Sony XM-2002GTW Service Manual page 20

XM-2002GTW
AMPLIFIER
Ref. No. Part No. Description
R234 1-218-875-11 METAL CHIP
R235 1-216-813-11 METAL CHIP
R236 1-216-813-11 METAL CHIP
R238 1-216-821-11 METAL CHIP
R239 1-216-845-11 METAL CHIP
R240 1-216-845-11 METAL CHIP
R241 1-249-421-11 CARBON
R242 1-249-428-11 CARBON
R243 1-216-805-11 METAL CHIP
R244 1-216-805-11 METAL CHIP
R245 1-216-805-11 METAL CHIP
R246 1-216-805-11 METAL CHIP
R247 1-216-805-11 METAL CHIP
R248 1-216-805-11 METAL CHIP
R249 1-234-499-11 ENCAPSULATED COMPONENT 0.22X2 5W
R250 1-234-499-11 ENCAPSULATED COMPONENT 0.22X2 5W
R251 1-234-499-11 ENCAPSULATED COMPONENT 0.22X2 5W
R252 1-215-880-31 METAL OXIDE
R253 1-216-853-11 METAL CHIP
R254 1-216-821-11 METAL CHIP
R255 1-216-829-11 METAL CHIP
R256 1-216-829-11 METAL CHIP
R260 1-216-827-11 METAL CHIP
R261 1-216-821-11 METAL CHIP
R301 1-216-833-11 METAL CHIP
R302 1-216-833-11 METAL CHIP
R303 1-216-833-11 METAL CHIP
R304 1-216-833-11 METAL CHIP
R305 1-216-833-11 METAL CHIP
R306 1-216-833-11 METAL CHIP
R307 1-216-827-11 METAL CHIP
R308 1-216-827-11 METAL CHIP
R309 1-216-837-11 METAL CHIP
R310 1-216-837-11 METAL CHIP
R701 1-216-839-11 METAL CHIP
R702 1-216-845-11 METAL CHIP
R703 1-216-833-11 METAL CHIP
R704 1-216-841-11 METAL CHIP
R800 1-216-841-11 METAL CHIP
R801 1-216-841-11 METAL CHIP
R802 1-216-841-11 METAL CHIP
R803 1-216-857-11 METAL CHIP
R804 1-216-833-11 METAL CHIP
R805 1-216-833-11 METAL CHIP
R806 1-216-833-11 METAL CHIP
R807 1-216-833-11 METAL CHIP
R808 1-216-857-11 METAL CHIP
R809 1-216-833-11 METAL CHIP
R810 1-216-833-11 METAL CHIP
R811 1-216-833-11 METAL CHIP
R812 1-216-833-11 METAL CHIP
R818 1-216-845-11 METAL CHIP
R820 1-216-817-11 METAL CHIP
R821 1-216-827-11 METAL CHIP
R823 1-218-857-11 METAL CHIP
R828 1-218-857-11 METAL CHIP
R833 1-218-867-11 METAL CHIP
R834 1-216-841-11 METAL CHIP
20
Remark Ref. No.
15K 0.5% 1/10W
220 5% 1/10W
220 5% 1/10W
1K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
2.2K 5% 1/4W
8.2K 5% 1/4W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
10 5% 2W F
470K 5% 1/10W
1K 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
3.3K 5% 1/10W
1K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
3.3K 5% 1/10W
3.3K 5% 1/10W
22K 5% 1/10W
22K 5% 1/10W
33K 5% 1/10W
100K 5% 1/10W
10K 5% 1/10W
47K 5% 1/10W
47K 5% 1/10W
47K 5% 1/10W
47K 5% 1/10W
1M 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
1M 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
100K 5% 1/10W
470 5% 1/10W
3.3K 5% 1/10W
2.7K 0.5% 1/10W
2.7K 0.5% 1/10W
6.8K 0.5% 1/10W
47K 5% 1/10W
Part No. Description
R844 1-216-833-11 METAL CHIP
R860 1-249-421-11 CARBON
R901 1-216-825-11 METAL CHIP
R902 1-216-827-11 METAL CHIP
R903 1-216-837-11 METAL CHIP
R904 1-216-836-11 METAL CHIP
R905 1-216-849-11 METAL CHIP
R906 1-216-829-11 METAL CHIP
R909 1-216-827-11 METAL CHIP
R910 1-216-833-11 METAL CHIP
R911 1-249-433-11 CARBON
R912 1-216-833-11 METAL CHIP
R913 1-249-411-11 CARBON
R914 1-216-821-11 METAL CHIP
R915 1-216-821-11 METAL CHIP
R916 1-216-801-11 METAL CHIP
R917 1-216-801-11 METAL CHIP
R918 1-216-821-11 METAL CHIP
R919 1-216-821-11 METAL CHIP
R920 1-216-821-11 METAL CHIP
R921 1-216-821-11 METAL CHIP
R924 1-216-821-11 METAL CHIP
R927 1-216-821-11 METAL CHIP
R928 1-216-797-11 METAL CHIP
R929 1-216-797-11 METAL CHIP
R930 1-216-797-11 METAL CHIP
R931 1-216-797-11 METAL CHIP
R932 1-216-797-11 METAL CHIP
R933 1-216-797-11 METAL CHIP
R936 1-216-825-11 METAL CHIP
R937 1-216-825-11 METAL CHIP
R938 1-216-813-11 METAL CHIP
R939 1-216-821-11 METAL CHIP
R940 1-216-841-11 METAL CHIP
R941 1-216-843-11 METAL CHIP
R942 1-216-837-11 METAL CHIP
R943 1-216-801-11 METAL CHIP
R944 1-216-801-11 METAL CHIP
R950 1-249-417-11 CARBON
R951 1-216-833-11 METAL CHIP
R952 1-216-833-11 METAL CHIP
< VARIABLE RESISTOR >
RV101 1-227-558-11 RES, VAR, CARBON 5KX2 (LEVEL)
RV102 1-227-558-11 RES, VAR, CARBON 5KX2 (LOW BOOST(40Hz))
RV307 1-227-557-11 RES, VAR, CARBON 20KX2 (FILTER)
< CERMET RESISTOR >
RV103 1-241-764-11 RES, ADJ CERMET 10K
RV203 1-241-764-11 RES, ADJ CERMET 10K
< SWITCH >
S801 1-692-990-21 SWITCH, SLIDE (FILTER)
< TRANSFORMER >
T901 1-439-635-22 TRANSFORMER, DC-DC CONVERTER
Remark
10K 5% 1/10W
2.2K 5% 1/4W
2.2K 5% 1/10W
3.3K 5% 1/10W
22K 5% 1/10W
18K 5% 1/10W
220K 5% 1/10W
4.7K 5% 1/10W
3.3K 5% 1/10W
10K 5% 1/10W
22K 5% 1/4W
10K 5% 1/10W
330 5% 1/4W
1K 5% 1/10W
1K 5% 1/10W
22 5% 1/10W
22 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
10 5% 1/10W
10 5% 1/10W
10 5% 1/10W
10 5% 1/10W
10 5% 1/10W
10 5% 1/10W
2.2K 5% 1/10W
2.2K 5% 1/10W
220 5% 1/10W
1K 5% 1/10W
47K 5% 1/10W
68K 5% 1/10W
22K 5% 1/10W
22 5% 1/10W
22 5% 1/10W
1K 5% 1/4W
10K 5% 1/10W
10K 5% 1/10W
