Summary of Contents for Chauvet Eclipse
- Page 1 Snapshot Use on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave Autoswitching Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com...
-
Page 2: Table Of Contents
Returns Procedure ..................................11 Claims......................................12 Technical Specifications ................................12 1. B EFORE EGIN What is included 1 x Eclipse™ 1 x Power cable 1 x Warranty Card 1 x User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. -
Page 3: Safety Instructions
There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact the dealer nearest to you. Eclipse™ User Manual 5/21/2009 5:12 PM... -
Page 4: Non-Interlocked Housing Warning
The legal requirements for using laser entertainment products vary from country to country. The user is responsible for the legal requirements at the location/country of use. Always use appropriate lighting safety cables when hanging lights and effects overhead. Eclipse™ User Manual 5/21/2009 5:12 PM... -
Page 5: Laser Safety Label Reproduction
LASER SAFETY LABEL REPRODUCTION EXPLANATORY, MANUFACTURER’S ID & CERTIFICATION LABEL LASER HAZARD WARNING LABEL LASER APERTURE LABEL NON INTERLOCKED HOUSING LABEL Eclipse™ User Manual 5/21/2009 5:12 PM... -
Page 6: Avoid Direct Eye Exposure
24, 2007. T 3R. (C OTICE DATED HIS LASER DEVICE IS LASSIFIED LASS IS THE INTERNATIONAL EQUIVALENT US C ). N performance LASS O MAINTENANCE IS REQUIRED TO KEEP THIS PRODUCT IN COMPLIANCE WITH LASER standards. Eclipse™ User Manual 5/21/2009 5:12 PM... -
Page 7: Introduction
High-power, 5W (1,000mA) LED Complies with FDA / CDRH standards for ClassIIIR Additional power output: max 50 units @ 120V Hanging bracket Product Overview Bracket adjustment knob (1 of 2) LED output Laser Aperture Eclipse™ User Manual 5/21/2009 5:12 PM... -
Page 8: Product Dimensions
Product Dimensions Eclipse™ User Manual 5/21/2009 5:12 PM... -
Page 9: Proper Usage
CAUTION: Use of controls, adjustments, or performance of procedures other than what is specified herein may result in hazardous radiation exposure Eclipse™ User Manual 5/21/2009 5:12 PM... -
Page 10: Setup
LED effect from off to full on Note! The lasers cannot be turned off. They can be set to a slow strobe. Note! At higher rotation speeds, the operation noise may increase from the fixture. This is normal. Eclipse™ User Manual 5/21/2009 5:12 PM... -
Page 11: General Troubleshooting
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Claims
Red diode ..........................650 nm 80 mW Laser Type ............................DPSS Cooling ............................Fan Cooled RANGE Coverage Angle ............................120° THERMAL Maximum ambient temperature ..................104° F (40° C) ORDERING INFORMATION Eclipse™ ............................ECLIPSE WARRANTY INFORMATION Warranty........................1-year limited warranty Eclipse™ User Manual 5/21/2009 5:12 PM...
