Message
STARTING AND OPERATING 491 properly. The MIL in the instrument cluster may turn VEHICLE LOADING on if the gas cap is not secured properly. Make sure The load carrying capacity of your vehicle is shown on that the gas cap is tightened each time the vehicle is the “Vehicle Certification Label”.
Page 494: Gross Vehicle Weight Rating (Gvwr)
492 STARTING AND OPERATING • Gross Axle Weight Rating (GAWR) rear WARNING! • Vehicle Identification Number (VIN) Because the front wheels steer the vehicle, it is • Type of Vehicle important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can •...
Page 495: Loading
STARTING AND OPERATING 493 Figure out the weight on the front and rear of the vehicle TRAILER TOWING separately. It is important that you distribute the load In this section you will find safety tips and information evenly over the front and rear axles. on limits to the type of towing you can reasonably do Overloading can cause potential safety hazards and with your vehicle.
Page 496 494 STARTING AND OPERATING exceed the GVWR. Refer to “Vehicle Loading/Vehicle evenly. Make sure that you do not exceed either front or Certification Label” in “Starting and Operating” for rear GAWR. Refer to “Vehicle Loading/Vehicle Certifica- further information. tion Label” in “Starting and Operating” for further information.
Page 497 STARTING AND OPERATING 495 Frontal Area some other connecting point of the vehicle. These kinds of hitches are the most popular on the market today and The frontal area is the maximum height multiplied by the they are commonly used to tow small and medium sized maximum width of the front of a trailer.
Page 498: Trailer Hitch Classification
496 STARTING AND OPERATING and trailer configuration/loading to comply with Gross Trailer Hitch Classification Definitions Axle Weight Rating (GAWR) requirements. Class Max. Trailer Hitch Industry Standards WARNING! Class I - Light Duty 2,000 lbs (907 kg) • An improperly adjusted Weight Distributing Hitch Class II - Medium Duty 3,500 lbs (1 587 kg) system may reduce handling, stability, braking...
Page 499: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING 497 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain: GCWR Max. Tongue Engine/Transmission (Gross Combined Frontal Area Max. GTW (Gross Trailer Wt.) Wt. Rating) 2.4L/Automatic 6,000 lbs 22 sq ft...
Page 500: Trailer And Tongue Weight
498 STARTING AND OPERATING NOTE: which will cause loss of control of the vehicle and trailer. Failure to load trailers heavier in front is the cause of • The trailer tongue weight must be considered as part many trailer collisions. of the combined weight of occupants and cargo, and Never exceed the maximum tongue weight stamped on should never exceed the weight referenced on the Tire...
Page 501 STARTING AND OPERATING 499 • The tongue weight of the trailer. CAUTION! • The weight of any other type of cargo or equipment • Do not tow a trailer at all during the first 500 miles put in or on your vehicle. (805 km) the new vehicle is driven.
Page 502 500 STARTING AND OPERATING WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to a collision. Follow these vehicle and trailer. Always connect the chains to guidelines to make your trailer towing as safe as the frame or hook retainers of the vehicle hitch.
Page 503 STARTING AND OPERATING 501 “Tires – General Information” in “Starting and Oper- WARNING! (Continued) ating” for proper tire inflation procedures. • Total weight must be distributed between the tow • Check the trailer tires for proper tire inflation pres- vehicle and the trailer such that the following four sures before trailer usage.
Page 504 502 STARTING AND OPERATING Towing Requirements — Trailer Brakes WARNING! • Do not interconnect the hydraulic brake system or • Do not connect trailer brakes to your vehicle’s vacuum system of your vehicle with that of the trailer. hydraulic brake lines. It can overload your brake This could cause inadequate braking and possible system and cause it to fail.
Page 505 STARTING AND OPERATING 503 The Trailer Tow Package may include a four- and seven- CAUTION! pin wiring harness. Use a factory approved trailer har- ness and connector. If the trailer weighs more than 1,000 lbs (454 kg) loaded, it should have its own brakes and they NOTE: Do not cut or splice wiring into the vehicles should be of adequate capacity.
Page 506 504 STARTING AND OPERATING Four-Pin Connector Seven-Pin Connector 1 — Female Pins 4 — Park 1 — Battery 5 — Ground 2 — Male Pin 5 — Left Stop/Turn 2 — Backup Lamps 6 — Left Stop/Turn 3 — Ground 6 —...
Page 507 STARTING AND OPERATING 505 or frequent trailer towing”. Refer to the “Maintenance Towing Tips Schedule” for the proper maintenance intervals. Before setting out on a trip, practice turning, stopping, and backing up the trailer in an area located away from NOTE: Check the four-speed automatic transmission heavy traffic.
Page 508 506 STARTING AND OPERATING AutoStick® Cooling System To reduce potential for engine and transmission over- • When using the AutoStick® shift control, select the heating, take the following actions: highest gear that allows for adequate performance and avoids frequent downshifts. For example, choose “4” if City Driving the desired speed can be maintained.
Page 509 STARTING AND OPERATING 507 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheel OFF the Ground FWD Models AWD Models Flat Tow NONE NOT ALLOWED NOT ALLOWED Dolly Tow Front NOT ALLOWED Rear NOT ALLOWED NOT ALLOWED On Trailer Recreational Towing —...
