- Page 1 Call Stacker Installation and Use Manual Issue 1, October 1999 © 1999 Bogen Communications, Inc. All rights reserved. 54-2025-01 9910 Model: LULCST PEC Code: 5325-150 COM Code: 408184018 Select Code: 701-000-118...
- Page 2 If they do, you will be given ade- quate notice in writing to allow you an opportunity to main- tain uninterrupted telephone service. Trademarks Centrex is a registered trademark of Lucent Technologies. Important Safety Information Always follow these basic safety precautions when installing and using the system: 1 .
-
Page 3: Table Of Contents
Contents Overview 1-1 Introduction Before You Start Installation Installation Steps Operation 3-1 Operation Maintenance Specifications... - Page 4 This page intentionally left blank.
-
Page 5: Overview
Overview Contents Introduction Before You Start Overview... -
Page 6: Introduction
Introduction The Call Stacker is a microprocessor based audio recording and announcement system. The Call Stacker is used in conjunction with a paging system to provide buffered announcement play to the paging system. Figure 1-1. Call Stacker Unit The Call Stacker features 5 Input Station (recording) channels, a single Page Output channel and 3 minutes of recording time. -
Page 7: Before You Start
Tone out circuit tester (optional, for troubleshooting) n Volt-ohm Meter (optional, for troubleshooting) n 4 wood screws, if mounted on wall 4. Verify Interface Compatibility with Telephone System and Paging System (see Table 1-1 on the next page). Overview 1-3... - Page 8 Table 1-1. Call Stacker Connectivity Chart. SYSTEM PARTNER PLUS PARTNER II Spirit 308/616, 1224/2448 Merlin 206/410/820 Merlin II Merlin Plus Merlin 1030/3070 Legend System 25 Definity System 85 Dimension Horizon NOTE: 1. In order for the Merlin II to send a forward disconnect, set the station option for AA/VMS. The 012 station module must be “F”...
-
Page 9: Installation
Installation Contents Installation Steps Installation... -
Page 10: Installation Steps
Installation Steps 1. Attach the reversible brackets to the Call Stacker using the 6-32 x 3/8" screws Figure 2-1. Wall Mounted Unit Figure 2-2. Rack Mounted Unit Installation provided, then secure the Call Stacker to a back board or into an equipment rack. - Page 11 Connect one or more of the Call Stacker's Input Station channels to PBX/KTS NOTE: PBX and KTS stations must have the analog station inputs on the telephone system through FCC/DOC approved ability to send a modular jacks.Connect the Call Stacker's Page Output channel to the paging...
- Page 12 Figure 2-3. Page Output Channel Connection of Call Stacker Figure 2-4. Connection to Lucent LUPCM Zone Paging System Figure 2-5. Connection to Telephone Paging Amplifier Installation...
- Page 13 4. Connect the detachable power supply cord between a 110/120 VAC outlet and the Call Stacker and verify the Power LED illuminates. 5. Turn the battery switch ON. Installation...
- Page 14 This page intentionally left blank. Installation...
-
Page 15: Operation
Operation Contents Operation Controls and Indicators Recording Announcements Announcement Playback Maintenance Troubleshooting Specifications Operation... -
Page 16: Operation
(see note below). PBX and KTS analog station interfaces (tip/ring pairs) to the Public Telephone Network, a PABX or a Key System. Audio and control contact signals to the paging system as shown in figure 2-3. Between outgoing announcements the control contact opens for a minimum of 250 msec. -
Page 17: Recording Announcements
“Enter zone code (Marque el codigo de la zona)” . Proceed Enabled to step 2. 2. Enter a DTMF tone sequence using the telephone keypad to select a paging NOTE: If the number of digits in the paging zone. -
Page 18: Announcement Playback
1. Dial up the input station connected to the Call Stacker and wait for the Call Disabled 2. Enter a DTMF tone sequence using the telephone keypad to select a paging NOTE: If the number of digits in the paging... -
Page 19: Maintenance
Maintenance Troubleshooting NOTE: The suggested There are no serviceable parts in the Call Stacker: reliable lifetime of the rechargeable battery used in If the Call Stacker does not operate during a power failure: the equipment is 36 months. To ensure the system has reliable battery backup, it is recommended the battery be replaced every 30 months.
