Operating-Settings Learn Routine - Python 750 Installation Manual

Many of the operating settings of this unit are programmable. They can be changed whenever necessary through a
computer-based Learn Routine™. The Valet
with a programmed transmitter to change the settings. To program settings remember: Door, Key, Choose, Transmit
and Release.
1.
2.
3.
Feature Number
1
2
3
4
5
6
7
8
9
10
11
© 1995,1997 Directed Electronics, Inc. Vista, CA

OPERATING-SETTINGS LEARN ROUTINE™

® /program push-button switch, plugged into the blue port is used together
Door
Open a door. Either the H1/5 GREEN or the H1/7 VIOLET door
trigger wire must be connected for the control unit to "see" an
open door.
Key
Turn the ignition on and then back off. The H1/9 YELLOW
switched ignition input must be connected.
Choose
Within 15 seconds, press and release the Valet
button the number of times corresponding to the number of
the desired feature (see the chart below). The one chirp
settings below are the factory default settings, except where
indicated by bold text.
One-chirp Setting
Active arming
Arm/disarm chirps on
Ignition-controlled door locks
Active locking only
Panic with ignition on
0.8 second door lock pulses
Forced passive arming on
Automatic engine disable on
VRS ® enabled
Code-Hopping™ on
Siren
Two-chirp Setting
Passive arming
Arm/disarm chirps off
Standard door locks
Passive locking
No panic with ignition on
3.5 second door lock pulses
Forced passive arming off
Automatic engine disable off
VRS ®
Code-Hopping™ off
Horn honk
18
®
/Program
disabled
97N437.597