Page 510 508 STARTING AND OPERATING CAUTION! CAUTION! Towing this vehicle with ANY of its wheels on the • DO NOT flat tow this vehicle. Damage to the ground can cause severe transmission and/or power drivetrain will result. If this vehicle requires tow- transfer unit damage.
Page 511: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS HAZARD WARNING FLASHERS ...511 ▫ Spare Tire Removal ....516 IF YOUR ENGINE OVERHEATS .
Page 512 510 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE ...535 ▫ All-Wheel Drive (AWD) Models ...536 ▫ Front-Wheel Drive (FWD) Models ..537 I n f o r ma t i o n P r o v i d e d b y :...
Page 513: Hazard Warning Flashers
WHAT TO DO IN EMERGENCIES 511 NOTE: With extended use the Hazard Warning flashers HAZARD WARNING FLASHERS may wear down your battery. The Hazard Warning flasher switch is located in the instrument panel switch bank, above the climate controls. IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the Press the switch to turn on the Hazard Warning potential for overheating by taking the appropriate ac-...
Page 514: L Engine - If Equipped
512 WHAT TO DO IN EMERGENCIES to High. This allows the heater core to act as a WARNING! (Continued) supplement to the radiator and aids in removing heat you see or hear steam coming from under the hood, from the engine cooling system. do not open the hood until the radiator has had time to cool.
Page 515: Wheel And Tire Torque
WHAT TO DO IN EMERGENCIES 513 Inspect the wheel mounting surface prior to mounting WHEEL AND TIRE TORQUE SPECIFICATIONS the tire and remove any corrosion or loose particles. Proper lug nut/bolt torque is very important to ensure that the wheel is properly mounted to the vehicle. Any time a wheel has been removed and reinstalled on the vehicle the lug nuts/bolts should be torqued using a properly calibrated torque wrench.
Page 516: Jacking And Tire Changing
514 WHAT TO DO IN EMERGENCIES Tighten the lug nuts/bolts in a star pattern until each WARNING! nut/bolt has been tightened twice. To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered.
Page 517: Jack Location
WHAT TO DO IN EMERGENCIES 515 WARNING! (Continued) • Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never put any part of your body under a vehicle that is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift.
Page 518: Preparations For Jacking
516 WHAT TO DO IN EMERGENCIES 6. Block both the front and rear of the wheel diagonally Preparations For Jacking opposite of the jacking position. For 1. Park the vehicle on a firm, level surface as far from the example, if changing the right front edge of the roadway as possible.
Page 519 WHAT TO DO IN EMERGENCIES 517 NOTE: Assemble components 2 and 3 by seating the small ball at the end of component 2 in the small hole at the end of component 3. This will lock these components together. Assemble components 1 and 2 so that the wheel nut socket at the end of component 1 faces upward when seated on component 2.
Page 520: Spare Tire Stowage
518 WHAT TO DO IN EMERGENCIES 3. Pull the spare tire out from underneath the vehicle and Spare Tire Stowage raise it upright so the tire’s tread is on the ground. NOTE: Refer to “Spare Tire Removal” for information on 4.
Page 521: Jacking Instructions
WHAT TO DO IN EMERGENCIES 519 Jacking Instructions WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a WARNING! jack. Carefully follow these tire changing warnings to • Do not get under the vehicle when it is on a jack. If help prevent personal injury or damage to your you need to get under a raised vehicle, take it to a vehicle:...
Page 522 520 WHAT TO DO IN EMERGENCIES Jack Warning Label CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. Jacking Locations 1. Remove the spare tire, jack, and jack-handle from stowage.
Page 523 WHAT TO DO IN EMERGENCIES 521 3. Place the jack in the notches underneath the lift area that is closest to the flat tire. Center the jack saddle between the drain flute formations on the sill flange. Turn the jack screw clockwise to firmly engage the jack saddle with the lift area of the sill flange.
Page 524 522 WHAT TO DO IN EMERGENCIES Rear Jacking Location Rear Jack Engaged With Jack Handle 4. Raise the vehicle by turning the jack screw clockwise with the jack handle. Raise the vehicle until the tire just clears the road surface and enough clearance is obtained to install the spare tire.
Page 525 WHAT TO DO IN EMERGENCIES 523 WARNING! CAUTION! Raising the vehicle higher than necessary can make Be sure to mount the spare tire with the valve stem the vehicle less stable. It could slip off the jack and facing outward. The vehicle could be damaged if the hurt someone near it.
Page 526 524 WHAT TO DO IN EMERGENCIES NOTE: 8. Lower the vehicle by turning the jack screw counter- clockwise with the jack handle. • For vehicles so equipped, do not attempt to install a center cap or wheel cover on the compact spare. 9.
Page 527: Road Tire Installation
WHAT TO DO IN EMERGENCIES 525 12. To stow the winch cable and retainer, fit the as- Road Tire Installation sembled jack-handle over the winch drive nut. Rotate Vehicles Equipped With Wheel Covers the jack-handle assembly clockwise until you hear the winch mechanism click three times.
Page 528 526 WHAT TO DO IN EMERGENCIES snapping the cover over the two lug nuts. Do not use a hammer or excessive force to install the cover. 4. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel. Lightly tighten the lug nuts.
