Summary of Contents for Toyotomi Laser Clean LC-S27
-
Page 2: Specifications
SPECIFICATIONS * Matching Room Size to HEAT RATING LC-S27 MODEL • Because the “Heat Load” of an area to be High 9,900 BTU / 2.9 kW heated is influenced by so many factors, it is HEAT RATING impossible to specify a heater output to an 2,900 BTU / 0.8 kW exact room size. -
Page 3: Operation Panel
OPERATION PANEL Fuel indicator Colon ˚C indicator Key-lock indicator Vent. indicator Timer Key Key-lock Button Adjustment Keys ON/OFF Button INDICATOR LAMP Timer lamp Operation lamp timer power Operation Lamp — flashing : Preheating mode constant : Heater in operation ˚C indicator —... -
Page 4: Unpacking And Placement
UNPACKING AND PLACEMENT CAUTION : Risk of burns. Do not operate the heater without the grille completely attached. 1. Take out heater from box carefully to avoid damage. 2. Remove all packing materials from heater. 3. Make sure all screws are tight and all parts intact. NOTE : Save shipping carton and all packing materials for future storage of your heater. - Page 5 FUELING WARNING : Use only water-clear kerosene (paraffin). Never use gasoline or other flammable liquids. ALWAYS extinguish heater before refill heater fuel tank. Fuel heater outside the living area. 1. Open the fuel tank lid on the top of heater cabinet and lift out the removable fuel tank.
-
Page 6: Operation
OPERATION CAUTION : Always make sure that there is sufficient ventilation. SET CLOCK It is only possible to set the correct time, when the heater is connected to the mains and not burning. 1. Use the Adjustment Keys ( ▼ hour / ▲ min.) to set the time. 2. - Page 7 TIMER IGNITION Your heater can be arranged to ignite automatcally at a chosen time by use of a pre-set “Timer”. This “Timer” can only be set after the clock setting has been completed. 1. Press the button and then the “Timer” key immediately after that.
-
Page 8: Temperature Regulation
TEMPERATURE REGULATION 1. Use the adjustment keys ( ▼ hour / ▲ min.) to adjust the temperature. 2. Adjust the temperature using the key on the right ( ▲ min.) to set the temperature to a higher setting and the key on the left ( ▼... -
Page 9: Fuel Indicator
FUEL INDICATOR When the Fuel indicator lights up, there is enough fuel left for another 10 minutes of heater use. The count-down of the remaining heating time can be seen in the information display. Every two minutes an alarm signal is sounded, warning you to refill the removable tank. -
Page 10: Emergency Message
EMERGENCY MESSAGE In the event that heater should extinguish itself, without any action or your part, you should look to the digital indicator for any of the following messages. MESSAGE MESSAGE MEANING (Digital Indicator) Temperature within the heater too high. e - 0 Power interrupted. -
Page 11: Routine Maintenance
ROUTINE MAINTENANCE CAUTION : Be sure to unplug heater before performing any checks or cleaning. CAUTION : Do not remove any parts from the heater except removable fuel tank, fuel acceptance fitting and air filter. WARNING : Allow heater to cool completely before cleaning or maintenance. 1. -
Page 12: Troubleshooting
TROUBLESHOOTING Should problems arise during operation or ignition, use this chart to determine the cause and the proper steps to take. Be sure to unplug heater and allow to cool completely before taking corrective measures. PROBLEM CAUSE SOLUTION POWER LAMP FAILS —... -
Page 13: Long Term Storage
LONG TERM STORAGE At the end of the heating season, you must store the heater in a dust-free plece, if possible in its original packaging. The following procedures are recommended 1. Drain Fuel Tank Remove any kerosene (paraffin), dust or water remaining in Fuel acceptance fitting the fuel sub tank and removable fuel tank to prevent rusting.
