MODEL
LC-33
IMPORTANT
READ AND UNDERSTAND INSTRUCTIONS BEFORE USING HEATER.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
•• • •• • • •• • • •• • • •• • • •• • •• • • •• • • •• • • •• • • •• • • ••••
•• • •• • • •• • • •• • • •• • • •• • •• • • •• • • •• • • •• • • •• • • ••••
INSTRUCTION MANUAL
• •• • •• • • •• • • •• • • •• • • •• • • •• • • •• • •• • •••
•• • •• • • •• • • •• • • •• • • •• • •• •
CONTENTS
1
1
5
9
10
• •• ••• ••• •• ••• ••• •• ••
11
••• •• ••• ••• ••• •• ••• ••• •• ••• ••
12
•• •• ••• ••• •• ••• ••• ••• •• ••
Advertisement
Related Manuals for Toyotomi LC-33
Summary of Contents for Toyotomi LC-33
-
Page 1: Table Of Contents
INSTRUCTION MANUAL MODEL LC-33 IMPORTANT READ AND UNDERSTAND INSTRUCTIONS BEFORE USING HEATER. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. CONTENTS SPECIFICATIONS ROUTINE MAINTENANCE • •• • •• • • •• • • •• • • •• • • •• • • •• • • •• • •• • •••... -
Page 3: Specifications
SPECIFICATIONS Matching Room Size to HEAT RATING LC-33 MODEL Because the “Heat Load” of an area to be High 11,000 BTU / 2,770 kcal heated is influenced by so many factors, it is HEAT RATING impossible to specify a heater output to an 2,900 BTU / 740 kcal exact room size. - Page 4 OPERATION PANEL Key-lock Button Digital Indicator Operation Lamp Save Key Extension Key Timer Key ON/OFF Button Adjustment Keys Operation Lamp —flashing: Preheating mode constant: Heater in operation Fuel Indicator —constant: Fuel tank empty. Only 10 minutes burning time remaining. Digital Indicator shows remaining burning time in minutes.
- Page 5 UNPACKING AND PLACEMENT 1. Take out heater from box carefully to avoid damage. 2. Remove all packing materials from heater. 3. Make sure all screws are tight and all parts intact. NOTE: Save shipping carton and all packing materials for future storage of your heater.
- Page 6 FUELING WARNING Use only clean kerosene (paraffin). Never use gasoline or other flammable liquids. ALWAYS extinguish heater before refill heater fuel tank. Fuel heater outside the living area. 1. Open the fuel tank lid on the top of heater cabinet and lift out the removable fuel tank.
-
Page 7: Operation
OPERATION CAUTION :Always make sure that there is sufficient ventilation. SET CLOCK It is only possible to set the correct time, when the heater is connected to the mains and not burning. 1. Use the Adjustment Keys (▼ hour/ ▲ min.) to set the time. 2. - Page 8 TIMER IGNITION Your heater can be arranged to ignite automatcally at a chosen time by use of a pre-set “Timer”. This “Timer” can only be set after the clock setting has been completed. 1. Press the button and then the “Timer” key immediately after that.
- Page 9 NOTE: The standard setting of the heater is 20°C. However, once the set temperature has been changed the new setting will remain in effect unless changed. NOTE: Room temperature measurements are taken directly behind the heater. These measurements may not represent the true room temperature. SAVE OPERATION The “SAVE”...
- Page 10 FUEL INDICATOR When the Fuel Indicator lights up, it means that there is only fuel left for 10 more minutes. The count-down of the remaining heating time can be seen in the Digital indicator. Now you have two options: you remove the removable fuel tank and refill it outside the living room or you push the Extension key.
-
Page 11: Emergency Message
EMERGENCY MESSAGE In the event that heater should extinguish itself, without any action or your part, you should look to the digital indicator for any of the following messages. MESSAGE MESSAGE MEANING (Digital Indicator) Temperature within the heater too high. e - 0 Power interrupted. -
Page 12: Routine Maintenance
ROUTINE MAINTENANCE CAUTION: Be sure to unplug heater before performing any checks or cleaning. CAUTION: Do not remove any parts from the heater except removable fuel tank, fuel acceptance fitting and air filter. WARNING: Allow heater to cool completely before cleaning or maintenance. 1. -
Page 13: Troubleshooting
TROUBLESHOOTING Should problems arise during operation or ignition, use this chart to determine the cause and the proper steps to take. Be sure to unplug heater and allow to cool completely before taking corrective measures. PROBLEM CAUSE SOLUTION POWER LAMP FAILS —... -
Page 14: Long Term Storage
LONG TERM STORAGE At the end of the heating season, you must store the heater in a dust-free plece, if possible in its original packaging. The following procedures are recommended 1. Drain Fuel Tank Remove any kerosene (paraffin), dust or water remaining in Fuel acceptance fitting the fuel sub tank and removable fuel tank to prevent rusting. - Page 15 Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
- Page 16 TOYOTOMI CO., LTD. 5-17, Momozono-cho, Mizuho-ku, Nagoya, Japan www.toyotomi.jp Printed in Japan New 07/16 8684001921...