Page 529 WHAT TO DO IN EMERGENCIES 527 nut torque refer to Torque Specifications in this sec- WARNING! tion. If in doubt about the correct tightness, have them checked with a torque wrench by your authorized To avoid the risk of forcing the vehicle off the jack, dealer or service station.
Page 530: Jump-Starting
528 WHAT TO DO IN EMERGENCIES 5. After 25 miles (40 km) check the lug nut torque with a CAUTION! torque wrench to ensure that all lug nuts are properly seated against the wheel. Do not use a portable battery booster pack or any other booster source with a system voltage greater JUMP-STARTING than 12 Volts or damage to the battery, starter motor,...
Page 531 WHAT TO DO IN EMERGENCIES 529 WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is ON. You can be injured by moving fan blades. • Remove any metal jewelry such as rings, watch bands and bracelets that could make an inadvertent electrical contact.
Page 532: Jump-Starting Procedure
530 WHAT TO DO IN EMERGENCIES 3. Remove the protective cover over the remote positive Jump-Starting Procedure (+) battery post. To remove the cover, press the locking tab and pull upward on the cover. WARNING! 4. If using another vehicle to jump-start the battery, park Failure to follow this jump-starting procedure could the vehicle within the jumper cables reach, set the result in personal injury or property damage due to...
Page 533 WHAT TO DO IN EMERGENCIES 531 3. Connect the negative end (-) of the jumper cable to the 6. Once the engine is started, remove the jumper cables negative (-) post of the booster battery. in the reverse sequence: Disconnecting The Jumper Cables 4.
Page 534: Freeing A Stuck Vehicle
532 WHAT TO DO IN EMERGENCIES If frequent jump-starting is required to start your vehicle, and REVERSE while gently pressing the accelerator you should have the battery and charging system in- pedal. Use the least amount of accelerator pedal pressure spected at your authorized dealer.
Page 535: Shift Lever Override
WHAT TO DO IN EMERGENCIES 533 NOTE: Press the ESC Off switch, to place the Electronic WARNING! Stability Control (ESC) system in ESC Partial Off mode, before rocking the vehicle. Refer to Fast spinning tires can be dangerous. Forces gener- “Electronic Brake Control”...
Page 536 534 WHAT TO DO IN EMERGENCIES 3. Open the center console and remove the shift lever 5. Insert a screwdriver or similar small tool into the override access cover (located in the front lower right access port, and push and hold the override release corner of the console storage bin).
Page 537 WHAT TO DO IN EMERGENCIES 535 TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheel OFF the FWD MODELS AWD MODELS Ground Flat Tow NONE IF transmission is operable: NOT ALLOWED •...
Page 538 536 WHAT TO DO IN EMERGENCIES If you must use the accessories (wipers, defrosters, etc.) CAUTION! (Continued) while being towed, the ignition must be in the ON/RUN • Do not push or tow this vehicle with another position, not the ACC position. vehicle as damage to the bumper fascia and trans- If the key fob is unavailable, or the vehicle’s battery is mission may result.
Page 539 WHAT TO DO IN EMERGENCIES 537 If the transmission is not operable, or the vehicle must CAUTION! be towed faster than 25 mph (40 km/h) or farther than 15 miles (24 km), it must be towed with the front wheels Towing this vehicle in violation of the above require- OFF the ground (using a flatbed truck, towing dolly, or ments can cause severe transmission and/or power...
Page 540 I n f o r ma t i o n P r o v i d e d b y :...
Page 541 MAINTAINING YOUR VEHICLE CONTENTS ENGINE COMPARTMENT — 2.4L ..541 ▫ Engine Oil Filter ..... .550 ENGINE COMPARTMENT —...
Page 542 540 MAINTAINING YOUR VEHICLE ▫ Brake System ......567 REPLACEMENT BULBS ....589 ▫...
Page 543: Engine Compartment - 2.4L
MAINTAINING YOUR VEHICLE 541 ENGINE COMPARTMENT — 2.4L 1 — Engine Coolant Reservoir 7 — Power Distribution Center (Fuses) 2 — Power Steering Fluid Reservoir 8 — Air Cleaner Filter 3 — Engine Oil Fill 9 — Automatic Transmission Dipstick (4–Speed Only) 4 —...
Page 544: Engine Compartment - 3.6L
542 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.6L 1 — Engine Coolant Reservoir 5 — Air Cleaner Filter 2 — Power Steering Fluid Reservoir 6 — Washer Fluid Reservoir 3 — Brake Fluid Reservoir 7 — Engine Oil Dipstick 4 — Power Distribution Center (Fuses) 8 —...
Page 545: Onboard Diagnostic System - Obd Ii
MAINTAINING YOUR VEHICLE 543 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and automatic could also affect fuel economy and driveability.
Page 546: Emissions Inspection And Maintenance Programs
544 MAINTAINING YOUR VEHICLE A loose, improperly installed, or damaged fuel filler cap Your vehicle has a simple ignition actuated test, which may also turn on the MIL. you can use prior to going to the test station. To check if your vehicle’s OBD II system is ready, you must do the EMISSIONS INSPECTION AND MAINTENANCE following:...
Page 547: Replacement Parts
MAINTAINING YOUR VEHICLE 545 the ignition or start the engine. This means that your before going to the I/M station. The I/M station can fail vehicle’s OBD II system is not ready and you should your vehicle because the MIL is on with the engine not proceed to the I/M station.
Page 548: Maintenance Procedures
546 MAINTAINING YOUR VEHICLE NOTE: Intentional tampering with emissions control Besides those maintenance items specified in the fixed systems may void your warranty and could result in civil “Maintenance Schedule”, there are other components penalties being assessed against you. which may require servicing or replacement in the future. WARNING! CAUTION! You can be badly injured working on or around a...
Page 549: Engine Oil
MAINTAINING YOUR VEHICLE 547 warmed engine is shut off. Checking engine oil level when CAUTION! (Continued) the engine is cold will give you an incorrect reading. • Your vehicle has been built with improved fluids Checking the oil while the vehicle is on level ground and that protect the performance and durability of your only when the engine is hot, will improve the accuracy of vehicle and also allow extended maintenance inter-...
Page 550 548 MAINTAINING YOUR VEHICLE American Petroleum Institute (API) Engine Oil CAUTION! (Continued) Identification Symbol could damage your engine. Also, be sure the oil fill cap is replaced and tightened after adding oil. This symbol means that the oil has been certified by the American Change Engine Oil Petroleum Institute (API).
Page 551 MAINTAINING YOUR VEHICLE 549 Engine Oil Viscosity — 2.4L Engine Helix® or equivalent is recommended for all operating temperatures. This engine oil improves low temperature MOPAR® SAE 5W-20 engine oil or equivalent Pennzoil® starting and vehicle fuel economy. or Shell Helix® is recommended for all operating tem- peratures.
Page 552: Engine Oil Filter
550 MAINTAINING YOUR VEHICLE Materials Added To Engine Oil Engine Oil Filter Selection The manufacturer strongly recommends against the ad- This manufacturer’s engines have a full-flow type oil dition of any additives (other than leak detection dyes) to filter. Use a filter of this type for replacement. The quality the engine oil.
Page 553: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 551 Maintenance-Free Battery WARNING! (Continued) Your vehicle is equipped with a maintenance-free battery. for repair or maintenance. Make sure that no one is You will never have to add water, nor is periodic main- near the engine compartment before starting the tenance required.
Page 554: Air Conditioner Maintenance
552 MAINTAINING YOUR VEHICLE WARNING! CAUTION! • Battery fluid is a corrosive acid solution and can • It is essential when replacing the cables on the burn or even blind you. Do not allow battery fluid battery that the positive cable is attached to the to contact your eyes, skin, or clothing.
Page 555 MAINTAINING YOUR VEHICLE 553 test. Drive belt tension should also be checked at this CAUTION! time. Do not use chemical flushes in your air conditioning WARNING! system as the chemicals can damage your air condi- tioning components. Such damage is not covered by •...
Page 556: A/C Air Filter - If Equipped
554 MAINTAINING YOUR VEHICLE A/C Air Filter — If Equipped Refer to the “Maintenance Schedule” for the proper maintenance intervals. WARNING! Do not remove the A/C air filter while the blower is operating or personal injury may result. The A/C air filter is located in the fresh air inlet behind the glove box.
Page 557: Body Lubrication
MAINTAINING YOUR VEHICLE 555 cover, make sure the retaining tabs fully engage the cover. CAUTION! The A/C air filter is identified with an arrow to indicate airflow direction through the filter. Failure to install the filter properly will result in the need to replace it more often.
Page 558: Windshield Wiper Blades
556 MAINTAINING YOUR VEHICLE operation and to protect against rust and wear. Prior to Operation of the wipers on dry glass for long periods the application of any lubricant, the parts concerned may cause deterioration of the wiper blades. Always use should be wiped clean to remove dust and grit;...
Page 559 MAINTAINING YOUR VEHICLE 557 3. Grab the bottom of the wiper blade and rotate it forward to unsnap the blade pivot pin from the wiper blade holder. 1 — Wiper Arm 2 — Pivot Cap NOTE: The rear wiper arm cannot be raised fully up- 1 —...
Page 560: Adding Washer Fluid
558 MAINTAINING YOUR VEHICLE 4. Install the wiper blade pivot pin into the wiper blade To prevent freeze-up of your windshield washer system holder at the end of the wiper arm, and firmly press in cold weather, select a solution or mixture that meets or the wiper blade until it snaps into place.
Page 561: Exhaust System
MAINTAINING YOUR VEHICLE 559 Exhaust System WARNING! The best protection against carbon monoxide entry into • Exhaust gases can injure or kill. They contain the vehicle body is a properly maintained engine exhaust carbon monoxide (CO), which is colorless and system.
Page 562 560 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure • The catalytic converter requires the use of un- proper catalyst operation and prevent possible catalyst leaded fuel only.
Page 563: Cooling System
MAINTAINING YOUR VEHICLE 561 To minimize the possibility of catalytic converter dam- Cooling System age: WARNING! • Do not shut off the engine or interrupt the ignition, when the transmission is in gear and the vehicle is in • When working near the radiator cooling fan, motion.
Page 564 562 MAINTAINING YOUR VEHICLE applicable). If the engine coolant (antifreeze) is dirty or If the engine coolant (antifreeze) is dirty or contains visible rusty in appearance, the system should be drained, sediment, have an authorized dealer clean and flush with flushed, and refilled with fresh engine coolant (anti- OAT coolant (antifreeze) (conforming to MS-12106).
Page 565 MAINTAINING YOUR VEHICLE 563 CAUTION! CAUTION! (Continued) • Do not use water alone or alcohol-based engine • Mixing of engine coolant (antifreeze) other than coolant (antifreeze) products. Do not use additional specified Organic Additive Technology (OAT) en- rust inhibitors or antirust products, as they may not gine coolant (antifreeze), may result in engine be compatible with the radiator engine coolant and damage and may decrease corrosion protection.
Page 566 564 MAINTAINING YOUR VEHICLE you use the same engine coolant (OAT coolant conform- (antifreeze) solution. The use of lower quality water ing to MS-12106) throughout the life of your vehicle. will reduce the amount of corrosion protection in the engine cooling system. Please review these recommendations for using Organic Additive Technology (OAT) engine coolant (antifreeze) Please note that it is the owner’s responsibility to main-...
Page 567 MAINTAINING YOUR VEHICLE 565 have a authorized dealer drain, flush, and refill with WARNING! OAT coolant (conforming to MS-12106) as soon as possible. • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety precaution. Cooling System Pressure Cap Never add engine coolant (antifreeze) when the The cap must be fully tightened to prevent loss of engine...
Page 568 566 MAINTAINING YOUR VEHICLE rules for your community. To prevent ingestion by ani- The radiator normally remains completely full, so there is mals or children, do not store ethylene glycol-based no need to remove the radiator cap unless checking for engine coolant in open containers or allow it to remain in coolant freeze point or replacing engine coolant (anti- puddles on the ground.
Page 569: Brake System
MAINTAINING YOUR VEHICLE 567 If an examination of your engine compartment shows no • Make sure that the coolant expansion bottle overflow evidence of radiator or hose leaks, the vehicle may be hoses are not kinked or obstructed. safely driven. The vapor will soon dissipate. •...
Page 570 568 MAINTAINING YOUR VEHICLE Clean the top of the master cylinder area before removing WARNING! the cap. If necessary, add fluid to bring the fluid level up to the requirements described on the brake fluid reser- Riding the brakes can lead to brake failure and voir.
Page 571 MAINTAINING YOUR VEHICLE 569 WARNING! WARNING! (Continued) • To avoid contamination from foreign matter or • Use only manufacturer’s recommended brake moisture, use only new brake fluid or fluid that has fluid. Refer to “Fluids, Lubricants, and Genuine been in a tightly closed container. Keep the master Parts”...
Page 572: Automatic Transmission
570 MAINTAINING YOUR VEHICLE WARNING! (Continued) CAUTION! • Do not allow petroleum based fluid to contaminate Using a transmission fluid other than the manufac- the brake fluid. Brake seal components could be turer’s recommended fluid may cause deterioration damaged, causing partial or complete brake failure. in transmission shift quality and/or torque converter This could result in a collision.
Page 573 MAINTAINING YOUR VEHICLE 571 4. Place the shift lever momentarily into each gear posi- CAUTION! tion (allowing time for the transmission to fully en- gage in each position), ending with the transmission in Do not use chemical flushes in your transmission as PARK.
Page 574 572 MAINTAINING YOUR VEHICLE 7. Wipe the dipstick clean and reinsert it until seated. NOTE: If it is necessary to check the transmission below Then, remove the dipstick and note the fluid level on the operating temperature, the fluid level should be both sides.
Page 575 MAINTAINING YOUR VEHICLE 573 Routine fluid level checks are not required, therefore the CAUTION! transmission filler tube is capped and no dipstick is provided. Your authorized dealer can check your trans- • Using a transmission fluid other than the manufac- mission fluid level using a special service dipstick.
Page 576: Awd Models Only
574 MAINTAINING YOUR VEHICLE In addition, change the fluid and filter if the fluid Frequency Of Fluid Change becomes contaminated (with water, etc.), or if the trans- Refer to the “Maintenance Schedule” for the proper mission is disassembled for any reason. maintenance intervals.
Page 577: Appearance Care And Protection From Corrosion
MAINTAINING YOUR VEHICLE 575 Frequency Of Fluid Change The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion Refer to the “Maintenance Schedule” for the proper resistance built into your vehicle. maintenance intervals. What Causes Corrosion? Appearance Care And Protection From Corrosion Corrosion is the result of deterioration or removal of Protection Of Body And Paint From Corrosion...
Page 578 576 MAINTAINING YOUR VEHICLE Washing CAUTION! • Wash your vehicle regularly. Always wash your ve- • Do not use abrasive or strong cleaning materials hicle in the shade using MOPAR® Car Wash, or a mild such as steel wool or scouring powder that will car wash soap, and rinse the panels completely with scratch metal and painted surfaces.
Page 579 MAINTAINING YOUR VEHICLE 577 • If you detect any stone chips or scratches in the paint, Wheel And Wheel Trim Care touch them up immediately. The cost of such repairs is • All wheels and wheel trim, especially aluminum and considered the responsibility of the owner.
Page 580 578 MAINTAINING YOUR VEHICLE • For tough stains, apply MOPAR® Total Clean, or a CAUTION! mild soap solution to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. Do not use scouring pads, steel wool, a bristle brush, or metal polishes.
Page 581 MAINTAINING YOUR VEHICLE 579 Cleaning Interior Trim liquid. Please do not use polishes, oils, cleaning fluids, solvents, detergents, or ammonia-based cleaners to clean Interior Trim should be cleaned starting with a damp your leather upholstery. Application of a leather condi- cloth, a damp cloth with MOPAR®...
Page 582 580 MAINTAINING YOUR VEHICLE To minimize the possibility of scratching the lenses and When cleaning the rear view mirror, spray cleaner on the reducing light output, avoid wiping with a dry cloth. To towel or rag that you are using. Do not spray cleaner remove road dirt, wash with a mild soap solution fol- directly on the mirror.
Page 583: Cleaning The Cupholders
MAINTAINING YOUR VEHICLE 581 If the belts need cleaning, use MOPAR® Total Clean, a Cleaning The Cupholders mild soap solution, or lukewarm water. Do not remove Clean with a damp cloth or towel using a mild detergent. the belts from the vehicle to wash them. Dry with a soft cloth.
Page 584: Interior Fuses
582 MAINTAINING YOUR VEHICLE Car- WARNING! (Continued) Mini- Cavity tridge Description • If the replaced fuse blows again, contact an autho- Fuse Fuse rized dealer. F101 – 10 Amp Interior Lights • If a general protection fuse for safety systems (air bag system, braking system), power unit systems F102 –...
Page 585 MAINTAINING YOUR VEHICLE 583 Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse F107 – 10 Amp Rear Camera – If F116 30 Amp – Rear Defroster Equipped Pink (EBL) F108 – 15 Amp Instrument Panel F117 –...
Page 586 584 MAINTAINING YOUR VEHICLE Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse F123 – 25 Amp Passenger Door F130 – 15 Amp Climate Control/ Clear Module Blue Instrument Panel F124 – 10 Amp Mirrors F131 –...
Page 587: Underhood Fuses (Power Distribution Center)
MAINTAINING YOUR VEHICLE 585 Underhood Fuses (Power Distribution Center) Car- Mini- Cavity tridge Description The power distribution center is located in the engine Fuse Fuse compartment. F101 60 Amp – Interior Power Dis- Yellow tribution Center Rail F102 60 Amp –...
Page 588 586 MAINTAINING YOUR VEHICLE Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse F106 60 Amp – Interior Power Dis- F144 40 Amp – Exterior Lights 2 Yellow tribution Center Green Rail Run/Accessory F145 30 Amp –...
Page 589 MAINTAINING YOUR VEHICLE 587 Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse F151 30 Amp – Headlamp Washer F158 – 10 Amp Active Hood Mod- Pink Motor – If ule – If Equipped Equipped F159 –...
Page 590 588 MAINTAINING YOUR VEHICLE Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse F164 – 25 Amp Powertrain Auto F170 – 15 Amp Emissions – Partial Clear Shutdown Blue Zero Emissions Ve- hicle Actuators F165 –...
Page 591: Replacement Bulbs
MAINTAINING YOUR VEHICLE 589 REPLACEMENT BULBS Car- Mini- Cavity tridge Description Fuse Interior Bulbs Fuse Bulb Number F177 – 20 Amp All Wheel Drive Yellow Module – If Courtesy/Reading Equipped Lamps (Incandescent) F178 – 25 Amp Sunroof – If Courtesy/Reading LED (Serviced at Autho- Clear Equipped...
Page 592 590 MAINTAINING YOUR VEHICLE Exterior Bulbs Exterior Bulbs – Rear (LED Version) Bulb Number Bulb Number Low Beam Headlamp 9006 Rear Tail/Stop Lamp LED (Serviced at Autho- rized Dealer) High Beam Headlamp 9005 Rear Tail (Liftgate) Lamp LED (Serviced at Autho- Front Park/Turn Signal 3757AK rized Dealer)
Page 593: Bulb Replacement
MAINTAINING YOUR VEHICLE 591 BULB REPLACEMENT NOTE: Lens fogging can occur under certain atmo- spheric conditions. This will usually clear as atmospheric conditions change to allow the condensation to change back into a vapor. Turning the lamps on will usually accelerate the clearing process.
Page 594: Front Fog Lamp
592 MAINTAINING YOUR VEHICLE 2. Remove the electrical connector from the fog lamp CAUTION! housing. Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol.
Page 595: Rear Turn Signal And Backup Lamp
MAINTAINING YOUR VEHICLE 593 Changing The Rear Turn Signal Lamp CAUTION! 1. Open the liftgate. Do not touch the new bulb with your fingers. Oil 2. Remove the two fasteners from the inboard side of the contamination will severely shorten bulb life. If the tail lamp housing.
Page 596 594 MAINTAINING YOUR VEHICLE 3. Carefully insert a trim stick (plastic flat-blade tool) Changing The Backup Lamp between the body panel and the outboard side of the 1. Open the liftgate. tail lamp housing with one hand and grasp the flange on the inboard side of the tail lamp housing with the 2.
Page 597 MAINTAINING YOUR VEHICLE 595 3. Carefully insert a trim stick (plastic flat-blade tool) 5. Remove the bulb from the connector socket and install between the tail lamp housing and the liftgate. Use the the replacement bulb. trim stick and hand pressure together to disengage the 6.
Page 598: License Plate Lamp
596 MAINTAINING YOUR VEHICLE 2. Insert a small flat-blade tool between the end of the License Plate Lamp lens with the locking tab and the surrounding housing 1. Push the small locking tab sticking out of the end of and then pivot the tool to separate the lens from the the lens toward the side of the vehicle and hold it in housing.
Page 599: Fluid Capacities
MAINTAINING YOUR VEHICLE 597 FLUID CAPACITIES U.S. Metric Fuel (Approximate) Front Wheel Drive (FWD) Models 20.5 Gallons 77.6 Liters All-Wheel Drive Models 21 Gallons 79.8 Liters Engine Oil With Filter 2.4L Engine (SAE 5W-20, API Certified) 4.5 Quarts 4.26 Liters 3.6L Engine (SAE 5W-20, API Certified) 6 Quarts 5.6 Liters...
Page 600: Fluids, Lubricants And Genuine Parts
598 MAINTAINING YOUR VEHICLE U.S. Metric 3.6L Engine and Single or Dual-Zone Climate Control System (MOPAR® 13.1 Quarts 12.4 Liters Antifreeze/Engine Coolant 10 Year/150,000 Mile Formula) 3.6L Engine and Three-Zone Climate Control System (MOPAR® 14.5 Quarts 13.7 Liters Antifreeze/Engine Coolant 10 Year/150,000 Mile Formula) * Includes heater and coolant recovery bottle filled to MAX level.
Page 601 MAINTAINING YOUR VEHICLE 599 Component Fluid, Lubricant, or Genuine Part Engine Oil – 3.6L Engine We recommend you use API Certified SAE 5W-20 Engine Oil, meeting the require- ments of Chrysler Material Standard MS-6395 such as MOPAR, Pennzoil® and Shell Helix®. Refer to your engine oil filler cap for correct SAE grade. Engine Oil Filter We recommend you use MOPAR®...
Page 602 600 MAINTAINING YOUR VEHICLE CAUTION! (Continued) OAT coolant (conforming to MS-12106), by an authorized dealer as soon as possible. • Do not use water alone or alcohol-based engine coolant (antifreeze) products. Do not use additional rust inhibitors or antirust products, as they may not be compatible with the radiator engine coolant and may plug the radiator.
Page 603: Chassis
MAINTAINING YOUR VEHICLE 601 Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission Use only ATF+4® Automatic Transmission Fluid. Failure to use ATF+4® fluid may affect the function or performance of your transmission. We recommend MOPAR® ATF+4® fluid. Power Transfer Unit (PTU) We recommend you use MOPAR®...
Page 604 I n f o r ma t i o n P r o v i d e d b y :...
Page 605: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS MAINTENANCE SCHEDULE ....604 ▫ Maintenance Chart.....607 I n f o r ma t i o n P r o v i d e d b y :...
Page 606 604 MAINTENANCE SCHEDULES On Electronic Vehicle Information Center (EVIC) MAINTENANCE SCHEDULE equipped vehicles, “Oil Change Required” will be dis- Your vehicle is equipped with an automatic oil change played in the EVIC and a single chime will sound, indicator system. The oil change indicator system will indicating that an oil change is necessary.
Page 607 MAINTENANCE SCHEDULES 605 Severe Duty All Models Required Maintenance Intervals. Change Engine Oil at 4000 miles (6,500 km) if the vehicle Refer to the Maintenance Schedules on the following is operated in a dusty and off road environment. This page for the required maintenance intervals. type of vehicle use is considered Severe Duty.
Page 608 606 MAINTENANCE SCHEDULES At Every Oil Change Interval As Indicated By Oil Change Indicator System: • Inspect engine cooling system protection and hoses. • Inspect exhaust system. • Inspect engine air cleaner if using in dusty or off-road conditions. I n f o r ma t i o n P r o v i d e d b y :...
Page 609 MAINTENANCE SCHEDULES 607 Maintenance Chart Refer to the Maintenance Schedules on the following pages for the required maintenance intervals. Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends, and replace if necessary.
Page 610 608 MAINTENANCE SCHEDULES Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Maintenance Replace engine air filter. Replace air conditioning filter. Replace spark plugs (2.4L Engine). ** Replace spark plugs (3.6L Engine). ** Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first.
Page 611 MAINTENANCE SCHEDULES 609 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Change the automatic transmission fluid and filter if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing. Replace rear drive assembly (RDA) fluid.
Page 612 610 MAINTENANCE SCHEDULES WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 613: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS SUGGESTIONS FOR OBTAINING SERVICE FOR ▫ Customer Assistance For The Hearing Or Speech YOUR VEHICLE ..... . .613 Impaired (TDD/TTY).
Page 614 612 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES ....619 ▫ Treadwear......619 ▫...
Page 615: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 613 SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.
Page 616: Chrysler Group Llc Customer Center
614 IF YOU NEED CONSUMER ASSISTANCE facilities, factory-trained technicians, special tools, and • Owner’s telephone number (home and office) the latest information to ensure the vehicle is fixed • Authorized dealer name correctly and in a timely manner. • Vehicle Identification Number (VIN) This is why you should always talk to an authorized •...
Page 617: In Mexico Contact
IF YOU NEED CONSUMER ASSISTANCE 615 Canadian residents with hearing difficulties that require In Mexico Contact: assistance can use the special needs relay service offered Av. Prolongacion Paseo de la Reforma, 1240 by Bell Canada. For TTY teletypewriter users, dial 711 Sante Fe C.P.
Page 618: Warranty Information
616 IF YOU NEED CONSUMER ASSISTANCE The manufacturer will not stand behind any service WARNING! contract that is not the manufacturer’s service contract. It is not responsible for any service contract other than the Engine exhaust (internal combustion engines only), manufacturer’s service contract.
Page 619: Mopar® Parts
IF YOU NEED CONSUMER ASSISTANCE 617 campaign. However, NHTSA cannot become involved in MOPAR® PARTS individual problems between you, your authorized MOPAR® fluids, lubricants, parts, and accessories are dealer, and the manufacturer. available from an authorized dealer. They are recom- mended for your vehicle in order to help keep the vehicle To contact NHTSA, you may either call the Auto Safety operating at its best.
Page 620: Publication Order Forms
618 IF YOU NEED CONSUMER ASSISTANCE Diagnostic Procedure Manuals PUBLICATION ORDER FORMS To order the following manuals, you may use either the Diagnostic Procedure Manuals are filled with diagrams, website or the phone numbers listed below. Visa, Mas- charts and detailed illustrations. These practical manuals tercard, American Express, and Discover orders are ac- make it easy for students and technicians to find and fix cepted.
Page 621: Department Of Transportation Uniform
IF YOU NEED CONSUMER ASSISTANCE 619 Call toll free at: Treadwear The Treadwear grade is a comparative rating, based on • 1–800–890–4038 (U.S.) the wear rate of the tire when tested under controlled • 1–800–387–1143 (Canada) conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded Visit us on the Worldwide Web at:...
Page 622: Temperature Grades
620 IF YOU NEED CONSUMER ASSISTANCE concrete. A tire marked C may have poor traction perfor- passenger car tires must meet under the Federal Motor mance. Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test WARNING! wheel, than the minimum required by law.
Page 623 INDEX I n f o r ma t i o n P r o v i d e d b y :...
Page 624 622 INDEX About Your Brakes ......431 Transporting Pets ..... . .102 ABS (Anti-Lock Brake System) .
Page 625 INDEX 623 Disposal ......565 Auto Unlock, Doors ......31 Anti-Lock Brake System (ABS) .
Page 626 624 INDEX Brake Control System, Electronic ....434 Caps, Filler Brake Fluid ......601 Fuel .
Page 627 INDEX 625 Certification Label......491 Older Children And Child Restraints ..79 Chains, Tire .
Page 628 626 INDEX Coolant Pressure Cap (Radiator Cap) ...565 Dealer Service......545 Cooling System.
Page 629 INDEX 627 Door Opener, Garage..... . .253 Electronic Vehicle Information Center (EVIC) ..307 Driving Remote Start ......27 Through Flowing, Rising, or Shallow Standing Emergency, In Case of Water .
Page 630 628 INDEX Exhaust Gas Caution .....44 Ethanol ....... .481 Fails to Start .
Page 631 INDEX 629 Flash-To-Pass ......227 Fluids, Lubricants and Genuine Parts ...598 Flexible Fuel Vehicles Fog Lights .
Page 632 630 INDEX Requirements ......480 Fuel ....... . .305 Saver Mode .
Page 633 INDEX 631 Delay ....... .224 Hood Release ......220 High Beam .
Page 634 632 INDEX iPod®/USB/MP3 Control ....370 Key, Sentry (Immobilizer) ....15 Bluetooth®...
Page 635 INDEX 633 Brake Assist Warning ....441 Intensity Control ......228 Brake Warning .
Page 636 634 INDEX Traction Control ......441 Maintenance Free Battery....551 Turn Signal .
Page 637 INDEX 635 Rearview ......115 Change Interval ......315 Vanity .
Page 638 636 INDEX Owner’s Manual (Operator Manual) ... . .4 Seats ....... .198 Steering .
Page 639 INDEX 637 Rear Camera ......248 Remote Control Rear Cupholder ......273 Starting System .
Page 640 638 INDEX Restraint, Head......206 Lap/Shoulder Belt Operation ....50 Restraints, Child .
Page 641 INDEX 639 Rear Seat ......47 Service Assistance ......613 Untwisting Procedure .
Page 642 640 INDEX Cold Weather ......411 Supplemental Restraint System - Airbag ..62 Engine Fails to Start .
Page 643 INDEX 641 Compact Spare ......462 Tread Wear Indicators ....465 General Information .
Page 644 642 INDEX Trailer and Tongue Weight ....498 UCI Connector ......370 Wiring .
Page 645 INDEX 643 Untwisting Procedure, Seat Belt ....52 Washers, Windshield ..... . .229 Upholstery Care .
Page 646 644 INDEX Wipers, Intermittent ..... . .230 Wrecker Towing ......535 I n f o r ma t i o n P r o v i d e d b y :...
Page 647 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 648 Chrysler Group LLC 15Y532-126-AA First Edition Printed in U.S.A. 15JC49-126-AB Second Edition Printed in U.S.A I n f o r ma t i o n P r o v i d e d b y :...

This manual is also suitable for:

Journey 2015

Dodge 2015 Journey Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

Quick Links

Chapters

Related Manuals for Dodge 2015 Journey

Summary of Contents for Dodge 2015 Journey
